Contents Important Information Important Safety Precautions Important Notice Identification of Controls Setting Up Connections First Time Configuration / Basic Operations Memorizing the Channels Programme Edit Adjusting the Picture Adjusting the Sound Adjusting Basic Settings Setting Clock & Timer Setting Child and Rating Locks Making Use of Time Shift Function Teletext &...
IMPORTANT INFORMATION If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as: ! Using cabinets or stands recommended by the manufacturer of the television. ! Only using furniture that can safely support the television.
Important Safety Precautions Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product.
Important Safety Precautions (Continued) 15. Stand---Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. Do not place the product on an unstable trolley, stand, tripod or table. Placing the product on an unstable base SOURCE MENU can cause the product to fall, resulting in serious personal injuries as well as damage to the product.
Important Notice About Temperature Do not use in hot and cold rooms (locations) When the unit is used in rooms (locations) with low temperature, the picture may leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.
Identification of Controls 1. Remote sensor/Light sensor Main Unit (front/side view) Receives signals from the remote control. Do not block. The light sensor will measure the room brightness, do not put anything around the sensor. 2. Power indicator Lights blue when in operating mode. Lights red when in standby mode.
Identification of Controls (Continued) Remote control unit 1. POWER: Switches the TV power on or Standby. 2. S.MODE: Selects sound mode. 3. P .MODE: Selects picture mode. 4. FAV.LIST: Displays the favorite channel list. 5. FAV+/ FAV–: Selects the favorite channel. 6.
Setting Up You should select a location for the TV: Selecting a location Where direct light does not reflect on the screen. · That has indirect and soft lighting. · Where the TV has access to an antenna or cable TV connection. ·...
Connections Cautions Before Connecting When connecting an external device to the TV, make sure that the TV and the device are turned off. Check the plugs on the ends of cables to make sure that they are the correct type before you try plugging them into jacks on the TV.
Connections (Continued) Connecting Headphones To connect headphones: TV Side Insert the plug of the headphone into the TV’s Headphone jack. When using headphones, adjust the headphone volume so as to avoid excessive levels, as hearing damage may result. Headphones Connecting a USB device Insert your USB device into the USB port.
Connections (Continued) How to connect an HDMI device: Connecting an HDMI device Connect the HDMI cable between the HDMI jack on the TV and HDMI output jack on the device. Note: If your device has an HDMI connection, we recommend you use that to get the best quality possible.
Connections (Continued) Connecting a VCR To connect a VCR: Connect the Audio/Video cables between the Audio (L/R)/Video jacks on the TV and VCR. TV REAR To play the VCR: 1. Turn on your TV, then press SOURCE button. The Input Source menu opens. 2.
First Time Configuration/Basic Operations Turning on your TV for the first time The first time you use the TV, you need to configure your TV: To configure your TV: Energy Save Mode Make sure that you have inserted the batteries in the To use this TV for displaying in a store, please select [Store/Dynamic].
Basic Operations (Continued) Selecting the input source Input Source To select the input source: Press SOURCE button. The Input Source list appears. AV 1 AV 2 Press 6 or 5 to select the input source, then press OK or 4 to confirm your choice.
Basic Operations (Continued) Adjusting the volume To adjust the volume: Press the VOL+/ – to increase or decrease the volume. Press the MUTE button to temporarily turn off the sound. To restore the sound, press the MUTE button again. Press the INFO button to display the information banner. Displaying the Information Banner The information banner displays current status information such as the channel number and signal source.
Memorizing the Channels Note: If the Lock System is On, Auto Tuning/DTV manual tuning/ATV manual tuning can not be operated without password. For details, please see <Setting Child and Rating Locks> section. Auto Tuning Auto Tuning will completely re-tune the TV and can be used to update the channel list.
Memorizing the Channels & Programme Edit Use the Manual Tuning operation if desired channels can not be preset ATV manual tuning - analogue only - by Auto Tuning or if you would like to preset channels to specific position numbers one by one. In CHANNEL menu, press 6 to select ATV Manual Tuning, then press4...
Programme Edit (Continued) You can create a favourite channel list so you can quickly browse Setting up a favourite channel list through your favourite channels by pressing FAV.LIST, then selecting a channel from the favourite channel list. Navigate to the CHANNEL menu, press 5 to select PICTURE SOUND...
Programme Edit (Continued) You can skip unnecessary channels so that only the channels you want Skipping channels to watch can be selected by CH / CH . You can still tune to the skipped channel by using the number buttons. Navigate to the CHANNEL menu, press 5 to select PICTURE...
