OWNER'S MANUAL for Models:
7030SL
7035/7035SL
IMPORTANT!
AND SAVE THIS MANUAL FOR FUTURE REFERENCE.
!
CAUTION!
CARBON MONOXIDE GAS AT THE SENSOR. CARBON MONOXIDE GAS MAY BE
PRESENT IN OTHER AREAS. THIS CARBON MONOXIDE ALARM IS DESIGNED
TO DETECT CARBON MONOXIDE GAS FROM ANY SOURCE OF COMBUSTION.
IT IS NOT DESIGNED TO DETECT SMOKE, FIRE OR ANY OTHER GAS. THIS
DEVICE IS DESIGNED TO PROTECT INDIVIDUALS FROM THE ACUTE EFFECTS
OF CARBON MONOXIDE EXPOSURE.
INDIVIDUALS WITH SPECIFIC MEDICAL CONDITIONS. IF IN DOUBT, CONSULT A
MEDICAL PRACTITIONER.
CONTENTS OF THIS MANUAL
1.... INFORMATION ABOUT CARBON MONOXIDE
2.... SPECIFICATIONS
3.... RECOMMENDED LOCATIONS OF ALARMS
4.... LOCATIONS TO AVOID
5.... INSTALLATION INSTRUCTIONS
6.... FEATURES AND OPERATION
7.... TESTING AND MAINTENANCE
8.... WHAT TO DO WHEN THE ALARM SOUNDS
9.... LIMITATIONS OF CARBON MONOXIDE ALARMS
10.... GOOD SAFETY HABITS
11.... DESCRIPTION OF AUDIBLE AND VISUAL SIGNALS
12.... SERVICE AND WARRANTY
WARNING!
!
LOW VOLTAGE WILL RENDER THIS UNIT INOPERATIVE.
Do not try to repair this carbon monoxide alarm yourself. Refer to instructions in
Section 12 for service.
9 Volt Battery CO Alarm, Single Station
9 Volt Battery CO Alarm with LCD Digital
Display and Peak Level Memory, Single Station
READ ALL INSTRUCTIONS BEFORE INSTALLATION
THIS ALARM WILL ONLY INDICATE THE PRESENCE OF
DISCONNECTING THE BATTERY OR A BATTERY WITH
- 1 -
E196731
U L
R
LISTED
IAS 6-96-2nd EDITION
IT WILL NOT FULLY SAFEGUARD
US
CO ALARM
R
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pro-Tech 7030SL
Summary of Contents for Pro-Tech 7030SL
- Page 1 E196731 LISTED IAS 6-96-2nd EDITION CO ALARM OWNER’S MANUAL for Models: 7030SL 9 Volt Battery CO Alarm, Single Station 7035/7035SL 9 Volt Battery CO Alarm with LCD Digital Display and Peak Level Memory, Single Station IMPORTANT! READ ALL INSTRUCTIONS BEFORE INSTALLATION AND SAVE THIS MANUAL FOR FUTURE REFERENCE.
