Instructions/Spare Parts Manual
Nilfisk Model GWD120
Nilfisk Model GWD220
Wet/Dry Tank Vacuum
CAUTION: This Nilfisk vacuum cleaner is not to be used in explosion-hazardous areas, as
serious injury could result.
Under no circumstances may this vacuum cleaner be used safely for the collection of hazardous or
toxic materials unless equipped with a HEPA filter. Be sure to install the HEPA filter according to
Nilfisk's written instructions.
Do not use this cleaner for the removal of hazardous substances unless you are licensed and/or
certified for this work by the all authorities having jurisdiction.
EMPTYING: If this vacuum cleaner is used to collect hazardous material, do not attempt to open
or empty its contents without personal protective clothing and respiratory protection. This
procedure must be completed in a contained environment. Contact with the cleaner, filters and all
other accessories used when picking-up hazardous materials must be handled according to federal
(EPA, OSHA), state and local regulations valid for the vacuumed substance.
ATTENTION EMPLOYER: Please ensure these instructions for use are made available and
understood by your employees or any other persons who may use this equipment.
To list all toxic and hazardous materials would be beyond the scope of these instructions. It is the
Employer's responsibility to identify, for Employee's and others' information, hazardous or toxic
materials which may be collected by this equipment. Such information must be communicated to
your Employees and other potential users of this equipment.
(single motor)
(dual motor)
Nilfisk-Advance America Inc.
300 Technology Drive
Malvern, PA 19355
Tel: 1.610.647.6420
Fax: 1.610.647.6427
www.pa.nilfisk-advance.com
e-mail:
