Summary of Contents for UFREE SCOOTER FS-E35
- Page 1 UFREE SCOOTER www.scooter-manufacturer.com OWNER/ OPERATORS MANUAL ELECTRIC SCOOTER FS-E35 CAUTION: Read and understand this manual thoroughly before operating and handling scooter. Please follow all safety procedures and warnings to reduce risk of electric shock!
-
Page 2: Table Of Contents
FOOT OPERATED MECHANICAL BRAKE........PAGE 4 RANGE AND SPEED............……..PAGE 4 STEERING ADJUSTMENT..............PAG E 4 CHARGING....................PAGE 4-5 SCOOTER OPERATION................PAGE 5 REMOVABLE PLATFORM, BATTERY ACCESS .......PAGE 6 DRIVE BELT ADJUSTMENT, REPLACEMENT.........PAGE 6 BATTERY INFORMATION..........…....PAGE 7 TROUBLESHOOTING GUIDE…………………………….....PAGE 7 UFREE SCOOTER www.scooter-manufacturer.com... -
Page 3: Introduction
UFREE SCOOTER www.scooter-manufacturer.com INTRODUCTION Thank you for your purchase of the Electric Scooter. The scooter will provide you with hours of fun and help you get some exercise, something we all need today. The scooter is an environmentally friendly mode of transportation since it is pollution free and whisper quiet. -
Page 4: Safety Warnings
UFREE SCOOTER www.scooter-manufacturer.com BEFORE YOU ATTEMPT TO RIDE THE SCOOTER, PLEASE READ AND UNDERSTAND THE FOLLOWING: •NEVER RIDE THE SCOOTER ON PUBLIC STREETS OR ROADS. CHECK LOCAL ORDINANCES WHERE RIDING IS PERMISSIBLE. •MINIMUM AGE IS RECOMMENDED AT 10 YEARS OLD TO OPERATE THE SCOOTER. -
Page 5: Unfolding And Folding
UFREE SCOOTER www.scooter-manufacturer.com ADJUSTMENTS AND OPERATION UNFOLDING AND FOLDING Your scooter is shipped in LIFT the folded and locked QUICK position. To unfold press RELEASE snap pins and lift the Quick HANDLE Release Handle and the opposite side. Adjustable Spring Loaded Handle (fig. -
Page 6: Adjustments And Operation
UFREE SCOOTER www.scooter-manufacturer.com ADJUSTMENTS AND OPERATION HAND OPERATED POWER SWITCH (Throttle) The Scooter is equipped with a handle Operated Power Switch located on the handlebars of the scooter (fig. 1). When turn "on", the power is on and the motor and rear wheel causes the scooter to move forward. -
Page 7: Charging
UFREE SCOOTER www.scooter-manufacturer.com Charging Procedure POWER USE REQUIREMENTS CAN SCOOTER BATTERY CHARGING VARY DEPENFING ON RIDER TRA- VERSED. TIMES ARE SCOOTER USETIME CHARGINGTIME RECOMMENDED AVERAGES. (BATTERDISCHARING) (DO NOT OVERCHARGE) 10 MINUTES --------------- 3-4 HOURS 20 MINUTES----------------- 5-6 HOURS 30 MINUTES----------------- 6-8 HOURS STD.110/220V... -
Page 8: Removable Platform, Battery Access
UFREE SCOOTER www.scooter-manufacturer.com ADJUSTMENTS AND OPERATION REMOVEABLEPLATFORM The Platform is removable to gain access to the Batteries. To remove, remove the four deck screws with a Phillips screwdriver (fig 6) and remove Brake Pedal and Spring. Platform will lift off of Scooter Frame. Reverse procedure to replace platform. -
Page 9: Battery Information
UFREE SCOOTER www.scooter-manufacturer.com IMPORTANT BATTERY INFORMATION BATTERY CARE 1. Store Scooter and Charge Batteries at a temperature between 50 and 100 F. The higher the temperature, the faster the Batteries will self discharge. Try to keep your Batteries charged. Inspect Batteries occasionally and keep the terminals clean &... - Page 10 UFREE SCOOTER www.scooter-manufacturer.com IF YOU HAVE ANY PROBLEMS, FIRST CALL YOUR LOCAL DISTRIBUTOR TO OBTAIN SERVICE AUTHORIZATION. All repairs and/or replacements will be performed or processed through the LOCAL DISTRIBUTOR. AII returning Scooters and or Parts must have preauthorization to do so. Unauthorized returns will not be processed.