-
Page 2: Information About Carbon Monoxide
1. INFORMATION ABOUT CARBON MONOXIDE WHAT IS CARBON MONOXIDE? Carbon monoxide (CO) is a highly toxic, invisible, odorless, and tasteless gas. HOW IS CO GENERATED IN THE HOME? Carbon monoxide is generated through incomplete combustion of fuel in various home appliances. Faulty ventilation of furnaces, water heaters, fireplaces, wood burning stoves, and space heaters are the major cause of high CO levels in the home. -
Page 3: Specifications
CO GAS EXPOSURE VERSUS TIME (400 PPM EXPOSURE) 400 PPM EXPOSURE MINUTES SYMPTOMS NONE NONE SLIGHT HEADACHE HEADACHE HEADACHE AND NAUSEA DROWSY VOMITING COLLAPSE COMA AND PERMANENT BRAIN DAMAGE PERMANENT BRAIN DAMAGE – DEATH 110 140 Minutes 2. SPECIFICATIONS CO RESPONSE TIME 70 PPM 60-240 MINUTES 150 PPM... -
Page 4: Recommended Location Of Alarms
RECOMMENDED LOCATION OF ALARMS The Consumer Products Safety Commission (CPSC) recommends the use of "at least one CO alarm per household located outside each sleeping area." (See diagrams "A" and “B”) CO poisoning can happen anywhere in the home, but because most CO poisoning cases occur while people are sleeping, the best location for the CO alarm is near the sleeping area in the home. -
Page 5: Installation Instructions
, Prior To Installing Your Alarm. LOCATIONS TO AVOID The proper power for the 7030SL and 7035/7035SL CO alarms is a 9V battery. Only use Ultralife U9VL-J Lithium or Duracell MN1604 Alkaline batteries. Constant exposures to high or low temperature, or high humidity, may shorten battery life. -
Page 6: Mounting Instructions
Write replacement date onto “REPLACE by” label affixed to side of alarm. MOUNTING INSTRUCTIONS: FOR 7035: FOR 7030SL/7035SL: Remove mounting plate from the box. After selecting the proper alarm location as described in Section 3, drive a screw... -
Page 7: Features And Operation
6. FEATURES AND OPERATION OPERATION: The CO alarm is operational once a battery is installed and testing is complete. The green LED will blink once per minute. For models 7035/7035SL, the LCD will also continuously display “ On” to indicate that the CO alarm has power. LOW BATTERY CONDITION: When the battery voltage drops below an acceptable level, the alarm will chirp once per minute and the green LED will blink for 5 seconds at... -
Page 8: Testing And Maintenance
7. TESTING AND MAINTENANCE WARNING! TEST YOUR CO ALARM AT LEAST ONCE A WEEK: To test your alarm, press the button on the cover and hold it down for a TEST/RESET minimum of 2 seconds until the red LED glows, then release. This test will simulate a CO concentration of approximately 150 ppm CO gas. -
Page 9: Cleaning Your Alarm
CLEANING YOUR ALARM: You can clean your alarm by using a vacuum cleaner brush to vacuum around the openings on the alarm. The outside of the alarm may be wiped with a damp cloth. AFTER CLEANING, CONFIRM THAT THE GREEN POWER LED BLINKS ONCE PER MINUTE, AND TEST YOUR ALARM BY OPERATING THE TEST/RESET BUTTON. -
Page 10: Limitations Of Carbon Monoxide Alarms
AUTOMATIC RESET: If a CO alarm activation is not manually reset, the horn will sound for at least 5 minutes. After 5 minutes, the alarm will automatically reset itself and return to normal operation if the CO which caused the alarm activation has cleared. IF YOU HAVE BEEN AWAY FROM HOME and you return to find your alarm(s) sounding, DO NOT ENTER YOUR HOME. -
Page 11: Good Safety Habits
Carbon monoxide alarms are devices that can provide an early warning of the presence of CO gas at a reasonable cost. However, alarms have sensing limitations and may not always sound a warning in the presence of CO. The alarm will not operate if the battery power is low or dead, or if the battery is missing. - Page 12 11. DESCRIPTION OF AUDIBLE AND VISUAL SIGNALS Condition LCD Readout LEDs Horn Displays “On” Green LED blinks once Normal operation Silent continuously every minute Beeps 4 times, pauses for Red LED flashes 4 times 5 seconds. Repeats this Displays current CO Alarm activation every 6 seconds in pattern for first 5 minutes.
-
Page 13: Service And Warranty
To return this product for service, pack carefully in a padded container. Ship prepaid along with your original sales receipt, an explanation of the problem and your return address to: Pro-Tech Safety Products P.O. Box 493727 Redding, CA 96049 Tel: 1-877-955-TECH (8324) http://www.protechsafety.com...
