  • Page 1 C.T.M. Power Chair C.T.M. Power Chair C.T.M Power Chair User Manual HS-2750...

  • Page 2: Table Of Contents

    HS-2750 User Manual Table of Contents 1.INTRODUCTION ---------------------------------------------------------1 2.IMPORTANT PRECAUTIONS -----------------------------------------2 3.PRODUCT OVERVIEW -------------------------------------------------6 4.PRODUCT OPERATION ------------------------------------------------8 5.BATTERIES AND CHARGING ---------------------------------------11 6.TROUBLE SHOOTING ------------------------------------------------13 7.MAINTENANCE AND CLEANING ----------------------------------15 8.ACCESSORIES ---------------------------------------------------------17 9.SPECIFICATION --------------------------------------------------------18...

  • Page 3: Introduction

    HS-2750 User Manual 1.INTRODUCTION Thank you and congratulations on purchasing your new C.T.M. Power Chair. It is designed to provide you with transportation ability indoors and outdoors. We pride ourselves on providing safe and comfortable products. Our goal is to ensure your complete satisfaction with our product.

  • Page 4: Important Precautions

    HS-2750 User Manual 2.IMPORTANT PRECAUTIONS 2-1 CAUTIONS BEFORE DRIVING ※Drive for the first time : 1.Before take the first trip with power chair, you should familiarize yourself well with the operation of power chair and with the operation elements. Please take your time to read this introduction booklet.
  • Page 5 HS-2750 User Manual 3.Do not place the power chair on a slope to avoid roll-away and danger. 4.Do not turn the power on before you get in and sit securely on the seat. Be certain that the power is turned off when get in, get out. This will eliminate the possibility of accidentally activating the remote module and causing injury.
  • Page 6 HS-2750 User Manual •Be mindful of road conditions and pass through obstacles slowly. •Even though your power chair has been rated with maximum climbable, we suggest not driving through an obstacle. 2-5 ELECTROMAGNETIC INTERFERENCE AND WARNINGS CAUTION: It is very important that you read this information regarding the possible effects of Electromagnetic Interference on your power chair.
  • Page 7 HS-2750 User Manual Warnings : Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones can affect the power chair. Following the warnings listed below should reduce the chance of unintended brake release or power chair movement, which could result in serious injury.

  • Page 8: Product Overview

    HS-2750 User Manual 3.PRODUCT OVERVIEW 3-1 LABELS INFORMATION OUTSIDE INSIDE Warning sticker 1.Please read the instruction Booklet carefully before using your power chair. 2.Keep the power chair properly maintained. 3.Do not drive the power chair on slippery surfaces or on slopes over 6°.
  • Page 9 (see section 4-6) Battery Box Folding Lever (see section 5-2) (see section 4-7) Footrest (see section 4-3) Figure 1 - HS-2750 Front View Backrest Folding Device (see section 4-5) Free Wheel Lever (see section 4-4) Motor Anti-Tip Wheels Figure 2 - HS-2750 Rear View...

  • Page 10: Product Operation

    HS-2750 User Manual 4.PRODUCT OPERATION Before attempting to drive this power chair on your own, it is important that you familiarize yourself with the controls, and how to operate them. Intended use : The C.T.M. Power Chair provide a means by which a disabled occupant i.e.
  • Page 11 HS-2750 User Manual 4-2 ARMREST OPERATION Flip up the armrest to get off or get onto the wheelchair from one side. (Fig. 6) Watch out for pinch warning Figure 6 Figure 6 4-3 FOOTREST ADJUSTMENT •Lift up footrest as arrows indicated to fold. (Fig. 7) •Adjust the footrest fixation screw to required hole's position...
  • Page 12 HS-2750 User Manual 4-7 FOLDING OPERATION Folding: 1. Confirm the front wheels are facing forwards for easier folding (Fig 11). 2. Lift up the folding lever under the seat and hold it still. (Fig 11-2). Figure 11 Figure 11 3. Tug the seat and backrest inwards (Fig 11-3).

  • Page 13: Batteries And Charging

    •Batteries must be charged before using the power chair for the first time. (see section 5-2) •Full charge the batteries after each day's use. (see section 5-2) •HS-2750 uses lithium battery. Recommended range of storage : Temperature : 25+-5oC, under 60oC during transportation. Humidity : 25% ~ 85%, out of this range might affect the performance of the charger and battery.
  • Page 14 HS-2750 User Manual 5-2 CHARGING OPERATION ※There are two charging ports, one is on battery box, and the other is on remote module. Battery box charging port 1.Pull the security latch (under the seat) open (Fig. 16-1) to pull the battery box out (Fig. 16).

  • Page 15: Trouble Shooting

    HS-2750 User Manual Please be aware that the travelling range of your power chair is impacted by how fast the batteries are discharged. This will depend on many circumstances, such as ambient temperature, condition of the surface of the road, tyre pressure, weight of the driver, driving environment (inclines etc.) and utilisation of your lighting system if fitted.
  • Page 16 HS-2750 User Manual Figure 22 OONAPU OONAPU ("Out Of Neutral At Power Up") is a safety feature that prevents accidental movement of the wheelchair, either when powering up, or when the wheelchair comes out of an inhibit state. If the LiNX LE System is turned on (or comes out of an inhibit state) while the joystick is not in the centre position, an OONAPU warning is displayed.

  • Page 17: Maintenance And Cleaning

    HS-2750 User Manual 7.MAINTENANCE AND CLEANING 7-1 REGULAR MAINTENANCE AND CLEANING The power chair needs some basic attention to ensure it provides reliable service. We recommend that the user ensures that the power chair is checked regularly for maintenance requirements and receives a thorough, annual maintenance check up.
  • Page 18 HS-2750 User Manual 7.MAINTENANCE AND CLEANING 7-2 INSPECTION CHECKS Please always check your power chair before you start your every journey. if you find the sign of power chair malfunction, please contact your authorized dealer. Check point Inspection What to do if the inspection is failed...

  • Page 19: Accessories

    HS-2750 User Manual 8.ACCESSORIES 8-1 Optional Accessories Please contact your distributor if you need the accessories below. Seatbelt High Capacity 30.15Ah Batteries ---- To be determined Increases power chair endurance. Increases stability during ride.

  • Page 20: Specification

    HS-2750 User Manual 9.SPECIFICATION Overall Length 1055 mm / 42" Overall Width 635 mm / 25" Overall Height 1030 mm / 40.6" Front Wheels 200 mm / 7.8" Rear Wheels 320 mm / 12.6" Weight W/ Batteries 29.5 kg / 65 lbs Max.
