Front View; Underside - MAXDATA PRO 800 IW User Manual

Front View

Underside

All air intake and
ventilation openings
must be kept free from
obstructions at all
times. If not, the device
is liable to overheat.
72
Fig. 7
(1) On/off button for WLAN
(2) Loudspeaker
(3) Ventilation slots
(1)
(2)
(3)
(4)
Fig. 8
Battery and battery release catch
Ventilation slots
System device cover
MiniCard slot cover (free)
System Overview
