- Page 1 Installation Instructions / Warranty Uno² 38830XX1...
- Page 2 Technical Données techniques Information Recommended water Pression d’eau recommandée pressure Max. water pressure Pression d’eau maximum Recommended hot water Température recommandée d'eau temp. chaude Max. hot water temp Température maximum d'eau chaude Flow rate Capacité nominale Hole size in mounting Dimension du trou dans la surface surface de montage...
-
Page 3: Installation Considerations
Installation Considerations • For best results, Hansgrohe recommends that this unit be installed by a licensed, professional plumber. • Please read over these instructions thoroughly before beginning installation. Make sure that you have all tools and supplies needed to com- plete the installation. - Page 4 English Installation If the mounting surface is less than 1⅜", install the faucet with the gray plastic spacer, fiber washer, metal washer and mounting nut. If the mounting surface is greater than 1⅜", install the faucet without the spacer. If the mounting surface is greater than ⅜", install the shaft extension.
- Page 5 Français Installation Placez l'anneau d'étanchéite et le robinet sur la surface de montage. Installez la rondelle de plastique, la rondelle en fibre, la rondelle de friction, et l'écrou de montage. S l'épaisseur du comptoir dépasse 1⅜ po, ou si l'espace disponible est insuffisant, omettez la rondelle de plastique.
- Page 6 English Set the High Temperature Limit Stop (optional): 3 mm Remove the screw cover. Loosen the handle screw complete turns. Remove the handle. Remove the flange and the high temperature limit stop. Replace the high temperature limit stop so that the pin goes through the desired hole.
- Page 7 Français Réglage de la butée limite d’eau chaude (en option) Enlevez le cache-vis. Desserrez la vis de la poignée ( tours complets). Enlevez la poignée. Enlevez le capot sphérique. Enlevez la butée limite d’eau chaude. Remettez en place la butée limite d’eau chaude de sorte que l’onglet de la cartouche soit dans la fente voulue de la butée.
- Page 8 English Replace the flange. Replace the handle. Tighten the handle screw. Replace the screw cover.
- Page 9 Français Remettez le capot sphérique en place. Réinstallez la poignée. Serrez la vis. Installez le cache-vis. Español Reemplace la cobertura de tuerca. Reemplace el mando. Apriete el tornillo de mando. Instale la cobertura de tornillo.
- Page 10 Replacement Parts / Pièces détachées / Repuestos 7886XX0 6763XX0 3804XX0 676000 7884000 60000 70000 6764000 5008000 8600001 1388000 1361000 XX = colors / couleurs / acabados 00 = chrome 80 = steel optik...
- Page 11 Cleaning Recommendation for Hansgrohe Products Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning. Cleaning Materials for Faucets and Showers Acids are a necessary ingredient of cleaning materials for removing lime, however please pay attention to the following points when cleaning faucets and showers:...
- Page 12 Recommandations pour le nettoyage des produits Hansgrohe Les robinetteries modernes de lavabo, de cuisine et de douche utilisent des matériaux très différents pour répondre aux besoins du marché en termes de conception et de fonctionnalité. Certaines règles de base doivent être respectées lors du nettoyage de ces produits afin d’éviter de les endommager ou d’avoir à...
- Page 13 Recomendación de limpieza para los productos de Hansgrohe Hoy en día, las griferías de baño y de cocina así como duchas modernas se componen de materiales muy distintos para satisfacer las exigen- cias del mercado respecto al diseño y la funcionalidad. Para evitar daños reclamaciones hay que tener en cuenta ciertos aspectos tanto en el uso como en su limpieza posterior.
-
Page 14: Limited Lifetime Consumer Warranty
Limited Lifetime Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products which are purchased by a consumer in the United States after March 1, 16, and installed in either the United States or Canada. - Page 15 Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may have other rights which vary from State to State. You may be required by law to give us a reasonable opportunity to correct or cure any failure to comply before you can bring any action in court against us under the Magnuson-Moss Warranty Act.
- Page 16 Hansgrohe, Inc. • 140 Bluegrass Lakes Parkway • Alpharetta, GA 30004 Tel. 770-360-880 • Fax 770-360-887 www.hansgrohe-usa.com...
