TG8070-8090FX(e-e).book Page 1 Wednesday, August 1, 2007 9:26 AM
KX-TG8070
This unit is compatible with Caller ID and SMS. To use these features,
you must subscribe to the appropriate service of your service
provider/telephone company.
Charge the batteries for about 8 hours before initial use.
(For Czech and Slovakia)
This cordless telephone is possible to use according to General licence No.:
VO-R/8/08.2005-23 (for Czech), VPR-7/2001 (for Slovakia).
Please read these operating instructions before using the unit and save them for future
reference.
Operating Instructions
Digital Cordless Phone
KX-TG8070FX
Model No.
KX-TG8072FX
Digital Cordless Answering System
KX-TG8090FX
Model No.
Advertisement
Table of Contents
Related Manuals for Panasonic KX-TG8070FX
Summary of Contents for Panasonic KX-TG8070FX
-
Page 1: Operating Instructions
TG8070-8090FX(e-e).book Page 1 Wednesday, August 1, 2007 9:26 AM Operating Instructions Digital Cordless Phone KX-TG8070FX Model No. KX-TG8072FX Digital Cordless Answering System KX-TG8090FX Model No. KX-TG8070 This unit is compatible with Caller ID and SMS. To use these features, you must subscribe to the appropriate service of your service provider/telephone company. -
Page 2: Table Of Contents
TG8070-8090FX(e-e).book Page 2 Wednesday, August 1, 2007 9:26 AM Table of Contents Preparation Useful Information Introduction ......3 Using the belt clip . -
Page 3: Introduction
L In the event of problems, you should contact your equipment supplier in the first instance. Declaration of Conformity: L Panasonic Communications Co., Ltd. declares that this equipment is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC. -
Page 4: Accessory Information
L When replacing the batteries, use only 2 rechargeable AAA (R03) size nickel metal hydride (Ni-MH) batteries. We recommend using Panasonic rechargeable batteries (Model No. P03P). L Replacement batteries may have a different capacity from that of the supplied batteries. -
Page 5: Important Information
TG8070-8090FX(e-e).book Page 5 Wednesday, August 1, 2007 9:26 AM Preparation L Do not spill liquids (detergents, cleansers, etc.) onto the telephone line cord plug, or allow it to Important information become wet at all. This may cause a fire. If the telephone line cord plug becomes wet, General immediately pull it from the telephone wall jack,... -
Page 6: Controls
TG8070-8090FX(e-e).book Page 6 Wednesday, August 1, 2007 9:26 AM Preparation Notice for product disposal, transfer, or return Controls L This product can store your private/confidential information. To protect your privacy/confidentiality, we recommend that you Base unit (KX-TG8070/KX-TG8072) erase the information such as phonebook or caller list entries from the memory before you dispose, transfer or return the product. -
Page 7: Displays
TG8070-8090FX(e-e).book Page 7 Wednesday, August 1, 2007 9:26 AM Preparation Handset Using the navigator key Press {^}, {V}, {<}, or {>} to navigate through menus and to select items shown on the display. Adjusting the receiver or speaker volume Press {^} or {V} while on a call. {<} {>} Displays... - Page 8 TG8070-8090FX(e-e).book Page 8 Wednesday, August 1, 2007 9:26 AM Preparation Display icons (located at the bottom of the Soft keys display) The handset features 2 soft keys. By pressing a soft key, you can select the feature or operation Icon Meaning indicated by the soft key icon shown directly above Lower case when entering...
-
Page 9: Connections
TG8070-8090FX(e-e).book Page 9 Wednesday, August 1, 2007 9:26 AM Preparation Charger (KX-TG8072) Connections The charger can be mounted on the wall, if required. Base unit (KX-TG8070/KX-TG8072) (220–240 V, 25 mm 50 Hz) Hook Screws Note: L Never install telephone wiring during a lightning storm. -
Page 10: Battery Installation And Replacement
L When installing the batteries, avoid touching the battery ends (S, T) or the unit contacts. L When replacing batteries, we recommend using the Panasonic rechargeable batteries noted on page 4, 5. Press the notch on the handset cover firmly and slide it in the direction of the arrow. -
Page 11: Screen Saver Mode
– on a call – operating the answering system Panasonic Ni-MH battery performance (supplied batteries) To use the handset when it is in screen saver mode, activate the handset display again by:... - Page 12 {OK} “03:30PM” is displayed. L If you forget your PIN, consult your nearest {OK} i {i} Panasonic service centre. Note: Press {^} or {V} to select “Call Options”. L To correct a digit, press {<} or {>} to move the i {OK} cursor to the digit, then make the correction.
