- Page 1 Turbo Air Speeds Up the Pace of Innovation CAUTION! Refrigerator PLEASE KEEP POWER SWITCH ON BEFORE OPERATING THIS EQUIPMENT Freezer Installation and Operation Manual Please read this manual completely before attempting to install or operate this equipment! <Solid Door> Dual Temperature...
-
Page 2: Table Of Contents
7. BEFORE REQUESTING SERVICE ..............8 8. WARRANTY....................9~11 SPECIFICATION EXTERIOR (WxDxH, Inch) 25.6x31.5x76.2 CUBIC FEET NET WEIGHT (lb) VOLTAGE (V / Hz) 110~120 / 60 AMPS (A) COMPRESSOR (HP) 1 / 3 REFRIGERANT R134a The specification can be changed without any prior notice. Turbo Air... -
Page 3: Serial Number
The serial number can be found on the data label located inside the unit. Please retain this serial number for service purposes. FEATURE CHART CONDENSER CONDENSER MOTOR COMPRESSOR TOP GRILLE EVAPORATOR AIR DUCT MOTOR DISPLAY PCB F-SENSOR COOLING MOTOR AIR DUCT AIR DUCT FROZEN (RETURN) (DISCHARGE) ROOM REFRIGERATED ROOM R-SENSOR Turbo Air... -
Page 4: Installation
- Please make sure that the unit levels from the front to the back and side to side. 7. Unit should be on dedicated outlet. 8. Place black plastic condensate pan through back or front. Please make sure pads are installed upwards, a drain hose is in pan. Turbo Air... -
Page 5: Cleaning
- Turn ‘off’ the power switch before disconnecting the power cord, whenever performing maintenance functions or cleaning the refrigerated cabinet. - Compressor warranties are void if compressor burns out due to low voltage. 2. RE-STARTING - If disconnected, wait for 5 minutes before re-starting. Turbo Air... -
Page 6: Basic Operation
Be careful when stationing the product so that it does not press against the back wall, and is at least 4 inches away from the evaporator compartment. 7. Evaporator fan motor(s) will run after all doors are completely closed. 1 TEMP.CONTROL BUTTON 3 QUICK FREEZE BUTTON 2 QUICK COOLING BUTTON 4 INNER TEMPERATURE Turbo Air... - Page 7 2. Once all frost is eliminated, the temperature continues to rise until it reaches 50°F (10°C). When this temperature is sensed by the defrost limit control, the defrost control changes to refrigeration mode. 3. The panel displays “ ” during the defrost cycle. Turbo Air...
-
Page 8: Before Requesting Service
• The door gasket has come out. The following are not malfunctions: • A water-flowing sound can be heard when the compressor stops. This is the sound of REFRIGERANT flowing. • The compressor does not run against defrosting function. Turbo Air... -
Page 9: Warranty
ONE YEAR WARRANTY Turbo Air warrants to the original purchaser of every new Turbo Air refrigerated unit, the cabinet and all parts thereof, to be free from defects in material or workmanship, under normal use and service, for a period of one (1) year from the date of original installation or 15 months after shipment date from Turbo Air , whichever occurs first. - Page 10 3. ALTERATION, NEGLECT, ABUSE, MISUSE, ACCIDENT, DAMAGE DURING TRANSIT OR INSTALLATION, FIRE, FLOOD, ACTS OF GOD. Trubo Air is not responsible for the repair or replacement of any parts that Turbo Air determines have been subjected after the date of manufacture to alteration, neglect, abuse, misuse, accident, damage during transit or installation, fire, flood, or an Act of God.
- Page 11 (1) year from the date of original installation or 15 months after shipment date from Turbo Air, whichever occurs first. Any part, covered under this warranty, that are by Turbo Air to have been defective within one (1) year of original installation or fifteen (15) months after shipment date from manufacturer, whichever occurs first, is limited to the repair or replacement, including labor charges, of defective parts or assemblies.
