- Page 1 C.T.M. Power Chair C.T.M. Power Chair C.T.M. Power Chair HS-5600 User's Manual...
-
Page 2: Table Of Contents
HS-5600 User's Manual TABLE OF CONTENTS INTRODUCTION ---------------------------------------------------------1 IMPORTANT PRECAUTION --------------------------------------------2 EMI AND WARNINGS ---------------------------------------------------3 INITIAL OVERVIEW -----------------------------------------------------5 ADJUSTMENTS ----------------------------------------------------------6 DISASSEMBLY AND ASSEMBLY --------------------------------------7 OPERATION --------------------------------------------------------------8 CHARGING THE BATTERIES -----------------------------------------9 MAINTANCE AND GENERAL CARE --------------------------------11 -------------------------------------------------13 TROUBLESHOOTING SPECIFICATION --------------------------------------------------------14... -
Page 3: Introduction
HS-5600 User's Manual INTRODUCTION Thank you and congratulations on purchasing your new C.T.M. Power Chair. It is designed to provide you with transportation indoors and outdoors. Chien Ti Enterprise Co., Ltd. is the manufacturer for the C.T.M. mobility power chair. -
Page 4: Important Precaution
HS-5600 User's Manual IMPORTANT PRECAUTIONS Here are some tips for your safety riding. Only one person at a time can ride a C.T.M. Power chair. Maximum load is 181 kg / 400 lbs. Turn off switch before getting on or off. -
Page 5: Emi And Warnings
HS-5600 User's Manual EMI AND WARMINGS It is very important that you read this information regarding the possible effects of Electromagnetic Interference on your motorized wheelchair. Powered wheelchairs and motorized scooters may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such a radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones. - Page 6 HS-5600 User's Manual 3.Long-range transmitters and transceivers such as commercial broadcast transmitters (radio and TV broadcast antenna towers) and amateur (HAM) radios. Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV sets, CD players, and cassette players, and small appliances, such as electric shavers and hair dryers, so far as we know, are not likely to cause EMI problems to your motorized scooter.
-
Page 7: Initial Overview
Adjustable Seatback And Headrest Armrest Joystick Seat Belt Adjustable Footplate Figure 1 - HS-5600 Power Chair Front View Self Diagnostic Warning Lights & Adjustment Battery Gauge Rear Bag Thumbscrews Speed Control Button... -
Page 8: Adjustments
HS-5600 User's Manual ADJUSTMENTS SEAT You can adjust your seatback angle and the headrest height. Lift up and push down the headrest easily. Lift up the lever to adjust the seatback angle. (See Fig. 4) ARMREST The armrest is width adjustable. Loosen two knobs to move Armrest. (See Fig. 5) -
Page 9: Disassembly And Assembly
HS-5600 User's Manual DISASSEMBLY AND ASSEMBLY Your C.T.M. power chair can be disassembled for your easy transportation. Before disassembling your chair, please ensure the power has turned off and not in the free-wheeling position. Unplug the joystick connectors. (See Fig. 09) Remove seat by gently lifting up the two levers under the seat. -
Page 10: Operation
HS-5600 User's Manual OPERATION Before operating your scooter, check the following: freewheeling lever is on D. speed dial is at the lowest speed (fully turned counterclockwise). 1.Sit on chair and fasten the seat belt. Insert the buckle (A) to (B) Depress the side button (C) to release. -
Page 11: Charging The Batteries
HS-5600 User's Manual CHARGING THE BATTERIES Your C.T.M. power chair is equipped with two sealed, service free 12V rechargeable batteries and one 24V. 5A charger. Batteries must be charged before using the chair for the first time and should be recharged after each day's use. Be sure the power switch is in the OFF position. - Page 12 HS-5600 User's Manual Keep in mind these rules Fully charge batteries at lease once a month, more if you use the chair regularly. Charge after each trip exceeding 3 kilometers (2miles). If storing your chair for some time, make sure that the batteries are fully charged, and on returning, charge them again before using scooter.
-
Page 13: Maintance And General Care
HS-5600 User's Manual MAINTANCE AND GENERAL CARE MAINTANCE All technical maintenance and repair of your chair should be done by an authorized dealer. The following areas required periodic inspection: Tire Pressure (for air-filled tires only) The condition of the tires and maintenance of the specified tire pressures not only influence tire life but also road safety to a very considerable extent. - Page 14 HS-5600 User's Manual Care of seat The seat material used by C.T.M. is a product of high quality, and will remain in good condition for many years if correctly treated. Regular cleaning and care are needed since dust and dirt, for instance from the roads, cause severe abrasion and can lead to the surface becoming prematurely brittle.
-
Page 15: Troubleshooting
HS-5600 User's Manual TROUBLESHOOTING TROUBLESHOOTING Flash codes indicate the nature of an abnormal condition directly from the SHARK lnformation Gauge. Without the use of any servicing tools, the condition can be simply diagnosed. Flash Code Description Possible stall timeout or user error. -
Page 16: Specification
HS-5600 User's Manual SPECIFICATION Overall Length 1135 mm / 44.7" Overall Width 635 mm / 25" Overall Height 1185 mm / 46.7" Wheels: Front 230 mm / 9" Wheels: Middle Wheels: Rear 360 mm / 14" Weight w/ Batteries 101.8 kg / 224.3 lbs Max.
