Real Time DVR
SHR-2160/2162/2080/2082 User's Manual
English

Advertisement

Table of Contents
loading

Related Manuals for Samsung SHR-2160

Summary of Contents for Samsung SHR-2160

  • Page 1 Real Time DVR SHR-2160/2162/2080/2082 User’s Manual English...

  • Page 2: Table Of Contents

    Contents Safety Regulations Before we start Standards Approvals Chapter 1 Overview 1. Introduction 2. Features 3. Part Names and Functions Chapter 2 Installation 1. Installation Environment Setup 2. Checking Product & Accessory 3. HDD Addition Chapter 3 Connecting with Other devices 1.
  • Page 3 Chapter 5 Menu Setup Before Use 1. System 5-12 2. Camera 5-16 3. Monitoring 5-18 4. Recording Mode 5-21 5. Event Record Mode 5-25 6. Record Schedule 5-27 7. Backup 5-28 8. Network 5-32 9. Network Setup Chapter 6 PTZ Camera Control 1.
  • Page 4 8. Monitoring Mode 9-53 9. Search Mode Appendix 10-1 1. Product Specification 10-4 2. HDD & Peripheral Device Specs 10-5 3. Outline Drawings 10-7 4. Factory Default 10-9 5. SHR-2160/2162/2080/2082 Smart Viewer Frame Specification for the Playback 10-11 6. Troubleshooting(FAQ) English...

  • Page 5: Safety Regulations

    Safety Regulations Please be sure to keep the following in mind for the right use of the product to pre-vent proprietary risk or damage. Do not use multiple plugs at once. This may cause abnormal heat generation or fire Do not put a vase, flowerpot, cup, cosmetics, medicine, or vessel with water around you.

  • Page 6: Before We Start

    [Battery] Changing the battery in the SHR-2160/2162/2080/2082 incorrectly may cause an explosion therefore you must use the identical battery that is being used in the SHR-2160/2162/2080/2082. The following are the specifications of the battery you are using now. -Normal Voltage : 3V -Normal Capacity : 220mAh -Continuous Standard Load : 0.2mA...

  • Page 7: Chapter 1 Overview

    Chapter 1 Overview English...

  • Page 8: Introduction

    SHR-2160/2162/2080/2082 USER’S MANUAL Introduction The Digital Video Recorder(DVR) compresses the 16 channel(SHR-2162/2160) / 8 channel(SHR-2082/2080) of camera video into MPEG4 data video file and the 4 channel of audio inputs into ADPCM data audio file in the real time to record them in the Hard Disk or retrieve them from the Hard Disk simultaneously.

  • Page 9: Features

    Features 16 / 8 CH Composite Input Connectors NTSC / PAL Video Source Compatible ( NTSC : SHR-2162, SHR-2160, SHR-2082, SHR-2080 SHR-2162N, SHR-2160N, SHR-2082N, SHR-2080N : SHR-2162P, SHR-2160P, SHR-2082P, SHR-2080P ) Able to record the CIF sized (NTSC - 352 x 240 / PAL - 352 x 288) video at the speed of...

  • Page 10: Part Names And Functions

    SHR-2160/2162/2080/2082 USER’S MANUAL Part Names and Functions [SHR-2160] [SHR-2162] Name Function Power LED Displays power on/off condition. Alarm LED lights on when an event occurs. HDD Access Displays Normal Access to HDD. Upon Access to HDD, LED repeats on and off.
  • Page 11 Name Function Displays the play screen of one channel and the live screen (small) of another channel as a PIP screen. Displays one channel play screen and MODE an 8-channel live screen. Split Screen Displays one channel play screen and Selection Button Mode an 12-channel live screen.
  • Page 12 SHR-2160/2162/2080/2082 USER’S MANUAL [SHR-2080] [SHR-2082] Name Function Power LED Displays power on/off condition. Alarm LED lights on when an event occurs. HDD Access Displays Normal Access to HDD. Upon Access to HDD, LED repeats on and off. Network LED Displays both network connection and data transmission conditions.
  • Page 13 Name Function Displays the play screen of one channel and the live screen (small) of another channel as a PIP screen. Displays one channel play screen and an 5-channel live screen. Mode Displays one channel play screen and an 8-channel live screen. AUDIO Audio Setup Sets the Audio On/Off.
  • Page 14 S-VIDEO S-VIDEO Video Signal Output Port NETWORK Network Connection Port - ALARM IN 1~16 (SHR-2160/2162) : Alarm Input Port - ALARM IN 1~8 (SHR-2080/2082) : Alarm Input Port ALARM - ALARM RESET IN : Alarm Reset Port - ALARM OUT1~4 : Alarm Output Port...

  • Page 15: Remote Control Unit

    Remote Control Unit Function Starts or ends the recording as the setup record RECORD setting in normal record mode. CD EJECT Opens/closes the CD-RW tray. (SHR-2082/2162) Selects single channel while in live mode. Used as a numeral input key in numeral input mode. 0 ~ 9 (For channel selection method, refer to footnote 1) Locks the record key.
  • Page 16 SHR-2160/2162/2080/2082 USER’S MANUAL - Remote Control Setup : From the setup menu: System Remote Control Device Remote Control : On/Off - System ID Setup : From the setup menu : System Remote Control Device System ID Footnote 1. How to operate the number keys (channel select)

  • Page 17: Chapter 2 Installation

    Chapter 2 Installation English...

  • Page 18: Installation Environment Setup

    SHR-2160/2162/2080/2082 USER’S MANUAL Installation Environment Setup Do not install DVR on the carpet or other soft material to prevent clogging of the air ventilator. To install DVR on the cabinet or rack, be sure to check the ventilation condition. You should pay attention to the following before you use the product.

  • Page 19: Checking Product & Accessory

    - Brackets are used to attach the product to the rack. Smart Viewer Software CD (PDF Manual included) Special Screws SHR-2160/2080 : 12 SHR-2162/2082 : 4 - Please keep special screws well to be used for HDD addition. 2 EA of RS-485/Alarm Terminal Block Remote Control Unit (R.C.U)

