Inserting the Battery

The battery is included in the notebook's shipping contents. This battery is only partially
charged.
Note that the charging time for the battery is 4-6 hours if the computer is switched off, or
6-10 hours if the computer is switched on.
It is absolutely essen-
tial to fully charge the
battery for initial op-
eration! Do not unplug
the power adapter
until the battery is fully
charged.

Removing the Battery

66
(1) Insert the battery into the battery slot in the direction
of the arrow. Gently push the battery until it locks into
place.
(2) The battery can now be charged.
(1) Slide the catch to the left and hold it in position.
(2) Slide the battery backwards to remove it from the holder.
You can now run the notebook with the power adapter alone!
Fig. 2
Fig. 3
Preparation
