Technical data

Max. load of dry laundry for washing
Water pressure
Measurements
Width
Depth
Height
NB: For specifications regarding electrical data, see the data panel on the front of the washing
machine (porthole area) - as shown in diagram above.
Appliance complies with European Directives 73/23/EEC and 89/336/EEC, replaced by
2006/95/EC and 2004/108/EC, and subsequent amendments.
Fig. 2
0,05 ÷ 0,8 MPa
26

SETTING UP + INSTALLATION

1
2
3
6 kg
WARNING:
DO NOT LEAVE THE PACKAGING WITHIN REACH OF CHILDREN AS IT IS A POTENTIAL
60 cm
SOURCE OF DANGER.
52 cm
82 cm
Apply the insulation sheet of corrugated material to the base
as shown.
Use the 4 feet to level the machine with the floor:
a) Turn the nut clockwise to release the screw adjuster on the foot.
b) Rotate the foot to raise or lower it until it stands firmly on the
ground.
c) Lock the foot in position by turning the nut
anti-clockwise until it comes up against the bottom of the machine.
Remove the polystyrene base and place the machine near
its permanent position (diagram 1).
Carefully cut through the hose retaining clip at the rear of
the appliance (diagram 2).
Remove the 4 fixing screws marked (A) and remove the 4
spacers marked (B) (diagram 3).
For some models 1 or more spacers will fall inside the
machine;
By tilting the machine, remove the mentioned spacers.
Cover the 4 holes using the caps provided in the instruction
booklet pack (diagram 4).
4
27
A
B
C