  • Page 20: Hdd Addition

    SHR-2160/2162/2080/2082 USER’S MANUAL HDD Addition SHR-2160/2080 HDD The user can add up to 3 HDDs to this product. However, there are many factors that can cause electrical shock, accidents, and malfunctioning of the device inside of the product. When the user does not correctly install or apply the proper settings, the device may not recognize the HDD or the device will not run.
  • Page 21 2. Remove the cover from the product. (Remove the cover by first lifting its back part upward after sliding the cover slightly backward.) English...
  • Page 22 SHR-2160/2162/2080/2082 USER’S MANUAL 3. There is a bracket (bracket-HDD) mounted on the right and left sides where you can mount the HDD, and you have to remove the screws that are holding the bracket that you want to mount an HDD onto.
  • Page 23 4. Remove the bracket-HDD from the product by separating the power supply cable, signal transmission cable (IDE cable), and fan cable then pulling it toward the center of the product to separate its fixed part from the bottom. English...
  • Page 24 SHR-2160/2162/2080/2082 USER’S MANUAL 5. When mounting an additional HDD, the primary master has to be mounted. Mount the HDD you want to add after setting the master/slave jumpers in the proper order. When adding one – Primary slave (add one When adding two –...
  • Page 25 7. Make sure that the bracket-HDD is mounted stably inside of the product, then connect the power supply cable, signal transmission cable (IDE cable), and fan cable to the HDD. 8. Check if there is any problem with connector or wiring inside of the product for connecting and mounting then close the cover.
  • Page 26 SHR-2160/2162/2080/2082 USER’S MANUAL SHR-2162/2082 HDD The user can add up to 2 HDDs to this product. However, there are many factors that can cause electrical shock, accidents, and malfunctioning of the device inside of the product. When the user does not correctly install or apply the proper settings, the device may not recognize the HDD or the device will not run.
  • Page 27 2. Remove the cover from the product. (Remove the cover by first lifting its back part upward after sliding the cover slightly backward.) 2-10 English...
  • Page 28 SHR-2160/2162/2080/2082 USER’S MANUAL 3. There is a bracket (bracket-HDD) mounted on the right and left sides where you can mount the HDD, and you have to remove the screws that are holding the bracket that you want to mount an HDD onto.
  • Page 29 4. Remove the bracket-HDD (A) from the product by separating the power supply cable, signal transmission cable (IDE cable), and fan cable then pulling it toward the center of the product to separate its fixed part from the bottom. Remove the bracket-HDD (B) by lifting it up after removing the screws.
  • Page 30 SHR-2160/2162/2080/2082 USER’S MANUAL 5. When mounting an additional HDD, the primary master has to be mounted. In general, HDD should be installed as the primary master of IDE, and the CD-RW drive should be installed as the secondary master of IDE.
  • Page 31 7. Make sure that the bracket-HDD is mounted stably inside of the product, then connect the power supply cable, signal transmission cable (IDE cable), and fan cable to the HDD. 2-14 English...
  • Page 32 SHR-2160/2162/2080/2082 USER’S MANUAL Primary HDD Secondary HDD 8. Check if there is any problem with connector or wiring inside of the product for connecting and mounting then close the cover. 9. Tighten cover mounting screws. (The left and right side each has 5 spots and back side ha...

  • Page 33: Chapter 3 Connecting With Other Devices

    Chapter 3 Connecting with other devices English...
  • Page 34 SHR-2160/2162/2080/2082 USER’S MANUAL Connecting the Video, Audio, and Monitor [SHR-2160/2162] English...
  • Page 35 [SHR-2080/2082] English...

  • Page 36: Connecting The Network

    SHR-2160/2162/2080/2082 USER’S MANUAL Connecting the Network Connecting to Internet through Ethernet(10/100BaseT) [SHR-2160/2162] Connecting to Internet through ADSL [SHR-2160/2162] English...
  • Page 37 Connecting to Internet through Ethernet(10/100BaseT) [SHR-2080/2082] Connecting to Internet through ADSL [SHR-2080/2082] English...

  • Page 38: Connecting The Usb

    - Wait until the USB device connected by hot plug is stabilized enough and click CONNECT in SHR-2160/2162/2080/2082 MENU before use. - USB port on the front and back of SHR-2160/2162/2080/2082 cannot be connected to same kinds of USB device. (For example, the case is that 2 CD-RW devices or 2 USB Memories are used by connection with the front and back of system.)

  • Page 39: Connecting The Alarm Input/Output

    Connecting the Alarm Input/Output The Alarm IN/OUT port in the back of SHR-2160/2162 is composed of the following elements. ALARM IN/OUT Connection Name Function - ALARM IN1 - ALARM IN2 - ALARM IN3 - ALARM IN4 - ALARM IN5 - ALARM IN6...
  • Page 40 SHR-2160/2162/2080/2082 USER’S MANUAL ALARM IN/OUT Connection [SHR-2160/2162] [SHR-2080/2082] English...
  • Page 41 The Alarm IN/OUT port in the back of SHR-2080/2082 is composed of the following elements. ALARM IN/OUT Connection Name Function - ALARM IN1 - ALARM IN2 - ALARM IN3 - ALARM IN4 - ALARM IN5 ALARM Input Port - ALARM IN6 - ALARM IN7 - ALARM IN8 On receiving an ALARM RESET signal, the...

  • Page 42: Connecting The Rs-485 Device

    SHR-2160/2162/2080/2082 USER’S MANUAL Connecting the RS-485 Device Connect the RS-485 Device through the back port of SHR-2160/2162. You can install and control the PTZ camera supporting the RS-485 communication. You can adopt either Half Duplex or Full Duplex method for the connection.
  • Page 43 Connect the RS-485 Device through the back port of SHR-2080/2082. You can install and control the PTZ camera supporting the RS-485 communication. You can adopt either Half Duplex or Full Duplex method for the connection. PTZ device SHR-2080/2082 Rear Half Duplex Type Data (–) Tx(–) Data (+)

  • Page 44: Chapter 4 Live

    Chapter 4 Live English...

  • Page 45: System Operation

    SHR-2160/2162/2080/2082 USER’S MANUAL System Operation Turn the power on and the following LOGO pops up on the screen. After the LOGO appears, all of LED in the front flickers 6 times to initialize the system for operation. Upon completion of normal initialization, the Live screen appears accompanying a beep sound.

  • Page 46: Live Screen Mode

    Live screen Mode Definition of Live Screen Icon The Live screen icons display the current setup and function status of each screen. V.Loss CAM_01 CAM_01 : Recording Icon Each icon represents Normal / Event (Alarm + Motion) / Schedule Recording. : Recording Video Size Icon Each icon represents the recording size of Normal / CIF.
  • Page 47 If there is no more video data input in the Video On, [V.Loss] appears in the channel. If you set Video On/Off to Off, [V.Off] will appear. Definition of Live Screen Mode SHR-2160 receives 16 live images and displays them in the following 9 modes. CAM_01 CAM_02 CAM_03 CAM_04...

  • Page 48: Selecting Live Screen Mode

    Selecting Live Screen Mode Each mode may be selected by [MODE Button] and [CH1 ~ CH16 Button] The following figure shows Live Mode of SHR-2160 after converted. The default is 16 Split Screen Mode. The 9 Split Screen mode default is [9Split 1] for [CH1 ~ CH9], [9Split 2] for [CH10 ~ CH16], and [9Split Screen change] for [9Split 1] and [9Split 2] alternatively.

