- Page 1 Owner’s Manual M o d e l N o . 233010 WARNING FOR YOUR SAFETY: For Outdoor Use Only (outside any enclosure) Solamente Para Uso En Exteriores (fuera de cualquier recinto)
- Page 2 Keep heater away from areas where injury or property damage. Please flammable liquids, gasoline, vapors, or contact your local Natural Gas explosives are stored or used. supplier for these services. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03...
-
Page 3: Table Of Contents
1/NFPA 54, Storage and Handling of Liquid Petroleum Gases, this manual to him or her to ANSI/NFPA 58 or CSA B149.1, Natural Gas and Propane Installation save for future reference. Code. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 4: Safety First
• Prior to operating heater, replace any guards or protective devices removed for servicing. • During operation, do not touch burner assembly. The surface of heater’s emitter can reach temperatures approaching 1600ºF. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... - Page 5 • Do not clean heater with combustible or corrosive cleaners. Use warm, soapy water. • Do not paint engine, engine access panel or dome. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03...
-
Page 6: Components & Hardware
1 & 2 Large Screw Medium Screw Dome Screw Small Lockwasher 1 & 2 Cap Nut Medium Nut Small Nut 1 & 2 Clip Finial Dome Bolt Hex Wrench Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 7: Assembly Instructions
• Secure Legs to Base using (2) Large Bolts, (2) Small lock washers and (2) Small nuts per leg. Finger tighten only. • Do not fully tighten until Step 2. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 8: Step 2 Attach Platform To Legs
Shroud rests on Base. Note: The fitting at end of gas line is 3/8 NPT female. Plumbing should be done from this point according to local code. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 9: Step 4 Attach Engine To Post
• Use top three setscrews to adjust Post’s angle as necessary. • Tighten all six setscrews. Note: Post must be perpendicular to Base. Failure to do so will adversely affect burner performance. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 10: Step 6 Connect Gas Line To Engine
• Fully tighten all of the screws in the rolled edge. • Slide Dome Cap over Dome Bolt, lining up notches in cap with Dome Ribs. Thread on finial until tight. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 11: Step 8 Attach Dome To Emitter
3 Holes are provided in the base for mounting. The means of permanently mounting the heater is up to the installer, and so no hardware is provided for this proceedure. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 12: Step 10 Check For Leaks
• Release Gas Line fitting from control valve and re-attach making sure connection is secure (see Step 6). • Retighten Clip. • If you continue to see bubbles after several attempts, contact 1-800-762-1142 for assistance. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 13: Step 11 Replace Engine Access Panel
• Install (1) AA battery. Negative end of battery goes in first. • Replace battery cover cap by turning cap clockwise. Note: Once you have successfully completed assembly steps 1-12 you are ready to begin operating your heater. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 14: Operation
Viewing Hole. If not, return to first bullet point. Pilot Pilot (Push in) If you experience any ignition problem consult “Troubleshooting” on page 16. HIGH HIGH Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 15: Re-Lighting
To extinguish Pilot, depress Control Knob and continue to turn it clockwise to OFF. Turn In-line Valve clockwise to OFF when heater is not in use. Note: After use, some discoloration of the emitter screen is normal. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 16: Operations Checklist
After Operation Gas control is in OFF position. Gas Tank valve is OFF. Heater is upright in a secure location. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 17: Troubleshooting
Carbon build-up Dirt or film on reflector and emitter Clean reflector and emitter Thick black smoke Blockage in burner Remove blockage and clean burner inside and outside Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 18: Maintenance
Use high-quality automobile wax to help maintain the appearance of your heater. Apply to exterior surfaces from the pole down. Do not apply to emitter screen or domes. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 19: Storage
Caution: Use only original equipment replacement parts. Use of unauthorized parts or modification of parts will void warranty and create an unsafe condition. Caution: Always allow heater to cool before attempting service. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 20: Warranty
This warranty gives you specific legal rights. You may also have other legal rights which vary from state to state. Since product improvement is an ongoing process at the manufacturer, we reserve the right to change this product’s specifications or design without notice. Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... -
Page 21: Specifications
Maximum – 10.5” W.C. Minimum – 7.0” W.C. Manifold Pressure: 11.00 in. W.C. Engine: IPP E3 Safety Features: 100% Burner shut-off Manufacturer: Blue Rhino Global Sourcing Made In: China Owner’s manual and assembly instructions: model 233010 natural gas outdoor patio heater 1/14/03... - Page 22 104 Cambridge Plaza Drive, Winston-Salem, NC 27104 USA (NASDAQ-RINO) 1.800.762.1142, www.bluerhino.com 104 Cambridge Plaza Drive, Winston-Salem, NC 27104 USA 1.800.762.1142, www.bluerhino.com © 2003 CPD Associates, All Rights Reserved Made in China © 2003 CPD Associates, Todos los Derechos Reservados Fabricado en China PN 233010-OM-200...
