POLTI VAPORETTO LECOASPIRA INTELLIGENT Usage Instructions

Steam cleaners
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the VAPORETTO LECOASPIRA INTELLIGENT and is the answer not in the manual?

Questions and answers

Related Manuals for POLTI VAPORETTO LECOASPIRA INTELLIGENT

Summary of Contents for POLTI VAPORETTO LECOASPIRA INTELLIGENT

  • Page 2 20-A...
  • Page 3 W1 W2 W4 Vaporetto Lecoaspira Intelligent - M0S09198 Edizione 2Q03...
  • Page 4 Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 6a Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 11a Fig. 11b Fig. 12 Fig. 14 Fig. 13 Fig. A Fig. B Fig. C Fig. D...

  • Page 5: Optional Accessories

    LECOASPIRA INTELLIGENT E2) Bristle fitting 1) Main switch E3) Liquid suction inserts 2) “OK” button E4) Insert for fitted carpet 3) “SET” button E5) Cotton cloths 4) Steam/programme “UP” button E6) Terry cloth cover 5) Steam/programme “DOWN” button E7) Parquet cloth with velcro 6) Carrying handle K) 120°...
  • Page 6 Read these instructions carefully before using the appliance. Dear customer, Thank you for choosing Polti. In choosing Vaporetto Lecoaspira, you have shown that you care about keeping your home clean and your family healthy, because Vaporetto Lecoaspira allows you to clean all washable surfaces in your home with the power of steam, dissolving and detaching dirt and suctioning up dust, dust mites and allergens in water.
  • Page 7 • If it is necessary to replace the power supply • Do not suck up burning or incandescent ob- cable, please refer to the nearest Polti autho- jects such as embers, ash or other material rised service centre, since the use of a spe- in which combustion is taking place.
  • Page 8 KALSTOP is available from Polti dealers or by mail-order from your Polti Polti declines liability for any damage or ac- Service Centre. cident derived from any use of Vaporetto •...
  • Page 9 • Lift the dirt container handle (22) unhooking • P8: PLANTS it from its position (Fig. 2) and remove the • P9: IRON (only if Polti iron is connected) container (20) (Fig. 3). • P0: TURBO VACUUM • Turn the dirt container handle (22) as shown in figure 4, and remove the “Eco ActiveFilter”...
  • Page 10 LECOASPIRA INTELLIGENT Using suction controls Simply press the suction button (A4) to start • Press the main switch (1): the appliance will vacuuming. come on in manual or “MA” mode. Hold down the suction button (A4) to select In this mode you can manually adjust the the appropriate speed for the surface to be amount of steam to be dispensed and the suc- cleaned.
  • Page 11 LECOASPIRA INTELLIGENT recommend always using the parquet which steam is dispensed. In any case you function with the universal brush (E), to- can stop the programme manually by pres- gether with the liquid suction insert (E3) sing the suction button (A4). or with the insert for fitted carpet (E4), •...
  • Page 12 NOTE: steam quantity is preset and cannot be manually adjusted. Suctioning is disabled and Steam ironing allowed--set the dial to its cannot be used. MAXIMUM travel at the end of the 3 dots symbol on your Polti iron • To protect users, European...

  • Page 13: Ironing Without Steam

    LECOASPIRA INTELLIGENT iron has reached the desired temperature. ning at maximum power; press the suction • Press the Steam request button (W2) to let button (A4) again to stop suctioning. steam out. This programme also effectively removes The steam flow will stop when you release animal fur from floors, carpets and rugs or the button.
  • Page 14 (8C) and suction indicator (8E) will flash. Bioecologico is available to purchase from your local Polti retailer. Turn off the appliance and do not turn it on again until you have replaced the water in the *May cause allergic reaction (in direct contact tank, as described in the section on “Emptying...
  • Page 15 (such as synthetic materials, place it; you may purchase a replacement from lacquered surfaces, etc.). an authorised Polti Service Centre). When cleaning glass surfaces in particularly If you wish to continue working, refill the contai- cold weather, preheat glass with steam from a ner with water.
  • Page 16 LECOASPIRA INTELLIGENT the following tools: low, preheat glass surfaces by spraying steam • coloured 120° brush (L), recommended to from about 50 cm away. remove dirt deposited on very narrow surfa- ces such as hobs, blinds, gaps between tiles, bathroom fixtures, etc.. To connect accessories for suction only (F-M- Different colours allow you to use the same Q-R-T-X-Y-Z), simply connect them without...
  • Page 17 LECOASPIRA INTELLIGENT and light sources. Wait 24 hours before put- ting the filter back into the appliance. JOKER BRUSH (F) • Replace the filter if it is torn. The Joker brush may be used to suction up all • Clean the filter every 4 months. types of solid and liquid dirt and is appropriate •...
  • Page 18 LECOASPIRA INTELLIGENT TROUBLE CAUSE SOLUTION The suction fan does not start No power supply Check the cable, plug and socket The boiler filling pump can be Air in the boiler circuit. Switch off the appliance, allow it heard working continuously to cool and repeat the opera- tions described in the “OPERA- TION”...
