Router Setup - Sitecom WL-114 Quick Installation Manual

Windows XP
• In the Taskbar, click on the Start button and select - Settings - Control Panel - Internet options.
• Select the tab Connections and click the Setup... button.
• When the New Connection Wizard starts, click on Next.
• Select Connect to internet and click on Next.
• Select Set up my connection manually and click on Next.
• Select Connect using a broadband connection that is always on and click on Next.
• Click on Finish to close the Wizard.
• In the Taskbar, click on the Start button and select - Settings - Control Panel - Internet options.
• Select the Connections tab and click on the LAN Settings button.
• Check carefully that none of the boxes in the Local Area Network (LAN) Settings window are checked.
The PC configuration is now completed.

Router setup

Manual configuration - Internet access
1 Ensure you have TCP/IP settings on your PC, as described above.
Do not forget to restart your PC after you have finished.
2 Start your web browser. In the Address field, enter the following: http://192.168.123.254
3 Login with the username admin and password admin.
4. The start up window will now be displayed. Click on Wizard.
5. The Setup wizard will now be displayed; check that the modem is connected and click on Next.
