Real Time DVR
SHR-2040/2041/2042 User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Samsung SHR-2040P

Summary of Contents for Samsung SHR-2040P

  • Page 1 Real Time DVR SHR-2040/2041/2042 User’s Manual...

  • Page 2: Safety Regulations

    SHR-2040/2041/2042 USER’S MANUAL Safety Regulations Please be sure to keep the following in mind for the right use of the product to pre-vent proprietary risk or damage. Do not use multiple plugs at once. This may cause abnormal heat generation or fire Do not put a vase, flowerpot, cup, cosmetics, medicine, or vessel with water around you.

  • Page 3: Before We Start

    Before we start This User’s Manual describes the basic usage of SHR-2040/2041/2042. This Manual contains all the matters necessary for using SHR-2040/2041/2042 such as brief instruction, part name, function, connecting other equipment, and menu setup of SHR-2040/2041/2042. SEC retains the copyright on this User’s Manual. This User’s Manual cannot be copied without SEC’s prior written approval.

  • Page 4: Table Of Contents

    Contents Safety Regulations Before we start Standards Approvals Chapter 1 Overview 1. Introduction 2. Features 3. Part Names and Functions Chapter 2 Installation 1. Installation Environment Setup 2. Checking Product & Accessory 3. HDD Addition Chapter 3 Connecting with Other device 1.
  • Page 5 Chapter 5 Menu Setup Before Use 1. System 5-12 2. Camera 5-16 3. Monitoring 5-18 4. Recording Mode 5-20 5. Event Record Mode 5-25 6. Record Schedule 5-27 7. Backup 5-28 8. Network 5-32 9. Network Setup Chapter 6 PTZ Camera Control 1.
  • Page 6 Chapter 9 Smart Viewer 1. Introduction 2. Feature 3. PC Specification(Recommendation) 4. Smart Viewer Installation 5. Smart Viewer Program Execution 6. Smart Viewer Initial Screen 7. Monitoring Mode 9-23 8. Search Mode 9-30 9. Setup Mode Appendix 10-1 1. Product Specification 10-4 2.

  • Page 7: Chapter 1 Overview

    Chapter 1 Overview...

  • Page 8: Introduction

    SHR-2040/2041/2042 USER’S MANUAL Introduction The Digital Video Recorder(DVR) compresses the 4 channel of camera input data into the MPEG4 video file and the 4 channel of voice input data into the ADPCM audio file in the real time to record them in the Hard Disk or retrieve them from the Hard Disk simultaneously. In addition, it transfers the Video/Audio out through a network in the real time and it is able to monitor the Video/Audio remotely by your PC.

  • Page 9: Features

    4 CH Composite Input Connectors NTSC / PAL Video Source Compatible ( NTSC : SHR-2040/SHR-2041/SHR2042, SHR-2040N / SHR-2041N / SHR-2042N PAL : SHR-2040P/SHR-2041P/SHR2042P) Able to record the CIF sized (NTSC-352 x 240/PAL-352 x 288) video at the speed of 120 ips(NTSC)/100ips(PAL)(Image Per Second)

  • Page 10: Part Names And Functions

    SHR-2040/2041/2042 USER’S MANUAL Part Names and Functions [SHR-2040] Name Function Power LED Displays power on/off condition. Alarm LED lights on when an event occurs. HDD Access Displays Normal Access to HDD. Upon Access to HDD, LED repeats on and off. Network LED Displays both network connection and data transmission conditions.
  • Page 11 Name Function PTZ Button Performs the TELE, WIDE, PRESET, and VIEW function. ZOOM ZOOM(TELE) Sets up Digital Zoom(x2). Button ( Performs the TELE function by pressing the PTZ button.) TELE FREEZE FREEZE(WIDE) Performs the FREEZE function in the DISPLAY Mode. Button ( Performs the WIDE function by pressing the PTZ button.) WIDE...
  • Page 12 SHR-2040/2041/2042 USER’S MANUAL [SHR-2041] [SHR-2042] Name Function Power LED Displays power on/off condition. Alarm LED lights on when an event occurs. HDD Access Displays Normal Access to HDD. Upon Access to HDD, LED repeats on and off. Network LED Displays both network connection and data transmission conditions. Backup LED Displays Back Up Mode.

  • Page 13: Search Function

    Name Function Displays 4 split screen. Displays the selected channel to the Single Mode Displays both LIVE Channel and Playback Channel in the PIP Screen simultaneously. MODE Mode Selection Search Displays 6 split screen. Button (1 CH playback screen and 4 CH live screen) Displays 9 split screen.
  • Page 14 SHR-2040/2041/2042 USER’S MANUAL [SHR-2040] Caution Caution Do not play DVR on the carpet or other soft material to prevent clogging of the air ventilator. To play DVR on the cabinet or rack, be sure to check the ventilation condition. Name Function Composite Video Signal Input Port (BNC Style Connector) VIDEO IN...
  • Page 15 [SHR-2041/2042] Caution Caution Do not play DVR on the carpet or other soft material to prevent clogging of the air ventilator. To play DVR on the cabinet or rack, be sure to check the ventilation condition. Name Function VIDEO IN Composite Video Signal Input Port (BNC Style Connector) You may use THROUGH port to transmit a video signal to the THROUGH...

  • Page 16: Chapter 2 Installation

    Chapter 2 Installation...

  • Page 17: Installation Environment Setup

    SHR-2040/2041/2042 USER’S MANUAL Installation Environment Setup Do not play DVR on the carpet or other soft material to prevent clogging of the air ventilator. To play DVR on the cabinet or rack, be sure to check the ventilation condition. You should pay attention to the following before you use the product. 1.

  • Page 18: Checking Product & Accessory

    Checking Product & Accessory Upon delivery of a product, you shall unwrap the product and put it on the even floor or where you want to use it. Then you shall check if the following items are in it. Main Body User’s Manual One Power Cord Two Brackets...

