This owner's manual is arranged into two parts. Following is a description of each.
General Information
This section contains general information you need to know to safely operate
and maintain your boat.
Specific Information
This section contains information that is specific to your boat such as dimensions, general
arrangement, specific safety information, special features and the electrical system.
If any of these sections are missing from this book contact your dealer.
Your dealer can find out when it will be available and order it for you.
290 Amberjack
Owner's Manual Part Number: MRP 1803605

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 290 AMBERJACK and is the answer not in the manual?

Questions and answers

Robert Perovic
March 9, 2025

Back to back folding seat, replacement,genuine spare,price

0

Related Manuals for Sea Ray 290 AMBERJACK

Summary of Contents for Sea Ray 290 AMBERJACK

  • Page 1 If any of these sections are missing from this book contact your dealer. Your dealer can find out when it will be available and order it for you. 290 Amberjack Owner’s Manual Part Number: MRP 1803605...
  • Page 3 Sea Ray • Owner’s Manual Supplement 290 Amberjack • MRP #1803605 © Sea Ray Boats, Inc., Printed in the U.S.A. March 1999. Revised: June 2000, May 2002, May 2004, June 2005. Sea Ray Boats, Inc. 2600 Sea Ray Blvd., Knoxville, TN 37914.
  • Page 4 290 Amberjack...

  • Page 5: Table Of Contents

    (This book contains 79 pages.) ® ® Information in this publication is based upon the latest product specifications available at printing. Sea Ray Boats, Inc. reserves the right to make changes at any time, without notice, in the colors, equipment, specifications, materials and prices of all models, or to discontinue models.

  • Page 6: Warranty Information

    Sea for complete details. If for some reason the card is miss- ® dealer. ing, contact your Sea Ray dealer for a new one. To find a dealer in your area call: 1-800-SRBOATS. ONSTRUCTION...

  • Page 7: General Information

    EPAIR AND ARTS ACILITIES To find a Sea Ray ® dealer in your area, call: Sea Ray ® TORAGE Customer Service: 1-800-SRBOATS FAX: 1-314-213-7878 WET STORAGE PROCEDURES: Special care for boats that are moored: If permanently moored in salt water...

  • Page 8: Docking / Lifting / Trailering

    . 6.2) gunwales. Do not place slings where they may lift on underwater fittings. REFER TO THE ENGINE OWNER'S MANUAL IN THE OWNER'S PACKET FOR INSTRUCTIONS AND WARRANTY INFORMATION. STERN STERN CLEATS STERN EYE 290 Amberjack...

  • Page 9: General Arrrangements & Dimensions

    Holding Tank (opt.) ....28 gal (106 liters) Dead Rise ..............2 1 ° 10’ 6” (3.20 m) . 7.2) NTERIOR EATING 290 AJ S EATING (Adjustable Double Helm Seat w/Flip-Up Thigh-Rise Bolster, Fold Out Aft Seat, Portside Back-To-Back Lounger Seat) . 7.3) 290 Amberjack...

  • Page 10: Supplemental General Information

    THIGH RISE BOLSTER F U E L F U E L F I L L F I L L BAIT PREP STATION W/LIVE BAITWELL SYSTEM COCKPIT FOLD OUT AFT SEAT TRANSOM FISH BOX TRANSOM D O O R 290 Amberjack...

  • Page 11: Deck Occupancy Location

    1 2 3 4 5 6 7 8 9 1 2 3 4 5 DANGER . 9.1) TO AVOID RISK OF SERIOUS INJURY OR DEATH SHUT OFF ENGINE WHEN NEAR SWIMMERS OR PRIOR TO USING SWIM PLATFORM AND BOARDING LADDER. 290 Amberjack...

  • Page 12: Accessory Locations

    PANEL PORT STBD STERN STERN FOLD OUT AFT SEAT CLEAT CLEAT TRANSOM FISH BOX LIFTING/TIE DOWN EYE LIFTING/TIE DOWN EYE LIGHT MAIN BREAKER SWIM LADDER (UNDER LID) SHORE POWER DOCKSIDE WATER INLET HOT & COLD TRANSOM SHOWER (OPT) 290 Amberjack...

  • Page 13: Propulsion System

    Inboard V-Drive Engines: This system incorporates sacrifice acceleration and power. Your particular require- an inboard engine with an angled transmission that ® ments should be discussed with your Sea Ray dealer. allows the drive shaft to pass through the hull under the engine.

