15 Lens barrel
16 [HDMI] socket (P151,
17 [AV OUT/DIGITAL] socket (P149, 156,
159, 162)
18 Tripod receptacle
•
When you use a tripod, make sure the
tripod is stable when the camera is
attached to it.
19 Card/Battery door
20 Release lever (P16)
21 DC coupler cover
•
When using an AC adaptor, ensure that
the Panasonic DC coupler (optional) and
AC adaptor (optional) are used. For
connection details, refer to P17.
Before Use
153)
(P16)
(P17)
18
- 8 -
15
16
17
19
21 20
