Summary of Contents for Hotpoint Ariston TCL 831 B

  • Page 1 English, 15 TCL831B...
  • Page 9 150g (5oz) 100g (3oz) 500g (1lb 2oz) 350g (12oz) 700g (1lb 6oz) 1000g (2lb 3oz) 300g (10oz) 200g (7oz) T-Shirt 125g (4oz)
  • Page 10 7 - 7.5kg 30-50 50-70 70-80 80-100 100-120 120-140140-160 30-40 40-50 50-70 40-80 80-140...
  • Page 14 7.5 kg 7.5 kg 3 kg...
  • Page 15: Table Of Contents

    Instruction booklet TUMBLE DRYER Contents Important Information, 16-17 English, 15 Installation, 18 Where to put your dryer Ventilation Door reversal instructions Water drain Electrical connection Before you start using your dryer Dryer description, 19 To open the door The features Control panel Start and programmes, 20-22 Choosing a programme...
  • Page 16: Important Information

    Important Information For your Condenser dryer to operate efficiently, you must follow the regular maintenance schedule shown below: Fluff Filter... ! You MUST clean the fluff filter after EVERY drying cycle. STEP 1. STEP 2. STEP 3. STEP 4. Open the door of your Pull out the filter (using Clean any fluff deposits Refit the filter - NEVER...
  • Page 17 Important Information Condenser Unit... ! You MUST clean the fluff from the condenser EVERY month. STEP 1. STEP 2. STEP 3. STEP 4. Open the condenser cover Remove the condenser by Flush the condenser, from Refit the condenser unit - hold the handle and rotating the 3 clips then the rear with water, to - ensure that the unit is...
  • Page 18: Installation

    Installation Where to put your dryer Water drain Place your dryer at a distance from gas ranges, If your dryer is installed next to a drain the water can be stoves, heaters, or cook tops because flames can plumbed into this drain. This does away with the need to damage the appliance.
  • Page 19: Dryer Description

    Dryer Description To open the door The features Water container Rating plate Press and release the front panel in position shown Model & Serial numbers Air intake Condenser unit grille Condenser cover (Cover open) Condenser cover handle Filter (Pull to open) Control panel Clean Condenser Light...
  • Page 20: Start And Programmes

    Start and Programmes Choosing a programme The green light stops flashing. 1. Plug the dryer into the electrical socket. During the drying programme, you can check on 2. Sort your laundry according to fabric type (see your laundry and take out items that are dry Laundry).
  • Page 21 Start and Programmes Programmes ! If none of the lights are on; Press the On/Off button ( and then select programme. Programme What it does... How to set it... Note: Dries your clothes on High Options available: 1. Position the PROGRAMME knob on Cottons Delayed Start heat setting, ready for...
  • Page 22: The Controls

    Start and Programmes The Controls Post Creasecare PROGRAMMES knob When selected, the clothes are occasionally tumbled after the end of the drying and cool tumble cycles, to ! Warning, if after pressing the Start/Pause button help prevent creases developing should you not be , the programmes knob position available to remove the load immediately the programme has changed, the new position will NOT change the...
  • Page 23: Laundry

    Laundry Sorting your laundry Wash Care Labels Check symbols on clothing labels to make sure Look at the labels on your garments, especially when that the articles can be tumble dried. tumble drying for the first time. The following symbols Sort laundry by fabric type.
  • Page 24: Special Clothing Items

    Laundry Special clothing items Times are approximate and can vary depending upon: Blankets and Bedspreads: acrylic items (Acilan, Courtelle, Orion, Dralon) must be dried with special Amount of water retained in clothes after spin care on LOW heat setting. Avoid drying for a long cycle: towels and delicates retain a lot of water.
  • Page 25: Warnings And Suggestions

    Warnings and Suggestions ! The appliance has been designed and built Do not tumble dry rubber, rubber backed articles and clothes, pillows fitted with foam rubber pads, foam according to international safety standards. (latex foam), rubber, plastic, shower caps, waterproof These warnings are given for safety reasons and must textiles, nappy pants or liners, polythene or paper.
  • Page 26: Maintenance And Care

    Maintenance and Care Switching off the electricity Cleaning the drum ! Unplug your dryer when not using it, when cleaning ! Do not use abrasives, steel wool or stainless steel it and during all maintenance operations. cleaning agents to clean the drum. A coloured film may start to appear on the stainless Clean the filter after each cycle steel drum, this may be caused by a combination of...
  • Page 27: Troubleshooting

    Troubleshooting One day your dryer seems not to be working. Before you call your Service Centre (see Service), go through the following troubleshooting suggestions: Problem: Possible causes / Solution: The tumble dryer won’t start. The plug is not plugged into the socket, or not making contact. There has been a power failure.
  • Page 28: Service

    Service 1 9 5 0 6 7 2 6 6 . 0 0 02/2008 - SIMLEX . Four Ashes, Wolverhampton Before calling the Service Centre: Spare Parts Use the troubleshooting guide to see if you can This dryer is a complex machine. Repairing it yourself solve the problem yourself (see Troubleshooting).
