Page 1 2005 by Harbor Freight Tools © manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions or replacement parts, please call 1-800-444-3353. Model 37793 .
Page 2: Specifications
Do not use any adapter plugs. Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. If the SKU 37793 For technical questions, please call 1-800-444-3353.
Page 3: Personal Safety
Always wear eye protection. Dust mask, non-skid safety shoes, hard hat, or hearing protection must be used for appropriate conditions. SKU 37793 For technical questions, please call 1-800-444-3353. PeRSonAl SAFetY...
Page 4: Tool Use And Care
Contact with “live” wire will make exposed metal parts of the tool “live” and shock the operator. this Router has sharp, fast-moving parts. Misuse can cause severe injury. Follow the safety instructions.
Page 5 Always use sharpened bits. If the bit stops abruptly, or the bit becomes blocked, remove the Router from the workpiece and shut it off. never start the Router while the bit is in contact with workpiece. Allow the tool to reach its normal operating speed before applying the bit to the workpiece.
Page 6 Router. This tool will do the work better and safer at the speed and capacity for which it was designed. Always unplug the Router from its electrical outlet before performing any inspection, maintenance, or cleaning procedures.
Page 7: Grounded Tools: Tools With Three Prong Plugs
When using more than one extension cord to make up the total length, make sure each cord contains at least the minimum wire size required. (See table A.) SKU 37793 For technical questions, please call 1-800-444-3353. 3-Prong Plug and outlet...
Page 8 * Based on limiting the line voltage drop to five volts at 150% of the rated amperes. Double Insulated Canadian Standards Association Underwriters Laboratories, Inc. SKU 37793 For technical questions, please call 1-800-444-3353. eXtenSion coRd lengtH 50 Feet 75 Feet...
Page 9: Installing Bits
Assembly Section, and the Assembly Drawing and Parts List at the end of this manual. If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual as soon as possible.
Page 10 The depth of cut is equal to the distance between the end of the Screw (32) and the top of the Hex Bolt (65). Loosen Lock Lever (26) and lower router body until Screw (32) stopper pole makes contact with the Hex Bolt (65). The depth of cut can now be seen.
Page 11 Tighten wing nuts (C). When cutting, move the router with the Straight Guide flat against the side of the material to be chamfered or grooved. See figure. note: Standoffs can be mounted to the Straight Guide to widen its operation. This also prevents larger bits from striking the Straight Guide.
Page 12 The cut size may be slightly different from that of the templet. Allow for the distance (Z) between the router bit and the outside of the Templet Guide by subtracting the bit diameter size from the Templet Guide (outside diameter), then divide that by 2.
Page 13: Operation
Allow bit to come to full speed, slowly engage material. Do not attempt to cut more than 5/8 inch in a single pass. The router bit should always be fed into the stock from left to right so as to match the clockwise rotation of the router.
Page 14: Maintenance
WARning! Make sure the Power Switch of the Plunge Router is in its “oFF” position and that the tool is unplugged from its electrical outlet before performing any inspection, maintenance, or cleaning procedures. Before each use, inspect the general condition of the Plunge Router. Check for loose screws, misalignment or binding of moving parts, cracked or broken parts, damaged electrical wiring, and any other condition that may affect its safe operation.
Page 15: Parts List
Pan Head Screw M5x80 Brush Holder Cap Carbon Brush 203 note: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. SKU 37793 For technical questions, please call 1-800-444-3353. PARtS liSt Part w/washer...
Page 16: Assembly Drawing
ASSeMBlY dRAWing SKU 37793 For technical questions, please call 1-800-444-3353. Page 16...
Page 17: Accessories Parts List
AcceSSoRieS PARtS liSt Part SKU 37793 For technical questions, please call 1-800-444-3353. description Templet Guide; Dimensions: A = 37/64”, B = 5/8”, C = 33/64” Collet Sleeve Trimmer Guide Straight Guide Wrench Guide Holder AcceSSoRieS PARtS Page 17...
Page 18: Limited 1 Year / 90 Day Warranty
1 YeAR / 90 dAY WARRAntY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that for a period of ninety days from date of purchase that the engine/motor, the belts (if so equipped), and the blades (if so equipped) are free of defects in materials and workmanship.