Adjusting the Picture To adjust the picture: Adjusting the picture Press MENU. The on-screen menu opens with the PICTURE menu displayed, then press 6 to access. Press 6 to highlight an option, press 3 to adjust the option; If a sub-menu exits, press 4 or OK to access.
Adjusting the Sound To adjust the sound: Adjusting the sound Press MENU. The on-screen menu opens. Press 3 or 4 to select SOUND menu, press 6 to access. PICTURE SOUND TIME OPTION LOCK CHANNEL Press 6 or 5 to highlight an option, press 3 or 4 to adjust the Sound Mode...
Adjusting Basic Settings Adjusting basic settings To adjust basic settings: Press MENU. The on-screen menu opens. PICTURE SOUND TIME OPTION LOCK CHANNEL Press 3 to display OPTION menu, press 6 to access. OSD Language English Hearing Impaired S/PDIF Output AUTO Press 6 or 5 to select an option, press 3...
Setting Clock & Timer To set TV clock Setting TV clock – For DTV programs, the clock displays the current time using time data received from your TV service provider. This information is based on a digital channel and does not need to be set manually, but you need to select your time zone PICTURE SOUND...
Setting Clock & Timer (continued) To set Sleep timer Setting Sleep timer Sleep timer lets you select the amount of time before your TV turns itself off automatically. This setting is cleared when the TV is turned off. PICTURE SOUND TIME OPTION LOCK...
Setting Child and Rating Locks You can prevent your children from watching TV by locking the TV and using age ratings. To enable child lock and rating feature, you must set Lock System to On through LOCK menu. Also you can set Lock System to On to lock auto tuning/manual tuning to protect some TV settings from being accidentally changed.
Setting Child and Rating Locks (continued) Setting parental ratings To set and enable parental ratings - digital only - Some digital broadcasters rate their programmes according to age. You can set your TV to display only programmes with age ratings higher than your child’s age. Before setting PICTURE SOUND TIME...
Making Use of Time Shift Function Checking File System before Time Shift Time Shift function is the recording of DTV programme to an external memory device (portable hard disk or USB device) to be viewed at a later time more convenient to the user. But before operation you must pay attention to the following notes: Before Time Shift, you need to check the File System successfully.
Teletext & Subtitle What Is Teletext? Your System receives Teletext signals broadcast by a TV network, and decodes them into graphical format for viewing. News, weather and sports information, stock exchange prices and programme previews are among the many services available. To Turn On/Off Teletext Select a TV channel providing the Teletext program.
Adjusting the Computer Image & Setting Hotel Mode Before adjusting the screen, make sure that you select the Adjusting the PC image correct source (D-SUB). To adjust the computer image: PICTURE SOUND TIME OPTION LOCK CHANNEL Press MENU. The on-screen menu opens with PICTURE Adaptive Contrast menu displayed.
Using MUSIC Player & Using USB Multi Media Player Using MUSIC player You can connect your MP3 player to MUSIC jack on the TV side to listen to music from your TV. Be sure to switch to MUSIC source firstly by pressing SOURCE button. During music playing and you want to save power, please go to OPTION menu and set Audio Only to Power Saving, then a message “Audio Only, it will go to power saving mode”...
Using USB Multi Media Player (continued) Playing music Generally, audio player supports MP3, WMA and USB 2.0 AAC formats, but for the sake of technical updating, some formats above may not be supported. PHOTO MUSIC MOVIE TEXT MUSIC To listen to music: Page 1 / 1 Connect USB device and switch to USB mode, MSTPVR...
Using USB Multi Media Player (continued) During movie play, you can press: Playing movie (continued) : Play /pause. USB 2.0 : Stop playing. : Fast forward. : Fast reverse. PHOTO MUSIC MOVIE TEXT Subtitle: Shows subtitle if available. Page 1 / 1 MOVIE STEREO: Selects audio track if available.
Troubleshooting If, after reading these operating instructions, you have additional questions related to the use of your television, please call the services center in your local area. Before calling service, please check the symptoms and follow suggested solutions. Remote Control Problem Possible Solutions The batteries could be weak.
Appendix: Installing the Stand If the stand is provided, please read these instructions thoroughly before attempting this installation. You must install your TV into the stand in order for it to stand upright on a cabinet or other flat surface. If you intend to mount your TV on a wall or other vertical surface, you must remove the stand column.
