Page 1 PX10...
Page 2 Thank you for purchasing Planet Audio sub for vehicle use, and has the-art product carefully designed manufactured and reliable performance. been thoroughly tested to ensure consistent of your have any question about the operation manual, c ontact your dealer subwoofer which are not answered by this the first instance.
Page 3: Recommended Enclosures
Recommended Enclosures Please note : Our recommended box volumes are given for internal air requirements. Amplitude Response(dB/Hz) Sealed Enclosure PX10 -1 5 300 400 500 Frequency Sealed Enclosure Box Volume : 0.6 Cu Box is given as internal air volume including driver displacement...
Page 4 Amplitude Response{dB/Hz) Ported Enclosure PX10 - 15 300 400 500 Frequency Ported Enclosure Box Volume 1.0 Cu Ft Box is given as internal air volume including driver displacement . 45 . 5 Port Frequency Port Diameter Inches Port Length Inches...
Page 5 Subwoofer Specifications Free Air Resonance (Fs): 45.76 Hz Mechanical "Q" (Qms): 5.770 Electrical "Q" (Qes): 0.841 Total Driver "Q" (Qts): 0.734 Equivalent Compliance (Vas): 0.640 18.110 liters 10.8 mm One-Way, Linear Excursion (X-Max): Sensitivity@ 1 W/1 m: 85 dB Impedance: Power Handling : 400 W (RMS)/800 W (Max) Calculating Enclosures...