  • Page 19: Hdd Addition

    SHR-2040/2041/2042 USER’S MANUAL HDD Addition You can add up HDD to the product.(2040-1 HDD/2041-3 HDDs/2042-2 HDDs) However, since the product contains has many parts which may incur electric shock, accident, or product breakdown and improper installation or setup may disturb HDD recognition or normal product operation, you shall consult with an expert of the agency where you bought the product.
  • Page 20 [SHR-2041] [SHR-2042]...
  • Page 21 SHR-2040/2041/2042 USER’S MANUAL 2. Detach the cover from the product. (Pull out the cover slightly and lift from the back side to detach.) [SHR-2040] [SHR-2041/2042]...
  • Page 22 3. A bracket(BRACKET- HDD) is mounted to each side of product to fix the HDD. Please loosen the screw of the bracket to which you want to fix HDD. BRACKET-HDD...
  • Page 23 SHR-2040/2041/2042 USER’S MANUAL 4. Pull BRACKET-HDD to the product center to detach the fixed part at the bottom and detach BRACKET-HDD from the product. 5. Tighten 4 special screws(BWH,6-32UNC,L10.5), supplied as an accessory to fix HDD to BRACKET-HDD. (A force to tighten the screw shall be strong enough to resist vibration.)
  • Page 24 6. Reattach HDD to the original position of BRACKET-HDD. (Assembly shall be done in the reverse procedure of disassembly as follows. Align the 5 fixing points at the bottom with the BRACKET-HDD fixing holes respectively and push BRACKET-HDD out of the product to align the screw fixing holes. Then, tighten the screws firmly.) 7.
  • Page 25 SHR-2040/2041/2042 USER’S MANUAL 8. Check the connector, wiring, and cable fixing condition inside the product and close the cover. 9. Tighten cover-fixing screws. (5 points on both sides and 1 point in the back side) You can apply 2 HDDs to each BRACKET-HDD as shown in the figure. Caution Caution For HDD addition, please select the same HDD with the existing HDD fixed to the product as...
  • Page 26 WARNING ! Regarding the sub fan, you need additional brackets and sub fans as follows. The sub fan is shaped like this when viewed from the front and back. Please pay attention to the fan direction to let wind go through the fan. @ Fix the fan as follows 2-10...
  • Page 27 SHR-2040/2041/2042 USER’S MANUAL # Please install the fan which is seen at the right from the front view of SHR-set as follows. 2-11...
  • Page 28 $ The cable should be out from the left hole. 2-12...

  • Page 29: Chapter 3 Connecting With Other Device

    Chapter 3 Connecting with other device...
  • Page 30 SHR-2040/2041/2042 USER’S MANUAL Connecting the Video, Audio, and Monitor [SHR-2040]...
  • Page 31 [SHR-2041/2042]...

  • Page 32: Connecting The Network

    SHR-2040/2041/2042 USER’S MANUAL Connecting the Network Connecting to Internet through Ethernet(10/100BaseT) [SHR-2040] Connecting to Internet through ADSL [SHR-2040]...
  • Page 33 Connecting to Internet through Ethernet(10/100BaseT) [SHR-2041/2042] Connecting to Internet through ADSL [SHR-2041/2042]...

  • Page 34: Connecting The Usb

    SHR-2040/2041/2042 USER’S MANUAL Connecting the USB 1. There are two USB connecting ports on the front and back of SHR-2040/2041/2042. 2. USB Hard Disk, USB CD/DVD, and USB Memory are connected through the front and back ports of SHR-2040/2041/2042. 3. Only one USB device can be connected with each USB connecting port. 4.

  • Page 35: Connecting The Alarm Input/Output

    Connecting the Alarm Input/Output The Alarm IN/OUT port in the back of SHR-2040/2041/2042 is composed of the following elements. ALARM IN/OUT Connection Name Function - ALARM IN1 - ALARM IN2 ALARM Input Port - ALARM IN3 - ALARM IN4 On receiving an ALARM RESET signal, the sys- tem cancels the current ALARM input and output - ALARM RESET IN signal and then resumes sensing.
  • Page 36 SHR-2040/2041/2042 USER’S MANUAL ALARM IN/OUT Connection...

  • Page 37: Connecting The Rs-485 Device

    Connecting the RS-485 Device Connect the RS-485 Device through the back port of SHR- SHR-2040/2041/2042. You can install and control the PTZ camera supporting the RS-485 communication. You can adopt either Half Duplex or Full Duplex method for the connection. PTZ device SHR-2040/2041/2042 Rear...

  • Page 38: Chapter 4 Live

    Chapter 4 Live...

  • Page 39: System Operation

    SHR-2040/2041/2042 USER’S MANUAL System Operation Turn the power on and the following LOGO pops up on the screen. After the LOGO appears, all of LED in the front flickers 6 times to initialize the system for operation. Upon completion of normal initialization, the Live screen appears accompanying a beep sound.

  • Page 40: Live Screen Mode

    Live screen Mode Definition of Live Screen Icon The Live screen icons display the current setup and function status of each screen. V.Loss CAM_01 CAM_01 : Recording Icon Each icon represents Normal / Event (Alarm + Motion) / Schedule Recording. : Recording Video Size Icon Each icon represents the recording size of Large / Normal / CIF.
  • Page 41 SHR-2040/2041/2042 USER’S MANUAL : Auto sequence Icon This icon appears in the auto sequence mode. : Backup Playback Icon This icon appears when the backup data is played. : Fan Error Icon This icon appears when the fan stops. : This icon appears when there is no HDD. V.Loss / V.Off : Video Input Status If there is no more video data input in the Video On, [V.Loss] appears in the channel.

  • Page 42: Selecting Live Screen Mode

    Selecting Live Screen Mode Each mode may be selected by [MODE Button] and [CH1 ~ CH4 Button]. The following figure shows Live Mode after converted. The default setup is 4 Split Screen Mode. You are able to choose other modes than Full Screen Mode by the [MODE] button in sequence.

  • Page 43: Live Channel Selection And Audio On/Off Setup

    SHR-2040/2041/2042 USER’S MANUAL Live Channel Selection and Audio On/Off Setup In other split modes than Full Screen Mode and Auto Sequence Mode, you can choose a channel to be displayed in each split area on your own. In addition, the channel being set to Audio On can be set to Audio On/Off in all Live Modes.

  • Page 44: Zoom Function

    Freeze and Zoom Freeze Function Freeze function pauses the video image in the Live Screen, it is only available in the Live Mode. You can set Freeze On/Off with [FREEZE] Button and [FREEZE LED] is turned on or off depending on the Freeze On/Off setup condition. Zoom Function Zoom function enlarges the selected area to double size, and it is only available in the single mode.

  • Page 45: Event Monitoring

    SHR-2040/2041/2042 USER’S MANUAL Event Monitoring Event monitoring displays the channel synchronized with a event on the screen when a special event (Sensor/Motion/Video Loss) occurs. Event monitoring On/Off and event duration setup is available in [Menu] [Monitoring] mode. If you set the event monitoring interval to 5 seconds and an event occurs at CH2 in the beginning as following figure, the system will display CH2 in the full screen for 5 second.

  • Page 46: Spot-Out Monitoring

    Spot-out monitoring Spot-out Monitoring has nothing to do with Live Screen Output, it monitors the full screen of a certain channel. If you select the Monitoring in the MENU, the one channel among CH1 ~ CH4 is output with a Spot-out or channels are output one by one at an interval as Auto Sequence Mode in the Live Mode.

  • Page 47: Chapter 5 Menu Setup

    Chapter 5 Menu Setup...

  • Page 48: Before Use

    SHR-2040/2041/2042 USER’S MANUAL Before Use Selection The yellow cursor shows the current window. Use the œ,ƒ,¦, ‹ key in the front to move the cursor on your desirous menu. If you press the “Enter” key with the cursor clicking on your desirable menu, the system will enter the new mode.

