OPERATIONS

VEGETABLE DRAWER

Vegetable Partitioner
Fix the partitioner by inserting it at the rear side of vegetable box as shown in the figure.
G
How to use
Vegetable drawer can be used through the control of knob.
G
Check the position of knob prior to store the food.
G
Do not locate the knob on the middle point.
G

DEODORIZER (OPTIONAL)

Unpleasant odor of food in fresh food
G
compartment is deodorized with no harm to
you and the food.
How to use
As Deodorizer is located in cooling air inlet for circulating air in fresh food compartment, there is
no need for any handling.
Do not prick the cooling air inlet with a sharp tip because Deodorizer may be damaged.
When storing food with a strong odor, wrap it or store it in a container with a lid because odor may be
passed on to other foods.
Re-Using of Deodorizer
Used some length and the odor is strong,
Deodorizer can be revived and re-used.
Separate Deodorizer in ceiling of refrigerator
compartment, using hair drier to remove
moisture or malodor and oxidize under sunlight
to decomposing malodor by ultraviolet.
GREEN ION DOOR COOLING
(OPTIONAL)
The anion coating in the duct cover purifies the air and
helps stored foods remain fresh longer.
If water of foreign substances enter the cool air vent while
cleaning, efficiency will be lowered. In addition, if gasket is
damaged, efficiency may be lowered owing to the escape
of cool air.

REFRESHMENT CENTER (OPTIONAL)

1. Tilting: Grasp the front pocket and slightly lift it up
Then pull it forward to tilt the transparent door bin.
2. Closing: Then place the door bin in its original
position until you hear a "click"
Cool air vent
19
Tilt
Partitioner
Click
