  • Page 1 F15C OWNER’S MANUAL U.S.A.Edition LIT-18626-05-47...
  • Page 3 EMU01449 TO THE OWNER Thank you for choosing a Yamaha out- board motor. This Owner’s manual con- A CAUTION indicates special precautions tains information needed for proper oper- that must be taken to avoid damage to ation, maintenance and care. A thorough the outboard motor.

  • Page 4: Table Of Contents

    EMA20010 CONTENTS GENERAL INFORMATION BASIC COMPONENTS OPERATION MAINTENANCE TROUBLE RECOVERY INDEX READ THIS OWNER’S MANUAL CAREFULLY BEFORE OPERATING YOUR OUTBOARD MOTOR.

  • Page 5: General Information

    EMB00010 Chapter 1 GENERAL INFORMATION IDENTIFICATION NUMBERS RECORD ..1-1 Outboard motor serial number ...1-1 EMISSION CONTROL INFORMATION...1-2 Star labels ..........1-3 SAFETY INFORMATION......1-4 IMPORTANT LABELS ......1-6 BASIC BOATING RULES ......1-7 FUELING INSTRUCTIONS.....1-11 Gasoline ..........1-12 ENGINE OIL ..........1-13 BATTERY REQUIREMENT ....1-14 PROPELLER SELECTION .......1-15 START-IN-GEAR PROTECTION ....1-16...

  • Page 6: Identification Numbers Record

    Record your outboard motor serial num- 401012 ber in the spaces provided to assist you in ordering spare parts from your Yamaha dealer or for reference in case your out- board motor is stolen. 1 Outboard motor serial number...

  • Page 7: Emission Control Information

    EMU01385 EMISSION CONTROL INFORMATION EMU01387 NORTH AMERICAN MODELS This engine conforms U.S. Environmental Protection Agency (EPA) 504**2 regulations for marine SI engines. See the label affixed to your engine for details. Approval label of Emission control certificate This label is attached to the bottom cowl- ing.

  • Page 8: Star Labels

    EMU01389 STAR LABELS Your outboard motor is labeled with a California Air Resources Board (CARB) star label. See below for a description of your particular label. 1 Star label 000851 One Star - Low Emission The one-star label identifies engines that meet the Air Resources Board’s 2001 exhaust emission standards.

  • Page 9: Safety Information

    EMU00917 8 This product emits exhaust gases which SAFETY contain carbon monoxide, a colorless, odorless gas which may cause brain INFORMATION damage death when inhaled. Symptoms include nausea, dizziness, 8 Before mounting or operating the out- and drowsiness. Keep cockpit and cabin board motor, read this entire manual.
  • Page 10 8 When a swimmer is in the water near you shift into neutral and shut off the engine. 8 Be informed about boating safety. Additional publications and information can be obtained from many organiza- tions, including the following: United States Coast Guard Consumer Affairs Staff (G-BC) Office of Boating, Public, and Consumer Affairs...

  • Page 11: Important Labels

    EMB30011 IMPORTANT LABELS WARNING LABELS WARNING This engine is equipped with a neutral starting device. The engine will not start unless the shift control is in neutral position. 6E0-83627-41 202**1 WARNING GBe sure shift control is in neutral before starting engine. (except 2HP) GDo not touch or remove electrical parts when starting or during operation.

  • Page 12: Basic Boating Rules

    EMB40010 Stand-on vessel BASIC BOATING RULES The vessel with the right-of-way has the duty to continue its course and speed, (Rules of the road) except to avoid an immediate collision. When you maintain your direction and Just as there are rules which apply when speed, the other vessel will be able to you are driving on streets and high ways, determine how best to avoid you.
  • Page 13 RULES WHEN ENCOUNTERING will clear one another if you continue on your set course and speed. VESSELS There are three main situations which you may encounter with other vessels which could lead to a collision unless the Steering Rules are followed: Meeting (you are approaching another vessel head-on) Crossing (you are travelling across the...
  • Page 14 its course and speed. You must stay out Sailing vessel right-of-way of its way until you are clear of it. Sailing vessels should normally be given Likewise, if another vessel is passing you, the right-of-way. The exceptions to this you should maintain your speed and are: direction so that the other vessel can steer When the sailing vessel is overtaking...
  • Page 15 letters and orange boarders. They signify speed zones, restricted areas, danger areas, and general information. Remember, markings may vary by geo- graphic location. Always consult local boating authorities before driving your boat in unfamiliar waters. MAIN CHANNEL BUOYS " 1 " " 3 " " 5 " " 7 " "...

  • Page 16: Fueling Instructions

    EMB01010 FUELING INSTRUCTIONS GASOLINE AND ITS VAPORS ARE HIGH- LY FLAMMABLE AND EXPLOSIVE! 8 Do not smoke when refueling, and keep away from sparks, flames, or other sources of ignition. 8 Stop engine before refueling. 8 Refuel in a well-ventilated area. Refuel portable fuel tanks off the boat.

