OWNER'S MANUAL
2008
990 SUPERMOTO
ART. NR. 3211247en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 990 SUPERMOTO 2008 and is the answer not in the manual?

Questions and answers

Related Manuals for KTM 990 SUPERMOTO 2008

Summary of Contents for KTM 990 SUPERMOTO 2008

  • Page 1 OWNER’S MANUAL 2008 990 SUPERMOTO ART. NR. 3211247en...

  • Page 2: Introduction

    INTRODUCTION We would like to congratulate you on your purchase of a KTM motorcycle. You are now the owner of a state-of-the-art sport motorcycle that guarantees to bring you lots of fun and enjoyment, provided that you clean and maintain it appropriately.

  • Page 3: Important Information

    » IMPORTANT INFORMATION INTENDED PURPOSE The 990 Supermoto is designed and constructed for normal use on public roads but not for use on race courses or offroad terrain. OWNER'S MANUAL Carefully read the entire Owner's Manual before you start riding your motorcycle, even if this will take a little time. It contains use- ful tips and information on the best way to handle the motorcycle and how to protect yourself from injuries.
  • Page 4 SPARE PARTS, ACCESSORIES For your own safety, only use spare parts and accessories approved by KTM. KTM shall not assume any liability for other products or consequential damage resulting from the use of such products.

  • Page 5: Table Of Contents

    » INDEX INTRODUCTION ........1 Footrests ........20 IMPORTANT INFORMATION .
  • Page 6 ......67 General information on KTM disk brakes ....43 TROUBLESHOOTING .

  • Page 7: Serial Number Locations

    » SERIAL NUMBER LOCATIONS Chassis number, Type label The chassis number is stamped on the right side of the steering head tube. Enter this num- ber in the field on page no 1. The type label is located next to the chassis number. Engine number, engine type The engine number and the engine type are stamped into the left side of the engine below the engine sprocket.

  • Page 8: Operation Instruments

    » OPERATION INSTRUMENTS Clutch lever The clutch lever [1] is fitted on the left hand side of the handle bar. The adjusting screw [A] is used to change the original position of the clutch lever (see maintenance work on chassis and engine). The clutch is hydraulically actuated and adjusts itself automatically.

  • Page 9: Combined Instrument

    » OPERATION INSTRUMENTS Combined instrument The combined instrument is divided into 4 parts. Function buttons: to select the display modes and basic settings in the display Tachometer: displays the engine speed Indicator lamps: provide additional information on the motorcycle operating condition Display: shows the speed, cooling liquid temperature, time, ambient temperature, distance traveled (ODO), trip master 1 (TRIP 1), trip master 2 (TRIP 2),...
  • Page 10 » OPERATION INSTRUMENTS SPEED [1] The speed can be displayed in kilometers per hour (km/h) or miles per hour (mph). CHANGING THE SPEED DISPLAY FROM KM/H - MPH or MPH - KM/H Switch on the ignition and press the MODE button more than 10 seconds in the ODO mode. CLOCK [2] The dots between the hours and minutes will blink in the CLOCK display.
  • Page 11 » OPERATION INSTRUMENTS FROST WARNING [1] The frost symbol will start to blink regardless of the mode if the ambient temperature drops below 3°C (37.5°F). ODO [2] Displays the total kilometers or miles traveled. This figure will not be cleared if the battery is disconnected.
  • Page 12 » OPERATION INSTRUMENTS TRIP 1 [1] The trip meter 1 is always active and counts up to 999.9. It is used to measure the length of the trip or the distance between 2 refueling stops. TO RESET TRIP 1 To reset the trip meter 1 to zero, switch on the ignition, select the TRIP 1 display mode and press the SET button more than 2 seconds.

  • Page 13: Cooling Liquid Temperature Display

    » OPERATION INSTRUMENTS Cooling liquid temperature display The temperature display [1] is shown in 12 bars. The more bars that light up, the hotter the heiß / hot / caldo / chaud / caliente cooling liquid. When the upper bar lights up 120°C (248°F), all of the bars will start to blink and the red warning lamp [2] will light up.

  • Page 14: Indicator Lamps

    The red warning lamp will light up if the voltage in the on-board electrics drops below 10 volts. Immediately drive to the nearest authorized KTM workshop and have the electrical system checked. The red indicator lamp lights up briefly when the ignition is switched on and indicates that the immobilizer has been deactivated.

