System and Network Setup ................10 Build Network Connection................10 2.1.1 Router Mode...................10 2.1.2 AP Mode....................11 2.1.3 Wi-Fi AP Mode ..................11 Connecting GR-1736..................11 Network setup....................12 2.3.1 Windows 2000..................12 2.3.2 Windows XP ...................13 2.3.3 Windows Vista / Windows 7 ..............14 Router IP Address Lookup................16...
Page 3
Statistics ....................68 6.3.2 Change Password ...................69 6.3.3 Firmware Upgrade.................69 6.3.4 Profile Save .....................70 6.3.5 Remote Manager..................73 6.3.6 Time Zone Setting ..................73 6.3.7 UPnP Setting...................74 6.3.8 VPN Passthrough Setting ..............75 6.3.9 Language Setting..................76 6.3.10 Routing Setup ..................77 User Manual v1.0.0 http://www.sapido.com.tw/...
Page 4
6.4.1 Network Config ..................81 6.4.2 Event Log....................83 Logout ......................84 Chapter 7 Samba Server ....................85 How to use GR-1736 as a Samba server ............85 Air play ......................86 Printer Server....................87 Chapter 8 DDNS Service Application ................89 Chapter 9 Q & A ......................94 Installation ......................94...
IMPORTANT NOTE FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance20cm between the radiator & your body. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 6
"Council Directive on the Approximation of the Laws of the Member Sates relating to Electromagnetic Compatibility" (89/336/EEC; 92/31/EEC; 93/68/EEC). The Declaration of Conformity can be found at the Sapido regional website. www.sapidotech.de CE Information of Disposal The electric and electronic equipment or unit which is labeled with crossed-out wheeled bin may not be disposed of with household waste.
Chapter 2 System and Network Setup The GR-1736 is an easy to setup and wireless device for various application and environment, especially for large installs such as hotels, offices space, warehouses, hot-spots and more. To begin with GR-1736, you must have the following minimum system requirements. If your system can’t correspond to the following requirements, you might get some unknown troubles...
Wi-Fi AP Mode Switch to WiFi AP Mode when you connect to the internet wirelessly through PC and wireless device without wireless LAN function equipped. Connecting GR-1736 Prepare the followings before the connection: PC or Notebook for setup ...
Make sure you are under “Router Mode”. Connect GR-1736 to xDSL/ Cable modem with the Ethernet cable, WAN to LAN. Turn on your Computer. Network setup After the network connection is built, the next step is setup the router with proper network parameters, so it can work properly in your network environment.
Click “Start” button (it should be located at lower-left corner of your computer), then click control panel. Double-click Network and Internet Connections icon, click Network Connections, then double-click Local Area Connection, Local Area Connection Status window will appear, and then click “Properties”. User Manual v1.0.0 http://www.sapido.com.tw/...
Click “Start” button (it should be located at lower-left corner of your computer), then click control panel. Click View Network Status and Tasks, and then click Manage Network Connections. Right-click Local Area Network, then select “Properties”. Local Area User Manual v1.0.0 http://www.sapido.com.tw/...
Page 15
Connection Properties window will appear, select “Internet Protocol Version 4 (TCP / IPv4)”, and then click “Properties”. Select “Obtain an IP address automatically” and “Obtain DNS server address automatically”, then click “OK”. User Manual v1.0.0 http://www.sapido.com.tw/...
Input “cmd”, and then click “OK”. Input “ipconfig”, then press “Enter” key. Please check the IP address followed by “Default Gateway” (In this example, the gateway IP address of router is 192.168.1.1) User Manual v1.0.0 http://www.sapido.com.tw/...
IP address of the wireless router in address bar, and the following message should be shown. Please click “admin” to login the GR-1736. Enter the User name and Password in to the blank and then Click Login. The default values for User Name and Password are admin (all in lowercase letters).
Page 18
User Manual v1.0.0 http://www.sapido.com.tw/...