-
Page 13: C Making/Answering Calls
TG8070-8090FX(e-e).book Page 13 Wednesday, August 1, 2007 9:26 AM Making/Answering Calls ■ Storing a number into the handset phonebook: Making calls {^}/{V}: “Add Phonebook” i {OK} i Enter a name (15 characters max.; page Lift the handset and dial the phone number. 30). -
Page 14: Answering Calls
TG8070-8090FX(e-e).book Page 14 Wednesday, August 1, 2007 9:26 AM Making/Answering Calls R button Adjusting the handset ringer volume when Pressing {R} allows you to use special features of receiving a call your host PBX such as transferring an extension Press {^} or {V}. call, or accessing optional telephone services. -
Page 15: Phonebook
TG8070-8090FX(e-e).book Page 15 Wednesday, August 1, 2007 9:26 AM Phonebook Erasing entries Handset phonebook Find the desired entry (page 15). i {MENU} The handset phonebook allows you to make calls {^}/{V}: “Erase” or “Erase All” i {OK} without having to dial manually. You can add 200 {YES} i {i} names and phone numbers. -
Page 16: Handset Settings
TG8070-8090FX(e-e).book Page 16 Wednesday, August 1, 2007 9:26 AM Handset Settings Handset settings To customise the handset: {MENU} (right soft key) Select r by pressing {^}, {V}, {<}, or {>}. i {OK} Press {^} or {V} to select the desired item in the handset settings menu. i {OK} Press {^} or {V} to select the desired item in the sub-menu. - Page 17 TG8070-8090FX(e-e).book Page 17 Wednesday, August 1, 2007 9:26 AM Handset Settings Special instructions for display setup Handset names Each handset can be given a customised name (“Bob”, “Kitchen”, etc.), which is shown on the display in standby mode. This is useful when you have multiple handsets. The current handset number is displayed next to the handset name.
-
Page 18: Base Unit Settings
*3 If you change the PIN, please make note of your new PIN. The unit will not reveal the PIN to you. *4 If you forget your PIN, consult your nearest Panasonic service centre. -
Page 19: Caller Id Service
TG8070-8090FX(e-e).book Page 19 Wednesday, August 1, 2007 9:26 AM Caller ID Service Editing a caller’s phone number Using Caller ID service before calling back Important: L This unit is Caller ID compatible. To use Caller {^}/{V}: Select the desired entry. i {OK} ID features (such as displaying caller phone Edit the number. -
Page 20: Sms (Short Message Service)
TG8070-8090FX(e-e).book Page 20 Wednesday, August 1, 2007 9:26 AM SMS (Short Message Service) {^}/{V}: Select the desired centre number location (1-4). i {OK} Using SMS Add or edit the number as necessary. i SMS allows you to send and receive text {OK} i {i} messages between other fixed-line and mobile Note:... -
Page 21: Sending A Message
TG8070-8090FX(e-e).book Page 21 Wednesday, August 1, 2007 9:26 AM SMS (Short Message Service) {^}/{V}: “Outgoing” i {OK} Sending a message {^}/{V}: Select a message. i {READ} To send the message, press {MENU}. i {^}/{V}: “Send” i {OK} Writing and sending a new message {MENU} (right soft key) i h i {OK} Editing and sending a saved/failed {^}/{V}: “Create”... -
Page 22: Sms Setting
TG8070-8090FX(e-e).book Page 22 Wednesday, August 1, 2007 9:26 AM SMS (Short Message Service) {^}/{V}: “SMS Alert” i {OK} Replying to a message {^}/{V}: Select the desired setting. i {OK} While reading a received message, press i {i} {MENU}. {^}/{V}: “Reply” i {OK} L If “Use Last Text?”... -
Page 23: Answering System Features
TG8070-8090FX(e-e).book Page 23 Wednesday, August 1, 2007 9:26 AM Answering System Features {^}/{V}: “Answer On” or “Answer Off” i Answering system {OK} i {i} Note: L When the answering system is turned on, s is Available for: displayed on the top of the display. KX-TG8090 The answering system can answer and record calls for you when you are unavailable to answer... -
Page 24: Listening To Messages
TG8070-8090FX(e-e).book Page 24 Wednesday, August 1, 2007 9:26 AM Answering System Features {^}/{V}: Select the desired language. i – for the handset, press {<} {OK} i {i} Press again to play the previous message. ■ To skip a message: Playing back the greeting message –... -
Page 25: Remote Operation