  • Page 15: Ignition Lock

    » OPERATION INSTRUMENTS Ignition lock The ignition lock has 3 switching positions. Ignition off, (engine can't be started) Ignition on, light on, (engine can be started) Ignition off, handlebar blocked To switch the ignition to position turn the ignition key to position and firmly press it into the lock.

  • Page 16: Securing Vehicle After Losing Key

    » OPERATION INSTRUMENTS Securing vehicle after losing key A lost key can be blocked for this vehicle. LOSS OF PRIMARY KEY, RESERVE KEY AVAILABLE – Switch on the ignition using the orange master key [2]. The red indicator lamp [1] lights up.

  • Page 17: Combination Switch

    » OPERATION INSTRUMENTS Combination switch The rocker switch LIGHTS [1] actuates the high beam or low beam. High-beam light Low-beam light The light signal (high beam) is actuated with button [2]. The indicator switch [3] returns to central position after actuation. Press flasher switch towards switch housing to switch off the flasher.

  • Page 18: Emergency Off Tip Switch, Starter Tip Switch

    » OPERATION INSTRUMENTS Emergency OFF tip switch, starter tip switch The emergency off switch [1] is provided for emergency situations and should not be used to switch off the engine. The engine is ready for operation in position (ignition circuit and starter circuit are switched on).

  • Page 19: Grips

    » OPERATION INSTRUMENTS Grips The grips [1] are used to maneuver the motorcycle. If carrying a passenger, the passenger can hold on to the grip during the ride. Seat lock, removing the seat The seat lock [3] can be locked with the ignition key. To remove the seat, insert the ignition key and turn 45°...

  • Page 20: Tool Set

    » OPERATION INSTRUMENTS Tool set The tool set [1] is located in the storage compartment under the seat. Helmet lock The steel rope [2] in the tool bag can be used to secure a helmet. To secure, remove the seat, run the rope through the helmet, attach both ends to the hook [3] and mount the seat.

  • Page 21: Side Stand

    » OPERATION INSTRUMENTS Side stand Fold the side stand [1] forward to the stop with your foot and put the weight of the motor- cycle on the stand. Make sure it is standing securely on a firm surface. The side stand is linked to the safety start system;...

  • Page 22: Compression Damping Of Fork

    » OPERATION INSTRUMENTS Compression damping of fork The fork's damping action during compression travel (compression damping) can be adjusted. This allows you adjust the damping behavior to match your driving style and the payload. The adjusting screws [1] are located on the fork leg axle passage. More information is provided in the chapter "Adjusting the fork and shock absorber.“...

  • Page 23: Damping Action During Compression Of Shock Absorber

    » OPERATION INSTRUMENTS Damping action during compression of shock absorber The shock absorber's damping action during compression travel (compression damping) can be adjusted. This allows you adjust the shock absorber's damping behavior to match your driving style and the payload. The damping rate can be adjusted in the low and high-speed range (Dual Compression Control).

  • Page 24: The Motorcycle

    – New wheels have a smooth surface, which inspection“ was performed by your author- means that they must be run in to achieve ized KTM workshop. The DELIVERY CER- full grip. For this purpose, ride the motor- TIFICATE and SERVICE MANUAL will be –...

  • Page 25: Accessories And Payload

    – The tires must be designed for a speed of over 240 KPH (speed symbol ZR) and – Never drive faster than 130 kph (80 mph) must be released by KTM. if you have mounted accessory parts on – Wheels with a different rim diameter or your motorcycle.

  • Page 26: Driving Instructions

    Arrange for the braking system to be checked by a KTM specialist, as com- plete failure of the braking system can be avoided.
  • Page 27 » DRIVING INSTRUCTIONS 5 CABLES Check the throttle cable for correct adjustment and smooth operation. 6 COOLING FLUID Check the level of cooling fluid when the engine is cold. 7 ELECTRICAL SYSTEM Start the engine and check the headlight, tail lamp, brake light, turn signals, indicator lamps, horn and emergency-off switch for proper functioning.

  • Page 28: Starting The Engine

    If the engine is not switched off, engine damage will occur within a short period of time. Check the engine oil level or contact a ktm workshop. – Maximum period for continuous starting: 5 seconds. Wait at least 5 seconds before try- ing again.

  • Page 29: Starting Off

    Do not shift gears ceed as described in the „Trouble- and accelerate carefully in curves. shooting“ section or contact a KTM Only accelerate to the extent that road and dealer. weather conditions allow. Be especially care- ful when you accelerate in curves.