  • Page 49: System

    System System Menu has the following items in detail. Date/Time/Language Setup ¦, ‹ Press the “Enter” key and the key to move to Y/M/D. œ, ƒ Use the key to change the date. Press the “Enter” key to come out of the mode. Time ¦, ‹...
  • Page 50 SHR-2040/2041/2042 USER’S MANUAL Note Note [Date/Time Change] Pressing “OK” after you change date and time, you will be asked by a pop-up window if you really confirm the change. Here, press ”Yes” to change the time. Since Date/Time does not change in backup process, be sure to stop the backup process before you change Date/Time.
  • Page 51 Password The Default Password is 4321. New Password This is used to change the system password inside SHR-2040/2041/2042. You are allowed to create a password up to 4 digits. Press the “Enter” key and a channel button from 1 ~ 4 at the left. Press the “Enter” key after change to move to “New Password Confirm”.

  • Page 52: Load Factory Default

    SHR-2040/2041/2042 USER’S MANUAL Load Factory Default It used to initialize all the menu setup values. The recorded data will not be deleted. Press “OK” in the confirmation window to start initializing. System Log System Log is used to check the important record by an administrator. It displays such contents of a system related log and its execution date/time as System Start, System Termination, and Menu Setup Change.

  • Page 53: Event Log

    System Log List System Start Starts the system. Time Change Changes the Date/Time. Login(Admin) Viewer Login (Admin) Load Factory Default Initializes the system. Logout(Admin) Viewer Logout (Admin) System Upgrade Changes the system S/W. Login(User) Viewer Login (User) Disk Full No Space in the HDD Logout(User) Viewer Logout (User) Backup Start...
  • Page 54 SHR-2040/2041/2042 USER’S MANUAL System Information and Setup Software Version : Displays the current version. Setup is not available. Broadcast Format : Displays the current Format(NTSC/PAL) . Setup is not available. Mac Address : 6 Byte hardware address. Setup is not available. Device Erase This erases the data in ATA / USB HDD / USB memory.

  • Page 55: Hdd Setup

    Caution Caution [Device Erase] Data will not be deleted in the backup mode. Please be sure to stop the backup before you delete a data. In the recording mode, suspend the recording and delete a data. Caution Caution [USB S/W Upgrade] Download the software to upgrade at http://www.sec.co.kr, CCTV Part.

  • Page 56: Hdd Mode Setup

    SHR-2040/2041/2042 USER’S MANUAL HDD Mode Setup HDD End Mode Stop : Stops recording when HDD is full during the recording. Overwrite : Deletes the original data and save a new data when HDD is full during the recording. HDD End Beep On : Beeps when the HDD is full in the recording mode.
  • Page 57 Caution Caution [Disk Overwrite] In the overwrite Mode, the previous Event data is deleted and the mode is changed. Remote control Device MENU for the use of Samsung system keyboard Remote Control Device Device Samsung System Keybord Baudrate Parity Date...

  • Page 58: System Shutdown

    SHR-2040/2041/2042 USER’S MANUAL System Shutdown Remote Control Device Terminates the work in action safely and turns the power off. Press “OK” in the confirmation window and plug out when you see “Safe to Power Off”. Caution Caution [System Shutdown] Power-off without terminating the system in the System Shutdown menu may incur improper motion like data loss and disk failure.

  • Page 59: Camera

    Camera The detailed Camera Menu items are as follows. Camera Config. Video On : Camera images from a selected channel appear. Off : Camera images from a selected channel disappear. Covert1 : Displays the information except for the Video information of selected channel. Covert2 : Does not display the any information.
  • Page 60 SHR-2040/2041/2042 USER’S MANUAL Title You can name the camera of selected channel. If you press the [Enter] key, the Virtual keyboard will come out. ‹¤Virtual Keyboard If you move the cursor, you can type text by text. Up to 15 texts can be typed. Keyboard cannot be composed of all spaces.

  • Page 61: Ptz Device

    It is supported by the PTZ device. The following protocols are now being supported. Samsung / Vic. / Pan. / AD / Phi. / Ern. / Pel-D / Pel-P / Vcl. / Dia. / Kal. Baurate Baurate is supported by the PTZ device. 600/ 1200/ 2400/ 4800/ 9600/ 19200/ 38400 Parity It is set to the one of None, Even, and Odd.

  • Page 62: Screen Setup

    SHR-2040/2041/2042 USER’S MANUAL Screen Setup It is a window to set Brightness/Contrast/Color for the camera image of each channel. Put the cursor on the channel that you want to adjust and set Brightness/Contrast/Color. Once selected, the channel appears in the right PIP area. Use the œ or ƒ button to adjust the value from 0 to 100.

  • Page 63: Monitoring

    Monitoring Event Monitoring It is possible to set to Off/3sec/5sec/10sec/20sec/30sec/Continuous. Off : Event Monitoring does not operate to turn to the screen where an event occurs. 3sec / 5sec / 10sec / 20sec / 30sec : Sets the duration time of screen in the Auto Sequence mode.
  • Page 64 SHR-2040/2041/2042 USER’S MANUAL Monitor You are not allowed to connect VGA OUT and Composite/S-Video OUT simultaneous- ly. Consequently, the user is obliged to choose either Composite Output or S-Video Output. Composite : Makes the output come out through the “Composite / S-Video OUT” port. VGA : Makes the output come out through the “VGA Out”...

  • Page 65: Recording Mode

    Recording Mode Record Mode Details for Record Mode Menu are as follows. NTSC If you press the front “REC” button, the mode value to be recorded will be set. For the setup of Event Recording Mode value, refer to 5-20. Event Recording Mode Setup Menu.
  • Page 66 SHR-2040/2041/2042 USER’S MANUAL Record Video size Mode Video size It sets the video to be recorded. Half D1 : (NTSC) 720x240(N) Normal (PAL) 720x288(N) Normal : (NTSC) 352x240(C) (PAL) 352x288(C) Auto Deletion Press the [Off] button at the bottom of left to select either OFF or On. Select “On”...

  • Page 67: Event Record Mode

    Event Record Mode The detailed items of Event Record Menu are as follows. Event Record Mode setup NTSC Event Record Mode setup Sets a mode to be recorded when an event occurs. V. Size (Video Size ) Sets the size of a screen to be recorded. Half D1 : (NTSC) 720x240(N) Normal (PAL) 720x288(N)
  • Page 68 SHR-2040/2041/2042 USER’S MANUAL Quality Quality will be determined. Select the one among Very High / High / Normal / Low. Rate Sets the Rate the number of screen recorded every second. It you set to 15ips, the system records too many screens per second and play continues intermittently since recording is more detailed.
  • Page 69 Alarm Detection Setup Off : Sensor does not operate. N.O(Normal Open) Sensor : Sensor remains open all the time and if closed, an alarm will be issued. (A Contact) N.C(Normal Close) Sensor : Sensor remains closed all the time and if open, an alarm will be issued.

