iNSTALLATiON
iNSTRUCTiONS
30" ELECTRIC SLIDE-IN RANGE
United
States
iNSTALLATiON AND SERVICE MUST BE PERFORMED BY A QUALiFiED iNSTALLER.
iMPORTANT:
SAVE FOR LOCAL ELECTRICAL iNSPECTOR'S
USE.
READ AND
SAVE THESE iNSTRUCTiONS
FOR FUTURE REFERENCE.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable
vapors and liquids in the vicinity
of this or any other appllance.
Table of Contents
instructions......................................... 2
Product Dimensions .........................................................
3
Cutout Dimensions ........................................................... 4
To Avoid Breakage ...........................................................
5
Power Supply Kit ..............................................................
6
Strap .............
6
Serial Plate Location ....................................................... 6
to the Range .......................... 7-8
Cabinet Construction ....................................................... 9
Range installation
..........................................................
10
Leveling the range .........................................................
10
Decorative
Rear Trim Installation
(if required) ........... 11
Check Operation
............................................................
11
Anti-Tip
....................................... 12
important
Notes to the Installer
1.
Read all instructions contained
in these installation
instructions
before
installing range.
2.
Remove alt packing
material
from the oven and
the drawer
compartments
before
connecting
the
electrical
supply to the range.
3.
Observe all governing
codes and ordinances.
4.
Be sure to leave
these
instructions
with
the
consumer.
important
Note to the Consumer
Keep these instructions
with your owner's guide for
future reference.
Printed
in Canada
P/N 318201629
(1209) Rev. B
English - pages 1-12
Espa_ol - pc_ginas 13-24
Advertisement
Chapters
Table of Contents
Related Manuals for Kenmore 79041112200
Summary of Contents for Kenmore 79041112200
-
Page 1: Table Of Contents
iNSTALLATiON iNSTRUCTiONS 30" ELECTRIC SLIDE-IN RANGE iNSTALLATiON AND SERVICE MUST BE PERFORMED BY A QUALiFiED iNSTALLER. United States iMPORTANT: SAVE FOR LOCAL ELECTRICAL iNSPECTOR'S USE. READ AND SAVE THESE iNSTRUCTiONS FOR FUTURE REFERENCE. FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appllance. -