  • Page 30: Braking

    Check the engine oil level or con- SCALDING HAZARD! Do not drive on, trol of your motorcycle. tact an authorized KTM workshop. until there is sufficient liquid in the col- – The frost symbol * in the combined instru- –...

  • Page 31: Stopping And Parking

    First, the brakes the braking effect. In extreme cases, the looked over by a KTM dealer. must be braked clean. entire braking system can fail. – Remember that the stopping distance –...

  • Page 32: Fuel

    » DRIVING INSTRUCTIONS Fuel In the condition at delivery, the LC8 engine requires unleaded fuel with at least RON 95 (USA = Premium PON 91, see technical specifications – engine). After refueling, it will take approx. 3 minutes for the fuel warning lamp to switch off and for TRIP F to automatically reset to 0 and return to the previous display mode.

  • Page 33: Periodic Maintenance Schedule

    Clean the oil jet for the clutch lubrication Check rubber boots for cracks or leaks Check fault memory with the KTM diagnosis tool Perform a status check of neutral, clutch, 2nd/3rd gear and side stand switch using the KTM diagnosis tool...
  • Page 34 » PERIODIC MAINTENANCE SCHEDULE 1st Service every every after 990 SUPERMOTO 2008 7500 km 15000 km 1000 km A clean motorcycle can be checked more quickly which saves money! once a year every 2 years Replace the graphite gasket in the rear exhaust manifold slide...

  • Page 35: Periodic Maintenance Schedule

    IF MOTORCYCLE IS USED FOR COMPETITION 7500 KM SERVICE SHOULD BE CARRIED OUT AFTER EVERY RACE! Service intervalls should never be exceeded by more than 500 km. Maintenance work performed by an authorized KTM workshop is not a substitute for care and maintenance by the driver! 990 SUPERMOTO 2008...
  • Page 36 » PERIODIC MAINTENANCE SCHEDULE 990 SUPERMOTO 2008 VITAL CHECKS AND CARE PROCEDURES TO CONDUCTED BY THE OWNER OR THE MECHANIC before after every each start every cleaning 1000 km Check oil level Check brake fluid level Check brake pads for wear...

  • Page 37: Maintenance Work On Chassis And Engine

    – Do not clean the motorcycle with a power washer otherwise water will get into the bearings, electric socket connectors, etc. – Use special KTM screws with the correct thread length to fasten the spoiler to the tank. Mounting other screws or longer screws could puncture the tank and cause fuel to leak out.

  • Page 38: Adjusting The Fork And Shock Absorber

    » MAINTENANCE WORK ON CHASSIS AND ENGINE Adjusting the fork and shock absorber 990 Supermoto FORK SHOCK 2008 There are a number of ways to adjust the fork and shock absorber to match the chassis to your driving style and the payload. We have provided a table with pragmatical values to help you tune up your motorcycle.

  • Page 39: Adjusting Rebound Damping Of Fork

    » MAINTENANCE WORK ON CHASSIS AND ENGINE Adjusting rebound damping of fork Hydraulic rebound damping determines the reaction when the fork is rebound. By turning the adjusting screw [1] (REB), the degree of damping of the rebound can be adjusted. Turn the knob clockwise to increase damping, turn it counterclockwise to reduce damping dur- ing rebounding.

  • Page 40: Compression Damping Of Shock Absorber

    » MAINTENANCE WORK ON CHASSIS AND ENGINE Compression damping of shock absorber The shock absorber can synchronize the compression damping in the low and high-speed range separately (Dual Compression Control). Low and high speed refers to the movement of the shock absorber during compression and not to the speed of the motorcycle.

  • Page 41: Rebound Damping Of Shock Absorber

    » MAINTENANCE WORK ON CHASSIS AND ENGINE Rebound damping of shock absorber By using the adjusting screw [1], the degree of damping of the rebound can be adjusted. Turn the knob in a clockwise direction to increase damping, turn it in a counterclockwise direction to reduce damping during rebounding.

  • Page 42: Checking The Chain Tension

    If you don’t happen to have a torque wrench at hand, make sure you have the tightening torque corrected by a KTM dealer as soon as possible. A loose wheel spindle can cause the motorcycle's handling performance to become instable and cause it to crash.

  • Page 43: Chain Maintenance

    – The chain does not have a chain joint for safety reasons. Always have the chain replaced in an authorized KTM workshop where the service technicans have the required riveting tool. – Never mount a normal chain joint.

