USER'S MANUAL AND OPERATING INSTRUCTIONS
MODELS:
C
ANS Z83.7b-2009 CSA 2.14b-2009
Adequate ventilation must
be provided.
GHP Group, Inc.
8280 austin ave.
GHP
Morton grove, il 60053-3207
8280 Austin Avenue
M o r t o n G rove , I L .
6 0 0 5 3 - 3 2 0 7
Tel: ( 847 ) 324 - 5900
Fax: ( 847 ) 324 - 5901
Toll Free (877) GHP Group
( 8 7 7 ) 4 4 7 - 4 7 6 8
www.ghpgroupinc.com
GENERAL HAZARD WARNING
Failure To CoMply wiTh The preCauTionS and inSTruCTionS provided wiTh
ThiS heaTer, Can reSulT in deaTh, SeriouS Bodily injury and properTy loSS,
or daMage FroM The hazardS oF Fire, exploSion, Burn. aSphyxiaTion, CarBon
Monoxide poiSoning, and/or eleCTriCal ShoCk.
only perSonS who Can underSTand and Follow The inSTruCTionS Should
uSe or ServiCe ThiS heaTer.
iF you need aSSiSTanCe or heaTer inForMaTion SuCh aS an inSTruCTion
Manual, laBelS, eTCeTera, ConTaCT The ManuFaCTurer.
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768 8:30 a.m. – 4:30 pm CST, Monday – Friday
50-10-153
PROPANE TANK TOP
CONSTRUCTION HEATER
TT15CL, TT30CL,
TT15CDGP, TT30CDGP,
TT15CPDG, TT30CPDG
US
CONSUMER: retain this manual for future reference.
or email us at customerservice@ghpgroupinc.com
www.ghpgroupinc.com
Printed in China
Rev. 2012-05-15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TT15CPDG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GHP Group TT15CPDG

Summary of Contents for GHP Group TT15CPDG

  • Page 1 6 0 0 5 3 - 3 2 0 7 Tel: ( 847 ) 324 - 5900 Fax: ( 847 ) 324 - 5901 Toll Free (877) GHP Group ( 8 7 7 ) 4 4 7 - 4 7 6 8 www.ghpgroupinc.com...

  • Page 3: Table Of Contents

    6 0 0 5 3 - 3 2 0 7 Tel: ( 847 ) 324 - 5900 Fax: ( 847 ) 324 - 5901 Toll Free (877) GHP Group ( 8 7 7 ) 4 4 7 - 4 7 6 8 www.ghpgroupinc.com...

  • Page 4: Specifications

    IGNITION
 Model BTU
OUTPUT
(high) TIME
(20
IB.
 TYPE PRODUCT PACKAGED CYLINDER) TT15CL 15,000 Match 28
Hrs.
(high) 2.52
lbs
/
1.14
kg 3.37
lbs
/
1.53
kg TT15CDGP 15,000 Match 28
Hrs.
(high) 2.52
lbs
/
1.14
kg 3.37
lbs
/
1.53
kg TT15CPDG 15,000 Piezo 28
Hrs.
(high) 2.62
lbs
/
1.19
kg 3.48
lbs
/
1.58
kg TT30CL 30,000 Match 14
Hrs.
(high) 5.19
lbs
/
2.35
kg 6.58
lbs
/
2.98
kg TT30CDGP 30,000 Match 14
Hrs.
(high) 5.19
lbs
/
2.35
kg 6.58
lbs
/
2.98
kg TT30CPDG 30,000 Piezo 14
Hrs.
(high)

  • Page 5: Product Features

    PROPANE TANK TOP HEATER GENERAL SAFETY INSTRUCTIONS accidents are always tragic especially because so many of them could have been prevented with little care and judgment. There are some basic good practices, we hope you will follow for safe use of your heater. IMPORTANT SAFETY INFORMATION •...

  • Page 6: Heater Assembly

    PROPANE TANK TOP HEATER TT30 SERIES HEATER ASSEMBLY Tools Required: Estimated Assembly Time: Contents: phillips head screwdriver 5 minutes Tank Top Heater (1) Tank Collar Bracket (1) M4x12 Machine Screws (2) DUAL BURNER MODEL The tank collar bracket must be assembled before the heaters can be attached to the propane tank. 1.

  • Page 7: Wiring Diagram

    PROPANE TANK TOP HEATER WIRING DIAGRAM eleCTrode black earth yellow TherMoCouple yellow M,p,u SaFeTy valve...