TG8070-8090FX(e-e).book Page 25 Wednesday, August 1, 2007 9:26 AM Answering System Features Refer to following table and press the corresponding keys for operations. Remote operation Note: Using a touch-tone phone, you can call your phone L You can hang up at any time. number from outside and access the unit to listen to messages or change answering system Remote commands... -
Page 26: Answering System Settings
TG8070-8090FX(e-e).book Page 26 Wednesday, August 1, 2007 9:26 AM Answering System Features For voice mail service subscribers Answering system settings Please note the following: – To receive messages correctly with your voice Setting Default setting Page mail service, we recommend that you do not use the unit’s answering system. -
Page 27: Multi-Unit Operation
“Enter PIN” is displayed. Enter the base unit PIN (default: “0000”). i {OK} Operating additional units L If you forget your PIN, consult your nearest Panasonic service centre. Additional handsets L When the handset has been registered successfully, w will stop flashing. If the key... -
Page 28: Intercom Between Handsets
TG8070-8090FX(e-e).book Page 28 Wednesday, August 1, 2007 9:26 AM Multi-unit Operation L If you want to register the handset to other base L To switch between handset 2 and the unit(s), follow “Registering a handset to a base outside call, press {SWAP}. unit”, page 27. -
Page 29: Useful Information
TG8070-8090FX(e-e).book Page 29 Wednesday, August 1, 2007 9:26 AM Useful Information Using the belt clip Attaching the belt clip Removing the belt clip... -
Page 30: Character Entry
TG8070-8090FX(e-e).book Page 30 Wednesday, August 1, 2007 9:26 AM Useful Information Character entry The dial keys are used to enter characters and numbers. Each dial key has multiple characters assigned to it. You can select which character is entered by pressing a dial key repeatedly. –... -
Page 31: Error Messages
L Insert the correct base unit PIN. If you forget your base Wrong PIN! unit PIN, consult your nearest Panasonic service centre. L You entered the wrong remote access code in step 5, “Turning remote operation on”, page 25. Try again. - Page 32 TG8070-8090FX(e-e).book Page 32 Wednesday, August 1, 2007 9:26 AM Useful Information Problem Cause & solution w is flashing and “Searching...” is L The handset is too far from the base unit. Move closer. shown on the handset display. L The base unit AC adaptor is not connected. Check the connections.
- Page 33 Cancel unused handset registrations from the base unit (page 27). L You entered the wrong PIN. If you forget your PIN, consult your nearest Panasonic service centre. L Place the handset and the base unit away from other electrical appliances.
- Page 34 TG8070-8090FX(e-e).book Page 34 Wednesday, August 1, 2007 9:26 AM Useful Information Answering system (KX-TG8090) Problem Cause & solution The unit does not record new L The answering system is turned off. Turn it on (page 23). messages. L If you subscribe to the voice mail service, messages are recorded by your service provider/telephone company not your telephone.
-
Page 35: Specifications
TG8070-8090FX(e-e).book Page 35 Wednesday, August 1, 2007 9:26 AM Useful Information *4 Includes the AC adaptor. Specifications Note: L Specifications are subject to change. ■ Standard: L The illustrations used in these operating DECT (Digital Enhanced Cordless instructions may differ slightly from the actual Telecommunications), product. -
Page 36: Index
TG8070-8090FX(e-e).book Page 36 Wednesday, August 1, 2007 9:26 AM Index Registration: 27 Remote access code: 25 Index Ringtones: 16 SMS alert: 22 Additional base units: 27 SMS feature: 20 Additional handsets: 27 Speakerphone: 13 Answering calls: 14 Answering system: 23 Temporary tone dialling: 14 Language: 23 Transfer calls: 28... - Page 37 TG8070-8090FX(e-e).book Page 37 Wednesday, August 1, 2007 9:26 AM Notes...
- Page 38 TG8070-8090FX(e-e).book Page 38 Wednesday, August 1, 2007 9:26 AM Notes...
- Page 39 TG8070-8090FX(e-e).book Page 39 Wednesday, August 1, 2007 9:26 AM Notes...
- Page 40 Copyright: This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd. © 2007 Panasonic Communications Co., Ltd. All Rights Reserved.