  • Page 44: General Information On Ktm Disk Brakes

    Brake pads available in the accessory trade are often not authorized for operation of your KTM motorcycle in road traffic. The brake pads design and friction factor and therefore the braking power can deviate significantly from original KTM brake pads. If you use different brake pads than those provided with the original equipment, it cannot be warranted that they are authorized for use in road traffic.
  • Page 45 DOT 4 brake fluid. Do not, in any event, use DOT 5 brake fluid. It is based on silicone oil and is dyed purple. KTM motorcycle gaskets and brake hoses are not designed for DOT 5 brake fluid.

  • Page 46: Changing The Basic Position Of The Handbrake Lever

    – If the brake fluid level drops below the minimum either the brake system has a leak or the brake pads are completely worn down. In this case, consult an authorized KTM dealer immediately.

  • Page 47: Checking The Front Brake Pads

    » MAINTENANCE WORK ON CHASSIS AND ENGINE Checking the front brake pads The brake pads can be seen from the rear. The linings must be at least 1 mm (0.04 in) thick. min. 1 mm At their most worn point brake pad linings should not be thinner than 1 mm, otherwise they could lead to brake failure.

  • Page 48: Checking Rear Brake Fluid Level

    – If the brake fluid level drops below the minimum either the brake system has a leak or the brake pads are completely worn down. In this case, consult an authorized KTM dealer immediately.

  • Page 49: Dismounting And Remounting The Front Wheel

    The front stand only adequately fixes the motorcycle together with the rear stand. The stands shown in the illustration can be found in the KTM Power Parts catalog. First mount the rear, then the front stand. Make sure the stands rest on solid ground and are correctly mounted.
  • Page 50 – If you do not have a torque wrench to mount the wheel, have the torques corrected by an authorized KTM workshop as soon as possible. A loose wheel spindle can cause the motorcycle's handling performance to become instable and cause it to crash.

  • Page 51: Dismounting And Mounting The Rear Wheel

    Special stands are required to dismount the wheels to make sure the motorcycle is securely fixed. The stands shown in the illustration can be found in the KTM Power Parts catalog. Mount the rear stand. Make sure the stand rests on solid ground and is correctly mounted.
  • Page 52 – If you don’t happen to have a torque wrench at hand, make sure you have the tighten- ing torque corrected by a KTM dealer as soon as possible. A loose wheel spindle can cause the motorcycle's handling performance to become instable and cause it to crash.

  • Page 53: Tires, Air Pressure

    34 psi 36 psi – Do not mount tires which have not been approved by KTM. Other tires could have adverse effects on the way your motorcycle rides. – Use tires of the same brand and type for the front and rear wheels.

  • Page 54: Battery

    » MAINTENANCE WORK ON CHASSIS AND ENGINE Battery The battery is located under the seat and is maintenance-free. Maintenance-free means you will not need to check the acid level. Clean the battery termi- nals regularly and grease with acid-free grease if necessary. The charge condition and type of charge are very important for the battery's service life.

  • Page 55: Charging The Battery

    To charge the battery while mounted, always use the KTM battery charger (Item no. 58429074000) to ensure that the electric system is not damaged by excess voltage. Always remove the battery if using other battery chargers! You can also use this charging device to test the off-load voltage and startability of the battery and generator.

  • Page 56: Main Fuse

    If a new fuse that has just been set in gets blown again, you are strongly advised to have it inspected by a KTM dealer. The fuse capacity is 30 Ampere. – Under no circumstances is a stronger fuse allowed to be set in or a fuse allowed to be „repaired“.

  • Page 57: Fuses For Individual Power Consumers

    Replace a blown fuse only with an equivalent one. If a new fuse that has just been set in gets blown again, you are strongly advised to have it inspected by a KTM dealer. Under no circumstances is a stronger fuse allowed to be set in or a fuse allowed to be “repaired”.

  • Page 58: Replacing The Headlight Lamp

    » MAINTENANCE WORK ON CHASSIS AND ENGINE Replacing the headlight lamp Remove the screws [1], tilt the headlight mask up towards the front and detach at the bottom. Never touch the glass of the bulb with your fingers. The glass of the bulb must remain absolutely free from grease.

  • Page 59: Adjusting The Headlight Range

    » MAINTENANCE WORK ON CHASSIS AND ENGINE Adjusting the headlight range The payload can make it necessary to correct the headlight range. The beam width of the head light can be adjusted using a TORX ® key T 20 (tool set). Turn clockwise to increase the beam width and counterclockwise to reduce the beam width.