  • Page 14: Water Pump & Filter

    U.S. Coast Guard installed on all vessels shall be 290 Amberjack...
  • Page 15 DISCHARGE SEACOCK . 13.2) VACU-FLUSH HEAD PUMPOUT HOSE (ROUTE TO DECK PLATE) VENT HOSE (ROUTE FROM VENT FILTER ON HOLDING TANK TO THRU-HULL W/LOOP) HOLDING TANK (SHOWN W/OUT MACERATOR) PORT ROUTE TO VACU-FLUSH VACUUM STBD HOSE HEAD GENERATOR 290 Amberjack...
  • Page 16 ROUTE TO OVERBOARD DISCHARGE SEACOCK ROUTE TO HEAD ASTE ATER OUTING PORT IESEL RIVE ENERATOR STBD . 14.2) PUMPOUT HOSE (ROUTE TO DECK PLATE) VENT HOSE HOLDING TANK VACUUM GENERATOR ROUTE TO OVERBOARD DISCHARGE SEACOCK ROUTE TO HEAD 290 Amberjack...

  • Page 17: Live Baitwell System

    This option is available in conjunction with the dockside pumpout. BAIT- WELL PUMP DISCHARGE OF SEWAGE DIRECTLY OVER- BOARD IS FOR USE WHERE APPROVED ONLY. 290 Amberjack...
  • Page 18 BAITWELL THRU-HULL DRAIN BILGE HATCH CUTOUT FWD ENGINE . 16.2) BULKHEAD SEA WATER PUMP ROUTE TO LIVE BAITWELL GENERATOR MOUNTING BOARD (OPT) HOSE SEA WATER STRAINER WATER LINE ROUTE TO SEA WATER SEA WATER WASHDOWN SEACOCK PORT STBD 290 Amberjack...

  • Page 19: Bilge Layout

    M Fire Extinguisher GG Washdown Seacock (Opt) Bilge Light Salt Water O Bilge Pump Check Valves HH Washdown Strainer (Opt) High Water Float Switch Generator (Opt) Q Bilge Pump A/C Water Pump (Opt) Float Switch High Water Bilge Pump 290 Amberjack...
  • Page 20 Starboard Engine Strainer Q Starboard Engine JJ Starboard Fuel Tank Coolant Recovery Bottle KK Generator Fuel Filter (Opt) High Water Float Switch LL Sea Water Pump (Opt) Bilge Pump MM A/C Junction Box (Opt) Float Switch NN Forward Bilge Light 290 Amberjack...

  • Page 21: Fresh & Grey Water Line Routing

    STBD . 19.2) STBD VIEW ROUTE TO DECK PLATE ROUTE TO VENT W/LOOP TEMPERING VALVE ROUTE TO THRU- HULL W/LOOP WATER ENGINE HEATER BULKHEAD STBD PORT ROUTE ALONG STRINGER TO WATER TANK WATER ROUTE TO TANK STBD ENGINE 290 Amberjack...
  • Page 22 DRAIN ROUTE TO GALLEY SINK DRAIN ROUTE TO PORT SHOWER DRAIN SHOWER STBD SUMP RAIN OUTING . 20.3) ROUTE TO COCKPIT HATCH DRAIN STBD (TYPICAL PORT & STBD) PORT ROUTE TO THRU-HULL ROUTE TO FISH BOX CHECK VALVE 290 Amberjack...
  • Page 23 IESEL RIVE PTION ROUTE TO ENTERTAINMENT CENTER WATER PUMP SINK OR BAITWELL ROUTE AFT UNDER SHELF WATER HEATER ROUTE TO THRU-HULL TEMPERING VALVE (CLOSED COOLING SYSTEM ONLY) ROUTE TO ROUTE TO ROUTE AFT WATERTANK STARBOARD ENGINE UNDER SHELF 290 Amberjack...

  • Page 24: Electrical Installation

    ® ® Sea Ray dealer for service. Sea Ray reserves the right to change or update the electrical system on any model at any time without notice to the consumer and is NOT obligated to make any updates to units built prior to changes.