  • Page 17: Gasoline

    Gasohol containing ethanol can be used if ethanol content does not exceed 10% and the fuel meets minimum octane ratings. Gasohol containing methanol recommended Yamaha because it can cause fuel system damage or engine performance prob- lems. 1-12...

  • Page 18: Engine Oil

    EMU01769 ENGINE OIL Recommended engine oil: 4-stroke motor oil with a combination of corresponding SAE and API as shown in the chart. 10W-30 10W-40 Engine oil quantity: See Chapter 4, “Specifications.” All 4-stroke engines are shipped from the factory without engine oil. 001162 1-13...

  • Page 19: Battery Requirement

    EMU01775 BATTERY REQUIREMENT Do not use a battery that does not meet the specified capacity. If a battery which does not meet specifications is used, the electric system could perform poorly or be overloaded, causing electric system damage. For electric start models, choose a battery which meets the following specifications.

  • Page 20: Propeller Selection

    Conversely, a larger-pitch pro- peller is more suitable for a smaller oper- ating load. Yamaha dealers stock a range of pro- pellers, and can advise you and install a propeller on your outboard that is best suited to your application.

  • Page 21: Start-In-Gear Protection

    3 Type of propeller (propeller mark) Refer to the section “CHECKING PRO- PELLER” for instructions on propeller 602021 removal and installation. EMU01209 START-IN-GEAR PROTECTION Yamaha outboard motors or Yamaha approved remote control units equipped with start-in-gear protection device(s). This feature permits the engine to be started only when it is Neutral.
  • Page 22 -MEMO-...

  • Page 23: Basic Components

    EMC00010 Chapter 2 BASIC COMPONENTS MAIN COMPONENTS......2-1 OPERATIONS OF CONTROLS AND OTHER FUNCTIONS ........2-2 Fuel tank..........2-2 Gear shift lever ........2-3 Choke knob ..........2-3 Recoil starter handle......2-3 Starter button ........2-3 Tiller handle...........2-4 Remote control........2-7 Steering friction adjusting lever..2-11 Trim angle adjusting rod....2-11 Warning indicator(s) ......2-11 Tilt lock mechanism......2-12 Tilt support knob.........2-12...

  • Page 24: Main Components

    EMU01206 MAIN COMPONENTS !2 !3 000934 000944 701061 101121 1 Top cowling * e Tiller handle 2 Top cowling lock lever r Steering friction adjusting lever 3 Oil drain bolt t Transom clamp handle 4 Anti-cavitation plate y Rope attachment 5 Propeller * u Tilt lock lever 6 Cooling water inlet...

  • Page 25: Operations Of Controls And Other Functions

    EMC20010 OPERATIONS OF CONTROLS OTHER FUNCTIONS EMC21012 FUEL TANK If your model was equipped with a portable fuel tank, its function is as fol- lows. 1 Fuel hose joint 2 Fuel meter(If equipped) 3 Fuel tank cap 4 Air vent screw(If equipped) EMC31010 Fuel hose joint This connector is provided for connecting...

  • Page 26: Gear Shift Lever

    EMC25010 GEAR SHIFT LEVER (for Tiller control model) Turning the gear-shift lever towards you engages the clutch with the forward gear so that the boat moves ahead. Turning the lever away from you engages the reverse gear so that the boat moves astern.

  • Page 27: Tiller Handle

    EMU01317 TILLER HANDLE (for tiller control models) Moving the tiller handle from side to side changes the steering direction. In addi- tion, this handle has the following func- tions. 1 Throttle control grip 508015 2 Throttle indicator 3 Throttle friction adjusting knob/screw 4 Engine stop button / Engine stop lanyard switch 5 Power tilt switch (if equipped)
  • Page 28 EMU01294 Throttle Friction Adjusting Knob A friction device in the tiller handle pro- vides resistance to movement of the throttle grip. This is adjustable for opera- tor preference. Resistance Knob Increase Turn clockwise 502016 Decrease Turn counterclockwise When constant speed is desired, tighten the adjusting knob to maintain the desired throttle setting.
  • Page 29 8 Attach the engine stop switch lanyard to a secure place on your clothing, your arm or leg while operating. 8 Do not attach the lanyard to clothing that could tear loose. Do not route the lanyard in such a way that it could become entangled, preventing it from functioning.