  • Page 60: Replacing The Brake Light And Taillight Bulbs

    » MAINTENANCE WORK ON CHASSIS AND ENGINE Replacing the brake light and taillight bulbs Remove the seat.Remove the screws from the handrails [1], rear side parts [2] and rear top part [3] and remove the parts. BULB FOR BRAKE LIGHT: Turn the bulb socket [4] approx.

  • Page 61: Cooling System

    If the fan is not working, and there appears to be sufficient cool- ing liquid, the only thing you can do is to drive on to your nearest authorized KTM work- shop at the least possible engine load.
  • Page 62 » MAINTENANCE WORK ON CHASSIS AND ENGINE A mixture of 50% antifreeze and 50% distilled water is used as the cooling liquid. How- ever, the anti-freeze protection must be at least -25° C (-13° F). Aside from antifreezing pro- tection, this mixture also provides great corrosion protection which is why it must not be replaced by pure water.

  • Page 63: Checking The Cooling Liquid Level In The Compensating Tank

    – Only continue to drive if there is enough cooling liquid in the system. Contact an author- ized KTM workshop to have the error eliminated. You will damage the engine if you con- tinue to drive when the cooling liquid temperature warning lamp is on.

  • Page 64: Bleeding The Cooling System

    » MAINTENANCE WORK ON CHASSIS AND ENGINE Bleeding the cooling system To completely bleed the cooling system, the motorcycle must be raised approx. 50 cm (20 in) in the front. Remove the radiator cap [1] and bleeder screw [2]. Add cooling liquid until it runs out of the vent holes without bubbles and immediately mount the screw to prevent air from entering the radiator.

  • Page 65: Changing The Original Position Of The Clutch Lever

    KTM uses biodegradable, hydraulic mineral oil to actuate the hydraulic clutch. Do not mix this oil with any other hydraulic oil. Always use original KTM hydraulic oil (available from your authorized KTM workshop) to make sure your clutch operates smoothly. Never refill with...

  • Page 67: Engine Oil

    5W/40 10W/50 KTM recommends Motorex Power Synt 4T in the 10W/50 viscosity (for temperatures over 0°C, 32°F) or 5W/40 (for temperatures under 0°C, 32°F). Checking the engine oil level Check the engine oil level when the engine is warm (at least 4 bars on the temperature indi- cator light up).

  • Page 68: Refilling Engine Oil

    Since many parts must be demounted for an oil change, we recommend having the engine oil changed by an authorized KTM workshop. During the guaranty period, the oil change must be performed by an authorized KTM mechanic. Otherwise, the guarantee will become void.
  • Page 69 » MAINTENANCE WORK ON CHASSIS AND ENGINE Remove the drain plug [5] from the oil tank and allow the oil to drain into a vessel. Remove the screws [6] and tilt the connector [7] to the side. Carefully pull the oil screen [8] out of the oil tank. Thoroughly clean the drain plugs, the cover and both oil screens.
  • Page 70 O-ring. Tighten the screws to 6 Nm. Only use original KTM oil filters. The engine can be damaged if other filters are used. Mount the oil drain plug on the oil tank with a new seal ring and tighten to 20 Nm.

  • Page 71: Troubleshooting

    We would like to point out that many oper- ations cannot be performed by oneself. In case of uncertainty, please contact an authorized KTM workshop.
  • Page 72 Error in the injection system Contact an authorized KTM workshop Engine will not reach full power Air filter/fuel filter heavily soiled Have the air filter/fuel filter replaced at an authorized KTM workshop Error in the injection system Contact an authorized KTM workshop...
  • Page 73 TROUBLE CAUSE REMEDY Engine overheats Defect fan or thermoswitch for fan Contact an authorized KTM workshop. FI lamp is blinking / lights up Error in the injection system Contact an authorized KTM workshop Immobilizer indicator lamp lit con- Ignition key was locked due to...

  • Page 74: Indicator Lamp Blink Code Fi

    KTM workshop Indicator lamp blink code The blink code (FI indicator lamp) indicates which component is affected by an error. This allows the error to be identified if no diagnosis tool is available.
  • Page 75 » TROUBLESHOOTING The blink code (FI indicator lamp) indicates which component is affected by an error. This allows the error to be identified if no diagnosis tool is available. The rhythm of the blinking lamp will let you determine the two-digit „blink code“, e.g.: Blink code 34: FI blinks 3x long, 4x short, pause, Blink code 06: FI blinks 6x short, pause...