  • Page 70: Motion Detection Setup

    SHR-2040/2041/2042 USER’S MANUAL Motion Detection Setup Motion Detection Mode Off : Motion Detection does not operate On : Motion Detection operates. Area Selects the Motion Detection area. It is composed of 45x40(NTSC)/45x48(PAL) sized Block. It is impossible to set 4 block rows(Up/Down/Left/Right) to allow them to be displayed in all monitors.
  • Page 71 Sensitivity Sets the sensitivity of motion detection. Sensitivity grade consists of Low Medium Very High in the ascending order. Alarm-Out Sets the Alarm-Out when Motion occurs. 5 Alarm Outs are supported. Select an alarm-out that you want to synchronize with the current motion channel. Multi-selection is possible.

  • Page 72: Record Schedule

    SHR-2040/2041/2042 USER’S MANUAL Record Schedule This setup selects a time to record automatically. Selection by the day or by the time is available. The default value is set to “Event Record”. Press “CH >” copies the value of Channel 1 to all the channels. The horizontal axis numbered from 0 to 23 represents the time value.
  • Page 73 Schedule / Event Record On occurrence of Event, Continuous Recording is replaced with Event Recording Mode. Holiday If you press “Holiday”, a calendar pops up and you are able to designate holidays. Move to a date and press “Enter” to complete designation. Press “Enter”...

  • Page 74: Backup

    SHR-2040/2041/2042 USER’S MANUAL Backup Backup If there is a device, the free space and the backup device is displayed. Select a date, time, and camera No. to backup, and press “Start”. When you change Start Date/Time or End Date/Time, free space keeps updated in the Free Space zone.

  • Page 75: Network

    Network IP Setup Connection Mode Designates the kind of the network connected to the main body of SHR-2040/2041/2042. Static IP : When the main body is connected to the network with Static IP. Dynamic IP : When the main body is connected to the network with Dynamic IP supplied by DHCP.
  • Page 76 SHR-2040/2041/2042 USER’S MANUAL Sets the IP address for the main body of SHR-2040/2041/2042 to connect with the network. If the Connection Mode is set to Static IP, you shall type in IP yourself. If the connection mode is Dynamic IP or ADSL(PPPoE), the IP allocated by the DHCP server or ADSL company will be automatically displayed.
  • Page 77 Transfer Protocol Settings You may select either TCP or UDP for the protocol type. If you select ADSL from the IP setup page, only TCP is available. While TCP is selected, Audio transmission is not available. The available Port(TCP) ranges from 554 to 998 and the port number will be changed by 4. Once the first digit is determined, the following 3 digits will change accordingly.
  • Page 78 SHR-2040/2041/2042 USER’S MANUAL Callback Settings The Callback function is used to forward a callback message to the IP where SmartViewer is in action in case Alarm, Motion Detection, or Video Loss event occurs. On/Off : Off is default but you may choose On. IP Address : IP setting is available only when On is selected from On/off Setting.

  • Page 79: Network Setup

    Network Setup Port Setup for SmartViewer Connection The Port value for DVR registration of SmartViewer (Setup Site Setup) shall be as same as that of the set (TCP). If you want to use the IP Router, you shall forward the activated Port depending on the current setting value.

  • Page 80: Chapter 6 Ptz Camera Control

    Chapter 6 PTZ Camera Control...

  • Page 81: Ptz Camera Control Mode

    SHR-2040/2041/2042 USER’S MANUAL PTZ Camera Control Mode Select a proper PTZ camera Configuration value in MENU to enter PTZ Control Mode. Selected in MENU, the PTZ symbol( ) is displayed on the channel in the screen. ¦ If you press the Enter( ) button among direction keys in front of Split Screen, a blue bar will appear in the monitor screen.
  • Page 82 When using the remote controller (SCC2000), direct camera control is available only for Samsung Protocol in the remote controller (refer to the SCC2000 user manual). If there is no PTZ control within the maximum 5 minutes in DVR, the PTZ mode is cancelled automatically.

  • Page 83: Basic Operation Of Pan, Tilt, & Zoom

    SHR-2040/2041/2042 USER’S MANUAL Basic Operation of PAN, TILT, & ZOOM Press the LEFT or RIGHT button in front SHR-2040/2041/2042 in PTZ Camera Control Mode to control PTZ Camera horizontally. TELE WIDE VIEW PRESET TILT Press the UP or DOWN button in front SHR-2040/2041/2042 in PTZ Camera Control Mode to control PTZ Camera vertically.

  • Page 84: Preset Setup

    Preset Setup Records a certain position of PTZ Camera. Memorizes up to 20 PTZ Camera positions at the moment. Note Note For AD Protocol PTZ Camera, this memorizes only 7 Presets. Press the Preset button in front of SHR-2040/2041/2042 in Single Screen PTZ Camera Control Mode to set up Preset.
  • Page 85 SHR-2040/2041/2042 USER’S MANUAL Move the cursor to right and press ENTER in PTZ Control Mode first. Then, press the “Enter” to run P/T/Z/ operation mode in the PIP screen and press the “Enter” again to cancel P/T/Z/ Motion Mode. Press Enter at the Position Name position to see Virtual Keyboard. Enter the type position name and press the “OK”...

  • Page 86: Camera Menu Setup

    Camera Menu is a menu supplied by PTZ Camera itself. This Menu sets up several conditions of PTZ Camera. Note Note Pan. or Samsung Protocol Camera only is authorized for Camera Menu setup. Press the Preset button in front of SHR-2040/2041/2042 in Single Screen PTZ Camera Control Mode to select Camera Menu. TELE...

  • Page 87: Preset View

    SHR-2040/2041/2042 USER’S MANUAL Preset View Preset setup allows your movement to a certain saved position of PTZ Camera. Press the VIEW button in front of SHR-2040/2041/2042 in Single Screen PTZ Camera Control Mode to select Preset.(For example, Samsung Protocol) TELE WIDE VIEW...

  • Page 88: Other View

    Control Mode to supply PTZ Camera. This is a very special function. Note Note Samsung, Pan., Pel-P, or Pel-D Protocol PTZ Camera supports this function. Samsung : Auto Pan / Scan / Pattern Pan. : Auto Pan / Sequence / Sort...

  • Page 89: Chapter 7 Recording

    Chapter 7 Recording...

  • Page 90: Rec (Normal Recording)

    SHR-2040/2041/2042 USER’S MANUAL REC (Normal Recording) Pressing REC the button starts recording as set in the record mode. Then, REC LED lights on and a recording icon appears on the screen. During the recording in HDD, the front HDD LED blinks. During the normal recording, you can stop it by pressing the REC button.

  • Page 91: Schedule Recording

    Schedule Recording While “Record Schedule” or “Schedule/Event recording” is selected in the Record Schedule menu, Schedule Recording automatically starts. Otherwise, Schedule Recording remains inactivated. During the Schedule Recording, Recording Icon appears on the screen. During the recording in HDD, the front HDD LED blinks. If the Event Recording is selected, the recording starts at the every event.

  • Page 92: Event Recording

    SHR-2040/2041/2042 USER’S MANUAL Event Recording Alarm Detection Sensor operation mode in Alarm of Event Record menu shall be set to N.O (Normal Open) or N.C (Normal Close). Motion Detection Motion detection in the Event Recording menu shall be set to On. Video Loss Detection Video Loss in Event Record menu shall be set to On.