  • Page 25: Battery

    ® Sea Ray recommended batteries are available through DANGER ® your Sea Ray dealer. • Never use an open flame in the battery stor- ALWAYS DISCONNECT BATTERY CABLES age area. BEFORE DOING ANY WORK ON THE ENGINE’S ELECTRICAL SYSTEM OR ALTERNATOR WIRING •...
  • Page 26 ATTERY ABLE OUTING . 24.1) 290 Amberjack...
  • Page 27 ATTERY ABLE OUTING KAD 44 EDC/DP) OLVO . 25.1) 290 Amberjack...
  • Page 28 ATTERY ABLE OUTING (V-D RIVE PTION . 26.1) 290 Amberjack...
  • Page 29 ATTERY ABLE OUTING (V-D RIVE ENERATOR PTION . 27.1) 290 Amberjack...

  • Page 30: Battery Switch

    • A battery will explode if a flame or spark ignites the free hydrogen given off during charging. ATTERY WITCH OCATION TARBOARD . 28.2) EPENDING NGINE PTION BATTERY SWITCHES JUNCTION BLOCK (CENTER BEHIND DC BREAKER PANEL) MAIN DC BREAKER PANEL 290 Amberjack...

  • Page 31: Fuel System

    TANK TO DECK PLATE W/ STATIC GROUND CONNECTION The 290 Amberjack standard gasoline fuel system ELECTRONIC consists of two 115 gallon fuel tanks, fuel tank vents, SHUTOFF VALVE anti-siphon valves, engine fuel supply lines and fuel fills (see fig. 29.1 & 29.2).

  • Page 32: Fuel System

    ROUTE TO ENGINE FILTER FUEL LINE HOSE, PORT ROUTE TO ENGINE VIEW PORT STBD PORT TANK VIEW PORT TANK STBD EQUIPMENT LOCATIONS AND FUEL HOSE ROUTING MAY BE DIFFERENT THAN THOSE ILLUSTRATED DUE TO VARYING REQUIREMENTS FOR EQUIPMENT OPTIONS. 290 Amberjack...
  • Page 33 PTION ENERATOR . 31.1) FUEL VENT FUEL FILL FUEL LINE (GENERATOR RETURN) FUEL LINE (GENERATOR FEED) FUEL SHUT-OFF VALVE FUEL LINE (RETURN) FUEL FILTER FUEL LINE (FEED) FUEL LINE RETURN . 31.2) DANGER/NOTICE FUEL FILL FUEL FILL CAP 290 Amberjack...

  • Page 34: Exhaust System

    Refer to Section 2, Bilge and Underwater Gear, Seacocks are operating. Prior to every boat use, examine the and Strainers for information. exhaust system fittings to ensure tightness. NGINE XHAUST AYOUT (5.7L/350 M AGNUM RIVE PTION . 32.1) BYPASS OUTLET EXHAUST HOSES MUFFLER • DRAIN PLUG 290 Amberjack...

  • Page 35: Ventilation System/Bilge Blower

    The bilge blowers are located on the port side of the transom. ILGE LOWER NSTALLATION BILGE VENT DECK . 33.2 ) INSERT HULL TRANSOM SEPARATION BETWEEN INTAKE HOSES ROUTE FROM BILGE BLOWERS (PORT) BILGE BLOWER HOSES STBD BILGE BLOWERS PORT ROUTE FROM LOWER 1/3 OF BILGE 290 Amberjack...

  • Page 36: Bilge Pumping System

    NOT be left in the “MANUAL” mode unless the bilge PACKET FOR INSTRUCTIONS AND WARRANTY is being pumped out for servicing. INFORMATION. ILGE UMPING NSTALLATION . 34.1) PORT STBD HIGH WATER FLOAT SWITCH (RAISED FOR CLARITY) BILGE PUMP FLOAT SWITCH HIGH WATER BILGE PUMP 290 Amberjack...

  • Page 37: Manual Bilge Pump (Option)

    (see fig. 35.1). ANUAL ILGE NSTALLATION . 35.1) WHITE BILGE HELM SEAT FLEX HOSE BASE ROUTE TO THRU-HULL MANUAL ROUTE FROM BILGE PUMP PUMP TO PICKUP MANUAL BILGE DECK PUMP PICKUP TRANSOM HULL 290 Amberjack...
  • Page 38 TEERING HROTTLE HIFT ABLE OUTING . 36.1) SHIFT CONTROL STEERING AT THROTTLE HELM CONTROL BOX PORT STBD POWER ENGINE ENGINE STEERING UNIT 290 Amberjack...
  • Page 39 TEERING HROTTLE HIFT ABLE OUTING (V-D . 37.1) RIVE PTION PORT STARBOARD STARBPARD PORT PORT STARBOARD SHIFT ENGINE SHIFT ENGINE THROTTLE THROTTLE HYDRAULIC LINES 290 Amberjack...