  • Page 49: Live Channel Selection And Audio On/Off Setup

    SHR-2160/2162/2080/2082 USER’S MANUAL Live Channel Selection and Audio On/Off Setup In other split modes than Full Screen Mode and Auto Sequence Mode, you can choose a channel to be displayed in each split area on your own. In addition, the channel being set to Audio On can be turned to Audio On/Off in all Live Modes.

  • Page 50: Zoom Function

    Freeze and Zoom Freeze Function Freeze function pauses the video image in the Live Screen, it is only available in the Live Mode. You can set freeze to on or off with the [FREEZE] button. Zoom Function Zoom function enlarges the selected area to double size, and it is only available in the single mode.

  • Page 51: Event Monitoring

    SHR-2160/2162/2080/2082 USER’S MANUAL Event Monitoring Event monitoring displays the channel synchronized with a event on the screen when a special event (Sensor/Motion/Video Loss) occurs. Event monitoring On/Off and event duration setup is available in [Menu] [Monitoring] mode. If you set the event monitoring interval to 5 seconds and an event occurs at CH2 in the beginning as following figure, the system will display CH2 in the full screen for 5 second.

  • Page 52: Spot-Out Monitoring

    Spot-out monitoring Spot-out Monitoring has nothing to do with Live Screen Output, it monitors the full screen of a certain channel. If you select the Monitoring in the MENU, the one channel among CH1 ~ CH16 is output with a Spot-out or channels are output one by one at an interval as Auto Sequence Mode in the Live Mode.

  • Page 53: Chapter 5 Menu Setup

    Chapter 5 Menu Setup English...

  • Page 54: Before Use

    SHR-2160/2162/2080/2082 USER’S MANUAL Before Use Selection The yellow cursor shows the current window. Use the œ,ƒ,¦, ‹ key in the front to move the cursor to desired menu. If you press the “Enter” key with the cursor clicking on your desired menu, the system will enter the new mode.

  • Page 55: System

    System Date/Time/Language Setup ¦, ‹ Press the “Enter” key and the key to move to Y/M/D. œ, ƒ Use the key to change the date. Press the “Enter” key to come out of the mode. Time ¦, ‹ Press the “Enter” key and the key to move to H/M/S.
  • Page 56 SHR-2160/2162/2080/2082 USER’S MANUAL Note Note [Date/Time Change] Pressing “OK” after you change date and time, you will be asked by a pop-up window if you really confirm the change. Here, press ”Yes” to change the time. Since Date/Time does not change in backup process, be sure to stop the backup process before you change Date/Time.
  • Page 57 The Default Password is 4321. New Password This is used to change the system password inside SHR-2160/2162/2080/2082. You are allowed to create a password up to 4 digits. Press the “Enter” key and a channel button from 1~9,10(operates as 0) at the left. Press the “Enter” key after change to move to “New Password Confirm”.

  • Page 58: Load Factory Default

    SHR-2160/2162/2080/2082 USER’S MANUAL Load Factory Default It is used to initialize all the menu setup values. Video data recorded will not be deleted. Press “OK” in the confirmation window to start initializing. System Log System Log is used to check the important record by an administrator.

  • Page 59: Event Log

    System Log List System Start Starts the system. Time Change Changes the Date/Time. Login(Admin) Viewer Login (Admin) Load Factory Default Initializes the system. Logout(Admin) Viewer Logout (Admin) System Upgrade Changes the system S/W. Login(User) Viewer Login (User) Disk Full No Space in the HDD Logout(User) Viewer Logout (User) Backup Start...
  • Page 60 Note 1 Note 1 [Internal HDD] This is a physical hard disk connected with the IDE cable inside the SHR-2160/2162/2080/2082 main body, and stores data. [External HDD] This is a physical hard disk connected with the port and terminal in the back of the SHR-2160/2162/2080/2082 main body, and stores data.

  • Page 61: Hdd Setup

    Caution Caution [Device Erase] Data will not be deleted in the backup mode. Please be sure to stop the backup before you delete a data. In the recording mode, suspend the recording and delete a data. Caution Caution [USB S/W Upgrade] Download the software to upgrade at http://www.sec.co.kr, CCTV Part.

  • Page 62: Hdd Mode Setup

    SHR-2160/2162/2080/2082 USER’S MANUAL HDD Mode Setup HDD End Mode Stop : Stops recording when HDD is full during the recording. Overwrite : Deletes the original data and save a new data when HDD is full during the recording. HDD End Beep On : Beeps when the HDD is full in the recording mode.
  • Page 63 Remote control Device MENU for the use of Samsung system keyboard Device A Remote Control Device, being connected to the RS485 port. This is a private ID of SHR-2160/2162/2080/2082. This private ID is essential for SSC-2000 because SSC-2000 can control many SHR-2160/2162/2080/2082 DVRs.

  • Page 64: System Shutdown

    SHR-2160/2162/2080/2082 USER’S MANUAL System Shutdown Remote Control Device Terminates the work in action safely and turns the power off. Press “OK” in the confirmation window and plug out when you see “Safe to Power Off”. Caution Caution [System Shutdown] Power-off without terminating the system in the System Shutdown menu may incur improper motion like data loss and disk failure.

  • Page 65: Camera

    Camera The detailed Camera Menu items are as follows. Camera Config. Image On : Camera images from a selected channel appear. Off : Camera images from a selected channel disappear. Covert1 : Displays the information except for the Video information of selected channel. Covert2 : Does not display the any information.
  • Page 66 SHR-2160/2162/2080/2082 USER’S MANUAL Title You can name the camera of selected channel. If you press the [Enter] key, the Virtual keyboard will come out. ‹¤Virtual Keyboard If you move the cursor, you can type text by text. Up to 15 texts can be typed.

  • Page 67: Ptz Device

    It is supported by the PTZ device. The following protocols are now being supported. Samsung / Vic. / Pan. / AD / Phi. / Ern. / Pel-D / Pel-P / Vcl. / Dia. / Kal. Baurate Baurate is supported by the PTZ device. 600 / 1200 / 2400 / 4800 / 9600 / 19200 / 38400 Parity It is set to the one of None, Even, and Odd.

  • Page 68: Screen Setup

    SHR-2160/2162/2080/2082 USER’S MANUAL Screen Setup It is a window to set Brightness/Contrast/Color for the camera image of each channel. Put the cursor on the channel that you want to adjust and set Brightness/Contrast/Color. Once selected, the channel appears in the right PIP area. Use the œ or ƒ button to adjust the value from 0 to 100.

  • Page 69: Monitoring

    Monitoring Event Monitoring It is possible to set to Off / 3sec / 5sec / 10sec / 20sec / 30sec / Continuous. Off : Event Monitoring does not operate to turn to the screen where an event occurs. 3sec / 5sec / 10sec / 20sec / 30sec : Sets the duration time of screen in the Auto Sequence mode.
  • Page 70 SHR-2160/2162/2080/2082 USER’S MANUAL Image output You are not allowed to connect VGA OUT and Composite/S-Video OUT simultaneously. In other words, the user must choose either VGA output or composite/S-video output. Composite : Makes the output come out through the “Composite / S-Video OUT” port.