  • Page 93: Chapter 8 Search And Play

    Chapter 8 Search and Play...

  • Page 94: Before Use

    SHR-2040/2041/2042 USER’S MANUAL Before Use Pressing the “SEARCH” button shows Search Menu on the screen as seen above. Calendar Search searches a video file by the use of a calendar at the desired time. Event Search searches a video file recorded by the occurrence of event. Date/Time Search searches a video file by the entering of a day and time.

  • Page 95: Calendar Search

    Calendar Search Be sure to select both the channel and the date to search. And press the [Start] button to search for the desired time. Use a calendar to search the video file of desired time. Four channels in maximum are in the range of search.

  • Page 96: Event Search

    SHR-2040/2041/2042 USER’S MANUAL Event Search Searches Normal Recording, Schedule Recording, Alarm Recording, Motion Recording, and V.Loss(Video Loss) Recording by the time. You shall select a channel to search to see the event information of the channel. On the basis of event information for each channel, the system searches a video file for the event.

  • Page 97: Date/Time Search

    Date/Time Search Use the Day/Time information to search a video file at the time as you desire. Up to 4 channels can be searched at once. After you select a channel with the œ, ƒ, [Enter] button, the checkbox on the right of selected event number will be checked.

  • Page 98: Go To First Search

    SHR-2040/2041/2042 USER’S MANUAL Go to First Search Searches the oldest one among recorded video files. Up to 4 channels can be searched at once. After you select a channel with the œ, ƒ, [Enter] button, the checkbox on the right of the selected channel number will be checked.

  • Page 99: Go To Last Search

    Go to Last Search Searches the latest one among recorded video files. Up to 4 channels can be searched at once. After you select a channel with the œ, ƒ,[Enter] button, the checkbox on the right of the selected channel number will be checked. Press the [Start] button want to start the search and to cancel.

  • Page 100: Backup

    SHR-2040/2041/2042 USER’S MANUAL Backup First, select the backup device. Mark the data of device. Select the file name to backup, and the detail information of a file is displayed in the below. The [Previous] button shows the previous page. The [Next] button shows the next page. The [Start] button plays the desired file.

  • Page 101: Playback

    Playback ‹ ¤ II Press the PLAY/PAUSE button( ) to play the data recorded in HDD. If you used the SEARCH button for playback just before, the system would remember the information of the played channel until you click the PLAY/PAUSE button( ‹...
  • Page 102 SHR-2040/2041/2042 USER’S MANUAL Definition Play Screen Mode Single Screen PIP Screen 4 Split Screen 6 Split Screen 9 Split Screen 4 Split Screen : If you select more than a channel, 4 Split Screen will appear. Single Screen : This appears when you select one channel in Search. If you press the [CH1~CH4] button in the other split screen, the selected channel appears with the single screen.
  • Page 103 Play at Faster Speed ‹ ‹ If you press the LEFT or RIGHT button( ¦ ¦ ) during the playback, you will be able to see the screen at the x2, x4, x8, x16, x32, and x64 speed either forwardly or reversely.

  • Page 104: Chapter 9 Smart Viewer

    Chapter 9 Smart Viewer...

  • Page 105: Introduction

    SHR-2040/2041/2042 USER’S MANUAL Introduction Smart Viewer is a program that a general PC user is able to install SHR-2040/2041/2042 to his PC to monitor the video and audio data in the real time through network without going to the site where SHR-2040/2041/2042 is installed.

  • Page 106: Feature

    Feature Thanks to the transmission of video data compressed by the MPEG-4 Video Compression method, it can play the video images of good quality. Thanks to the G.726 Voice Compression method, it supplies the voice data of good quality. Use of armored MIC improves the quality of remote voice. Thanks to the transmission of video/audio stream through RTP(Real-Time Transport Protocol), the real-time video playback is excellent and multi-users’...

  • Page 107: Pc Specification(Recommendation)

    SHR-2040/2041/2042 USER’S MANUAL PC Specification(Recommendation) OS : Win98SE, WinMe, Win2000, WinXP Recommendation : CPU Pentium 3, 1GHz or higher RAM 256 MB or higher VGA RAM 32Mb or higher DirectX 8.1 or higher Note Note Depending on Recording Rate, Video Size, and user’s PC specification set to SHR-SHR-2040/2041/2042, the number of Smart Viewer playback frame varies.

  • Page 108: Smart Viewer Installation

    Smart Viewer Installation Smart Viewer Installation Put a Smart Viewer Program CD in CD-ROM and open the “Smart Viewer” folder in the CD. Run the “Setup.exe” file.
  • Page 109 SHR-2040/2041/2042 USER’S MANUAL Click the “Next” button. If you agree with Smart Viewer License, click “Yes”. Designate a folder to install Smart Viewer in it and click “Next”.
  • Page 110 The system proceeds with setup file installation and system setup. Installation is complete. Click the “Finish” to terminate the installation.

  • Page 111: Smart Viewer Program Execution

    SHR-2040/2041/2042 USER’S MANUAL Smart Viewer Program Execution Double-click the Smart Viewer icon in the background screen to run the program.

  • Page 112: Smart Viewer Initial Screen

    Smart Viewer Initial Screen Screen Description ! This is the button to enter the Search mode in which you can search and play remote the video file recorded in SHR-2040/2041/2042 and enter the Monitoring mode for real-time video monitoring. @ This button terminates or minimizes the program. # It displays the current date, day, and time.

