Explanation of LED Displays

Table 1
Symbol Bedeutung
Lights green when the notebook is switched on. Flashes green in power
save mode.
Lights green when the wireless LAN function (wireless network) is
activated.
Lights green when the battery is fully charged. Flashes orange when the
battery is being charged. Flashes red when the battery is almost empty.
Lights or flashes green when the optical disk drive or hard disk drive is
being accessed.
Lights when Caps Lock is on.
Lights when Num Lock is on.
Lights green when the silent mode is on.
MAXDATA Notebook ECO 4511 IW
Fig. 9
(1) Power on LED
(2) WLAN
(3) Battery level
(4) Hard disk drive / optical disk drive
(5) Caps Lock
(6) Num Lock
(7) Silent mode
7
