USER GUIDE 1. PRECAUTIONS 2. PRODUCT INFORMATIONS 3. POWER ON / OFF 4. PLAYER FUNCTION 5. TRANSCODING TOOL 6. TECHNICAL SPECIFICATIONS...
Page 3
Do not touch power supply adapter with wet hands. Otherwise, it may cause an electric shock Use standard power supply adapter. Otherwise, it may cause damage to this player by using a non-Standard power supply adapter Make sure power supply faucet connected to correct underground cable.
Page 4
Keep this player between 0°c and 40°c. Do not put player in dust or damp condition. Otherwise, it may damage the player. Do not expose player in sun shine directly. Otherwise, it may damage the player Do not put the player close to a credit card, etc… Otherwise, it may damage magnetic parts of credit card, etc …...
PRODUCT INFORMATIONS Product functions Compatible with audio format MP3/WMA/WAV format. Compatible with video format AVI/ASF format. Support function of picture browsing JPEG/BMP/GIF/PNG format. Support function of E-book E-book files in TXT format (in ANSI) Support function of FM radio Frequency ranging from 87.5 to 108 MHZ Support FLASH playing With Macromedia Flash Lite 2.1.
Connection External audio connection: with double jack line connection Stereo earphone connection: plugged needed for radio reception Connect with TV: with supplied audio/video cable, for TV input Computer connection thanks to USB cable Caution: Unexpected interruption may cause damage to this product! Charge Tips: During recharge, please don’t pull out plug, the product will be damaged.
PLAYER FUNCTION OPERATION INSTRUCTION Main menu interface 9 icons on main menu interface. On the bottom bar : volume, power, time (as picture) Tips: This product is compatible with Windows 98Se, Me, Windows 2000, Windows XP, Windows Vista, MAC OS 10 etc. Video Select “Video”...
Page 9
e. During video play, click the center of the screen to display the tool bar. Click “ ’ or “ ” to play backward or forward. Click “ ” to play again. Tips: Forward or Backward function is under condition of video playing. Audio Select “Audio”...
Page 10
During audio playing, click “ ” or “ ” to play Backward or Forward. Click “ ” to select the EQ mode. Click “ ” to switch to the cycle mode. Lyrics synchronous display To make lyrics and music display synchronously, make sure music and lyrics files are both copied in same MP3 folder with same file name, lyrics file name should be: *.LRC, otherwise lyrics can not be displayed synchronously when playing music files.
Page 11
Select Select “ ”, click “ ” and “ ” to change saved frequency; click “ ” and “ ” to switch previous or next saved channel; press “Esc” to exit station. Auto Search Select “Auto Seek” and click “ok”, FM will search automatically (87.5 MHz-108 MHz) and save each station searched to preset spot (former preset station will be covered), if 20 preset stations are saved, auto search function will stop, and automatically switch to effective radio;...
Page 12
E_books Select "E-book" to enter into E-book interface. The format of e-book is TXT file format (ANSI); 1. Select article and read. 2. Click " ", " " to move up and down. Click " ", " " to move to previous page and next page 3.
TP-Calibration Click TP-Calibration to adjust the touch screen. Repeat clicking the middle of yellow cross cursor. After the calibration is successful, it will automatically back to “Tool” Setup Select "Setup" in main interface to enter system settings. Language 6 available languages. Default You can select “Yes”...
Page 14
Steps: 1. Running PMP Transcoding application Tool. Functions of above picture 1. Select the conversion mode: Media mode for video / CD mode for music / Image mode for picture 2. Audio sample rate: choose between 8K / 16K / 45K 3.
General Malfunctions and solutions 1. Cannot Start up. Player may be out of battery. Connect it to AC adapter, recharge for around 10 mn and try again. 2. Shut down automatically after start up. a. Not enough power leads to auto-off. b.
Page 16
Format Sampling Rate 32KHz. 64K bps Audio Recording Output 3.5mm stereo/video joint Input 3.5mm stereo/video joint USB 2.0 Languages English, German, French, Italian, Spanish, Portuguese Systems Windows 98SE/ME/2000/XP/VISTA – MAC OS Other Features Calculator, Calendar - 14 -...