  • Page 113: Monitoring Mode

    SHR-2040/2041/2042 USER’S MANUAL Monitoring Mode DVR(SHR-2040/2041/2042) / SITE Connection - Select the name of DVR(SHR-2040/2041/2042) or site for connection and click the connection button. Note Note You can set the name, IP, and password of DVR(SHR-2040/2041/2042) for connection in the Setup mode. Also, the site setup which permits simultaneous connection to multi-DVRs(SHR-2040/2041/2042) is available in the Setup mode.
  • Page 114 Note Note No more than 3 users, one Admin. authorized user and 2 User authorized users are allowed to access SHR-2040/2041/2042 simultaneously.(In the case of multicast, 5 User authorized users are allowable.) Caution Caution Once occupied by 3 users( In the case of multicast, 6 users), SHR-2040/2041/2042 does not permit more connection.
  • Page 115 SHR-2040/2041/2042 USER’S MANUAL Time Information - As soon as you are connected to SHR-2040/2041/2042, the current date, day, and time of SHR-2040/2041/2042 will be displayed. - Otherwise, the current date, day, and time of your PC will be displayed. Connection Information - As soon as you are connected to SHR-2040/2041/2042, the connection button will display connection status.
  • Page 116 Note Note # Clicking the speaker icon turns the audio of channel on or off. : Audio OFF : Audio ON If you turn the audio of a SHR-2040/2041/2042 channel off, “Disable” will be displayed. : Audio Disabled For the Audio on channel now, use the following audio button to adjust the volume and set the mute.
  • Page 117 SHR-2040/2041/2042 USER’S MANUAL Event Log Display Window - Click the Log button to activate the log display window. - It displays the event(alarm, user connection, and setup change) occurring at SHR-2040/2041/2042 in the real-time. Note Note [Event Message] ‹ Connecting.. : Trying to connect to SHR-2040/2041/2042. ‹...
  • Page 118 Caution Caution When Time Change, Load Factory Default, Network Change, System Shutdown, or Hdd Format event occurs, Smart Viewer terminates the connection automatically. Camera connection Indication Window - Displays the connection condition of DVR and CAMERA in the list. Note Note [DVR Icon Color] ‹...
  • Page 119 SHR-2040/2041/2042 USER’S MANUAL Screen Split Selection Button - Small Sized Single / Single / Quad / Nine-Split Mode Sixteen-Split Mode - You can change the Split Mode of the screen under monitoring. Sequence Mode Button - Changes the channel to be played at the preset interval. - The sequence time interval can be set at the Setup Mode?Viewer Setup.
  • Page 120 : When monitoring with Quad Mode : When monitoring with Single Mode : Camera Off Note Note The number in the screen icon indicates the screen position in SmartViewer. : The orange icon indicates the current channel is connected to a camera. : The gray icon indicates the current channel is connected to a camera but not displayed in the screen.
  • Page 121 SHR-2040/2041/2042 USER’S MANUAL NEXT Button - Click the NEXT(Mouse Left Button) to see the channel next to the current channel. - In Single Mode : 1 1 (CH) - In Quad Mode : 1,2,3,4 1,2,3,4 (CH) - In Nine-Split Mode : 1,2,3,4 1,2,3,4 (CH) - In Sixteen-Split Mode : 1,2,3,4 1,2,3,4 (CH)
  • Page 122 FAVORITE Button - If you press FAVORITE, the FAVORITE window will be activated. If you click the current FAVORITE, the cameras saved in the current setting value will be displayed in the screen. You may delete the selected FAVORITE or all FAVORITE setting values.
  • Page 123 SHR-2040/2041/2042 USER’S MANUAL Video Recording Button - If you select a channel in the playback and click the “Save” button, the video will be saved in a file format with the extension of * .dvr in a designated folder of your - The name of the directory in which an image will be saved, the file name, and the image save length shall be set up at the Setup Mode Viewer Setup.
  • Page 124 Note Note The PAN / TILT / ZOOM function is supported to all the cameras. But, POWER ZOOM is supported only by Samsung Smart Dome Camera, and assured to the operation of TILT below 45°. 9-20...
  • Page 125 The name of @,#, and $ functions varies depending on the camera and some cameras do not support these functions. - The Samsung camera supports all the functions and names. - The Panasonic camera supports all the functions, but with different names.
  • Page 126 # This is a button for the role of Enter. Note Note The Camera Menu Setup function is supported by Samsung and Panasonic camera only. Caution Caution As far as SHR-2040/2041/2042 uses the PTZ camera control functions, Smart Viewer can not control PTZ Camera.

  • Page 127: Search Mode

    SHR-2040/2041/2042 USER’S MANUAL Search Mode The initial screen of search mode - The search mode is divided into the remote mode to search and play the SHR-2040/2041/2042 video and the local mode to play .dvr file saved in the directory designated by your PC. ! To change to the search mode for the remote control of video recorded in SHR-2040/2041/2042.
  • Page 128 DVR(SHR-2040/2041/2042) Selection/Change by contacting SITE - Same as “DVR(SHR-2040/2041/2042)/SITE Connection” of the monitoring mode. DVR(SHR-2040/2041/2042) Selection/Change by contacting SITE - Select SHR-2040/2041/2042 from the Contact list. - SHR-2040/2041/2042 turns black if contacted with the ADMIN authority and turns gray if contacted with the USER authority. - Without the ADMIN authority, search is not accessible.
  • Page 129 SHR-2040/2041/2042 USER’S MANUAL Calendar Window - If the video data in on-line SHR-2040/2041/2042 was recorded, the date turns red. - If you click the date in red, the saved video information is displayed. - The currently selected date will be marked with a thick red box. - ¦¤: Moves to the previous month.
  • Page 130 @ Backup Button - If not playback(Stop), the video save button performs the backup function. - If the save button is pressed, the window for backup pops up. - Set a Start/End tome for backup and select a file format to save. - The backup starts when the “Start”...
  • Page 131 SHR-2040/2041/2042 USER’S MANUAL $ Print - This function outputs the screen zone of the playback video which is now being displayed. % Setup Mode Button - This button pops up the setup mode window. Play Buttons ! Play : Play @ Reverse Play : Reverse Play # Stop : Stop $ Fast Forward : Faster Play...
  • Page 132 Note Note During the play(Play/RevPlay/FF/FB), disconnection or change to the both monitor- ing mode and local mode is not permitted. Click the Stop button first before the change. Time Line - Displays the time information of video in SHR-2040/2041/2042 selected on the calendar window.
  • Page 133 SHR-2040/2041/2042 USER’S MANUAL Next Button - Changes the channel as the Next button does in the monitoring mode. Note Note During the video playback(Play/RevPlay/FF/FB), the channel change is not available. Reload Button - Updates the record time information in the calendar window and time line. Local Mode - Plays *.dvr file saved in the directory of your PC by the Record function.

  • Page 134: Setup Mode

    Setup Mode Initial Screen ! Button to select items for DVR Setup, Viewer Setup, Site Setup, and S/W Version setup. @ It shows what the selected Setup item can set up in detail. # button to terminate the setup window. $ Button to save the information revised in the setup window, remark the information prior to such a revision, or terminate the setup window.
  • Page 135 SHR-2040/2041/2042 USER’S MANUAL Setup Item Selection Button - It is used for the selection of each setup item. - It is composed of 4 items- DVR Setup, Viewer Setup, Site Setup, and S/W Version. - DVR Setup: Allows you to change the remote menu setup items of SHR-2040/2041/2042.

