POLTI VAPORETTO LECOASPIRA FRIENDLY Usage Instructions

Steam cleaners
Hide thumbs Also See for VAPORETTO LECOASPIRA FRIENDLY:
Table of Contents

Advertisement

Quick Links

FRIENDL Y

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAPORETTO LECOASPIRA FRIENDLY and is the answer not in the manual?

Questions and answers

Related Manuals for POLTI VAPORETTO LECOASPIRA FRIENDLY

Summary of Contents for POLTI VAPORETTO LECOASPIRA FRIENDLY

  • Page 1 FRIENDL Y...
  • Page 2 Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 6a Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 12 Fig. 11a Fig. 11b Fig. 11c Fig. A Fig. C Fig. B Fig. D...
  • Page 3 OPTIONAL Z1 Z2 Z4...

  • Page 4: Optional Accessories

    LECOASPIRA FRIENDLY O1)Guard A) Suction switch O2) Cloths B) Boiler switch 7) Spare seals C) “No water” indicator lamp 8) Funnel D) Pressure indicator light 9) Tank cleaning brush Carrying handle 10) Bioecological J) Safety cap K) Steam control knob L ) Monobloc socket door M) Monobloc socket N) Air outlet grill...
  • Page 5 The heart of the filtration system is represented by the exclusive “Eco-Active” water filter, patented by Polti. The “Eco-Active” water filter uses the natural purifying force of water to trap dirt, preventing dispersion of dust into the environment. In addition, the HEPA filter collects impurities including pollen as well as dust mites.

  • Page 6: Safety Warnings

    - In case of breakdown or malfunction switch off the appliance and never attempt to disassemble it, but refer to an authorized Polti Service Centre. - This appliance is equipped with safety devices which are to be replaced only by a suitably qualified te- chnician.
  • Page 7 This allows avoiding scale formation and protec- ting the metal walls of the boiler. KALSTOP FP 2003 can be found in small appliance stores and Polti service centres. Alternatively, use a 50/50 mixture of tap water and demineralised water.

  • Page 8: Correct Use Of The Product

    Polti S.p.A. declines all liability for any damage or accident deriving from any use of this appliance which is not in conformity with the instructions contained in this booklet.

  • Page 9: Preparing For Use

    Do not use only demineralized water but mix it as described above with tap water. We recommend you use original Polti products only, as products of other brands may not be suitable for use in Polti products and could cause unwelcome difficulties. Never use distilled water or scented water.