  • Page 30: Remote Control

    EMU00094 REMOTE CONTROL Both the shifter and the throttle are actu- ated by the remote control lever. In addi- tion, this remote control also has the elec- trical switches. 1 Remote control lever 2 Neutral interlock trigger 3 Neutral throttle lever 000608 4 Main switch / Choke switch 5 Engine stop lanyard switch...
  • Page 31 EMU00099 Neutral Interlock Trigger To shift out of Neutral, the neutral inter- lock trigger of the remote control lever must first be pulled up. 701036 EMU00100 Neutral Throttle Lever To open the throttle without shifting into either Forward or Reverse, place the remote control lever in the Neutral posi- tion and lift the neutral throttle lever.
  • Page 32 EMU00102 Choke Switch While the main switch is being pressed in START at “ON” or “START”, the choke system will switch on, to supply a rich mixture required to start the engine. (When the key is released, it will switch off automati- cally.) 701042 EMU00934...
  • Page 33 EMU01316 Power Tilt Switch The power tilt adjusts the motor angle in relation to the transom. The power tilt switch is located on the remote control lever grip. Pushing the switch “UP” tilts the motor up. Pressing the switch “DN” tilts the motor down.

  • Page 34: Steering Friction Adjusting Lever

    EMU01295 STEERING FRICTION ADJUSTING LEVER A friction device provides resistance to steering movement. This is adjustable according to operator preference. Resistance Lever Increase Turn to port 408033 Decrease Turn to starboard Do not overtighten the friction adjusting lever. If there is too much resistance, it may be difficult to steer, which could result in an accident.

  • Page 35: Tilt Lock Mechanism

    EMD44110 TILT LOCK MECHANISM (for Manual tilt model) The tilt-lock mechanism is used to pre- vent reverse thrust from the propeller lift- ing the outboard motor when reversing. To lock it, set the tilt-lock lever in the Lock position. To release it, place the tilt-lock lever in the Tilt position.

  • Page 36: Top Cowling Lock Lever

    EMD62011 TOP COWLING LOCK LEVER To remove the engine top cowling, turn the lock lever. Then lift off the cowling. When replacing the cowling, check to be sure it fits properly in the rubber seal. Then lock the cowling again by moving the lever upward.

  • Page 37: Warning System

    EMU00169 WARNING SYSTEM Do not continue to operate the engine if the warning device has activated. Consult your Yamaha dealer if the problem can- not be located and corrected. 701054 EMU00170 OVERHEAT WARNING This engine has an overheat warning device. If the engine temperature rises too high, the warning device will activate.

  • Page 38: Low Oil Pressure Warning

    Check oil level and add oil as needed. If the oil level is correct, consult your Yamaha dealer. Do not continue to run the engine if the low oil pressure lamp is “ON”. Serious engine damage may occur.

  • Page 39: Operation

    EMF00010 Chapter 3 OPERATION INSTALLATION ........3-1 Mounting the outboard motor ....3-2 Clamping the outboard motor.....3-4 BREAKING IN (RUNNING IN) ENGINE ..3-5 PRE-OPERATION CHECKS ......3-6 Checking the engine oil level....3-7 FILLING FUEL ...........3-8 STARTING ENGINE .........3-9 WARMING UP ENGINE ......3-16 SHIFTING ..........3-17 Forward..........3-17 Reverse ..........3-18 STOPPING ENGINE .......3-19...

  • Page 40: Installation

    EMF10010 INSTALLATION Incorrect engine height or obstructions to smooth water flow (such as the design or condition of the boat or accessories such as transom ladders/depth finder trans- ducers) can create airborne water spray while the boat is cruising. Severe engine damage may result if the motor is operat- ed continuously in the presence of air- borne water spray.

  • Page 41: Mounting The Outboard Motor

    EMF12012 MOUNTING THE OUTBOARD MOTOR Improper mounting of the outboard motor could result in hazardous condi- tions such as poor handling, loss of con- trol, or fire hazards. Observe the follow- ing: 8 The information presented in this sec- tion is intended as reference only. It is possible provide complete...
  • Page 42 Overpowering a boat may cause severe instability. Do not install an outboard motor with more horsepower than the maximum rating on the capacity plate of the boat. If the boat does not have a capacity plate, consult the boat manufac- turer.

  • Page 43: Clamping The Outboard Motor

    EMU01318 CLAMPING THE OUTBOARD MOTOR 1) Place the outboard on the transom so that it is positioned as close to the center as possible. Tighten the tran- som clamp screws evenly and secure- ly. Check the clamp-screws for tight- ness occasionally during operation of the motor as they can work loose due 409011 to engine vibration.

  • Page 44: Breaking In (Running In) Engine

    EMF50312 BREAKING IN (RUNNING IN) ENGINE Your new engine requires a period of break-in (running-in) to allow mating sur- faces of moving parts to wear-in evenly. Correct break-in (running-in) will help ensure proper performance and longer engine life. Failure to follow the break-in (running-in) procedure may result in reduced engine life or even severe engine damage.

  • Page 45: Pre-Operation Checks

    EMF40013 PRE-OPERATION CHECKS If any item in the pre-operation check is not working properly, have it inspected and repaired before operating the out- board motor. Otherwise, an accident could occur. Do not start the engine out of water. Overheating and serious engine damage can occur.