  • Page 76: Indicator Lamp Blink Code Immobilizer

    » TROUBLESHOOTING Indicator lamp blink code immobilizer The blink code (immobilizer indicator lamp) specifies the module affected. From the blink rhythm, you can identify a two-digit number, the so-called blink code. E.g. blink code 15: lamp blinks 1x short, 1 second pause, 5x short. Other blink codes following a 3 second pause. BLINKCODE ERROR DESCRIPTION Key not programmed...

  • Page 77: Cleaning

    » CLEANING Regular cleansing and paintwork care is part of the maintenance work and helps to maintain the value of your motorcycle. Never clean your motorcycle with a high-pressured cleaner or a high-pressured water jet. The water could otherwise run into the electrical components, connectors, sheathed cables, bearings, carburetor etc.

  • Page 78: Conservation For Winter Operation

    » CONSERVATION FOR WINTER OPERATION In the event that the motorcycle is also used in winter and on roads where one has to expect salt spraying, you will have to take precautions against the aggressive road salt. – clean motorcycle thoroughly and let it dry –...

  • Page 79: Storage

    » STORAGE Should you desire to make a pause over a longer space of time, please observe the following instructions: – Drive the tank empty to be able to fill up with fresh fuel when starting the motorcycle up again. –...

  • Page 80: Technical Specifications – Chassis

    ..........12V 5W (socket W2,1x9,5d) indicator lamps ..........LED position light rear..........12V WR5W (socket W2,1x9,5d) stoplight ............12V PR21W (socket BAW15s) licens plate illumination ........12V 5W (socket W2,1x9,5d) flasher .............12V RY10W (socket BAU15s) * further tire releases are available on the Internet at www.ktm.com...
  • Page 81 » TECHNICAL SPECIFICATIONS – CHASSIS CHASSIS 990 SUPERMOTO 2008 Battery 12V 11.2 Ah maintenance-free Steering head angle 65.1° Wheel base 1510 ± 10 mm (59.4 in) Seat height, unloaded 875 mm (34.4 in) Ground clearance, unloaded 195 mm (7.7 in) Dry weight 191 kg (421.6 lbs)
  • Page 82 » TECHNICAL SPECIFICATIONS – CHASSIS TIGHTENING TORQUES – CHASSIS 990 SUPERMOTO 2008 Collar bolt on front wheel spindle M24x1.5 60 Nm Collar nut wheel spindle rear M25x1.5 90 Nm AH bolt shock absorber top/bottom M14x1.5 80 Nm Collar nut for swing arm bolt M19x1.5...
  • Page 83 » TECHNICAL SPECIFICATIONS – CHASSIS TIGHTENING TORQUES – CHASSIS 990 SUPERMOTO 2008 HH bolt for side stand switch Loctite 243 + 2 Nm Drain plug on oil tank M12x1,5 25 Nm Exhaust nuts on manifold evenly, do not bend sheet metal...
  • Page 84 » TECHNICAL SPECIFICATIONS – ENGINE ENGINE 990 LC8 2008 Design liquid-cooled, 2-cylinder 4-stroke engine with 75° V arrangement with balancer shaft and electric starter Displacement 999 ccm Bore / Stroke 101/62.4 mm Compression ratio 11.5:1 Fuel unleaded fuel with at least RON 95 (USA: Premium PON 91*) Valve timing 4 valves controlled over bucket tappet and 2 camshafts, camshaft drive with gears/chain Valve diameter...

  • Page 85: Technical Specifications – Engine

    Only use fully synthetic engine oils that meet the JASO MA quality requirements (see infor- mation on the can). KTM recommends Motorex Power Synt 4T in the 10W/50 viscosity (for temperatures over 0°C, 32°F) or 5W/40 (for temperatures under 0°C, 32°F).

  • Page 86: Head Word Index

    ....45 General information on KTM disk brakes ....43 Checking the front brake pads .
  • Page 87 » HEAD WORD INDEX Immobilizer ........14 Starting the engine .
  • Page 88 » USE THIS SPACE FOR NOTES...
  • Page 89 » USE THIS SPACE FOR NOTES...
  • Page 90 *3211247en* 3211247en 12/2007 FOTO: MITTERBAUER KTM Group Partner KTM Sportmotorcycle AG A–5230 Mattighofen www.ktm.com...
