OVEN AND ACCESSORIES

1
11
12
17
21
9:37 AM Page 2
3
2 4 5
10 9
13
18
19
Coupling
20
1 Door
2 Door hinges
3 Grill heating element
4 Oven lamp
5 Waveguide cover
6
6 Door lock openings
7 7 Control panel
8 Door opening button
8
9 Coupling
10 Oven cavity
11 Door seals and sealing surfaces
12 Door safety latches
13 Ventilation openings
14 Outer cabinet
15 Back plate
16 Rear cabinet
14
17 Power supply cord
15
16
ACCESSORIES:
Check to make sure the following accessories are
provided:
(18) Turntable (19) Roller stay
(20) High Rack (21) Low Rack
Place the roller stay on the floor of the cavity.
Place the turntable on the roller stay so that it fits over
coupling.
To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please
mention two items: part name and model name to
your dealer or SHARP authorised service agent.
This microwave will be supplied with 2 racks (High
and Low).