  • Page 71: Recording Mode

    Recording Mode Record mode Record mode menu’s detailed list is as follows. Record Quality & Auto Deletion Recording picture quality Sets the recording picture quality. You can set up from highest/high/normal/low Auto Deletion If you click the off button on the lower left-hand corner, you can select from on/off. If you select on, you can select the range of dates you can search by moving with the date selection button.
  • Page 72 SHR-2160/2162/2080/2082 USER’S MANUAL Record Rate & Video Size NTSC When you press the REC button in the front, it selects the record mode settings. Record/seconds Sets the recording frame rate. The frame rate is number of the recorded scenes per sec- ond.

  • Page 73: Event Record Duration

    Event Record Duration Pre-Event Pre-Event Section Event time Records the situation until Alarm is issued. Off : No recording 5sec / 10sec / 20sec / 30sec : The recording time options before Alarm issue Post-Event Post-Event Section Event time Records the situation since Alarm is issued. Off : No recording 5sec / 10sec / 20sec / 30sec / 1min / 3min / 5min / 10min / 20min : Sets the recording time after an event occurs.

  • Page 74: Event Record Mode

    SHR-2160/2162/2080/2082 USER’S MANUAL Event Record Mode Event record menu’s detailed list is as follows. 5-21 English...
  • Page 75 Alarm Detection Setup Off : Sensor does not operate. N.O(Normal Open) Sensor : Sensor remains open all the time and if closed, an alarm will be issued. (A Contact) N.C(Normal Close) Sensor : Sensor remains closed all the time and if open, an alarm will be issued.

  • Page 76: Motion Detection Setup

    SHR-2160/2162/2080/2082 USER’S MANUAL Motion Detection Setup Motion Detection Mode Off : Motion Detection does not operate On : Motion Detection operates. Area Selects the Motion Detection area. It is impossible to set 4 block rows(Up / Down / Left / Right) to allow them to be displayed in all monitors.
  • Page 77 Sensitivity Sets the sensitivity of motion detection. Sensitivity grade consists of Low Medium Very High in the ascending order. Alarm-Out Sets the Alarm-Out when Motion occurs. 5 Alarm Outs are supported. Select an alarm-out that you want to synchronize with the current motion channel. Multi-selection is possible.

  • Page 78: Record Schedule

    SHR-2160/2162/2080/2082 USER’S MANUAL Record Schedule This setup selects a time to record automatically. Selection by the day or by the time is available. The default value is set to “Event Record”. Press “CH >” copies the value of Channel 1 to all the channels.
  • Page 79 Schedule / Event Record On occurrence of Event, Continuous Recording is replaced with Event Recording Mode. Holiday If you press “Holiday”, a calendar pops up and you are able to designate holidays. Move to a date and press “Enter” to complete designation. Press “Enter”...

  • Page 80: Backup

    SHR-2160/2162/2080/2082 USER’S MANUAL Backup Backup If there is a device, the free space and the backup device is displayed. Select a date, time, and camera No. to backup, and press “Start”. When you change Start Date/Time or End Date/Time, free space keeps updated in the Free Space zone.

  • Page 81: Network

    ADSL(PPPoE) : When the main body is connected to the ADSL network with PPPoE. Bandwidth Designates the network speed to which the main body of SHR-2160/2162/2080/2082 is connected. Unlimited / 2 Mbps / 1 Mbps / 600 Kbps / 300 Kbps In case of ADSL, the bandwidth should be selected 600 Kbps or 300 Kbps.
  • Page 82 SHR-2160/2162/2080/2082 USER’S MANUAL Sets the IP address for the main body of SHR-2160/2162/2080/2082 to connect with the network. If the Connection Mode is set to Static IP, you shall type in IP yourself. If the connection mode is Dynamic IP or ADSL(PPPoE), the IP allocated by the DHCP server or ADSL company will be automatically displayed.
  • Page 83 Multicast / Unicast. The default value is 5. Note Note If you want to connect IP Router with the main body of SHR-2160/2162/2080/2082, you shall designate a port for SHR-2160/2162/2080/2082 in the IP Router setup menu. The main body of SHR-2160/2162/2080/2082 uses 4 ports for TCP communication.
  • Page 84 SHR-2160/2162/2080/2082 USER’S MANUAL Callback Settings The Callback function is used to forward a callback message to the IP where SmartViewer is in action in case Alarm, Motion Detection, or Video Loss event occurs. On/Off : Off is default but you may choose On.

  • Page 85: Network Setup

    Network Setup Port Setup for SmartViewer Connection The Port value for DVR registration of SmartViewer (Setup Site Setup) shall be as same as that of the set (TCP). If you want to use the IP Router, you shall forward the activated Port depending on the current setting value.

  • Page 86: Chapter 6 Ptz Camera Control

    Chapter 6 PTZ Camera Control English...

  • Page 87: Ptz Camera Control Mode

    If you succeed in entering PTZ Camera Control Mode, the PTZ symbol on the monitor screen will turn yellow from white while the PTZ button in front of SHR-2160/2162/2080/2082 will turn blue. PTZ Camera Control Mode supports Pan, Tilt, and Zoom operation.
  • Page 88 Other PTZ Camera Control Modes perform its control in a single screen. Press the channel selection button in the left front to select the PTZ setting channel and press the PTZ button. If you succeed in entering Single Screen PTZ Camera Control Mode, the PTZ symbol on the screen will turn yellow from white while the PTZ button will turn blue.

  • Page 89: Basic Operation Of Pan, Tilt, & Zoom

    When using a remote control device (SCC2000), it is possible to control the camera with the remote control limited to the Samsung protocol. (refer to SCC2000 user manual) If there is no PTZ control for 5 minutes from the DVR, PTZ mode is automatically cancelled.

  • Page 90: Preset Setup

    Memorizes up to 20 PTZ Camera positions at the moment. Note Note For AD Protocol PTZ Camera, this memorizes only 7 Presets. Press the Preset button in front of SHR-2160/2162/2080/2082 in Single Screen PTZ Camera Control Mode to set up Preset. TELE WIDE...
  • Page 91 SHR-2160/2162/2080/2082 USER’S MANUAL Move the cursor to right and press ENTER in PTZ Control Mode first. Then, press the “Enter” to run P/T/Z/ operation mode in the PIP screen and press the “Enter” again to cancel P/T/Z/ Motion Mode. Press Enter at the Position Name position to see Virtual Keyboard. Enter the type position name and press the “OK”...

  • Page 92: Camera Menu Setup

    Press the Preset button in front of SHR-2160/2162/2080/2082 in Single Screen PTZ Camera Control Mode to select Camera Menu. TELE WIDE VIEW PRESET Press the “Preset” button in front of SHR-2160/2162/2080/2082 to return to the upper menu from camera menu. English...