  • Page 46: Checking The Engine Oil Level

    EMF43010 Controls 8 Check throttle, shift, and steering for proper operation before starting the engine. 8 The controls should work smoothly, without binding or unusual free play. 8 Look for loose or damaged connec- tions. 8 Check operation of the starter and stop switches when the outboard motor is in the water.

  • Page 47: Filling Fuel

    While many additives available may reduce deposits, Yamaha recommends the use of Ring Free Fuel Additive, avail- able from your Yamaha dealer. Ring Free has repeatedly proven its ability to clean combustion deposits from inside the engine, notably the critical piston-ring- land area, and fuel system components.

  • Page 48: Starting Engine

    EMU01147 STARTING ENGINE 8 Before starting the engine, make sure that the boat is tightly moored and that you can steer clear of any obstructions. Be sure there are no swimmers in the 902053 water near you. 8 When the air vent screw is loosened, gasoline (petrol) vapor will be released.
  • Page 49 EMU01497 PROCEDURE FOR TILLER CONTROL MODEL 4) Place the gear-shift lever in the neu- tral position. NOTE: The start-in-gear protection device pre- vents the engine from starting except when in Neutral. 406023* 5) Attach the engine stop switch lanyard to a secure place on your clothing, or your arm or leg.
  • Page 50 EMF63112* Manual start model 7) Pull out the choke knob completely. After the engine starts, return the knob to the original position. NOTE: 8 It is not necessary to use the choke when restarting a warm engine. 8 If the choke knob is left pulled out after 226011 the engine starts, the engine will stall.
  • Page 51 EMF63511* Electric start model 7) Pull out the choke knob completely. After the engine starts, return the choke knob to the original position. NOTE: 8 It is not necessary to use the choke when restarting a warm engine. 8 If the choke knob is left pulled out, the 226011 engine will stall.
  • Page 52 EMU00247 PROCEDURE FOR REMOTE CONTROL MODEL 4) Place the remote control lever in the Neutral position. NOTE: The start-in-gear protection device pre- vents the engine from starting except when in Neutral. 701015 5) Attach the engine stop switch lanyard to a secure place on your clothing, or your arm or leg.
  • Page 53 EMU00945 Electric Start Model 7) Open the throttle slightly lifting the neutral throttle lever upwards partial- ly. You may need to change the throt- tle opening slightly depending on engine temperature. After the engine starts, return the throttle to the original position. 701014 NOTE: 8 As a starting point, lift the lever just...
  • Page 54 8 Do not turn the main switch to “START” when the engine is running. 8 Do not keep the starter-motor turning for more than 5 seconds. The battery will rapidly become exhausted and it will be impossible for it to start the engine.

  • Page 55: Warming Up Engine

    Check the oil level and add oil if necessary. If the cause for the low oil pressure warning indicator cannot be found, consult your Yamaha dealer. 8 A continuous flow of water from the pilot hole shows that the water pump is pumping water through the cooling passages.

  • Page 56: Shifting

    EMU00261 SHIFTING Before shifting, make sure there are no swimmers or obstacles in the water near you. To change the shifting position from for- ward to reverse or vice-versa, close the throttle first so that the engine idles (or runs at low speeds). EMU00265 FORWARD Tiller control model...

  • Page 57: Reverse

    EMU01326 REVERSE When operating in Reverse, go slowly. Do not open the throttle more than half. Otherwise, the boat may become unsta- ble, which could result in loss of control and an accident. 1) Place the throttle control grip in the fully closed position (for Tiller control model).

  • Page 58: Stopping Engine

    EMU00273 STOPPING ENGINE Let it cool off for a few minutes at idle or low speed first. Stopping the engine immediately after operating at high speed is not recommended. EMU00277 506021 1) Push and hold the engine stop button or turn the main switch to “OFF”. START 701023 2) If the fuel joints are provided, discon-...

  • Page 59: Trimming Outboard Motor

    EMU01412 TRIMMING OUTBOARD MOTOR The trim angle of the outboard motor helps determine the position of the bow of the boat in the water. The correct trim angle will help improve performance and fuel economy while reducing strain on the engine.

  • Page 60: Adjusting Trim Angle

    ADJUSTING TRIM ANGLE EMU00951 Manual tilt model There are 4 or 5 holes provided in the clamp bracket to adjust the outboard motor trim angle. 1) Stop the engine. 2) Remove the trim angle adjusting rod 1 from the clamp bracket while tilting the motor up slightly.
  • Page 61 EMU01414 Power Tilt Model 8 Be sure all people are clear of the out- board motor when adjusting the tilt angle, also be careful not to pinch any body parts between the drive unit and clamp bracket. 701034 8 Use caution when trying a trim position for the first time.
  • Page 62 EMU19160 Trim angle settings and boat handling When the boat is on plane, a bow-up atti- tude results in less drag, greater stability and efficiency. This is generally when the keel line of the boat is up about 3 to 5 degrees.