  • Page 40: Fire Extinguishing System

    1. Make sure the seacock for the cooling pump is open. 2. Turn ON the AIR CONDITIONER PUMP/RELAY cir- cuit breaker on the main distribution panel. GROUND REFER TO THE OWNER'S MANUAL PACKET FOR INSTRUCTIONS AND WARRANTY INFORMATION. 290 Amberjack...
  • Page 41 CONDENSATE LINE FILTER TO UPPER GALLEY CABINET DUCT HOSE ROUTE UNDER GALLEY TOP TO HEAD GRILL DUCT HOSE ROUTE ALONG FWD BULKHEAD TO DIVERTER . 39.2) DUCT HOSE ROUTE OUTBOARD OF HANGING LOCKER TO UPPER DINETTE CABINET STBD PORT 290 Amberjack...
  • Page 42 WATER HOSE THRU-HULL A/C CONDENSATE ROUTE TO SHOWER SUMP PORT ROUTE FROM A/C STBD CONDENSATE DRAIN COMPONENT BOARD BILGE A/C JUNCTION LIGHT ENGINE A/C PUMP BULKHEAD A/C STRAINER A/C SEACOCK W/ HIGH SPEED PICKUP SPEED TRANSDUCER (OPT) DEPTH TRANSDUCER 290 Amberjack...
  • Page 43 A/C L (V-D OUTING RIVE PTION . 41.1) ENGINE BULKHEAD HOSE HOSE WATER INLET A/C SEACOCK A/C STRAINER A/C PUMP 290 Amberjack...

  • Page 44: Engine Cooling System

    REFER TO THE WINDLASS OWNER’S MANUAL IN THE OWNER’S PACKET FOR INSTRUCTIONS AND NCHORING RRANGEMENT WARRANTY INFORMATION. This sport cruiser maybe equipped with a optional windlass and anchor chute. Stow the anchor in the anchor storage when not in use. Note: Before using 290 Amberjack...

  • Page 45: Generator Information

    The is safely ventilated. generator is warranted separately by the generator 6. Gasoline Generator: Push “START/RUN” switch manufacturer, not Sea Ray ® . Follow the recommended to center position. A buzzer will sound until the gen- maintenance and warranty schedule in your Generator erator starts.

  • Page 46: Carbon Monoxide Monitor

    DC distribution panel. It is extremely important that you become totally familiar with your CO monitor and its functions. SEE THE OWNER’S HANDBOOK IN YOUR OWNER’S MANUAL PACKET FOR DETAILED INFORMATION AND OPERATING INSTRUCTIONS. 290 Amberjack...
  • Page 47 TO GENERATOR) GENERATOR) ENERATOR OUTING (V-D RIVE PTIONAL OUTLET TUBE EXHAUST HOSE . 45.2) GENERATOR MUFFLER EXHAUST HOSE (ROUTE TO GENERATOR-HOSE TO ROUTE FURTHER FORWARD FOR DIESEL GENERATOR) HOSE (ROUTE TO GENERATOR) GENERATOR STRAINER STBD PORT GENERATOR SEACOCK 290 Amberjack...

  • Page 48: Location Of Through-Hull Fittings

    OIL DRAIN TWIN LOCKER DRAIN ENGINE STERN DRIVE HULL DRAIN STOVE SUMP ENGINE EXHAUST BY-PASS PUMP VENT (OPTIONAL V-DRIVE) UTOUTS . 46.3) OVERBOARD TRANSDUCER GENERATOR SPEED LOG DISCHARGE (OPT) (OPT) INTAKE (OPT) BATWELL (OPT) SALT WATER WASHDOWN (OPT) 290 Amberjack...
  • Page 49 U L L I T T I N G S (V-D RIVE PTION . 47.1) ENGINE SEACOCK TRANSDUCER BATWELL (OPT) SALT WATER A/C (OPTION) WASHDOWN SHAFT LOG SHAFT LOG GENERATOR OPTION EXHAUST TUBE EXHAUST TUBE OVERBOARD DISCHARGE (OPT) RUDDER PORTS 290 Amberjack...

