Instruction
Sheet
forWaterTank
Insulation
Installation
Kit Part # 106807
(W101 77505)
Kit Contents:
1 Instruction
Sheet
2 1 1!2"screws
1 EPS Foam Block
1 Foam Tape
NOTE: This kit fits non-Iceland
25 cu. ft. models.
1.
Unplug the refrigerator
or disconnect
power.
2.
Remove crisper drawers ( Figure l ),crisperglasstop(Figure2)andcrisperframe(Figure3).
FigureI
Figure 2
Figure 3
3.
If present,
remove previously
installed gasket from the back flange of crisper frame and permagum
surrounding
the dell air feed hole
(this will require disassembly
of dell pantry).
4.
Using a 1/4"hex driver, unscrew the water tank while keeping
the water lines connected.
See Figure 4.
Figure 4
5.
Checkwatertankandc_nnectingwater_inesf_ranyfr_zenwater._ficeispresent_defr_stwithaheatgun.
©WMrtpooE Corporation 2 007
Instruction
Sheet W10130142 Rev.A 8/07
(AItRightsReserved)
page 1 of 2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dacor EF36BNFSS
Summary of Contents for Dacor EF36BNFSS
- Page 1 Instruction Sheet forWaterTank Insulation Installation Kit Part # 106807 (W101 77505) Kit Contents: 1 Instruction Sheet 2 1 1!2"screws 1 EPS Foam Block 1 Foam Tape NOTE: This kit fits non-Iceland 25 cu. ft. models. Unplug the refrigerator or disconnect power.
- Page 2 Apply foam tape to EPS Foam Block as shown in Figure 5. EPS FOAM BLOCK Tip the water tank forward and push it onto the EPS Foam Block as shown in Figure 6. _u_6 Using the (2) 1-1/2" screws provided in the kit, screw the water tank and EPS Foam Block back into the refrigerator with a W' hex driver.
