- Page 1 C.T.M. Folding Power Chair C.T.M. Folding Power Chair C.T.M. Folding Power Chair HS-6200 User's Manual...
-
Page 2: Table Of Contents
HS-6200 User's Manual Table of Contents Introduction.................1 Electromagnetic Interference and Warnings......3 Safety Instructions...............5 Initial Overview..............6 Unpacking and Assembly............8 Special Features..............11 Safe Driving Techniques.............14 Batteries and Charging............16 Tire..................18 Maintenance,and Cleaning..........19 Troubleshooting..............20 Specification..............22... -
Page 3: Introduction
Mobility Scooters and Power Chairs that are developed by a team of specialists with outstanding design skills and competence. The HS-6200 is an excellent chair that includes ergonomic features. It combines safety and comfort and gives users extraordinary experience and convenience in operation. - Page 4 User's Manual We wish you an enjoyable riding experience. If you have any questions, you can contact: C.T.M.HOMECARE PRODUCT, INC. 13815 Magnolia Ave. #B, Chino CA 91710 Toll Free : 1-866-466-8168 Tel : 909-590-1388 Fax : 909-590-3365 E-Mail : ctm@ctmhomecare.com http : //www.ctmhomecare.com...
-
Page 5: Electromagnetic Interference And Warnings
HS-6200 User's Manual ELECTROMAGNETIC INTERFERENCE AND WARNINGS CAUTION: It is very important that you read this information regarding the possible effects of Electromagnetic Interference on your power chair. Powered wheelchairs and motorized scooters may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones. - Page 6 HS-6200 User's Manual 3.Long-range transmitters and transceivers such as commercial broadcast transmitters (radio and TV broadcast antenna towers) and amateur (HAM) radios. Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV sets, CD players, and cassette players, and small appliances, such as electric shavers and hair dryers, so far as we know, are not likely to cause EMI problems to your power chair.
-
Page 7: Safety Instructions
HS-6200 User's Manual SAFETY INSTRUCTIONS Safety is the main consideration when practicing with your chair. It is required that you read and comprehend all the operating and safety instructions discussed in this manual. And ensure your chair is correctly fitted and adjusted by your dealer or the prescribing healthcare professional. -
Page 8: Initial Overview
Flip up and Height Adjustable Armrests Connectorless Battery Boxes Fiber Glass Reinforced 2 High Torque Motors Nylon Leg Rests Mated to Precision Sealed for Life Gear reducers Low Profile Cast Aluminum Wheels with Multi-Terrain Tires Figure 1 - HS-6200 Front View... - Page 9 Height Adjustable Armrests Knob Battery Box Back & Forth Adjstable Armrests Plug Free Wheel Lever Free Wheel Lever Anti-Tip Wheels Figure 2 - HS-6200 Back View Battery Level lndicator Charging Socket speed Indicator Horn On/Off Switch Speed Control Button Figure 3 - Joystick Top View...
-
Page 10: Unpacking And Assembly
HS-6200 User's Manual UNPACKING AND ASSEMBLY Pull two Pull Handles upward from the Holder (A) and (B), then turn outward to take out the battery.(See Fig. 5) Remove the Battery (C) by sliding along the slider.(See Fig. 6) Figure 5... - Page 11 HS-6200 User's Manual Slowly grasp the centre of the seat upholstery, one hand at the front and the other at the rear, pull the seat upholstery up vertically.(See Fig. 11) Push down the pulled up seat upholstery evenly.(See Fig. 12)
- Page 12 HS-6200 User's Manual When put the battery box (H) back to original position, place the battery box at the slide terminal, (Do not set too far back otherwise the battery box won't be fit into the slide tube accurately.)(See Fig. 15) Battery boxes are separate into front and rear sections, please disassemble and assemble accordingly.(See Fig.
-
Page 13: Special Features
The height adjustable T-type armrest is provided as standard equipment on the chair. Adjustment for the HS-6200 is facilitated by a thumbscrew fitted from the outside of the armrest support at the lower end. To activate the thumbscrew simply loosen and remove it from the locating hole. - Page 14 HS-6200 User's Manual 1.The distance of your controller unit can be easily changed for the desired position. To adjust it, loosen the thumbscrew (L) and slide into or out of the controller bracket.(Figure 22) Figure 22 Figure 22 Seat The C.T.M. chair features seat upholstery that can be tightened. While there should be no adjustment necessary upon delivery of your new chair, over time stretch could occur.
- Page 15 User's Manual Leg Rests The HS-6200 is equipped with a swing-away & detachable leg rests, which are height adjustable. To adjust the height, remove the securing screws and nuts from each side and slide the extension tube and leg rests up or down to the desired height. Retighten the securing hardware as Fig.
-
Page 16: Safe Driving Techniques
HS-6200 User's Manual SAFE DRIVING TECHNIQUES Driving your Chair Before sitting on your chair, verify: 1. The chair is switched off. 2. Swing away the armrests and leg rests if appropriate. 3. The battery charger is disconnected from both the chair and the wall outlet. - Page 17 HS-6200 User's Manual Chair Operation on surfaces that require Special Care When driving up or down ramps it is recommended that the user: 1. Visually checks to see if the angle of the slope is less than 10 degrees. 2. Checks to see that the ramp surface is roughened to prevent slippage.
-
Page 18: Batteries And Charging
Charging the batteries : 1. Position HS-6200 power chair next to a standard wall outlet. 2. Connect the battery charger to the wheelchair input battery charging socket, which is located on the front of the controller. - Page 19 HS-6200 User's Manual Replacing the batteries CAUTION ! - If you have doubts about your ability to lift any components, it is recommended that you seek qualified dealer so as to avoid injury. 1. Turn the power off. 2. Disconnect the battery connection plug at the front of the battery tray.
-
Page 20: Tire
HS-6200 User's Manual TIRE You should inspect the tires frequently for damage, the presence of foreign bodies, unusual wear and sufficient tread depth. Tread depth should if possible not be allowed to drop below 1/16". If replacement tires are needed, please contact the nearest C.T.M. -
Page 21: Maintenance,And Cleaning
13. Visually inspect the controller harnesses. Make sure that they are not frayed, cut or have any wires exposed. See your authorized dealer if there is a problem with any of these harnesses. 14. Ensure that all parts of the controller system are securely fastened to your HS-6200. Do not over tighten any screws. -
Page 22: Troubleshooting
HS-6200 User's Manual TROUBLESHOOTING Here are some suggestions about solving problems you may have with your power chair. There are 10 LED Self-Diagnostic Warning Lights on the Control Panel. To check the Self-Diagnostic Warning Lights, turn the power chair on and count the number of flashes. - Page 23 HS-6200 User's Manual Other Problems Power chair will not move when the power is turned on: 1.Check the Battery Level Indicator on the joystick. All the LED lights should be on. 2.Check the Self-Diagnostic Warning Light. It should be steady. If it is flashing, see the chart on page 20 for the problem identification.
-
Page 24: Specification
HS-6200 User's Manual SPECIFICATION SPECIFICATIONS HS-6200 HS-6200N 42.3" 41.1" Overall Length 24" 23.2" Overall Width 35.4" 35.4" Overall Height 7.4" 8" Wheels: Front Wheels: Middle 13" 13" Wheels: Rear 156.3 lbs 154.8 lbs Weight w/ Batteries 5 mph 5 mph Max.