  • Page 50: Dash Layout

    THROTTLE WINDLASS (OPT) STERN CONTROL STATION DRIVE TRIM BREAKER PANEL SWITCHES DEPTH FINDER (RAYDATA OPT) DIESEL AUTO FIRE EXTING- UISHER GPS/LORAN OVERIDE (OPT) (OPT) VHF RADIO (OPT) DRINK HOLDER T R I M SPOTLIGHT TABS (OPT) ACCESS DOOR 290 Amberjack...
  • Page 51 SHIELD LIGHTS STBD W I P E R VENT ELECT- W I P E R RONICS ACCESS ALARM TEST CONSOLE DIMMER PRESSURE COOLANT TEMP ’ EFER TO THE ENGINE OWNER BATTERY MANUAL FOR ADDITIONAL INFORMATION PREHEAT CHECK ENGINES 290 Amberjack...

  • Page 52: Min Dc Breaker Panel Location

    OCATION . 50.1) STARBOARD PORT WINDLASS CONTROL CABIN MAIN STATION MAIN MERCATHODE/ ELECTRONICS VOLVO EDC MERCATHODE/ CONVERTER #2 VOLVO EDC FORWARD EMERGENCY CONVERTER #1 PUMP EMERGENCY SUMP PUMP BILGE PUMP BILGE PUMP STEREO MEMORY BLOWER #1 BLOWER #2 290 Amberjack...

  • Page 53: Ac & Dc Distribution Panel

    FOR GASOLINE OR VAPORS OPERATE BLOWERS FOR 4 MINUTES RUN BLOWER BELOW CRUISING SPEED ACCESSORY C.O. MONITOR MASTER IGNITION PORT STARBOARD I G N I T I O N PORT STARBOARD I G N I T I O N 290 Amberjack...

  • Page 54: Canvas Information

    WARRANTY INFORMATION. Sport Cruiser Canvas Placement (Note: Your Sport Boat May Not Be Equipped With All Of The Canvas Shown) ® With Sea Ray’s commitment to boating safety refers (fig. 52.1) you to the Owner’s Manual General Information Section located in the Owner’s Packet. One area in particular SUNBRELLA ®...

  • Page 55: Cabin & Cockpit Switch Location & Function

    O C AT I O N U N C T I O N . 53.1) GALLEY (BEHIND SINK) AC LIGHTS DC LIGHTS HEAD (FACE OF CABINET) LIGHTS INTERIOR LIGHTS MAIN (ENTRANCE) LIGHTS BAITWELL (INSIDE CABINET) BAITWELL/ BAITWELL WASHDOWN LIGHTS 290 Amberjack...