  • Page 63: Tilting Up/Down

    NOTE: Depending on the type of boat, the out- board motor trim angle may have little effect on the trim of the boat when oper- ating. EMH10111 TILTING UP/DOWN If the engine will be stopped for some time, or if the boat is moored in shallows, the engine should be tilted up to protect the propeller and casing from damage by collision with obstructions, and also to...
  • Page 64 EMU00290 PROCEDURE FOR TILTING UP Manual tilt model 1) Place the gear shift lever in Neutral. 2) Remove the fuel line connection from the motor. 3) Place the tilt lock lever in the release position. 4) Hold the rear of the top cowling with 406023* one hand and fully tilt the engine up.
  • Page 65 EMU01312 PROCEDURE FOR TILTING UP Power tilt model 1) Remove the fuel-line connection from the motor. 304045 2) Push the power tilt switch “UP” until the outboard has tilted up completely. 701034 000610 3) Push the tilt support knob into the clamp bracket to support the engine.
  • Page 66 EMU01313 PROCEDURE FOR TILTING DOWN Power tilt model 1) Push the power tilt switch “UP” until the engine is supported by the tilt rod. 2) Pull out the tilt support knob. 3) Push the power tilt switch “DN” (Down) to lower the engine to the desired position.

  • Page 67: Cruising In Shallow Water

    EMG70011 CRUISING IN SHALLOW WATER Manual tilt model The outboard motor can be tilted up par- tially to allow operation in shallow water. 000922 8 Place the gear shift in the Neutral posi- tion before using the shallow water cruising system. 8 Run the boat at the lowest possible speed when using the shallow water cruising system.
  • Page 68 EMG71211 PROCEDURE Manual tilt model 1) Place the gear shift lever in the neu- tral position. 406023* 2) Place the tilt lock lever in the release position. 402016 3) Slightly tilt up the engine. The tilt- support bar will lock automatically, supporting the engine in a partially raised position.
  • Page 69 EMU01319 CRUISING IN SHALLOW WATER Power tilt model The engine can be tilted up partially to allow operation in shallow water. 000922 8 Place the gear shift in the Neutral posi- tion before setting for shallow water cruising. 8 Return the engine to its normal posi- tion as soon as the boat is back in deeper water.

  • Page 70: Cruising In Other Conditions

    EMH60010 CRUISING IN OTHER CONDITIONS CRUISING IN SALT WATER After operating in salt water, wash out the cooling-water passages with fresh water to prevent them from becoming clogged- up with salt deposits. NOTE: Refer to cooling system flushing instruc- tions in “TRANSPORTING AND STORING OUTBOARD MOTOR”.

  • Page 71: Maintenance

    EMK00010 Chapter 4 MAINTENANCE SPECIFICATIONS ........4-1 TRANSPORTING AND STORING OUTBOARD MOTOR .......4-3 Trailering outboard motor ....4-3 Storing outboard motor .......4-5 PERIODIC MAINTENANCE......4-9 Replacement parts ........4-9 Maintenance chart ......4-10 Greasing..........4-12 Cleaning and adjusting spark plug ...4-13 Checking top cowling ......4-14 Checking fuel system ......4-15 Inspecting fuel filter ......4-16 Inspecting idling speed ......4-17 Changing engine oil......4-18...

  • Page 72: Specifications

    EMK10111* SPECIFICATIONS Model Unit F15MHC Item DIMENSIONS Overall Length mm (in.) 1,001 (39.4) Overall Width mm (in.) 427 (16.8) Overall Height mm (in.) 1,080 (42.5)/1,207 (47.5) Transom height mm (in.) 440 (17.3)/567 (22.3) Weight kg (lb.) 45 (99)/47 (104) PERFORMANCE Full throttle operating range r/min 4,500–5,500...
  • Page 73 F15EHC F15PRC F15PHC 1,001 (39.4) 643 (25.3) 1,001 (39.4) 427 (16.8) 369 (14.5) 427 (16.8) 1,080 (42.5)/1,207 (47.5) —/1,207 (47.5) —/1,207 (47.5) 440 (17.3)/567 (22.3) —/567 (22.3) —/567 (22.3) 48 (106)/50 (110) —/54 (119) —/55 (121) 4,500–5,500 4,500–5,500 4,500–5,500 11.0 (15.0) @5,000 11.0 (15.0) @5,000 11.0 (15.0) @5,000 900–1000...

