Engine Compartment Layout - Sea Ray 290 Select EX Owner's Manual

G S E
ASOLINE INGLE NGINE
A
B
C
A: BILGE COMPONENT BOARD
B: STERN DRIVE POWER TRIM PUMP
C: BILGE BLOWER
D: TRANSDUCER
E: HIGH WATER BILGE PUMP FLOAT
SWITCH
F: BILGE PUMP FLOAT SWITCH
G: AUTOMATIC FIRE EXTINGUISHER
12
E C
NGINE OMPARTMENT
( . 12.1)
FIG
D E F
L
AYO U T
M
G H I
H: BILGE PUMP
I: HIGH WATER BILGE PUMP
J: TRIM TAB PUMP
K: HEAD SYSTEM OVERBOARD DISCHARGE
SEACOCK
L: FUEL TANK
M: BATTERIES
L
K
J
C
290 Select EX
