Having trouble with the sound system?
Condition
Possible Cause
No sound (power LED not lit):
• power switch OFF
• blown fuse
No sound (power LED lights):
• no output from source
• input cable unplugged
• input volume control low or off
• accessory or expansion module not in option bay
Distorted sound:
• poor or improper connection on input cable
• input signal too strong
Excessive hum or noise:
• input cable not shielded
• not using balanced microphone
Having trouble with the wireless system?
Condition
Possible Cause
No sound (TX ON indicator lights):
• wireless volume control low or off
• no mic plugged into belt-pack transmitter
No sound (TX ON indicator off):
• sound system not turned on
• transmitter power switch turned off
• low battery or no battery in transmitter
ANCHOR Audio, Inc. (310) 784-2300
100-0135-000 / Revision A - 09/03

TROUBLESHOOTING GUIDE

Xtreme
Sound System
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Xtreme and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anchor Xtreme

Summary of Contents for Anchor Xtreme

  • Page 1: Troubleshooting Guide

    No sound (TX ON indicator off): • sound system not turned on • transmitter power switch turned off • low battery or no battery in transmitter Xtreme Sound System Owner’s Manual ANCHOR Audio, Inc. (310) 784-2300 100-0135-000 / Revision A - 09/03...

  • Page 2: Important Safeguards

    210 - 240 VAC, 50/60 Hz, 250 watts max. (250 watts maximum) DATE OF MANUFACTURE The date of manufacture of this Anchor Audio product can be determined by the six digit Dimensions (HWD): 22.5 x 13 x 10", 57 x 33 x 26 cm serial number code.
  • Page 3 Dual function (speech projection on/off) unpowered companion speaker for the Xtreme Sound System (Speaker cable not included) and workmanship. We’re proud of our products and appreciate the confidence which you have shown by SC-50NL selecting an Anchor system.

  • Page 4: Getting Started

    Returning Systems For Service or Repair Harmful 1. Unscrew battery compartment cover on lower end of mic. feedback may Should your unit require service, contact your dealer or the Anchor IMPORTANT: occur when 2. Install 2 fresh ‘AA’ alkaline batteries.
  • Page 5 The wireless receiver is mounted inside If you • Sound reflections from hard surfaces, walls, etc. experience the Xtreme and can be set to any of 16 available channels. ongoing Avoiding & Eliminating Feedback 1. Locate the Wireless Channel interference selector on the back panel.

  • Page 6: System Setup

    This will benefit the of the Xtreme for a composite output. listeners in the rear while minimizing the risk of overpowering the CD Slot listeners in front.

  • Page 7: General Operation

    Speaker Out Two Unit Application The Speaker Out on the Xtreme is a biamped output (separate Place each unit along the aisles pointing just off the centerline of the amplifier for each of the high and low frequencies) intended for use audience.
  • Page 8 You can use this function to record your presentation or with shielded Condenser cable to avoid to "daisy chain" another powered sound system to the Xtreme for Mic Power hum, buzzing greater crowd coverage. Note: This output is post source level; any...