  • Page 93: Preset View

    SHR-2160/2162/2080/2082 USER’S MANUAL Preset View Preset setup allows your movement to a certain saved position of PTZ Camera. Press the VIEW button in front of SHR-2160/2162/2080/2082 in Single Screen PTZ Camera Control Mode to select Preset.(For example, Samsung Protocol) TELE...

  • Page 94: Other View

    Other View Press the “VIEW” button in front of SHR-2160/2162/2080/2082 in Single Screen PTZ Camera Control Mode to supply PTZ Camera. This is a very special function. Note Note Samsung, Pan., Pel.-P, or Pel.-D Protocol PTZ Camera supports this function.

  • Page 95: Chapter 7 Recording

    Chapter 7 Recording English...

  • Page 96: Rec (Normal Recording)

    SHR-2160/2162/2080/2082 USER’S MANUAL REC (Normal Recording) Pressing REC the button starts recording as set in the record mode. Then, REC LED lights on and a recording icon appears on the screen. During the recording in HDD, the front HDD LED blinks.

  • Page 97: Schedule Recording

    Schedule Recording While “Record Schedule” or “Schedule/Event recording” is selected in the Record Schedule menu, Schedule Recording automatically starts. Otherwise, Schedule Recording remains inactivated. During the Schedule Recording, Recording Icon appears on the screen. During the recording in HDD, the front HDD LED blinks. If the Event Recording is selected, the recording starts at the every event.

  • Page 98: Event Recording

    SHR-2160/2162/2080/2082 USER’S MANUAL Event Recording Alarm Detection Sensor operation mode in Alarm of Event Record menu shall be set to N.O (Normal Open) or N.C (Normal Close). Motion Detection Motion detection in the Event Recording menu shall be set to On.

  • Page 99: Chapter 8 Search And Play

    Chapter 8 Search and Play English...

  • Page 100: Before Use

    SHR-2160/2162/2080/2082 USER’S MANUAL Before Use Pressing the “SEARCH” button shows Search Menu on the screen as seen above. Calendar Search searches a video file by the use of a calendar at the desired time. Event Search searches a video file recorded by the occurrence of event.

  • Page 101: Calendar Search

    Calendar Search Be sure to select both the channel and the date to search. And press the [Start] button to search for the desired time. Use a calendar to search the video file of desired time. When you select the desired channel with the enter button and the ¦, ‹ button, the section of the date that has a recorded image is colored in blue for the selected channel.

  • Page 102: Event Search

    SHR-2160/2162/2080/2082 USER’S MANUAL Event Search Searches Normal Recording, Schedule Recording, Alarm Recording, Motion Recording, and V.Loss(Video Loss) Recording by the time. You shall select a channel to search to see the event information of the channel. On the basis of event information for each channel, the system searches a video file for the event.

  • Page 103: Date/Time Search

    Date/Time Search Use the Day/Time information to search a video file at the time as you desire. Up to 16channels can be searched at once. After you select a channel with the œ, ƒ, [Enter] button, the checkbox on the right of selected event number will be checked.

  • Page 104: Go To First Search

    SHR-2160/2162/2080/2082 USER’S MANUAL Go to First Search Searches the oldest one among recorded video files. Up to 16 channels can be searched at once. After you select a channel with the œ, ƒ, [Enter] button, the checkbox on the right of the selected channel number will be checked.

  • Page 105: Go To Last Search

    Go to Last Search Searches the latest one among recorded video files. Up to 16 channels can be searched at once. After you select a channel with the œ, ƒ,[Enter] button, the checkbox on the right of the selected channel number will be checked. Press the [Start] button want to start the search and to cancel.

  • Page 106: Backup

    SHR-2160/2162/2080/2082 USER’S MANUAL Backup First, select the backup device. Mark the data of device. Select the file name to backup, and the detail information of a file is displayed in the below. The [Previous] button shows the previous page. The [Next] button shows the next page.

  • Page 107: Playback

    Playback ‹ ¤ II In order to play data recorded on the HDD, press the play/pause button ( If you used the SEARCH button for playback just before, the system would remember the information of the played channel until you click the PLAY/PAUSE button( ‹...
  • Page 108 SHR-2160/2162/2080/2082 USER’S MANUAL Play screen mode: You can change play screen mode with the mode button and number buttons as the figure below. Single 8 +1 split 12 +1 split 15 +1 split Live channel Mode button Play channel Number buttons 16/9/4 split Single screen : Comes up when you select and play 1 channel in search.
  • Page 109 Play at Faster Speed ‹ ‹ If you press the LEFT or RIGHT button( ¦ ¦ ) during the playback, you will be able to see the screen at the x2, x4, x8, x16, x32, and x64 speed either forwardly or reversely.

  • Page 110: Smart Viewer

    Chapter 9 Smart Viewer English...
  • Page 111 Introduction Smart Viewer is a program that a general PC user is able to install SHR-2160/2162/2080/2082 to his PC to monitor the video and audio data in the real time through network without going to the site where SHR-2160/2162/2080/2082 is installed.
  • Page 112 (If the multicast is used, up to 6 users can connect.) With a Smart Viewer, you are allowed to connect to as many as 16 SHR-2160/2162/2080/2082s to monitor them simultaneously. Smart Viewer is optimized in the resolution of 1024X768. English...

  • Page 113: Pc Specification(Recommendation)

    VGA RAM 32Mb or higher DirectX 8.1 or higher Note Note Depending on Recording Rate, Video Size, and user’s PC specification set to SHR-2160/2162/2080/2082, the number of Smart Viewer playback frame varies. For the detailed specification, refer to Appendix 5. English...

  • Page 114: Smart Viewer Installation

    Smart Viewer Installation Smart Viewer Installation Put a Smart Viewer Program CD in CD-ROM and open the “Smart Viewer” folder in the CD. Run the “Setup.exe” file. English...
  • Page 115 SHR-2160/2162/2080/2082 USER’S MANUAL Click the “Next” button. If you agree with Smart Viewer License, click “Yes”. Designate a folder to install Smart Viewer in it and click “Next”. English...
  • Page 116 The system proceeds with setup file installation and system setup. Installation is complete. Click the “Finish” to terminate the installation. English...

  • Page 117: Smart Viewer Program Execution

    SHR-2160/2162/2080/2082 USER’S MANUAL Smart Viewer Program Execution Double-click the Smart Viewer icon in the background screen to run the program. English...

  • Page 118: Smart Viewer Initial Screen

    ^ These buttons select the window displays the event message and the window displays the connection condition of camera. & This window displays the event message from SHR-2160/2162/2080/2082 in the real-time. * These buttons display the status of current channel.