Chapter 3 Internet Connection This Chapter describes how to setup GR-1736 to the internet. The GR-1736 is delivered with the following factory default parameters. Default IP address: 192.168.1.1 (Router Mode) 192.168.1.254 (AP Mode) 192.168.1.254 (WiFi AP Mode) Default IP subnet mask: 255.255.255.0...
Page 20
2. Google Android Phone: please turn on "USB modem mode” when connecting router. 3. Window Mobile Phone: please enable “USB to PC” function. User Manual v1.0.0 http://www.sapido.com.tw/...
Enter the User name and Password into the blank and then click Login. The default values for User Name and Password are admin (all in lowercase letters). 3.2.1 One button setup This page is used to configure all of the server router function. User Manual v1.0.0 http://www.sapido.com.tw/...
BR485d support 2.4GHz and 5GHz band Wireless Setup Input DNS information which is provided by your ISP Encryption 3.2.2 Parental Control 3.2.2.1 URL Filtering URL Filtering is used to restrict users to access specific websites in internet User Manual v1.0.0 http://www.sapido.com.tw/...
URL Filtering function. 3.2.2.2 Mac Filter Schedule When enabled, filtering will be based on the MAC address of LAN computers. Any computer with its MAC address on this list will be blocked from accessing the Internet. User Manual v1.0.0 http://www.sapido.com.tw/...
Current Filter Table Click Delete Selected will delete the selected item. Click Delete All Delete Selected & Delete will delete all items in this table. Reset You can click Reset to cancel. 3.2.2.3 Schedule Wireless available schedule User Manual v1.0.0 http://www.sapido.com.tw/...
3.2.3 AirCloud Storage 3.2.3.1 FTP server Item Description FTP server start or stop Enable FTP Server Agree anonymous account login to FTP server Enable Anonymous to Login User Manual v1.0.0 http://www.sapido.com.tw/...
The WAN access type is depended on the service that you contract with the provider. The GR-1736 provides five selections for the WAN access type, Static IP, DHCP Client, PPPoE, PPTP and L2TP. Check with your ISP if you don’t know the WAN type.
3.2.4.1 Static IP Select WAN under the IP Config menu, and choose Ethernet Port for the WAN Interface. Its associated setting will show up. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 28
Input ISP Default Gateway Address, . Default Gateway Input DNS information which is provided by your ISP Select 3G as a back up solution or none. Backup select Some ISPs require MAC address registration. In this case, enter Clone Mac Address User Manual v1.0.0 http://www.sapido.com.tw/...
Reset to clear all the input data. 3.2.4.2 DHCP Client Item Description Select "DHCP Client" WAN Access Type You can keep the default as the host name, or input a specific Host Name name if required by your ISP. User Manual v1.0.0 http://www.sapido.com.tw/...
MAC address registered to the provider to "Clone MAC Address" Click on Apply Change to save the setting date, or you may click Apply Change & Reset on Reset to clear all the input data. 3.2.4.3 PPPoE User Manual v1.0.0 http://www.sapido.com.tw/...
Page 31
MAC address registered to the provider to "Clone MAC Address" Click on Apply Change to save the setting date, or you may click Apply Change & Reset on Reset to clear all the input data. User Manual v1.0.0 http://www.sapido.com.tw/...
3.2.4.4 PPTP Item Description Select "PPTP" WAN Access Type Input your server IP address provided by your ISP. If you don’t Server IP Address know, please check with your ISP. User Manual v1.0.0 http://www.sapido.com.tw/...
MAC address registered to the provider to "Clone MAC Address" Click on Apply Change to save the setting date, or you may click Apply Change & Reset on Reset to clear all the input data. 3.2.4.5 L2TP User Manual v1.0.0 http://www.sapido.com.tw/...
WAN IP address, to see is there any WAN IP address available. This option is to enable Web Server Access function on WAN. Enable Web Server Access on WAN User Manual v1.0.0 http://www.sapido.com.tw/...
Enter the subscribing access point's phone number. Phone Number Select Attain DNS Automatically. Or select Set DNS Manually, if you want to specify the DNS, and enter the DNS provided by your ISP in DNS 1 2 3. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 36
WAN IP address available. This option is to enable Web Server Access function on WAN. Enable Web Server Access on WAN Click “Finish” to complete the setting Apply Change Rebooting this product is started. Please wait for a while. User Manual v1.0.0 http://www.sapido.com.tw/...
