- Page 2 " # ................1 ....................2 & ..............2 ) * + ................3 ...... 5 0' ..............5 0' ....5 * ) 1 2 3332 4 ............5 2 3332 4 ..5 * ) 1 $ 5' ..7 * ) 1 % 3 ......
- Page 3 Thank you very much for purchasing the Transcend 2.5” Portable Hard Disk. This device is designed to expedite exchanging huge amounts of data between a 2.5” hard disk drive (HDD) installed in the 2.5” Portable Hard Disk and any desktop or notebook computer.
- Page 4 & The 2.5” Portable Hard Disk has the following features: Fully compatible with USB 2.0 specification • Fully backward compatible with USB 1.1 specification • Fully compatible with IEEE 1394A specification • Easy Plug and Play installation • LED indicates Power On and Data Access •...
- Page 5 1. Take out the screws and remove the back panel of the 2.5” Portable Hard Disk by pulling and sliding it slightly until it releases from the case. 2. Plug the HDD into the IDE connector and put the HDD horizontally onto the circuit board.
- Page 6 4. Push and slide the circuit board into the case. The sides of the circuit board should be put into the tracks. track 5. Insert the screws into the back panel of the 2.5” Portable Hard Disk. 6. The 2.5” Portable Hard Disk is now ready for use. *Note: For some desktop or notebook computers, the 2.5”...
- Page 7 1. Power on the computer where you will connect the 2.5” Portable Hard Disk and make sure the IEEE 1394A port is enabled and working properly. 2. Connect the 2.5” Portable Hard Disk to the IEEE 1394A port of your computer; meanwhile, you will need Windows 98SE source CD to install the files needed to use this device.
- Page 8 2. The Stop TS0GHDC2 IEEE 1394 SBP2 Device pop-up menu will appear. Click to remove the hardware. 3. The Safe To Remove Hardware window will appear. Click “OK”. 4. Your 2.5” Portable Hard Disk is now ready to be removed.
- Page 9 Portable Hard Disk to the computer until the driver is installed. 2. Insert the Driver CD into the CD-ROM drive. Run the Setup.exe program located within folder D:\TS0GHDC2\Driver\Win98se of the Driver CD (Where “D” is the CD-ROM drive letter). 3. Click “Yes” to continue driver installation.
- Page 10 5. Connect the 2.5” Portable Hard Disk to the USB port on your computer. (If necessary for additional power, also connect the 2.5” Portable Hard Disk to another USB port on your computer.) Your computer will automatically detect the 2.5” Portable Hard Disk and appear in Windows explorer. 6.
- Page 11 2. The Safely Remove Hardware pop-up menu will appear. Click “Stop” to remove USB device safely. 3. Your 2.5” Portable Hard Disk is now ready to be disconnected from your computer. The driver of the 2.5” Portable Hard Disk can be uninstalled by running Add/Remove Programs in Settings/Control Panel.
- Page 12 The 2.5” Portable Hard Disk is now ready for use. You can find a new drive with a newly assigned drive letter in My Computer window. * ) 1 2 3332 4 1. Locate the green arrow icon on the system tray. Click left button of the mouse on the icon.
- Page 13 * ) 1 % $ 5' 1. Complete hardware setup and driver installation. 2. Connect the 2.5” Portable Hard Disk to your Mac. A disk icon will appear on the desktop. You may use this device as if it were a Mac Hard Disk. 3.
- Page 14 Humidity······························8% ~ 90% RH Emission/Safety ··················FCC Class B, CE, BSMI Dimensions ·························131.5mm (L) x 82mm (W) x 20.5mm (H) Weight·································135 g (No HDD) " ) HDD Capacity Transcend P/N TS0GHDC2 (No HDD) USB2.0 + 40GB TS40GHDC2 (40GB HDD Inside) IEEE 1394A...
- Page 15 During the warranty period should this Transcend 2.5” Portable Hard Disk fail under normal use in the recommended environment due to improper workmanship or materials, Transcend will repair the product or replace it with a comparable one. This warranty is subject to the conditions and limitations set forth herein.
