E9TK2FD_EN.book Page 1 Wednesday, July 29, 2009 12:16 PM
DVD / VIDEO CASSETTE RECORDER
DVR70DTKF2
OWNER'S MANUAL
ON/STANDBY
© 2009 Toshiba Corporation
EN
PAL
SECAM
OPEN/CLOSE
VCR
DVD
For Customer Use:
Carefully read the Model No. and Serial No. located at the
back of the unit and enter the information below. Retain
this information for future reference.
Model No. __________________________
Serial No. __________________________
1
