GHP Group RMC-KFA650TDGD User's Manual And Operating Instructions

Kerosene portable forced air heaters

Advertisement

Quick Links

INDOOR/OUTDOOR PRODUCTS
KEROSENE PORTABLE
FORCED AIR HEATERS
"USER'S MANUAL AND

OPERATING INSTRUCTIONS"

COMPLIES WITH
ANSI A10.10-1998
CAN/CSA/B140.0-03 AND CSA
B140.8-1967
MODEL : RMC-KFA650TDGD
Before the first use of this heater, please read this USER'S MANUAL very
carefully. This USER'S MANUAL has been designed to instruct you as to
the proper manner in which to assemble, maintain, store, and most
importantly, how to operate the heater in a safe and efficient manner.
Please keep this manual for future reference.
CONSUMER : Retain this manual for future reference.
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768 8:30 a.m. - 4:30 pm CST, Monday - Friday.
or email us at customerservice@ghpgroupinc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RMC-KFA650TDGD and is the answer not in the manual?

Questions and answers

Summary of Contents for GHP Group RMC-KFA650TDGD

  • Page 1: Operating Instructions

    ANSI A10.10-1998 CAN/CSA/B140.0-03 AND CSA B140.8-1967 MODEL : RMC-KFA650TDGD Before the first use of this heater, please read this USER’S MANUAL very carefully. This USER’S MANUAL has been designed to instruct you as to the proper manner in which to assemble, maintain, store, and most importantly, how to operate the heater in a safe and efficient manner.
  • Page 2: Risk Of Electric Shock

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! DANGER: IMPROPER USE OF THIS HEATER CAN RESULT IN SERIOUS INJURY OR DEATH FROM BURNS, FIRE, EXPLOSION, ELECTRICAL SHOCK AND/OR CARBON MONOXIDE POISONING. WARNINGS: 1. RISK OF INDOOR AIR POLLUTION! 0 Use this heater only in well ventilated areas. Provide at least a three-square foot (2,800 sq. cm.) opening of fresh outside air for each 100,000 BTU/hr.
  • Page 3 2. FEATURES Upper Shell Front Handle Hot Air Outlet Shell Lower Fan Guard Fuel Gauge Fuel Cap Lamp Power Cord Thermostot Knob Room Temp. Display Power/Reset Switch Fuel Drain Bolt Wheel Figure 1. RMC-KFA650TDGD MODEL...
  • Page 4: Unpacking And Assembly

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 3. UNPACKING AND ASSEMBLY 1. REMOVE THE HEATER AND ALL PACKING MATERIALS FROM THE BOX. (See Fig.2) NOTE: Save the shipping carton and packing materials for future storage. Wheels Cap Nuts Bushings Threaded Axle Harware Kit HW-KFA1020 Figure 2.
  • Page 5 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Front Handle Screw Wheel Cap Nut Axle Bushing Figure 3. Assembling Handle & Wheel and Cord wrap 4. KEROSENE (1-K) For optimal performance of this heater, it is strongly suggested that 1-K kerosene be used. 1-K kerosene has been refined to virtually eliminate contaminants, such as sulpher.
  • Page 6: Fueling Your Heater

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 5. OVERVIEW OF HEATERS DESIGN Fuel System: This heater is equipped with a Fuel pump(Gear)that pulls fuel through the fuel line connected to the fuel tank and then pushes fuel through a filter and a solenoid valve and out the burner head nozzle.
  • Page 7: To Start Heater

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 7. UTILISATION A.) VENTILATION RISQUE DE POLLUTION DE L’AIR INTÉRIEUR/UTILISEZ L’APPAREIL DE CHAUFFAGE UNIQUEMENT DANS DES ENDROITS BIEN VENTILÉS. Afin de laisser penetrer l’air frais exterieur, prevoyez une ouverture minimum de 2 800 cm2 (3/4 pi2) par 100 000 BTU/h de debit calorifique.
  • Page 8: To Stop Heater

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! TO STOP HEATER CAUTION ; Never unplug heater while heater is running Heater must go through cooling cycle. The cooling cycle cools the combustion chamber. Damage to heater can occur if combustion chamber is not cooled.
  • Page 9: Long Term Storage Of Your Heater