  • Page 136: Dvr Setup

    DVR Setup - Click the [DVR Setup] button for DVR Setup. - You can change remotely the setup items of SHR-2040/2041/2042 Menu, being connected with Smart Viewer. - DVR Setup is composed of 5 items; System, Camera/Audio, Monitoring, Recording, and Network. Note Note ou are authorized with access to DVR Setup in an Admin authority only...
  • Page 137 SHR-2040/2041/2042 USER’S MANUAL Detailed DVR Setup Items ! System - Information Information shows the information on on-line SHR-2040/2041/2042. SHR204X-V1.0.0-20050701080722 Note For the detailed items of DVR Setup, refer to Chapter 5. - Password Sets the password for the control of SHR-2040/2041/2042 Menu or SHR-2040/2041/2042 key input.
  • Page 138 Caution Caution System Password shall be composed of numeric only, up to 8 digits. Note Note - The Delete key and the combination of Ctrl+C or Ctrl+V in the keyboard are not supported at the System Password input. - Use the BACKSPACE key to delete the contents. Note Note Default System Password is set to 4321.
  • Page 139 SHR-2040/2041/2042 USER’S MANUAL - Language Language sets the language in which on-line SHR-2040/2041/2042 will be expressed Note Note The change of language by the system language results in the change of language expression setup of SHR-2040/2041/2042. In short, the language setup of Smart Viewer does not change.
  • Page 140 - Remocon (Remote Control Device) Remocon can set the remote control device installed to SHR-2040/2041/2042. Note Note If you install the remote control device to the main body of SHR-2040/2041/2042 and activate the setup, PTZ control is not available in the Viewer. 9-36...
  • Page 141 SHR-2040/2041/2042 USER’S MANUAL @ Camera - Config. Config. sets Video, Audio On/Off, Camera Title, and Auto Sequence Time for each channel of on-line SHR-2040/2041/2042. Caution Caution - Only English is supported for the title. If you type in and apply the title in your native language, warning message pop sup to ask your retyping.
  • Page 142 - PTZ device It sets Camera ID, Protocol, Baud Rate, Parity, Data Bit, Stop Bit, and Serial Mode when connecting the dome camera to all the channels. # Monitoring - Monitoring It sets both the event monitoring and OSG display of the live mode. 9-38...
  • Page 143 SHR-2040/2041/2042 USER’S MANUAL $ Recording - Rec. Mode It sets the Video Size, Quality, and Rate values during the recording by the setting the recoding ON/OFF for the related channel in the live mode. NTSC 12.5 12.5 12.5 12.5 Note Note Full D1(L) Video Size does not support 15ips, 10ips (NTSC) / 12.5ips, and 8.33ips(PAL) Rate.
  • Page 144 - Event Rec. It sets the Video Size, Quality, Rate, Pre Alarm, and Post Alarm values to be recorded when an event occurs. NTSC Note Note Full D1(L) Video Size does not support 15ips, 10ips(NTSC)/12.5ips, and 8.33ips(PAL) Rate. 9-40...
  • Page 145 SHR-2040/2041/2042 USER’S MANUAL - Alarm Rec. It sets the information necessary for the alarm recording. Note Note More than one camera should be selected to apply the alarm. - Motion Rec. It sets the information necessary for the recording by the motion Detection. 9-41...
  • Page 146 - Video Loss Video Loss sets up the information on how to inform the user of Video Loss of SHR-2040/2041/2042. % Network - Password It sets the password for Admin and User when connecting with SHR-2040/2041/2042 through the network in Smart Viewer. Caution Caution - Network password should be composed of numeric and it can be input up to 8 digits.
  • Page 147 SHR-2040/2041/2042 USER’S MANUAL Note Note - The Delete key and the combination of Ctrl+C or Ctrl+V in the keyboard are not supported to the network password input. - Use the BACKSPACE key to delete the contents. Note Note - Default Admin Password is set to 654321. - Default User Password is set to 654321.
  • Page 148 Callback - You can set the Callback function of SHR-2040/2041/2042. - In the event of Alarm, Motion Detection, or Video Loss, set the IP address and port of PC where SmartViewer is installed to forward Callback messages. In failure of message forwarding, set the value for retrial. Transfer Protocol - You can change the transfer protocol setting value.

  • Page 149: Viewer Setup

    SHR-2040/2041/2042 USER’S MANUAL Note Note - SHR-2040/2041/2042 uses 4 ports for TCP connection. - The PORT number is flexible and 4 consecutive numbers are grouped for the change ( 554,555,556,557 558,559,560,561 ) - If you use the IP Router for network composition, you should allocate a protocol for SHR-2040/2041/2042.
  • Page 150 Video Recording ! Naming - Being connected to SHR-2040/2041/2042 in the monitoring or search mode, you can save the video displayed with .dvr file and name it. - If you set to “Camera No. + Serial No.”, the file name depends on the camera number and serial number.
  • Page 151 SHR-2040/2041/2042 USER’S MANUAL Sequence Time - When connecting with SHR-2040/2041/2042 in the monitoring mode, set the auto sequence time if the auto sequence is set. The time can be set from 10 to 20 minutes. OSD Display - Sets if OSD shall be displayed on each channel of Smart Viewer. - Whether you check “Enable”...

  • Page 152: Site Setup

    Site Setup - Click the [Site Setup] button for Site Setup. - The information of DVR(SHR-2040/2041/2042) or Site that you want to connect by Smart Viewer is set in the Site Setup. - Smart Viewer allows you to connect with DVR(SHR-2040/2041/2042) or Site registered only here.
  • Page 153 SHR-2040/2041/2042 USER’S MANUAL DVR List - The information of DVR(SHR-2040/2041/2042) that you want to connect by Smart Viewer is set in the DVR List. - You can register a new DVR(SHR-2040/2041/2042) or delete and edit the DVR(SHR-2040/2041/2042) selected from the registered list, and the name and IP / MAC Address of the registered DVR(SHR-2040/2041/2042) is displayed in DVR List.
  • Page 154 ! To add a new DVR(SHR-2040/2041/2042) - If you press the [New] button, the following window will pop up where you are able to add a new DVR(SHR-2040/2041/2042) information. 1. Network Modes - LAN - If DVR(SHR-2040/2041/2042) is connected to the LAN, set the network mode to LAN.
  • Page 155 SHR-2040/2041/2042 USER’S MANUAL 2.Network Modes - ADSL - If DVR(SHR-2040/2041/2042) is connected to the ADSL, set the network mode to ADSL. - If the ADSL connected to DVR(SHR-2040/2041/2042) uses Static IP, select Static IP in the Address Type and input the name and IP Address of DVR(SHR-2040/2041/2042).
  • Page 156 Note Note - The MAC address of DVR is written at the side label of the product. It is also found in the system information of DVR Menu. - If the DVR(SHR-2040/2041/2042) is connected to ADSL, the network bandwidth is low.
  • Page 157 SHR-2040/2041/2042 USER’S MANUAL # To Edit the old DVR(SHR-2040/2041/2042) - If you select a DVR(SHR-2040/2041/2042) in the DVR list to edit and press the [Edit] button, the following message box pops up. Press [OK] button to edit the DVR(SHR-2040/2041/2042). - When the DVR(SHR-2040/2041/2042) to edit is connected with the Smart Viewer, the following message box pops up and the DVR(SHR-2040/2041/2042) cannot be edited.
  • Page 158 Site List - You can register and control the many DVRs(SHR-2040/2041/2042) to be connected with the smart viewer at once with a site in the site list. You are allowed to register a new site ,and delete or edit the selected site in the registered list.
  • Page 159 SHR-2040/2041/2042 USER’S MANUAL @ To delete an old site or DVR(SHR-2040/2041/2042) - If you select a site or DVR(SHR-2040/2041/2042) in the site list for deletion and press the [Delete] button, the following message box pops up. Press the [OK] button to delete either site or DVR(SHR-2040/2041/2042). - When deleting the DVR(SHR-2040/2041/2042), it is deleted from the site composition but the DVR(SHR-2040/2041/2042) information is not deleted.
  • Page 160 - When the site to edit is connected with the Smart Viewer, the following message box pops up and the site cannot be edited. Be sure to cut the connection between the DVR(SHR-2040/2041/2042) and the Smart Viewer before you edit it. - If you select a DVR(SHR-2040/2041/2042) and press the [Edit] button, the following message box pops up and the DVR(SHR-2040/2041/2042) cannot be edited.
  • Page 161 SHR-2040/2041/2042 USER’S MANUAL S/W Version - If you press the [S/W Version] button, the smart viewer version, system requirements, and the version of DVR(SHR-2040/2041/2042) System S/W, being connected to the smart viewer, are displayed. - You can upgrade the on-line DVR(SHR-2040/2041/2042) System S/W remotely. You are authorized with S/W upgrade in an Admin authority only.
  • Page 162 Smart Viewer Version - Smart Viewer Version and system requirements are displayed. DVR Version SHR-2040/2041/2042 - DVR Version not only displays the connected DVR(SHR-2040/2041/2042) name if any DVR(SHR-2040/2041/2042) is being connected with Smart Viewer or the name of DVR(SHR-2040/2041/2042) composing a site if any DVR(SHR-2040/2041/2042) is being connected with the site but also displays DVR(SHR-2040/2041/2042) S/W version.
  • Page 163 SHR-2040/2041/2042 USER’S MANUAL @ Click the following button to open the “SHR-2040/2041/2042 Firmware” file in format. 2040/2041/2042 2040/2041/2042 # Press the [Upgrade] button to transmit a file to the selected DVR(SHR-2040/2041/2042) and start the upgrade of DVR(SHR- 2040/2041/2042) S/W. $ The progress of file transmission and upgrade is displayed at the bottom. Caution Caution Be sure to suspend all the DVR system functions in action such as recording, MENU,...