  • Page 74: Transporting And Storing Outboard Motor

    For further details, consult your Yamaha dealer. 001185 8 Never get under the lower unit while it is tilted, even if a motor support bar is used.
  • Page 75 EMU00327 Clamp handle mounting model When transporting or storing the out- board motor while removed from a boat, fold the tiller handle and lean the motor on the tiller handle to keep in a horizontal position. Keep the power unit higher than the pro- peller at all times.
  • Page 76 “Yamaha Fuel Conditioner and Stabilizer” (Part No. LUB-FUELC-12- 00) to each gallon of fuel. NOTE: The use of “Yamaha Fuel Conditioner and Stabilizer” eliminates the need to drain the fuel system. Consult your Yamaha dealer or other qualified mechanic if the...
  • Page 77 4) Run the engine at a fast idle for 10~15 minutes. 5) Just prior to turning off the engine, quickly spray “Yamaha Stor-Rite Engine Fogging Oil” (Part No. LUB- STRRT-12-00) into the silencer cover. When properly done, the engine will...
  • Page 78 1) Wash down the exterior of the out- board with fresh water and dry off completely. 2) Spray the engine’s exterior with “Yamaha Silicone Protectant” (Part No. LUB-SILCNE-13-00). 3) Wax the cowling with a non-abrasive wax such as “Yamaha Silicone Wax” (Part No. ACC-11000-15-02).
  • Page 79 EMK29011 Battery Care Battery electrolyte is poisonous and dan- gerous, causing severe burns, etc. It con- tains sulfuric acid. Avoid contact with skin, eyes, or clothing. Antidote: EXTERNAL; Flush with water. INTERNAL; Drink large quantities of water or milk. Follow with milk of mag- nesia, beaten egg, or vegetable oil.

  • Page 80: Periodic Maintenance

    Be sure to turn off the engine when you perform maintenance unless otherwise specified. If the owner is not familiar with machine servicing, this work should be done by a Yamaha dealer or other quali- fied mechanic. Maintenance, replacement, or repair of the emission control devices and systems may be performed by any marine engine repair establishment or individual.

  • Page 81: Maintenance Chart

    Refer to the sections in this chapter for explanations of each owner-specific action. The mark (G) indicates the check-ups which you may carry out yourself. The mark (1) indicates work to be carried out by your Yamaha dealer. Initial Every...
  • Page 82 Every Item Actions 500 hours 1000 hours (2.5 years) (5 years) Timing belt Replacement 4-11...

  • Page 83: Greasing

    EML00011 GREASING Yamaha marine grease (Water resistant grease) 103192 4-12...

  • Page 84: Cleaning And Adjusting Spark Plug

    Do not attempt to diagnose any problems yourself. Instead, take the outboard motor to a Yamaha dealer. You should periodically remove and inspect the spark plug because heat and deposits will cause the spark plug to slowly break down and erode.

  • Page 85: Checking Top Cowling

    1 Spark plug gap 2 Spark plug I.D. mark (NGK) 903022 EMU16350 CHECKING TOP COWLING Check the fitting of the top cowling by pushing it with both hands. If the fitting is loose have it repaired by a Yamaha dealer. 4-14...

  • Page 86: Checking Fuel System

    Check the fuel line for leaks, cracks, or malfunctions. If any problem is found, it should repaired immediately Yamaha dealer or other qualified mechan- Checking points 8 Fuel system parts leakage. 8 Fuel hose joint leakage. 8 Fuel hose cracks or other damage.

  • Page 87: Inspecting Fuel Filter

    EMK50310 Check the fuel filter periodically. The fuel filter is a one-piece, disposable type. If foreign matter is found in the fil- ter, replace it. For replacement of the fuel filter, consult a Yamaha dealer. 207054 4-16...

  • Page 88: Inspecting Idling Speed

    If not warmed up fully, the idle speed will measure higher than normal. If you have difficulty verifying the idle speed, or the idle speed requires adjustment, consult a Yamaha dealer or other qualified mechan- 4-17...

  • Page 89: Changing Engine Oil

    EMU01415 CHANGING ENGINE OIL 8 Avoid draining the engine oil immedi- ately after stopping the engine. The oil is hot and should be handled with care to avoid burns. 8 Be sure the outboard is securely fas- tened to the transom or a stable stand. 8 Change the engine oil after the first 10 hours of operation, and every 100 hours or at 6-month intervals thereafter.
  • Page 90 Continued operation with a problem could cause severe engine damage. If the problem cannot be found and corrected, consult your Yamaha deal- 6) Turn off the engine and wait 3 min- utes. Recheck the oil level using the dipstick to be sure the level falls between the upper and lower marks.

  • Page 91: Replacing Fuse

    001552 allow excessive current flow. This could cause electrical system damage and a fire hazard. NOTE: If the new fuse blows again immediately, consult a Yamaha dealer. 1 Fuse holder 2 Fuse (20A) 3 Spare fuse (20A) 4-20...

  • Page 92: Checking Wiring And Connectors

    EMK78011 CHECKING WIRING AND CONNECTORS 1) Check that each grounding wire is properly secured. 2) Check that each connector is engaged securely. EMK78110 606011* EXHAUST LEAKAGE Start the engine and check that no exhaust leaks from the joints between the exhaust cover, cylinder head and crank case.