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 8. LONG TERM STORAGE OF YOUR HEATER 1. Remove fuel drain bolt from rear bottom side of fuel tank using 3/4” socket or adjustable wrench and drain. 2. Using a small amount of kerosene, swirl and rinse the inside of the tank. NEVER mix water with the kerosene as it will cause rust inside the tank.
  • Page 10: Maintenance

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 9. MAINTENANCE WARNING!! NEVER SERVICE HEATER WHILE IT IS PLUGGED IN OR WHILE HOT! USE ORIGINAL EQUIPMENT REPLACEMENT PARTS. Use of third party or other alternate components will void warranty and may cause unsafe operating conditions.
  • Page 11 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! C.) SPARK PLUG SPARK PLUG CLEAN AND REGAP EVERY 600 HOURS BURNER HEAD OPERATION OR REPLACE AS NEEDED. - Remove upper shell (See page 9). SPARK PLUG WIRE - Remove spark plug wire from spark plug (See Figure 8) - Remove spark plug from burner head using medium phillips screw driver.
  • Page 12 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! E.) PHOTOCELL CLEAN PHOTO CELL ANNUALLY OR AS NEEDED. - Remove upper shell(See Page 9) - Remove photocell from photocell Bracket and disconnect photocell from connector. - Clean photocell lens with cotton swab. - Inspect photcell lens for damage.
  • Page 13 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! G.) FUEL FILTER CLEAN TWICE PER HEATING SEASON OR AS NEEDED. Tank Fuel Filter - Remove fan guard.(See page 11). PUMP - Disconnect fuel line (B) from pump and pump SCREW fuel filter assembly with 3/8” wrench (See Figure 13) - Remove two screws that fix bracket-filter to shell lower and remove bracket-filter.
  • Page 14 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! H.) PUMP PRESSURE ADJUSTIMENT - Remove pressure gauge plug from pump with 1/8” allen wrench. - Install accessory pressure gauge to pressure gauge port. (See Figure 15) - Start heater (See operation, page 6) Allow motor to reach full speed.
  • Page 15: Troubleshooting Guide

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . TROUBLE SHOOTING GUIDE TROUBLE POSSIBLE CAUSE CORRECTIVE ACTION 1. Wrong pump pressure 1. See Pump Pressure Adjustment, Heater ignites but MAIN PCB page 13. assembly shuts heater off after 2. Dirty Fuel Filter a short period of time.
  • Page 16: Wiring Diagram

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . WIRING DIAGRAM...
  • Page 17: Specifications

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . SPECIFICATIONS ( " " 8 . RMC-KFA650TDGD RMC-KFA650TDGD Fuel Consumption-Gal./ ( ./Hr) 4.9(18.55) Fuel Tank Capacity-Gal ( ) 29.0(110.0) (kgf/ ) Pump Pressure PSI 110(7.73) s t l Size(W D H), Inch( ) 32.8”...
  • Page 18 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . EXPLODED PARTS DRAWING (RMC-KFA650TDGD MODEL) NOTE: SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS.
  • Page 19: Parts List

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . PARTS LIST PART No. KEY No. DESCRIPTION Quantity RMC-KFA650TDGD Fuel Tank Assembly 2151-0021-01 Fuel Drain Bolt 4329-0072-00 Bracket-Cord 3131-0357-01 Flange Screw 4319-0015-00 Fuel Gauge 2156-0054-00 Fuel Filter 3221-0009-00 Fuel Cap 2151-0022-00 Filler Neck Assembly...
  • Page 20 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . PARTS LIST (BURNER HEAD ASSEMBLY & MOTOR AND PUMP ASSEMBLY) NOTE: SPECIFY MODEL NUMBER AND PART NUMBER WHEN DRDERING PARTS. KEY NO. DESCRIPTION PART NO. QTY. Burner Head 3531-0012-00 Plug 3541-0060-00 Nozzle SP-KFA1028 Spark Plug SP-KFA1009...
  • Page 21 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! . PARTS LIST (Wheel and Handle) NOTE: SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS. KEY No. DESCRIPTION PART No. Quantity Wheel Support Frame 3551-0041-00 Handle Frame 3551-0043-00 Frame Supportor 3551-0044-00 Front Handle 3551-0042-00 Wheel 3720-0004-00...