  • Page 164: Appendix

    Appendix...

  • Page 165: Product Specification

    SHR-4160N/P USER’S MANUAL Product Specification Item Details Remarks 32bit RISC CPU Memory SDRAM : 128MByte Flash : 16 MByte Embedded OS Broadcasting NTSC System Input Voltage 2040-DC 12V, AC 110-220(NTSC), AC 110-230(PAL) 2041/2042 - AC 110-220(NTSC) AC 100-230(PAL) Power Consumption 2040 : 30Watt, 2041 : 60Watt, 2042 : 51Watt Composite 16 Channel - 1.0Vp-p...
  • Page 166 Item Details Remarks Compression Video : MPEG4 Method Audio : ADPCM Resolution Quality Level Max Image Rate Very High 15ips(NTSC)/ CIF(C) High 25(PAL) 352X240(NTSC) Standard /352X288(PAL) Video Size & Very High Performance Half D1(N) High 15ips(NTSC)/ 720X288(NTSC) Standard 12.5(PAL) /720X288(PAL) Recording Very High 30ips(NTSC)/...
  • Page 167 SHR-2040/2041/2042 USER’S MANUAL Item Details Remarks Calendar Event - Normal, Schedule, Alarm, Motion, Video Loss Search Mode Date/Time Go to First Go to Last Backup Data Decoding Performance Video size Play Back Video size & 30ips(NTSC)/25ips(PAL) 30ips(NTSC)/25ips(PAL)/1CH Performance Half D1(N) 15ips(NTSC)/12.5ips(PAL) 15ips(NTSC)/12.5ips(PAL)/1CH Full D1(L) 30ips(NTSC)/25ips(PAL) 30ips(NTSC)/25ips(PAL)/1CH Full D1 is supported in the 1 ch mode only Single...

  • Page 168: The Specification Of Hdd And Peripheral Device

    Internal ATA HDD/IEEE1394/USB HDD I/F External HDD Maker RPM Capactity Interface Buffer Series Name Model No Remark SV12.03N Attached model i n shi p ment 120 GB 2MB SpinPoint V80 Samsung 5,400 Ultra ATA-133 SV1604N 160 GB 7,200 6Y120LO 120 GB DiamondMax Plus 9 Ultra ATA-133...

  • Page 169: Outline Drawings

    SHR-2040/2041/2042 USER’S MANUAL Outline Drawings [SHR-2040] [SHR-2041] 10-5...
  • Page 170 [SHR-2042] 10-6...

  • Page 171: Factory Default

    SHR-2040/2041/2042 USER’S MANUAL Factory Default This restores the Network information and preset values in SHR-2040/2041/2042 to the original state at the time of factory shipment. Factory Default will be done as follows; - Use System / Load Factory Default in MENU or, - If you hold on to the Mode button in Live Mode and keep pressing the CH5 button for 5 seconds, the system will return to the Factory default condition.
  • Page 172 Classification Detailed Items Factory Setup Duration Event Monitoring Date OSD Display Time Monitoring Title Status Spot Out Channel Spot Out Event Monitor Monitor Out Composite Out 1CH DVR Support Mode Record Mode Video Size Setup Quality Normal Rate 30ips(NTSC)/25ips(PAL) Continuous Recording Record Schedule Event Recording Video Size...

  • Page 173: Frame Specification For The Playback

    SHR-2040/2041/2042 USER’S MANUAL SHR-2040/2041/2042 Smart Viewer Frame Specification for the Playback NTSC FRAME Viewer Screen VIDEO SIZE RATE Split Mode Half D1(N) CIF (C) Nine-split 1 frame/sec 15 frame/sec Fore-split 15 frame/sec 15 frame/sec Single 15 frame/sec 15 frame/sec Half D1(N) CIF (C) Nine-split 10 frame/sec...
  • Page 174 FRAME Viewer Screen VIDEO SIZE RATE Split Mode Half D1(N) CIF (C) Nine-split 1 frame/sec 12.5 frame/sec 12.5 Fore-split 12.5 frame/sec 12.5 frame/sec Single 12.5 frame/sec 12.5 frame/sec Half D1(N) CIF (C) Nine-split 8.33 frame/sec 8.33 frame/sec 8.33 Fore-split 8.33 frame/sec 8.33 frame/sec Single 8.33 frame/sec...

  • Page 175: Troubleshooting(Faq)

    SHR-2040/2041/2042 USER’S MANUAL Troubleshooting(FAQ) 1. The system power is dead and LED in front of the system does not operate at all. - Please check the power connection. - Check the power voltage. - If all your efforts like above end up with nothing, check or exchange the power supply.
  • Page 176 7. The channel button does not operate in Live. - If the current screen is Event Monitoring, the channel button does not operate. Then, press the Alarm button to terminate the current screen and select a channel. 8. The cursor cannot reach Start during Calendar Search. - Please check both the channel and the date for play are left checked.
  • Page 177 SHR-2040/2041/2042 USER’S MANUAL 13. Smart Viewer in operation is disconnected. - If you change time, network setup, HDD format, Default Setup, or HDD attachment or detachment for SHR-2040/2041/2042 DVR, the current Smart Viewer will be automatically disconnected. - Check network connection. Smart Viewer, if disconnected from Network, will try reconnection up to 5 times.
  • Page 178 Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