  • Page 119: Setup Mode

    SHR-2160/2162/2080/2082 USER’S MANUAL Setup Mode Initial Screen ! Button to select items for DVR Setup, Viewer Setup, Site Setup, and S/W Version setup. @ It shows what the selected Setup item can set up in detail. # button to terminate the setup window.
  • Page 120 - Viewer Setup : Allows you to set the various kinds of item concerning the operation of Smart Viewer. - Site Setup : Allows you to set SHR-2160/2162/2080/2082 information, that is SHR-2160/2162/2080/2082 name, IP Address, ID, and Password that you are going to contact through Smart Viewer or registers all the registered SHR-2160/2162/2080/2082s at a site for control.

  • Page 121: Dvr Setup

    SHR-2160/2162/2080/2082 USER’S MANUAL DVR Setup - Click the [DVR Setup] button for DVR Setup. - You can change remotely the setup items of SHR-2160/2162/2080/2082 Menu, being connected with Smart Viewer. - DVR Setup is composed of 5 items; System, Camera/Audio, Monitoring, Recording, and Network.
  • Page 122 Note For the detailed items of DVR Setup, refer to Chapter 5. - Password Sets the password for the control of SHR-2160/2162/2080/2082 Menu or SHR-2160/2162/2080/2082 key input. - Record lock During record setup, you can set up record lock and lock cancel.
  • Page 123 - If you change the Data/Time value, SHR-2160/2162/2080/2082 automatically cuts the connection with Smart Viewer to apply the new time setup. - Upon completing the new time setup for SHR-2160/2162/2080/2082, you are permitted to resume the connection with the Smart Viewer.
  • Page 124 - Language Language sets the language in which on-line SHR-2160/2162/2080/2082 will be expressed Note Note The change of language by the system language results in the change of language expression setup of SHR-2160/2162/2080/2082. In short, the language setup of Smart Viewer does not change.
  • Page 125 Sets the remote control to on/off. You can set the remote control’s ID to 0-99. Note Note If you install the remote control device to the main body of SHR-2160/2162/2080/2082 and activate the setup, PTZ control is not available in the Viewer. 9-15 English...
  • Page 126 @ Camera - Config. Config. sets Video, Audio On/Off, Camera Title, and Auto Sequence Time for each channel of on-line SHR-2160/2162/2080/2082. Caution Caution - Only English is supported for the title. If you type in and apply the title in your native language, warning message pop sup to ask your retyping.
  • Page 127 SHR-2160/2162/2080/2082 USER’S MANUAL - PTZ device It sets Camera ID, Protocol, Baud Rate, Parity, Data Bit, Stop Bit, and Serial Mode when connecting the dome camera to all the channels. # Monitoring - Monitoring It sets both the event monitoring and OSG display of the live mode.
  • Page 128 $ Recording - Rec. Qual. Auto Del. In this mode, you can set to normal (general recording) quality, event recording quality, and auto-delete. NTSC 9-18 English...
  • Page 129 SHR-2160/2162/2080/2082 USER’S MANUAL - Rec. Rate Video Size When recording in normal or event, you can set the rate (recording speed) and video size (resolution). The set video size here influences the setting of the normal and event recording rate.
  • Page 130 - Alarm Rec. It sets the information necessary for the alarm recording. Note Note More than one camera should be selected to apply the alarm. - Motion Rec. It sets the information necessary for the recording by the motion Detection. 9-20 English...
  • Page 131 % Network - Password It sets the password for Admin and User when connecting with SHR-2160/2162/2080/2082 through the network in Smart Viewer. Caution Caution - Network password should be composed of numeric and it can be input up to 8 digits.
  • Page 132 - Default Admin Password is set to 654321. - Default User Password is set to 654321. - IP Settings It sets the network connection method of SHR-2160/2162/2080/2082. SHR- SHR-2160/2162/2080/2082 supports the connection with Static IP, Dynamic IP, and ADSL(PPPoE). It can set the network bandwidth.
  • Page 133 SHR-2160/2162/2080/2082 USER’S MANUAL Callback - You can set the Callback function of SHR-2160/2162/2080/2082. - In the event of Alarm, Motion Detection, or Video Loss, set the IP address and port of PC where SmartViewer is installed to forward Callback messages. In failure of message forwarding, set the value for retrial.

  • Page 134: Viewer Setup

    Note Note - SHR-2160/2162/2080/2082 uses 4 ports for TCP connection. - The PORT number is flexible and 4 consecutive numbers are grouped for the change ( 554,555,556,557 558,559,560,561 ) - If you use the IP Router for network composition, you should allocate a protocol for SHR-2160/2162/2080/2082.
  • Page 135 Video Recording ! Naming - Being connected to SHR-2160/2162/2080/2082 in the monitoring or search mode, you can save the video displayed with * .dvr file and name it. - If you set to “Camera No. + Serial No.”, the file name depends on the camera number and serial number.
  • Page 136 - Sets if the smart viewer is automatically connected to SHR-2160/2162/2080/2082 or site at the initial operation. - If you check “Auto Connection On”, the names of SHR-2160/2162/2080/2082 and Site currently registered at the DVR/Site list will be displayed in the following list.

