Panasonic MC-E4051 Operating Instructions Manual

Vacuum cleaner model no. mc-e4051/e4053
Hide thumbs
Table of Contents

Advertisement

Quick Links

VACUUM CLEANER

MC-E4051/E4053
MODEL NO.

Operating Instructions

We would advise that you carefully study these Operating Instructions before attempting
to operate the unit and that you note the Important Safety Instructions.
Please keep in a safe place with your Authorised Dealer Service booklet.
This product complies with the European directive 73/23/EEC and 89/336/EEC and with the Australian
Standards AS 3350.2.2 (1995) and Australian EMC requirements for the C-Tick Mark.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic MC-E4051

Summary of Contents for Panasonic MC-E4051

  • Page 1: Vacuum Cleaner

    VACUUM CLEANER MC-E4051/E4053 MODEL NO. Operating Instructions We would advise that you carefully study these Operating Instructions before attempting to operate the unit and that you note the Important Safety Instructions. Please keep in a safe place with your Authorised Dealer Service booklet.

  • Page 2: Table Of Contents

    If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.

  • Page 3: Important Safety Instructions For The User

    • Do not use to pick up flammable or combustible materials, or others that may become so or use in areas where they may be present. • This appliance should be serviced by an authorised Panasonic Service Centre, and only genuine Panasonic spare parts should be used.

  • Page 4: Identification Of Main Parts

    IDENTIFICATION OF MAIN PARTS Handle Upper cord hook On/Off switch Mains lead Hose Crevice nozzle Dust compartment release handle Dusting brush Dust compartment cover Handle release button Main filter Carrying handle Main filter screen Suction inlet Dust compartment Wands Exhaust filter Motor protector (inside) Foot pedal...

  • Page 5: B) Mains Lead Release

    B) MAINS LEAD C) ON/OFF SWITCH On-Off Switch Quick Release Cord Hook Wrap the mains lead around the upper Turn the upper cord hook to release the To start or stop the cleaner, push the and lower cord hooks and push the mains switch button to ‘I’...

  • Page 6: F) Motor Protector

    F) MOTOR PROTECTOR G) THERMAL CUT-OUT This cleaner has a thermal cut-out which automatically trips to protect the cleaner from overheating. If a clog prevents the Motor Protector normal flow of air to the motor, the thermal cut-out turns the motor off automatically to allow the motor to cool in order to prevent possible damage to the cleaner.

  • Page 7: Maintenance And Servicing

    MAINTENANCE AND SERVICING Always follow all safety precautions when cleaning and servicing the vacuum cleaner. WARNING: Electrical Shock And Personal Injury Hazard Disconnect from electrical supply before servicing or cleaning the unit. Failure to do so could result in electrical shock or personal injury from cleaner suddenly starting.

  • Page 8: C) Dust Bin Cleaning And Removal

    C) DUST BIN CLEANING Always empty the dust bin when dirt level reaches the “MAX FILL” line. CAUTION: Electrical Shock And Personal Injury Hazard Always disconnect the cleaner from mains outlet before carrying out any service or maintenance on the cleaner. Release Locked Lever...

  • Page 9: D) Dust Bin Filter Changing And Cleaning

    D) DUST BIN FILTER CHANGING AND CLEANING Check primary filter frequently and clean when dirty. Remove the dust bin assembly as outlined in the DUST BIN CLEANING section and empty contents of dust bin. Primary CAUTION: Make sure dust bin is empty before fil- Filter ter is removed.

  • Page 10: E) Cleaning Secondary Filter

    Check filter after emptying dust bin. To remove, pull out on both sides of the exhaust filter cover. Grasp the exhaust filter and pull out to remove. MC-E4051 (Electrostatic Filter) When replacing or reinstalling the electrostatic filter, make Electrostatic sure the gray side of the filter is facing the vacuum cleaner.

  • Page 11: G) Belt Changing Cleaning

    G) BELT CHANGING AND CLEANING WARNING: Electrical Shock And Personal Injury Hazard Disconnect from electrical supply before servicing or cleaning the unit. Failure to do so could result in electrical shock or personal injury from cleaner suddenly starting. Frequently check and remove hair, string and lint build-up in the brush area. If build-up becomes excessive, follow the steps below. Should the belt become loose or should it break, follow the Belt Removal Instructions.
  • Page 12 TO REPLACE BELT Seat left end of agitator into nozzle base. To seat agitator end, Motor place rounded portion of agitator end cap down into slot in Shaft nozzle base. Belt Loop the new belt on the motor shaft. Loop the other end of belt onto the belt pulley on the right end of agitator.

  • Page 13: H) Blockages

    H) BLOCKAGES The hose located on the vacuum cleaner carries the dirt from the nozzle up to the dust bin. If the hose should become clogged: Suction Inlet Unplug the cleaner from mains outlet. Hose Inlet Remove hose coupling and check hose coupling and hose inlet for clogs according to the following procedure.

  • Page 14: I) Troubleshooting Guide

    IMPORTANT: The thermal cut-out will not reset if the unit is not disconnected from the mains socket. MAINS LEAD IMPORTANT: If the mains lead becomes damaged, it must be repaired by Panasonic, authorised service centre or a qualified person in order to avoid any hazard.

  • Page 15: Specifications

    SPECIFICATIONS MODEL NO. MC-E4051 MC-E4053 POWER SOURCE 230-240V / 50Hz 230-240V / 50Hz MAX. INPUT POWER 1600w 1800w MOTOR PROTECTION DUST BIN CAPACITY 2.4 litres 2.4 litres EXHAUST FILTER ELECTROSTATIC HEPA DIMENSIONS (W x L x H) 360x375x1110 360x375x1110 NET WEIGHT 7.3 kg...

  • Page 16: Consumables / Accessories

    • Most major credit and debit cards accepted. • All enquiries transactions and distribution facilities are provid- ed directly by Panasonic UK Ltd. • It couldn’t be simpler! • Also available through our Internet is direct shopping for a wide range of finished products, take a browse on our website for further details.
  • Page 17 - 17 -...
  • Page 18 Matsushita Electric Industrial Co., Ltd http://www.panasonic.co.jp/global/ Part No. CØ1ZCNZØØEØØ Printed in P.R.C Service No. ACØ1ZCNZØEØØ...