  • Page 56: Wire Harness Installation

    I R E A R N E S S N S T A L L A T I O N TERN RIVE NGINE ILGE ARNESS NSTALLATION . 54.1) STBD PORT 290 Amberjack...
  • Page 57 ROUNDING ARNESS NSTALLATION . 55.1) STBD PORT 290 Amberjack...
  • Page 58 Print #09-873, 1 of 2, REVISION #0 .56.2) PORT SPEAKER SPOT LIGHT VBERTH LIGHT #2 PORT NAV LIGHT GALLEY RECEPTACLE HORN 12V RECEPTACLE GALLEY SWITCHES MICROWAVE GALLEY GROUND BUSS STOVE REFRIGERATOR HEAD RECEPTACLE PORT STBD Print #09-873, 2 of 2, REVISION #0 290 Amberjack...
  • Page 59 . 57.2) DECK ROUTE TO CONTROL STATION SALON OVERHEAD LIGHT STBD WINDSHIELD WIPER WINDSHIELD VENT, MASTER LIGHT GALLEY GALLEY GROUND BUSS OVERHEAD LIGHT PORT GALLEY PORT WIND- SWITCHES SHIELD WIPER STBD Print #09-883, 1 of 1, REVISION #0 290 Amberjack...
  • Page 60 POILER ARNESS NSTALLATION . 58.1) GPS ANTENNA PORT SPOILER LIGHT MAST LIGHT STARBOARD SPOILER LIGHT VHF ANTENNA ROUTE TO GPS IN DASH ROUTE TO VHF IN DASH Print #09-877, 1 of 1, REVISION #0 290 Amberjack...
  • Page 61 A/C STRAINER STRAINER FORWARD BAITWELL/WASHDOWN GROUNDING BUSS SEACOCK STARBOARD ENGINE STRAINER STARBOARD ENGINE SEACOCK HULL CUT AWAY FOR CLARITY BAITWELL/WASHDOWN STRAINER A/C SEACOCK GENERATOR STRAINER GENERATOR SEACOCK TO AFT GROUNDING BUSS Print #09-203, 2 of 2, REVISION #0 290 Amberjack...
  • Page 62 ILGE ARNESS NSTALLATION (V-D . 60.1) RIVE 290 Amberjack...
  • Page 63 ILGE ARNESS NSTALLATION (V-D RIVE ENERATOR PTION . 61.1) 290 Amberjack...
  • Page 64 2 9 0 A J D C S C H E M AT I C (V-D RIVE PTION Print #09-599, 1 of 1, REVISION #0 290 Amberjack...
  • Page 65 2 9 0 A J D C S C H E M AT I C (V-D /4.2 L D-T RIVE RONIC IESEL PTION Print #09-600, 1 of 1, REVISION #0 290 Amberjack...
  • Page 66 I R I N G C H E M AT I C I R I N G C H E M AT I C Print# 09-601, 2 of 4, Revision #3 Print #09-601, 1 of 4, REVISION #1 290 Amberjack...
  • Page 67 2 9 0 A J D C W I R I N G C H E M AT I C Print# 09-601, 3 of 4, Revision #1 290 Amberjack...
  • Page 68 2 9 0 A J D C W I R I N G C H E M AT I C Print #09-601, 4 of 4, REVISION #7 290 Amberjack...
  • Page 69 4 . 2 L D - T C H E M AT I C I T H R O N I C I E S E L P T I O N Print #09-602, 1 of 3, REVISION #0 290 Amberjack...
  • Page 70 4 . 2 L D - T C H E M AT I C I T H R O N I C I E S E L P T I O N Print #09-602, 2 of 3, REVISION #0 290 Amberjack...
  • Page 71 2 9 0 A J D C S C H E M AT I C Print #09-602, 3 of 3, REVISION #01 290 Amberjack...
  • Page 72 2 9 0 A J D C S C H E M AT I C (W/V KAD 44 EDC/DP E OLVO NGINE Print #09-603, 1 of 2, REVISION #2 290 Amberjack...
  • Page 73 2 9 0 A J D C S C H E M AT I C (W/V KAD 44 EDC/DP E OLVO NGINE Print #09-603, 2 of 2, REVISION #2 290 Amberjack...
  • Page 74 2 9 0 A J C D C W A B I N I R I N G C H E M AT I C Print# 09-605, 1 of 2, Revision #3 290 Amberjack...
  • Page 75 2 9 0 A J C D C W A B I N I R I N G C H E M AT I C Print# 09-605, 2 of 2, Revision #3 290 Amberjack...
  • Page 76 2 9 0 A J M D C B A I N R E A K E R A N E L I R I N G C H E M AT I C Print #09-606, 1 of 1, REVISION #6 290 Amberjack...

  • Page 77: Wiring Schematics

    C H E M AT I C I T H O F R A N S A R L I N I N D L A S S P T I O N Print #09-614, 1 of 1, REVISION #0 290 Amberjack...
  • Page 78 E S T E R B E K E E N E R AT O R I G H O LTA G E I A G R A M Print# 09-618, 1 of 1, Revision#0 Print #09-630, 1 of 1, REVISION #0 290 Amberjack...
  • Page 79 C H E M AT I C ( 2 2 0 V / 5 0 H I T H E N E R AT O R P T I O N Print# 09-631, 1 of 1, Revision#0 Print #09-632, 1 of 1, REVISION #0 290 Amberjack...
  • Page 80 I A G R A M ( 2 2 0 V / 5 0 H Z W I T H E N E R AT O R Print #09-633, 1 of 1, REVISION #0 Print #09-640, 1 of 1, REVISION #0 290 Amberjack...

  • Page 81: International Homologations

    6. N.K.K. (Nippon Kaiji Kyokai) - Japan 7. B.S.I. (British Standards Institute) - England 8. Ministerio Obras Publicas Y Transporters - Spain 9. EC Directive - European Community ® Further information may be obtained from Sea Ray Customer Service. 1-800-SRBOATS. 290 Amberjack...
  • Page 82 290 Amberjack...
  • Page 83 2 9 0 A • D M B E R J A C K E C K C C U P A N C Y L A N WARNING WARNING Anchor should be independently se- WARNING cured to prevent accidental release. PERSONAL INJURY HAZARD When underway, keep passengers DO NOT STAND OR WALK...
  • Page 84 2 9 0 A • G & D M B E R J A C K E N E R A L R R A N G E M E N T S I M E N S I O N S 31’...
