- Page 1 128MB~8GB JetFlash™ User’s Manual P/N: TS128M~8GJF2A ( Version 1.1 )
-
Page 2: Table Of Contents
Introduction Package Contents ...1 Features ...1 System Requirements ...2 Driver Installation Driver Installation for Windows 98SE ...2 Driver Installation for Windows Me, 2000, and XP ...4 Driver Installation for Mac OS 9.0 or Later ...4 Driver Installation for Linux Kernel 2.4.2 or Later...4 Uninstall the Win98 Driver To Safely Unplug JetFlash To Remove JetFlash in Windows 98SE ...5... -
Page 3: Package Contents
Thank you very much for purchasing Transcend’s JetFlash™. This small device is designed to expedite exchanging huge amounts of data between any desktop or notebook computer with a USB port. With higher storage capacity and a much faster data transfer rates than other typical portable storage media, it can easily replace floppy diskettes and hard disks. -
Page 4: System Requirements
System Requirements Desktop or notebook computer with USB port One of following operating systems: ® • Windows 98SE ® • Windows ® • Windows 2000 ® • Windows • Mac™ OS 9.0 or later • Linux™ Kernel 2.4.2 or later Driver Installation for Windows 98SE Put the Driver CD into the CD-ROM (Auto-Run supported). - Page 5 Select Install or update driver. Click Start to continue. After Install or update driver is completed, click OK. Plug JetFlash into an available USB port. A new Removable Disk drive with a newly assigned drive letter appears in the My Computer window.
-
Page 6: Driver Installation For Windows Me, 2000, And Xp
Driver Installation for Windows Me, 2000, and XP No driver is required. These Windows operating systems have built-in drivers to support JetFlash. Simply plug JetFlash into an available USB port, and Windows will install the files needed to use your device. A new Removable Disk drive with a newly assigned drive letter appears in the My Computer window. -
Page 7: To Safely Unplug Jetflash
Select Uninstall driver. Click Start to continue. After Uninstall driver has been completed, click OK. To Safely Unplug JetFlash To Remove JetFlash in Windows 98SE Unplug JetFlash from your system directly when data is not being transferred. To Remove JetFlash in Windows Me, 2000, and XP Click the icon on the system tray. -
Page 8: To Remove Jetflash In Mac Os
Follow the on-screen instructions to complete the procedure. The Safe To Remove Hardware message window appears. JetFlash is now ready to be unplugged. To Remove JetFlash in Mac OS Drag and drop the Disk icon corresponding to JetFlash into the trashcan. Then unplug JetFlash from the USB port. -
Page 9: System Requirements For Boot-Up Function
System Requirements for the Boot-Up Function • A desktop or notebook computer that supports USB-ZIP or USB-HDD as the First Boot Device in BIOS • Windows 98SE or Me on the C: drive • Any anti-virus program present must be turned off Boot-Up Function is not supported for Mac or Linux Operating Systems. -
Page 10: Format Introduction
Format Introduction Type of Format Quick: Erase and check blocks at the same time. If there are any bad blocks, mark them as Bad and perform a DOS format. Full: Do a Surface Scan for a Read/Write Check. A Read/Write Check can find if there is any bad block which will be marked as Bad and perform a DOS format. -
Page 11: Create One Partition
Configuration Slide the Disk-Volume bar to adjust the disk size of your JetFlash. You can make one disk or two disks by adjusting the volume sizes. The options will change automatically and enable your choice. Make an USB-ZIP startup disk: When the size of Disk 1 is set to be larger than 2MB. - Page 12 Option 1: Make an USB-ZIP startup disk a. Select Type of format (Quick, Full or Configure device only) and Make USB-ZIP startup disk option. Click Start to continue. b. After the completion of the format, you need to re-insert JetFlash to enable the settings.
- Page 13 Option 2: Make an USB-HDD startup disk (Only for Windows 98SE) a. Select Type of format (Quick, Full or Configure device only) and Make USB-HDD startup disk option. Click Start to continue. After the completion of the format, you need to re-insert JetFlash to enable the settings.
-
Page 14: Create Two Partitions
Create Two Partitions Slide the Disk-Volume bar to adjust the size of Disk1 to fit your needs. The size of Disk2 will be changed automatically according to the size of Disk1, as adjusted by the user. JetFlash can be setup to a USB-ZIP or USB-HDD boot-up mode as indicated below. Disk 1 Option Size... - Page 15 b. After the completion of the format, you need to re-insert JetFlash to enable the settings. Restart your computer and press the Delete key (or whatever key combination is correct for your computer) during boot-up to enter Setup (CMOS Setup Utility) to reconfigure BIOS. c.
- Page 16 b. After the completion of the format, you need to re-insert JetFlash to enable the settings. Restart your computer and press the Delete key (or whatever key combination is correct for your computer) during boot-up to enter Setup (CMOS Setup Utility) to reconfigure BIOS. c.
-
Page 17: Security Function
The Security Function is not supported by Mac or Linux Operating Systems. Security Function for Windows 98SE, Me, 2000, and XP Create Single Partition You must run the mFormat Utility program on the JetFlash to enable this feature. This procedure will reformat the JetFlash and erase any data saved to the JetFlash memory. In order to avoid loss of data, please backup the files before proceeding through this procedure. - Page 18 Set default password window will appear and require you to enter the password. Enter the Password and the Password hint you want, and click OK. Return to the Format Utility window. Click Start to continue. Make sure you have performed a backup of the files on your JetFlash. Click OK to continue or Cancel to exit.
- Page 19 Set default password window will appear and require you to enter the password. Enter the Password and the Password hint you want, and click OK. Return to the Format Utility window. Click Start to continue. After the completion of the format, you need to re-insert JetFlash to enable the settings.
-
Page 20: Use Of Jetflash With Security Function Enabled
Use of JetFlash with Security Function Enabled Insert JetFlash and run the mFormat Utility program. Click the Login button Enter the correct password to access data on the secured disk. When you finish, you need to safely remove JetFlash to protect data (procedure described as below). -
Page 21: Change The Password
Change the Password Insert JetFlash, run the mFormat Utility program and click Login, the Login window appears. Click Change >> to continue. Key in the New password, Re-Enter new password and a Hint. Click OK to complete the change of password. If You Forget the Password If you forget your password, you can use the password hint to remember it. -
Page 22: Pc-Lock Function
Once the PC-Lock function is enabled, you can use the JetFlash as a key to lock your computer, protecting it from being used by unauthorized persons. The PC-Lock function is not supported on Mac and Linux Operating Systems. To use the PC-Lock function, you must login into the Windows OS with Administrator rights. - Page 23 Then click on the Enable button to enable the PC-Lock function.
-
Page 24: Specifications
Specifications Size: Weight: Data Retention: Erase Cycles: Speed: Certificates: Ordering Information Transcend P/N TS128MJF2A TS256MJF2A TS512MJF2A TS1GJF2A TS2GJF2A TS4GJF2A TS8GJF2A 75mm x 25mm x 11mm (Mini Size) 88mm x 33mm x 15mm (Normal Size) 15 g (Mini Size) 24 g (Normal Size) Up to 10 years ＞... -
Page 25: Jetflash Limited Warranty
Transcend. We consistently position ourselves to be significantly above the industry norm. It’s all part of our commitment to Customer Satisfaction. All Transcend Information, Inc. (Transcend) products are warranted and tested to be free from defects in material and workmanship and to conform to the published specifications.
