La Crosse Technology WS-9001U Instruction Manual

FCC ID: OMOTX38U (transmitter)
RF Exposure mobile:
The internal / external antennas used for this mobile transmitter must pro-
vide a separation distance of at least 20 cm (8 inches) from all persons and
must not be co-located or operating in conjunction with any other antenna
or transmitter."
Statement according to FCC part 15.19:
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, in-
cluding interference that may cause undesired operation.
Statement according to FCC part 15.21:
Modifications not expressly approved by this company could void the user's
authority to operate the equipment.
Statement according to FCC part 15.105:
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful inter-
ference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particu-
lar installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
TABLE OF CONTENTS
Topic Page
Inventory of Contents 3
Features 4
Setting Up 6
Battery Installation 7
Function keys 10
LCD Screen and Settings 11
Indoor Temperature Display and
Indoor MIN/MAX Records 11
Outdoor Temperature Display and
Outdoor MIN/MAX Records 13
Reset MIN/MAX records 14
915 MHz Reception 14
Mounting 15
Maintenance and care 19
Specification 20
Warranty Information 21
FAQ 25
GB
P.2
WS-9001U
915 MHz
Wireless Weather Station
Instruction Manual
OUT
MAX
in / out min / max
This product offers:
INSTANT TRANSMISSION
is the state-of-the-art new
w i r e l e s s t r a n s m i s s i o n
technology, exclusively de-
s i g n e d a n d d ev e l o p e d by L A C R O S S E
TECHNOLOGY. INSTANT TRANSMISSION offers
you can an immediate update (every 27.5 seconds!)
of all your outdoor data measured from the
transmitters: follow your climatic variations in real-
time!
INVENTORY OF CONTENTS
1. Temperature station.
2. Wireless Temperature Transmitter (TX38U-IT) and
mounting bracket.
3. Instruction Manual.
ADDITIONAL EQUIPMENT (not included)
1. 1 Philips screwdriver.
2. 2 Fresh "AAA" IEC LR3, 1.5V Alkaline Batteries.
3. 2 Fresh "AA" IEC LR6, 1.5V Alkaline Batteries.
GB
P.3
FEATURES
The Temperature Station
OUT
LCD Display
MAX
Function Keys
in / out min / max
Hanging hole
Battery
compartment
cover
Foldout Stand
GB
P.4
Contents
Language Page
English 2
French 38
Spanish 78
• Temperature display in degrees Fahrenheit (˚F)
• Indoor and Outdoor temperature display with MIN/
MAX recording
• All MIN/MAX recordings can be reset
• Low battery indicator
• Wireless transmission at 915 MHz
• Outdoor signal reception intervals at 27.5-second
• Table standing or wall mounting
The Outdoor Temperature Transmitter
• Remote transmission of outdoor temperature to
Temperature Station by 915 MHz
GB
P.5