  • Page 137: Site Setup

    Site Setup - Click the [Site Setup] button for Site Setup. - The information of DVR(SHR-2160/2162/2080/2082) or Site that you want to connect by Smart Viewer is set in the Site Setup. - Smart Viewer allows you to connect with DVR(SHR-2160/2162/2080/2082) or Site registered only here.
  • Page 138 - The information of DVR(SHR-2160/2162/2080/2082) that you want to connect by Smart Viewer is set in the DVR List. - You can register a new DVR(SHR-2160/2162/2080/2082) or delete and edit the DVR(SHR-2160/2162/2080/2082) selected from the registered list, and the name and IP / MAC Address of the registered DVR(SHR-2160/2162/2080/2082) is displayed in DVR List.
  • Page 139 - If you press the [New] button, the following window will pop up where you are able to add a new DVR(SHR-2160/2162/2080/2082) information. 1. Network Modes - LAN - If DVR(SHR-2160/2162/2080/2082) is connected to the LAN, set the network mode to LAN. - If the LAN connected to DVR(SHR-2160/2162/2080/2082) uses Static IP, select Static IP in the Address Type and input the name and IP address of DVR(SHR-2160/2162/2080/2082).
  • Page 140 2.Network Modes - ADSL - If DVR(SHR-2160/2162/2080/2082) is connected to the ADSL, set the network mode to ADSL. - If the ADSL connected to DVR(SHR-2160/2162/2080/2082) uses Static IP, select Static IP in the Address Type and input the name and IP Address of DVR(SHR-2160/2162/2080/2082).
  • Page 141 @ Deletion of an old DVR(SHR-2160/2162/2080/2082) - If you select a DVR(SHR-2160/2162/2080/2082) in the DVR list for deletion and press the [Delete] button, the following message box pops up. Press the [OK] button to delete the DVR(SHR-2160/2162/2080/2082).
  • Page 142 # To Edit the old DVR(SHR-2160/2162/2080/2082) - If you select a DVR(SHR-2160/2162/2080/2082) in the DVR list to edit and press the [Edit] button, the following message box pops up. Press [OK] button to edit the DVR(SHR-2160/2162/2080/2082). - When the DVR(SHR-2160/2162/2080/2082) to edit is connected with the Smart Viewer, the following message box pops up and the DVR (SHR-2160/2162/2080/2082) cannot be edited.
  • Page 143 SHR-2160/2162/2080/2082 USER’S MANUAL Site List - You can register and control the many DVRs(SHR-2160/2162/2080/2082) to be connected with the smart viewer at once with a site in the site list. You are allowed to register a new site ,and delete or edit the selected site in the registered list.
  • Page 144 @ To delete an old site or DVR(SHR-2160/2162/2080/2082) - If you select a site or DVR(SHR-2160/2162/2080/2082) in the site list for deletion and press the [Delete] button, the following message box pops up. Press the [OK] button to delete either site or DVR (SHR-2160/2162/2080/2082).
  • Page 145 DVR list is added to the site selected in the site list. The DVR(SHR-2160/2162/2080/2082) set to ADSL cannot be added to the site. - You can add up to 4 DVRs(SHR-2160/2162/2080/2082) to a site and the DVR(SHR-2160/2162/2080/2082) composing the site can be deleted in the site list.
  • Page 146 DVR(SHR-2160/2162/2080/2082), your access will be denied. SHR216X-VO.7.4-20050520 ! Displays the smart viewer version and system requirements. @ Displays the version and name of DVR if any DVR(SHR-2160/2162/2080/2082) is being connected with the smart viewer. You are also able to upgrade remotely the on-line DVR(SHR-2160/2162/2080/2082) S/W.
  • Page 147 - DVR Version not only displays the connected DVR(SHR-2160/2162/2080/2082) name if any DVR(SHR-2160/2162/2080/2082) is being connected with Smart Viewer or the name of DVR(SHR-2160/2162/2080/2082) composing a site if any DVR(SHR-2160/2162/2080/2082) is being connected with the site but also displays DVR(SHR-2160/2162/2080/2082) S/W version.
  • Page 148 Be sure to suspend all the DVR system functions in action such as recording, MENU, backup, and playback before you upgrade the DVR(SHR-2160/2162/2080/2082) S/W. Never try to turn the DVR(SHR-2160/2162/2080/2082) power off during the S/W upgrade. The S/W upgrade requires about 5 minutes.

  • Page 149: Monitoring Mode

    2. Admin User Connection Failure - Where SHR-2160/2162/2080/2082 that you wish to connect to has been already occupied by other user in an Admin authority, you are authorized with access to SHR-2160/2162/2080/2082 concerned in a User authority.
  • Page 150 Note Note No more than 3 users, one Admin. authorized user and 2 User authorized users are allowed to access SHR-2160/2162/2080/2082 simultaneously.(In the case of multicast, 5 User authorized users are allowable.) Caution Caution Once occupied by 3 users( In the case of multicast, 6 users), SHR-2160/2162/2080/2082 does not permit more connection.
  • Page 151 SHR-2160/2162/2080/2082 USER’S MANUAL Time Information - As soon as you are connected to SHR-2160/2162/2080/2082, the current date, day, and time of SHR-2160/2162/2080/2082 will be displayed. - Otherwise, the current date, day, and time of your PC will be displayed. Connection Information - As soon as you are connected to SHR-2160/2162/2080/2082, the connection button will display connection status.
  • Page 152 # Clicking the speaker icon turns the audio of channel on or off. : Audio OFF : Audio ON If you turn the audio of a SHR-2160/2162/2080/2082 channel off, “Disable” will be displayed. : Audio Disabled For the Audio on channel now, use the following audio button to adjust the volume and set the mute.
  • Page 153 ‹ Setup Start / End (Local) : Start/Finish the Menu screen at SHR-2160/2162/2080/2082. ‹ Video Loss CH[N] : Video Loss at the N channel of SHR-2160/2162/2080/2082 encountered. ‹ Alarm Detection CH[N] : Alarm issued at the N channel of SHR-2160/2162/2080/2082.
  • Page 154 - Displays the connection condition of DVR and CAMERA in the list. Note Note [DVR Icon Color] ‹ Successfully connected to SHR-2160/2162/2080/2082, the icon turns yellow, otherwise, turns black. [DVR Icon Color] ‹ Connected to CAMERA for monitoring, the icon turns yellow.
  • Page 155 10,11,12,13,14,15,16 1,2,3,4,5,6,7,8,9(CH) - In Sixteen-Split Mode : 1,2,3,4,5,...,13,14,15,16 1,2,3,4,5,...,13,14,15,16 (CH) Note Note When connecting many DVRs (SHR-2160) with site, the sequence operates as follows. - In Single Mode : DVR1:1CH DVR1:16CH DVR2:1CH DVR2:16CH - In Quad Mode : DVR1:1,2,3,4CH DVR1:13,14,15,16CH...
  • Page 156 : When monitoring with Quad Mode : When monitoring with Single Mode : Camera Off Note Note The number in the screen icon indicates the screen position in SmartViewer. : The orange icon indicates the current channel is connected to a camera. : The gray icon indicates the current channel is connected to a camera but not displayed in the screen.
  • Page 157 1,2,3,4,5,6,7,8,9 (CH) - In Sixteen-Split Mode : 1,2,3,4,5,...,13,14,15,16 1,2,3,4,5,...,13,14,15,16 (CH) Note Note When connecting many DVRs (SHR-2160) with site, it operates the next action as follows. - In Single Mode : DVR1:1CH DVR1:16CH DVR2:1CH DVR2:16CH - In Quad Mode : DVR1:1,2,3,4CH...
  • Page 158 FAVORITE Button - If you press FAVORITE, the FAVORITE window will be activated. If you click the current FAVORITE, the cameras saved in the current setting value will be displayed in the screen. You may delete the selected FAVORITE or all FAVORITE setting values.
  • Page 159 SHR-2160/2162/2080/2082 USER’S MANUAL Video Recording Button - If you select a channel in the playback and click the “Save” button, the video will be saved in a file format with the extension of * .dvr in a designated folder of your...
  • Page 160 Note Note The PAN / TILT / ZOOM function is supported to all the cameras. But, POWER ZOOM is supported only by Samsung Smart Dome Camera, and assured to the operation of TILT below 45°. 9-50 English...
  • Page 161 The name of @,#, and $ functions varies depending on the camera and some cameras do not support these functions. - The Samsung camera supports all the functions and names. - The Panasonic camera supports all the functions, but with different names.
  • Page 162 # This is a button for the role of Enter. Note Note The Camera Menu Setup function is supported by Samsung and Panasonic camera only. Caution Caution As far as SHR-2160/2162/2080/2082 uses the PTZ camera control functions, Smart Viewer can not control PTZ Camera.