  • Page 10: Operation

    If you decide you no longer wish to use the steam, release the steam button (1C). Vaporetto Lecoaspira Friendly enables the flow of steam to be optimised by turning the adjustment knob (K) (Fig. 7).
  • Page 11 (Fig. 9). 7.3) CONNECTING THE ACCESSORIES All the Vaporetto Lecoaspira Friendly accessories can be connected directly to the handle (1B) or to the extension tubes (2) or (3), previously assembled (see preceding paragraph). To connect the specific accessories for the suction and steaming features (2-3-4-5-6): proceed as follows: - Couple the desired accessory to the handle, until the blocking button (1E) hooks on (Fig.
  • Page 12 LECOASPIRA FRIENDLY - Check the strength of the connection. - To release it, just hold the button down (1D) and separate the components (fig. B). To connect the brushes (E3) to the accessory 120° (5) just screw them on to it. The different co- lours allow you to always use the same brush on the same surface.
  • Page 13 LECOASPIRA FRIENDLY A - ORDINARY CLEANING A1) HARD FLOORS (MARBLE, GRANITE, TILE) ACCESSORIES TO BE USED: extension tubes (2)(3), universal brush (4) with inserts, as per the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER Extension tubes + universal brush + 2 + 3 +4 + 4A Vacuuming dust bristle insert...
  • Page 14 LECOASPIRA FRIENDLY A2) CARPETING/RUGS N.B. Before treating delicate fabrics with steam, consult the manufacturer’s instructions and al- ways carry out a test on a hidden part or on a sample of the material. Allow the steamed part to dry to make sure that no changes in colour or deformations have occurred. ACCESSORIES TO BE USED: extension tubes (2)(3), universal brush (4) with inserts, as per the following table: REFERENCE...
  • Page 15 LECOASPIRA FRIENDLY A3) TILE WALLS ACCESSORIES TO BE USED: steam + suction nozzle (6) with insert as per the following table: REFERENCE LET- ACCESSORIES PHOTOGRAPH FUNCTION Steam + suction nozzle Steam delivery and and window cleaning fit- 6 + 6A vacuum ting 200 mm STEAM-VACUUM FUNCTION...
  • Page 16 LECOASPIRA FRIENDLY A4) PARQUET AND TERRACOTTA N.B. Please pay careful attention when cleaning wooden surfaces and treated terracotta flooring with steam as prolonged use of steam may damage the wax, polish or colour of the surfaces to be cleaned. We therefore recommend dispensing steam on these surfaces only for short periods of time and suggest always using a cloth, avoiding direct steam being dispensed onto the surface.
  • Page 17 LECOASPIRA FRIENDLY PARQUET AND TERRACOTTA VACUUM FUNCTION To vacuum up dirt and dust on parquet/terracotta Press the suction switch (A) to begin vacuuming. Regulate the suction regulator (1D) to vacuum up dust or liquid (see paragraph entitled Vacuum only function).To stop suction, simple press the switch (A).
  • Page 18 LECOASPIRA FRIENDLY A4) SANITARI/RUBINETTERIE/PIANO COTTURA ACCESSORI DA USARE: accessorio 120° (5) with insert, steam + suction nozzle (6) with insert as per the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER 120º accessory + colou- Steam flow (to remove 5+E3 red brush stubborn dirt) Steam suction nozzle + 6 + 6B + O1...
  • Page 19 LECOASPIRA FRIENDLY B - EXTRAORDINARY CLEANING B1) GLASS/MIRRORS/SHOWER CUBICLE ACCESSORIES TO BE USED: steam + suction nozzle (6) with insert as per the following table: REFERENCE LET- ACCESSORIES PHOTOGRAPH FUNCTION Steam + suction nozzle Steam delivery and and window cleaning fit- 6 + 6A vacuum ting 200 mm...
  • Page 20 LECOASPIRA FRIENDLY B2) UPHOLSTERY/WALL COVERINGS/CAR INTERIORS/MATTRESSES N.B. Before treating leather or delicate fabrics with steam, consult the manufacturer’s instructions and always carry out a test on a hidden part or on a sample of the material. Allow the steamed part to dry to make sure that no changes in colour or deformations have occurred.
  • Page 21 LECOASPIRA FRIENDLY B3) REMOVING STAINS FROM CARPETS/UPHOLSTERY ACCESSORIES TO BE USED: accessory 120° (5) as per the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER 120º accessory + cloth 5 + O2 Steam delivery STEAM-VACUUM FUNCTION To eliminate a specific mark After having turned the boiler on, following the instructions given in the paragraph entitled "Operation", set steam pressure according to the surface to be treated is (see paragraph enti- tled Steam flow regulation).
  • Page 22 LECOASPIRA FRIENDLY B4) LIMESCALE/SPACE BETWEEN TILES ACCESSORIES TO BE USED: accessory 120° (5) with accessory as per the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER Steam flow (to remove 120º accessory + brush 5+E3 stubborn dirt) STEAM - VACUUM FUNCTION To remove deposited scale, remove dirt in tile grouting After having turned the boiler on, following the instructions given in the paragraph entitled "Operation", set steam pressure according to how dirty the surface to be treated is (see para-...
  • Page 23 LECOASPIRA FRIENDLY B5) DOUBLE CURTAINS ACCESSORIES TO BE USED: steam + suction nozzle (6) with insert as per the following table: REFERENCE ACCESSORIES PHOTOGRAPH FUNCTION LETTER Steam nozzle+ bri- 6+6B+O1 Steam delivery stle insert+ guard N.B. After having assembled the bristle insert, the steam + suction nozzle must be covered with the guard supplied (O1).

  • Page 24: Steam Function

    Do not swallow. Keep out of the reach of children. CONTAINS: Eugenol, Citral, Cinnamal* Contents: 100 ml Bioecologico is available in pine or citrus scents. Bioecologico is available to purchase from your local Polti retailer. *May cause allergic reaction (in direct contact with the skin).

  • Page 25: Steam Ironing

    C - OPTIONAL ACCESSORIES Z) PROFESSIONAL IRON Vaporetto Lecoaspira Friendly can quickly become an extremely efficient ironing system, allowing you to iron more quickly and with less effort. Simply connect the iron accessory to the product for Vaporetto Lecoaspira (Mod. PFEU0021). The iron can be purchased from Polti service centres and the best electrical appliance stores.
  • Page 26 When surfaces and fabrics are sanitised using the Steam Disinfector, the risk of contagion deriving from surface contamination is drastically reduced. The Steam Disinfector is a Polti exclusive and is only available from the best electrical appliance stores.

  • Page 27: Cable Storage

    Empty the container again and put Vaporetto Lecoaspira Friendly away. 2) CABLE STORAGE Before putting Vaporetto Lecoaspira Friendly away, store the power cable (P) in the specific space (R) proceeding as described below: Remove the water container (W) as described in the chapter “preparing for use”.

  • Page 28: General Maintenance

    LECOASPIRA FRIENDLY ATTENTION: • Do not clean the filter with the brush as it can be damaged, thereby reducing its filtering capacity. • Do not use detergents, do not rub the filter, and do not wash it in a dishwasher. GENERAL MAINTENANCE Before any kind of maintenance, make sure that the power cable is not plugged in to the mains.

  • Page 29: Troubleshooting

    LECOASPIRA FRIENDLY TROUBLESHOOTING PROBLEM CAUSE SOLUTION The vacuum does not start No power Check the cable, plug and socket Suction power is decreased Nozzle, suction hose or suc- Clean the filter and remove any bloc- tion tube are blocked. kages of tubes and accessories. HEPA filter is blocked or dirty Proceed as described in the para- graph entitled "WASHABLE HEPA...