  • Page 93: Checking Power Tilt System

    5) Operate the motor to tilt down. Check that the tilt rod operates smoothly. NOTE: If any operation is abnormal, consult a Yamaha dealer. Recommended fluid; Yamaha power trim & tilt fluid or ATF (DEXRON-II) 000604 4-22...

  • Page 94: Checking Propeller

    EML08013 CHECKING PROPELLER You could be seriously injured if the engine accidentally starts while you are near the propeller. 8 Before inspecting, removing installing the propeller, remove the 210014* spark plug caps from the spark plugs. Also, put the shift control in Neutral, put the main switch in the “OFF”...
  • Page 95 Otherwise, the propeller could come off during operation and be lost. 1) Apply Yamaha Marine grease or a corrosion resistant grease to the pro- peller-shaft. 2) Install the thrust washer and propeller on the propeller-shaft. 3) Install the washer and tighten the pro- peller nut to the specified torque.

  • Page 96: Changing Gear Oil

    Inspect the used oil after it has been drained. If the oil is milky, water is get- ting into the gear case which can cause gear damage. Consult a Yamaha dealer for repair of the lower unit seals. NOTE: For disposal of used oil consult your Yamaha dealer.

  • Page 97: Cleaning Fuel Tank

    Gasoline (petrol) is highly flammable, and its vapors are flammable and explosive. 8 If you have any question about properly doing this procedure, consult your Yamaha dealer. 8 Keep away from sparks, cigarettes, flames or other sources of ignition when cleaning the fuel tank.

  • Page 98: Inspecting And Replacing Anode(S)

    Yamaha outboard motors are protected from corrosion by sacrificial anodes. Inspect the external anodes periodically. Remove scales from the surfaces of the anodes. Consult a Yamaha dealer for 604011 replacement of external anodes. Do not paint anodes, as this would ren- der them ineffective.

  • Page 99: Checking Battery

    EMU04041 CHECKING BATTERY (for Electric start models) Battery electrolytic fluid is dangerous; it contains sulfuric acid and therefore is poi- sonous and highly caustic. Always follow these preventive mea- sures: 8 Avoid bodily contact with electrolytic fluid as it can cause severe burns or permanent eye injury.
  • Page 100 NOTE: Consult a Yamaha dealer when charging or re-charging batteries. EMU01279 Connecting the Battery Mount the battery holder securely in a dry, well-ventilated, vibration-free loca- tion in the boat.

  • Page 101: Checking Bolts And Nuts

    8 Make sure the main switch (on applica- ble models) is “OFF” before working on the battery. 8 Reversal of the battery leads will dam- age the rectifier. 8 Connect the RED lead first when installing the battery and disconnect the RED lead last when removing it.

  • Page 102: Cleaning Cooling-Water Passages

    EMU01172 CLEANING COOLING-WATER PASSAGES Flushing device equipped model Perform this procedure right after opera- tion for the most thorough flushing. 1) After shutting off the engine, unscrew the garden-hose connector 2 from the fitting 1 on the bottom cowling. 2) Screw the garden-hose connector 2 onto a garden hose 3 which is con- nected to a fresh-water supply.

  • Page 103: Motor Exterior

    Check the motor for scratches, nicks, or flaking paint. Areas with damaged paint are more likely to corrode. If necessary, clean and paint the areas. A touch-up paint is available from a Yamaha dealer. EML44010 COATING THE BOAT BOTTOM A clean hull improves boat performance.
  • Page 104 -MEMO-...

  • Page 105: Trouble Recovery

    EMN00010 Chapter 5 TROUBLE RECOVERY TROUBLESHOOTING ......5-1 TEMPORARY ACTION IN EMERGENCY ..........5-5 Impact damage ........5-5 Power tilt will not operate....5-5 Starter will not operate......5-6 Treatment of submerged motor..5-9...

  • Page 106: Troubleshooting

    A problem in the fuel, compression, or ignition systems can cause poor starting, loss of power, or other problems. The troubleshooting chart describes basic checks and possi- ble remedies. (This chart covers all Yamaha outboard motors. Therefore, some items may not apply to your model.) If your outboard motor requires repair, bring it to a Yamaha dealer.
  • Page 107 3. Fill tank with clean, fresh fuel. 4. Fuel filter clogged. 4. Clean or replace filter. 5. Failed ignition parts. 5. Have serviced by a Yamaha dealer. 6. Warning system activated. 6. Find and correct cause of warning. 7. Spark plug gap incorrect.
  • Page 108 5. Engine oil contaminated or 5. Replace oil with fresh, specified sounds or deteriorated. type. indicator lamp 6. Oil filter clogged. 6. Have serviced by a Yamaha lights. dealer. 7. Oil feed/injection pump 7. Have serviced by a Yamaha malfunctions. dealer.
  • Page 109 13. Check wires for wear or breaks. ignition wiring. Tighten all loose connections. Replace worn or broken wires. 14. Failed ignition parts. 14. Have serviced by a Yamaha dealer. 15. Specified engine oil not used. 15. Check and replace oil with specified type.