  • Page 163: Search Mode

    The initial screen of search mode - The search mode is divided into the remote mode to search and play the SHR-2160/2162/2080/2082 video and the local mode to play * .dvr file saved in the directory designated by your PC.
  • Page 164 USER authority. - Without the ADMIN authority, search is not accessible. Remote Mode - This mode transfers the video data recorded in SHR-2160/2162/2080/2082 by network for the playback. - Up to 4 channels are allowed for simultaneous search and playback.
  • Page 165 SHR-2160/2162/2080/2082 USER’S MANUAL Calendar Window - If the video data in on-line SHR-2160/2162/2080/2082 was recorded, the date turns red. - If you click the date in red, the saved video information is displayed. - The currently selected date will be marked with a thick red box.
  • Page 166 @ Backup Button - If not playback(Stop), the video save button performs the backup function. - If the save button is pressed, the window for backup pops up. - Set a Start/End tome for backup and select a file format to save. - The backup starts when the “Start”...
  • Page 167 SHR-2160/2162/2080/2082 USER’S MANUAL $ Print - This function outputs the screen zone of the playback video which is now being displayed. % Setup Mode Button - This button pops up the setup mode window. Play Buttons ! Play : Play...
  • Page 168 ! The channels being displayed in the playback screen will be activated in the white background. @ Time Line : The time information of video recorded in SHR-2160/2162/2080/2082. # Time Bar : Displays the current time of video being displayed in the playback screen.
  • Page 169 SHR-2160/2162/2080/2082 USER’S MANUAL Next Button - Changes the channel as the Next button does in the monitoring mode. Note Note You may not change the channel while playing an image (Play/Reverse Play/Fast Forward/Fast Backward). Reload Button - Updates the record time information in the calendar window and time line.

  • Page 170: Appendix

    Appendix English...

  • Page 171: Product Specification

    SHR-2160/2162/2080/2082 USER’S MANUAL Product Specification Specs Details Notes 32bit RISC CPU SDRAM : 64MByte Memory Flash : 16 MByte Operating System Embedded OS Broadcasting NTSC System AC 110~220(NTSC) Input Voltage AC 100~230(PAL) Power Usage 2160/2080 : 56W, 2162/2082 : 60W Composite 16(8) Channel - 1.0Vp-p...
  • Page 172 PAL : 0.8 / 1.6 / 3.1 / 6.3 / 12.5 / 25ips (True Recording ips: 0.781/1.563/3.125/6.25/12.5/25ips) SHR-2162/2082 : ATA HDD x 3(MAX) MAX HDD Size : 250GB x 3 = 750GB Internal SHR-2160/2080 : ATA HDD x 4(MAX) Save MAX HDD Size : 250GB x 4 = 1TB USB HDD External...
  • Page 173 SHR-2160/2162/2080/2082 USER’S MANUAL Specs Details Notes Calendar search Event search - Alarm, Motion, Video Loss Search Mode Date/time search Initial search Latest search Backup search Recording Specs Total Resolution 120/100i Resolution & 16Ch ps(CIF) Play Back Recording Specs 30ips(NTSC)/25ips(PAL) 7.5ips(NTSC)/6.3ips(PAL)

  • Page 174: Hdd & Peripheral Device Specs

    HDD & Peripheral Device Specs ATA HDD Maker Capacity Interface Buffer Series Name Model Name Remark 160GB 5400 IDE, P-ATA Spinpoint SV1604E Samsung 200GB 7200 IDE, P-ATA Spinpoint SP2014N 160GB 7200 IDE, P-ATA WD Caviar SE WD 1600 Western Digital...

  • Page 175: Outline Drawings

    SHR-2160/2162/2080/2082 USER’S MANUAL Outline Drawings [SHR-2160] [SHR-2162] 10-5 English...
  • Page 176 [SHR-2080] [SHR-2082] 10-6 English...

  • Page 177: Factory Default

    SHR-2160/2162/2080/2082 USER’S MANUAL Factory Default This restores the Network information and preset values in SHR-2160/2162/2080/2082 to the original state at the time of factory shipment. Factory Default will be done as follows; - Use System / Load Factory Default in MENU or, - If you hold on to the Mode button in Live Mode and keep pressing the CH5 button for 5 seconds, the system will return to the Factory default condition.
  • Page 178 Classification Detailed Items Factory Setup Duration Event Monitoring Date OSD Display Time Title Status Monitoring Spot Out Channel Spot Out Event Monitor Monitor Out Composite Out Play channel location Lower right-hand corner Multi-channel change 5 seconds Normal Quality Standard Record Quality & Auto Deletion Event Quality Standard Auto Deletion...

  • Page 179: Shr-2160/2162/2080/2082 Smart Viewer Frame Specification For The Playback

    SHR-2160/2162/2080/2082 USER’S MANUAL SHR-2160/2162/2080/2082 Smart Viewer Frame Specification for the Playback NTSC FRAME Viewer Screen VIDEO SIZE RATE Split Mode Half D1(N) CIF (C) 16-split 0.5 frame/sec 9-split 2.5 frame/sec 4-split 7.5 frame/sec Single 7.5 frame/sec Half D1(N) CIF (C) 16-split 0.25 frame/sec...
  • Page 180 Note The play frame specification of Smart Viewer varies on the setup of SHR-2160/2162/2080/2082 Recording Rate and Video Size or the screen split mode of Smart Viewer. The above specification is applicable only when the main body of SHR-2160/2162/2080/2082 is connected with a fast network like LAN. When the main body of SHR-2160/2162/2080/2082 is connected with a slow network like ADSL, the play speed will be 0.5 Frame/sec.

  • Page 181: Troubleshooting(Faq)

    SHR-2160/2162/2080/2082 DVR. 6. You cannot enter MENU by forgotten password. - If you forget the password, you shall reset SHR-2160/2162/2080/2082 DVR to the values set at the factory. Keep pressing both the "MODE" button and the "PTZ" button on the left for 5 seconds until LED lights on in the order of 1 2 3 4 5 The password default is "4321".
  • Page 182 Please consult with an expert who works for the shop where you bought the product. 13. You cannot connect to SHR-2160/2162/2080/2082 DVR through Smart View. - Check if 3 Smart Viewer users are in connection with SHR-2160/2162/2080/2082 DVR. SHR-2160/2162/2080/2082 DVR allows no more than 3 users’ connection with Smart Viewer at a time.
  • Page 183 5 times. If it remains unconnected after 5 time trial, it will automatically give up connection. - As far as SHR-2160/2162/2080/2082 DVR is connected to the ADSL network, you may be disconnected from Smart Viewer when the network conditions goes bad.
