Turbo Air Speed up the Pace of Innovation
Glass Door
Refrigerator & Freezer
Installation and Operation Manual
Please read this manual completely before attempting to install or operate this equipment!
REFRIGERATOR
TGM-5SD
TGM-7SD
TGM-10SD
TGM-12SD
TGM-15SD
TGM-20SD
TGM-23SD
TGM-35SD
TGM-47SD
TGM-72SD
FREEZER
TGF-5SD
TGF-10SD
TGF-15SD
TGF-23SD
TGF-35SD
TGF-47SD
TGF-72SD
www.turboairinc.com
CAUTION!
PLEASE KEEP POWER
SWITCH ON BEFORE
OPERATING THIS EQUIPMENT
Advertisement
Related Manuals for Turbo Air TGM-5SD
Summary of Contents for Turbo Air TGM-5SD
- Page 1 CAUTION! PLEASE KEEP POWER SWITCH ON BEFORE OPERATING THIS EQUIPMENT Turbo Air Speed up the Pace of Innovation Glass Door Refrigerator & Freezer Installation and Operation Manual Please read this manual completely before attempting to install or operate this equipment!
-
Page 2: Table Of Contents
The serial number can be found on the data label located inside the unit. Please retain the unit serial number for service purposes. ENERGY STAR As an Energy Star Partner, the following products meet the Energy Star guidelines for energy efficiency. TGM-5SD / TGM-7SD / TGM-10SD / TGM-12SD / TGM-20SD / TGM-23SD... -
Page 3: Installation
INSTALLATION 1. GOOD AIR CIRCULATION - Please make sure to avoid any partition or objects that may stop the air flow. - Please make sure there is enough space for air circulation to the rear of the unit. Recommended space between the rear of the unit to the wall is at least 5 inches. 2. -
Page 4: Cleaning
CLEANING 1. CLEANING STAINLESS STEEL INTERIOR AND EXTERIOR : Damage to stainless steel finish due to improper use of cleaning products or non- recommended products is NOT covered under this product's warranty. • Do - Use warm, soapy water and a soft, clean cloth or sponge. - Rinse surfaces with clean, warm water and dry immediately to avoid water spots. -
Page 5: Basic Operation
BASIC OPERATION 1. Plug in to turn on the power and lamp switch located to the right side of the bottom grille. The display panel will light up and make a beeping noise.The compressor will begin to run. 2. The default temperature setting is at “37˚F” for the Refrigerators. The default temperature setting is at “-8˚F”... - Page 6 DISPLAY PANEL OF FREEZERS TEMP CONTROL BUTTON LAMP SWITCH 1 LAMP SWITCH 2 INTERIOR TEMP INDICATOR POWER SWITCH TURBO FREEZE BUTTON TURBO FREEZE DOOR OPENING FAN RUNNING...
- Page 7 DISPLAY PANEL OF REFRIGERATORS TEMP CONTROL BUTTON LAMP SWITCH 1 LAMP SWITCH 2 INTERIOR TEMP INDICATOR POWER SWITCH TURBO FREEZE BUTTON TURBO FREEZE DOOR OPENING FAN RUNNING...
- Page 8 TURBO FREEZE 1. If you push the T.F. (Turbo Freeze) button, the compressor will run for 120 minutes to bring down the temperature more rapidly. 2. If you push the T.F. button again during Turbo Freeze mode, the compressor will return to the normal operation.
- Page 9 INNER TEMPERATURE DISPLAY 1. It displays inside temperature. 2. Display range is -40˚F to 99˚F (-40˚C ~ +40˚C). 3. When inside temperature is lower than -40˚F, the panel will display ʻ ʼ. when inside temperature is higher than +99˚F, the panel will show ʻ ʼ.
-
Page 10: Before Requesting Service
BEFORE REQUESTING SERVICE SYMPTOMS CAUSES SOLUTIONS The unit is freezing or • The temperature is set too high • Push the temperature button to or low to contain food fresh. the suitable position. melting food. The unit does not • There is a power connection •... -
Page 11: Warranty
THREE YEAR WARRANTY Turbo air warrants to the original purchaser of every new Turbo air refrigerated unit, the cabinet and all parts thereof, to be free from defects in material or workmanship, under normal use and service, for a period of three (3) year from the date of original installation or 39 months after shipment date from Turbo air , whichever occurs first. - Page 12 3. ALTERATION, NEGLECT, ABUSE, MISUSE, ACCIDENT, DAMAGE DURING TRANSIT OR INSTALLATION, FIRE, FLOOD, ACTS OF GOD. TURBO AIR is not responsible for the repair or replacement of any parts that Turbo Air determines have been subjected after the date of manufacture to alteration, neglect, abuse, misuse, accident, damage during transit or installation, fire, flood, or an Act of God.
-
Page 13: Warranty
(3) year from the date of original installation or 39 months after shipment date from Turbo Air, whichever occurs first. Any part, covered under this warranty, that are by Turbo Air to have been defective within three (3) year of original installation or thirty-nine (39) months after shipment date from manufacturer, whichever occurs first, is limited to the repair or replacement, including labor charges, of defective parts or assemblies.