  • Page 110: Temporary Action In Emergency

    607011 3) Whether damage is found or not, return to the nearest harbor slowly and carefully. 4) Have a Yamaha dealer inspect the outboard motor before operating it again. EMU01321 POWER TILT WILL NOT OPERATE...

  • Page 111: Starter Will Not Operate

    EMN30111 STARTER WILL NOT OPERATE If the starter mechanism does not operate (engine cannot be cranked with the starter), the engine can be started with an emergency starter rope. 8 Use this procedure only in an emer- gency and only to return to port for repairs.
  • Page 112 EMN34810 Emergency Starting Engine 1) Remove the top cowling. 2) Remove the cable 1 by pulling out it from the starter if equipped. 208065* 3) Remove both ends of the choke rink rod 2. 204053** 4) Remove the starter/ flywheel cover after removing 3 bolts.
  • Page 113 7) Insert the knotted end of the emer- gency starter rope into the notch in the flywheel rotor and wind the rope several turns clockwise. 8) Pull the rope slowly until resistance is felt. 9) Give a strong pull straight out to crank and start the engine.

  • Page 114: Treatment Of Submerged Motor

    6) Take the outboard motor to a Yamaha dealer as soon as possible. Do not attempt to run the motor until it has been completely inspected.

  • Page 115: Index

    EMP00010 Chapter 6 INDEX INDEX............6-1...
  • Page 116 EMP10010 INDEX Emergency starting engine.....5-7 Emission control information....1-2 Engine oil ..........1-13 Adjusting trim angle......3-21 Engine stop button ........2-5 Air vent screw...........2-2 Engine stop lanyard switch .....2-5, 2-9 Exhaust leakage ........4-21 Basic boating rules ........1-7 Battery care..........4-8 Filling fuel ..........3-8 Filling fuel tank .........4-5 Battery requirement ......1-14 Breaking in (running in) engine....3-5 Flushing cooling system and fogging...

  • Page 117: Propeller Selection

    Mounting height ........3-3 Throttle control grip.........2-4 Mounting the outboard motor ....3-2 Throttle friction adjusting knob ....2-5 Throttle friction adjusting screw ..2-10 Neutral interlock trigger ......2-8 Throttle indicator........2-4 Neutral throttle lever .......2-8 Tiller handle..........2-4 Tilt lock mechanism.......2-12 Operations of controls and other Tilt support bar........2-12 functions ...........2-2 Tilt support knob........2-12...
  • Page 118 1. Be sure your new Yamaha is registered for warranty. Your boat dealer should do this at the time of sale. Make sure your dealer gives you a copy of the completed Yamaha regis- tration card for your records.
  • Page 119 5. Your warranty applies specifically to repairs made in the country of purchase. If your U.S.-purchased Yamaha needs warranty service while in Canada, or your Canadian pur- chased Yamaha needs service while in the United States, Yamaha will assist the local dealer whenever possible. However, some products available in one country may not be sold or serviced in the other.
  • Page 120 Yamaha Motor Corporation, U.S.A. hereby warrants that new Yamaha 1999-or-later model four-stroke outboard motors originally dis- tributed by Yamaha Motor Corporation, U.S.A. will be free from defects in material and workmanship for the period of time stated here- in, subject to certain stated limitations. Warranty coverage for outboards distributed by non-US Yamaha affiliated companies may be different.
  • Page 121 Charges for removal of the motor from a boat and transporting the motor to and from an authorized Yamaha Outboard Motor Dealer are excluded from warranty coverage.
  • Page 122 The federal government requires each manufacturer of a motor vehicle to maintain a complete, up-to-date list of all first purchasers against the possibility of a safety-related defect and recall. This list is complied from the purchase registrations sent to Yamaha Motor Corporation, U.S.A.
  • Page 123 Yamaha outside the U.S.A. or Canada, please contact an autho- rized Yamaha dealer in your country. Keep a copy of your sales contract or invoice for the purchase of your Yamaha and present it if you need warranty repairs. This document should show the date of purchase, which is important evidence the repairing dealer will need to be sure your Yamaha is covered by warranty.
  • Page 124 Printed in Japan April 2003-0.5 × 1 ! 66M-28199-17 (F15AMH, F15AEH, F15AEP, F15AEHP) Printed on recycled paper...
  • Page 125 (A l’usage du concessionnaire) MODÉLE ET NO. DE SÉRIE DU MOTEUR HORS-BORD (sur l’étiquette d’identification de la presse de fixation) YAMAHA DEALER NUMBER NO. DU CONCESSIONNAIRE YAMAHA DEALER NAME YAMAHA MOTOR CO., LTD. NOM DU MADE IN JAPAN CONCESSIONNAIRE PAYS D'ORIGINE JAPON USAGE...
  • Page 126 PLACE POSTAGE HERE ATTN: WARRANTY DEPARTMENT...

Table of Contents