MAC address registered to the provider to "Clone MAC Address" Click on Apply Change to save the setting date, or you may click Apply Change & Reset on Reset to clear all the input data. User Manual v1.0.0 http://www.sapido.com.tw/...
Open a Web browser, and enter (Default Gateway) into the blank. Enter the User name and Password in to the blank and then Click Login. The default values for User Name and Password are admin (all in lowercase letters). User Manual v1.0.0 http://www.sapido.com.tw/...
Page 39
MAC address registered to the provider to "Clone MAC Address" Click on Apply Change to save the setting date, or you may click Apply Change & Reset on Reset to clear all the input data. User Manual v1.0.0 http://www.sapido.com.tw/...
WiFi AP Mode- Using as a Network Converter Make sure to shift the mode into WiFi AP Mode. http://192.168.1.254 The default gateway is and for User Name and Password are admin (all in lowercase letters). Click Login to enter. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 41
MAC address registered to the provider to "Clone MAC Address" Click on Apply Change to save the setting date, or you may click Apply Change & Reset on Reset to clear all the input data. User Manual v1.0.0 http://www.sapido.com.tw/...
Chapter 4 Wireless Setup Wireless Setup There are two ways to setup wireless LAN with GR-1736. You can use either way to setup Wireless LAN. 4.1.1 Setup Wireless LAN by WPS button You can setup wireless LAN easily by using the WPS button if both WLAN router and the WLAN adapter (client) are WPS supported.
Page 43
(7) Back to the WLAN adapter utility and click its “PBC” (C) button. The utility will start searching the destination connection. (8) Confirm the information form the Utility User Manual v1.0.0 http://www.sapido.com.tw/...
(9) After completes the WPS setup. Please confirm that it can be connected to the Internet. Note: The setup image might be some differences when using other branded Adapter. 4.1.2 Wireless Basic Setup from Web GUI The Wireless Basic Settings include Band, Mode, SSID, Channel Number and other wireless settings. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 45
Enable this function will control your router use lower or upper channel. 2.4G Channel Number Please select the channel; it has Auto, 1, 2~11 or 13 options. 5G Channel Number Please select the channel; it has Auto, 36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132,1 36,140,149,153,157,161,165. http://www.sapido.com.tw/ User Manual v1.0.0...
4.1.2.1 Multiple APs The GR-1736 can support several SSIDs (wireless LAN group). It can be used as if there are multiple wireless LAN access points with one product. Each SSID could be set with different data rate, WMM and access type.
Example: When users enable the Universal Repeater to connect to the upper level device, please fill in the upper level devices channel and SSID. Click on Apply Changes to save the settings. (Please disable the DHCP service first) User Manual v1.0.0 http://www.sapido.com.tw/...
There are five Encryption types supported: “None”, “WEP”, “WPA (TKIP)”, ”WPA2(AES)”, and “WPA2 Mixed”. Enabling WEP can protect your data from eavesdroppers. If you do not need this feature, select “None” to skip the following setting. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 49
It is a safety system by using authentication to protect your wireless network. Encryption- WPA (WPA, WPA2, and WPA2 Mixed), WPA Authentication Mode (1) Enterprise (RADIUS): Please fill in the RADIUS server Port, IP Address, and Password User Manual v1.0.0 http://www.sapido.com.tw/...
Select column and click on “Delete Selected” button. Take the wireless card as the example. (1) Please select Deny Listed in Wireless Access Control Mode first, and then fill in the MAC User Manual v1.0.0 http://www.sapido.com.tw/...
Page 51
MAC Address field. Click Apply Changes to save the setting. (2) The MAC address what you set will be displayed on the Current Access Control List. (3) The wireless client will be denied by the wireless router. User Manual v1.0.0 http://www.sapido.com.tw/...
