- Page 1 Congratulations on your purchase of the Planet Audio BB104D Subwoofer. Planet Audio takes great pride in producing products that sound and look great, but stand up to the daily rigors applied by audio enthusiasts around the world.
- Page 2 BB104D 10” Subwoofer Dual 4 Ω Voice Coils 1800 W Peak Power Handling Copper Cap & Sleeve for Low Distortion Designed for Sound Quality...
-
Page 3: Product Specifications
Product Specifications Dual 4 Ω Impedance 41 Hz Resonant Frequency 0.722 3.79 0.891 0.63 ft³ (17.8 liters) 13 mm Xmax Sensitivity (1 W/ 1 m) 85 dB 1800 W Peak Power Handling 6” (152 mm) Mounting Depth 9-1/8” (232mm) Cutout Diameter... -
Page 4: Wiring Options
Wiring Options Parallel Series 2 Ω 8 Ω Multiple Subwoofers 4 Ω 1 Ω... - Page 5 Enclosure The BB104D is designed to operate in two types of enclosures, sealed and ported. Since the woofer has pole-vent, it needs a minimum clearance from the rear wall of the enclosure of 0.75” (19 mm). Below you will find the dimensions to make the enclosure to suit the subwoofer, it has been designed for maximum output while retaining great sound quality.
