MEMUP M40 User's Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Feel Design
User
& Installation Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the M40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MEMUP M40

Summary of Contents for MEMUP M40

  • Page 1 Feel Design User & Installation Guide...

  • Page 2: Table Of Contents

    USER & INSTALLATION GUIDE 1.Warning ......................1 2.Product Informations .................. 3 3.Power On / Power Off .................. 5 4.Player function operation instruction............6 5.Setup......................11 6.Transcoding tool..................11 7.Technical Specifications ................14...

  • Page 3: Warning

    Do not touch power supply adapter with wet hands. It may cause an electric shock Use standard power supply adapter. It may cause damage to this player by using a non- Standard power supply adapter Make sure power supply faucet connected to correct underground cable.
  • Page 4 Keep this player between 0°c and 40°c. Do not put player in dust or damp condition. It may damage the player. Do not expose player in sun shine directly. It may damage the player Do not put the player close to a credit card, etc… It may damage magnetic parts of credit card, etc …...

  • Page 5: Product Informations

    PRODUCT INFORMATIONS Product functions Compatible with audio format MP3/WMA/WAV format. Compatible with video format AVI/ASF format. Support function of picture browsing JPEG/BMP/GIF/PNG format. Support function of E-book E-book files in TXT format (in ANSI Unicode) Support function of FM radio Frequency ranging from 87.5 to 108 MHZ Support FLASH playing With Macromedia Flash Lite 2.1.
  • Page 6 Function display 1. Power 10. Power Indicator 2. Esc: Escape 11. CHG Indicator 3. Mic: Microphone 12. USB Port 4. Up: Previous 13. AV Out / Earphones Jack 5. Play: Play / Pause / Confirm 14. AV In 6. Down: Next 15.

  • Page 7: Power On / Power Off

    Connection External audio connection: with double jack line connection Stereo earphone connection: plugged needed for radio reception Connect with TV: with supplied audio/video cable, for input and output Computer connection thanks to USB cable Caution: Unexpected interruption may cause damage to this product! Charge Tips: During recharge, please don’t pull out plug, the product will be damaged.

  • Page 8: Player Function Operation Instruction

    PLAYER FUNCTION OPERATION INSTRUCTION Main menu interface 9 icons on main menu interface. On the bottom bar : volume, power, time (as picture) Tips: This product is compatible with Windows 98Se, Me, Windows 2000, Windows XP, Windows Vista, MAC OS 10 etc. Video Player Select “Video Player”...
  • Page 9 e. During video play, press “Menu”, then icons of video function will display: “Mode” Icon of video function will change from grey to light green. Press “Up” or “Down” to switch forward or backward. you can press “Up” or “Down” to change speed (x2x4x8x16), and press “Play”...
  • Page 10 During audio play, press “Menu”, icon “Mode” will change from grey to green. Press “Up” or “Down” to switch forward or backward. Press “Vol+” or “Vol-” to switch to EQ mode. During forward or backward, you can press “Up” or “Down” to change speed (x2x4x8x16), and press “Play”...
  • Page 11 Select Channel Choose “Select Channel”, press “Up” and “Down” to change saved frequency; press “Up” and “Down” to switch previous or next saved channel; press “Esc” to exit station. Auto Search Select “Auto Search”, FM will search automatically (87.5 MHz-108 MHz) and save each station searched to preset spot (former preset station will be covered), if 20 preset stations are saved, auto search function will stop, and automatically switch to effective radio;...
  • Page 12 E_books Select "E-book", press "Play" to enter The format of e-book is TXT file format (ANSI Unicode); 1. Select "E-book", press "Play" to enter. 2. Press "Vol +", "Vol -" to select files and press "Play" to read, and press "Up", "Down" to move to previous page and next page 3.

  • Page 13: Setup

    Setup Select "Setup" in main interface and press "Play" to enter system settings. Language 6 available languages. TV Out “LCD Output”, "NTSC Output", and "PAL Output". Default You can select “Yes” or "No" to recover, setup includes starting image. Data will not be changed. Sound Control speaker and sound.
  • Page 14 Steps: 1. Running SPCA5050 Transcoding application Tool. Functions of above picture: Add file： Select input file Clear list： Clear file list Browse： Select destination Option： Setup parameters Start： Start conversion Stop： Stop conversion Exit： Exit current mode of conversion Help： Click to look help information Progress bar: Display conversion progress 2.
  • Page 15 Quality： 50-100（better the quality is, larger output file size will be） Frame size: Frame size settings available are: 320x240, 352x288, 640x480, and 720x480 Encoder: Format： 48kbps, 16000Hz, stereo Caution： Output file will cover existing file which has same name in folder. 4.

  • Page 16: Technical Specifications

    TECHNICAL SPECIFICATIONS 108mm*72mm*16.6mm Dimension Weight 160g Screen 4" TFT -LCD/480*272 RGB Battery Built-In 1800mAH Lithium Battery Adaptor 100~240V 50/60Hz AC input; 5V/2A DC output Memory 512MB~8GB SD Card 32MB~4GB Format MP3,WMA,WAV Audio Bit Rate 32KB/S Sampling Rate 16 / 24 / 32 / 44.1 / 48KHZ Format ASF(MPEG-4), AVI(XVID) Frame...