Chapter 5 Router Mode Security Setup This section contains configurations for the GR-1736’s advanced functions such as: virtual server, DMZ, and Firewall to provide your network under a security environment. 5.1.1 Virtual Server The Virtual Server feature allows users to create Virtual Servers by re-directing a particular range of service port numbers (from the WAN port) to a particular LAN IP address.
Please enter the specific IP address for DMZ host. DMZ Host IP Address Click on Apply Changes to save the setting data. Or you may click Apply Changes & Reset on Reset to clear all the input data. User Manual v1.0.0 http://www.sapido.com.tw/...
Kbps or check the Automatic uplink speed. Manual Uplink Speed Set the downlink speed by manual to assign the download or upload Automatic downlink bandwidth by the unit of Kbps or check the Automatic downlink speed / Manual Downlink speed. Speed User Manual v1.0.0 http://www.sapido.com.tw/...
Apply Changes & Reset on Reset to clear all the input data. It will display all ports that are filtering now. Current Filter Table Click Delete Selected will delete the selected item. Click Delete All Delete Selected & Delete User Manual v1.0.0 http://www.sapido.com.tw/...
When enabled, LAN clients are blocked / filtered from accessing the Internet based on their IP addresses. Item Description Please select Enable IP Filtering to filter IP addresses. Enable IP Filtering Please enter the IP address that needs to be filtered. Local IP Address User Manual v1.0.0 http://www.sapido.com.tw/...
Current Filter Table Click Delete Selected will delete the selected item. Click Delete All Delete Selected & Delete will delete all items in this table. Reset You can click Reset to cancel. 5.2.4 Denial of Service User Manual v1.0.0 http://www.sapido.com.tw/...
VLAN Settings Item Description Add VLAN tag to packet Set VLAN ID(1~4096) It indicates the frame priority level. Values are from 0 (best effort) to Priority 7 (highest); 1 represents the lowest priority Enable or Disable CIF User Manual v1.0.0 http://www.sapido.com.tw/...
Enable or disable the webcam Control from the WAN side Whether to allow viewing webcam images from the WAN Port webcam Connection port view webcam View live webcam video watch Record Setup Save form: Provide two formats AVI and JPG User Manual v1.0.0 http://www.sapido.com.tw/...
Page 61
How many frames in one folder Note:a JPG file size is about 13KB, and AVI file size is about 45127KB (when maximum recording frames is 1000), file size may vary due to webcam models have different sizes User Manual v1.0.0 http://www.sapido.com.tw/...
WAN is changed, and the information will be updated to DDNS service provider automatically. Choose correct Service Provider from drop-down list, here including Service Provider DynDNS, TZO, ChangeIP, Eurodns, OVH, NO-IP, ODS, Regfish GR-1736 embedded in User Manual v1.0.0 http://www.sapido.com.tw/...
Click on Apply Changes to save the setting data. Or you may click on Apply Changes & Reset Reset to clear all the input data. Wireless Advanced Setup In Advanced Settings page, more 802.11 related parameters are tunable. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 64
Users can get better wireless transmission efficiency when they Short GI enable this function. Users can adjust RF output power to get the best wireless network RF Output Power environment. Users can choose from 100%, 70%, 50%, 35%, and User Manual v1.0.0 http://www.sapido.com.tw/...
Access Point in a minute without any hassle. GR-1736 could support both Self-PIN or PBC modes, or use the WPS button (at real panel) to easy enable the WPS function.
Page 66
(2). Fill in the PIN number from the wireless card in Client PIN Number field, and then click “Start PIN”. (3). Click PIN from Adapter Utility to complete the WPS process with the wireless router. User Manual v1.0.0 http://www.sapido.com.tw/...
Start PBC: (1). Press the WPS button (A) from GR-1736 and wait for Wireless/WPS LED light (B) changed into orange. (2). Press the WPS button (C) from the adapter until the setup window shows up. (3). Open a web browser to check the internet connection.
6.3.1 Statistics It shows the packet counters for transmission and reception regarding to Ethernet networks User Manual v1.0.0 http://www.sapido.com.tw/...