  • Page 8: Refilling The Propane Gas Tank

    PROPANE TANK TOP HEATER PROPANE SUPPLY This heater requires a 20 lb propane cylinder for operation. (not included). The propane (LP) gas tank must also be equipped with the following: • A collar to protect the propane gas valve. • A shutoff valve terminating a Propane gas cylinder valve outlet as specified in the American National Standard for Compressed gas Cylinder valve outlet and inlet Connections.
  • Page 9 PROPANE TANK TOP HEATER CONNECTING HEATER TO PROPANE TANK Read and understand all safety information before connecting heater to propane tank. 1. (Applies to dual burner models only). Place heater onto tank with tank collar bracket over tank collar (Fig. 1) Mounting bolt knob should be positioned to the outside of tank collar and be positioned as closely as possible directly opposite to the cylinder valve outlet.
  • Page 10 PROPANE TANK TOP HEATER PROPANE TANK TOP HEATER CONNECTING HEATER TO PROPANE TANK CONNECTING HEATER TO PROPANE TANK FIGURE 2 FIGURE 2 electrode Spark Plug TT30 SERIES TT30 SERIES Tip over Switch Tip Over Switch Inlet Connector inlet Connector piezo (noTe: some models only) Piezo Propane Tank Valve (NOTE: some models only)

  • Page 11: Checking For Leaks

    PROPANE TANK TOP HEATER CHECKING FOR LEAKS Check all gas connections with a 50/50 soap and water solution to be sure they are tight and leak proof. The formation of bubbles indicate a gas leak. Correct all leaks before using the heater. •...
  • Page 12 PROPANE TANK TOP HEATER LiGHTiNG iNsTRUcTiONs WHEN UsiNG MaTcH (cONTiNUED) FIGURE 4 1. Open Cylinder valve by turning counterclockwise Burner Front 2. Turn heater regulator knob clockwise to the electrode “High” ( ) position. (Fig. 4) WARNING: stand to the side of unit while ignition hole lighting.
  • Page 13 PROPANE TANK TOP HEATER TURNING OFF THE HEATER 1. Tightly close propane tank valve by turning fully clockwise 2. Turn the heater regulator knob to the “OFF” ( ) position. wait at least 30 minutes for the heater to cool before handling heater.
  • Page 14 PROPANE TANK TOP HEATER LiGHTiNG iNsTRUcTiONs FOR PiEzO iGNiTiON MODELs (cONTiNUED) 1. Stop! Read all safety information first. 2. Open cylinder valve by turning counterclockwise WARNING: stand to the side of unit while lighting. Do not stand or have any part of your body over or in front of heater while lighting.

  • Page 15: Maintenance

    PROPANE TANK TOP HEATER LIGHTING UNDER WIND CONDITIONS when using this heater outdoors on a windy day, it will be necessary to use a match or long stem butane lighter to ignite the burner. It may be difficult to keep the match lit long enough under windy conditions. Follow the “Lighting instructions when Using a Match”...

  • Page 16: Troubleshooting

    2. Ignitor
misaligned
with
Thermocouple
shield 2. Realign
ignitor
with

thermocouple
shield. 3. Wire
frayed
or
damaged. 3. Replace
wire. 5. Flames
flashback/burn
inside
 1. Debris
or
spider
webs
in
mixing
tube. 1. Clean
burner
tube
with
bottle
brush,
rinse
in
water the
mixing
tube
and
drain
thoroughly
before
reintsalling. 2. Clogged
orifice 2. Remove
and
clean
using
compressed
air. REPLACEMENT PARTS LIST Part
Number ITEM DESCRIPTION TT15CPDG TT15CL/TT15CDGP TT30CPDG TT30CL/TT30CDGP Regulator
Assembly TYQ‐14A TYQ‐14A TYQ‐14A TYQ‐14A Burner
Assembly TT15‐00‐01 TT15‐00‐01 TT15‐00‐01 TT15‐00‐01 Thermocouple
Assembly...
  • Page 17 PROPANE TANK TOP HEATER PROPANE TANK TOP HEATER REPLACEMENT PARTS ILLUSTRATION REPLACEMENT PARTS ILLUSTRATION TT15 SERIES TT15 SERIES TT30 SERIES TT30 SERIES...
  • Page 18 ThiS page inTenTionally leFT Blank.

  • Page 19: Warranty

    This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any defect in materials and workmanship for a period of one (1) year from the date of retail sale. GHP Group, Inc., at it’s option, will either provide replacement parts or replace or repair the unit, when properly returned to the retailer where purchased or one of our service centers as directed by GHP Group, Inc., within one (1) year of retail purchase.

  • Page 20: Warranty Registration

    6 0 0 5 3 - 3 2 0 7 Tel: ( 847 ) 324 - 5900 Fax: ( 847 ) 324 - 5901 SAVE THIS CARD! Toll Free (877) GHP Group ( 8 7 7 ) 4 4 7 - 4 7 6 8 www.ghpgroupinc.com Place...

This manual is also suitable for:

Tt30cpdgTt15clTt30clTt15cdgpTt30cdgp
