Planet Audio AC8D Product Specifications

8” (20 cm) subwoofer

Enlarged version

Technical Support

Congratulations on your purchase of the Planet Audio "AC" Series

If you need technical support with your Planet Audio product or have

Subwoofer. Planet Audio takes great pride in producing products

questions about its use, please contact us:

that sound and look great, but stand up to the daily rigors applied

805.751.4853

by audio enthusiasts around the world.

www.PlanetAudioUSA.com

Due to ongoing product development, specifications are subject to change without notice.

Table of Contents

Do you have a question about the AC8D and is the answer not in the manual?

Page 1 Technical Support Congratulations on your purchase of the Planet Audio “AC” Series If you need technical support with your Planet Audio product or have Subwoofer. Planet Audio takes great pride in producing products questions about its use, please contact us: that sound and look great, but stand up to the daily rigors applied 805.751.4853...
Page 2 Enclosures The AC8D is designed to work in a very compact sized sealed enclosure, 0.35ft³. Since the woofer has pole-vent, it needs a mini- mum clearance from the rear wall of the enclosure of 0.75” (19 mm). Below you will find the dimensions to make the enclosure to suit the subwoofer, it has been designed for maximum output while retaining great sound quality.
Page 3 Wiring your Subwoofer Product Specifications Impedance 4 Ω Parallel Series Resonant Frequency 35 Hz 0.61 9.52 0.66 3.083 cu ft. (87.3 liters) Xmax 10 mm Sensitivity (1 W/ 1 m) 87 dB Peak Power Handling 1200 W 2 Ω 8 Ω Mounting Depth 5-3/16”...
