1
-
with the supplied Ethernet cable, connect your PC to any of the 4 LaN ports
on the back of the NB9wmaXXn
-
Connect an ADSL2+ Splitter/Filter to your telephone wall socket
-
with the supplied RJ-11 telephone cable, connect the ADSL port on your
NB9wmaXXn to the socket labeled aDSL modem on your Splitter/Filter
Connecting your Device
Telephone
Socket
Splitter
ADSL/Modem
Phone
Computer
connected via
Ethernet