This function can upgrade the firmware of the router. There is certain risk while doing firmware upgrading. Firmware upgrade is not recommended unless the significant faulty is found and published on official website. If you feel the router has unusual behaviors and is caused environment. check website User Manual v1.0.0 http://www.sapido.com.tw/...
Users can create a backup file that contains current router settings. This backup file can be used to restore router settings. This is especially useful in the event you need to reset the router to its default settings. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 71
Save Configuration (1). Click Save (2). Please click “Save” to save the configuration to your computer. (3). Select the location which you want to save file, then click Save. Load configuration file (1). Click Choose File User Manual v1.0.0 http://www.sapido.com.tw/...
Page 72
(2). Select configuration file then click Open (3). Click Upload to upload configuration file to GR-1736. (4). After 90 seconds, GR-1736 will reboot automatically. Reload factory default setting (1). Please click Reset User Manual v1.0.0 http://www.sapido.com.tw/...
(2). Please click OK to start reload factory default setting to GR-1736. (3). After 90 seconds, GR-1736 will reboot automatically. 6.3.5 Remote Manager Item Description HTTP Connection Port Users can access GUI by this port,default is 80 Allow user access GUI from WAN side...
Please click on Apply Changes to save the setting data. Or you Apply Changes & Reset & may click on Reset to clear all the input data. Or you may click on Refresh Refresh to update the system time on the screen. 6.3.7 UPnP Setting User Manual v1.0.0 http://www.sapido.com.tw/...
(data sharing, communications, and entertainment) and in corporate environments for simplified installation of computer components. GR-1736 supports UPnP function, and can cooperate with other UPnP devices. When you activate UPnP, please click My Network Places. Users will see an Internet Gateway Device icon.
Reset to clear all the input data. Refresh 6.3.9 Language Setting The GR-1736 provide 12 languages for Web GUI. You can select the language interface from the dropdown list and by following steps. User Manual v1.0.0 http://www.sapido.com.tw/...
It is the type of routing characterized by the absence of communication between routers regarding the current topology of the network.This is achieved by manually adding routes to the router routing table. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 78
There are 3 options: Transmit Disable:do not send any RIP packet out Send RIP1 packet out Send RIP2 packet out There are 3 options: Receive Disable:do not receive any RIP packet Only receive RIP1 packet Only receive RIP2 packet User Manual v1.0.0 http://www.sapido.com.tw/...
Motherboard that supports WOL, as well as a Network Controller (NIC) supporting this function. Most of the newer Motherboard (circa 2002 and On), have an On Board NIC that supports WOL. Otherwise you need to install a PCI NIC that is WOL capable. User Manual v1.0.0 http://www.sapido.com.tw/...
Log & Status The category provides Network Config and Event Log status for users to know the operation status. User Manual v1.0.0 http://www.sapido.com.tw/...
6.4.1 Network Config Users can check the Internet status under this category, including Firmware version, Wireless setting, Connecting Time, WAN, TCP/IP …information. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 82
User Manual v1.0.0 http://www.sapido.com.tw/...
Apply Changes & Refresh & to renew the system time, or on Clear to clear all the record. Clear * The following figure is an example when users click Apply Changes to record the event log. User Manual v1.0.0 http://www.sapido.com.tw/...
Logout This function logs out the user. 6.6 App Hyperlinks provide users quick and convenient for users to download with a third-party software on the machine User Manual v1.0.0 http://www.sapido.com.tw/...
Chapter 7 Samba Server The GR-1736 is able to act as a Samba server to share the file on USB storage in local network. How to use as a Samba server GR-1736 Plug in the USB hard disk/Flash. \\192.168.1.1 Star your web browser and input Star “My Computer”...
5. Click Next, and then provide the following information: In Name or address of server providing LPD, type the Domain Name System (DNS) name or Internet Protocol (IP) address of the host for the printer you are adding. The User Manual v1.0.0 http://www.sapido.com.tw/...
Page 88
A network-connected printer must have a card that supports LPD for LPR printing to work properly. You can also add ports using the Print Server Properties dialog box. For more information, click Related Topics. Please refer DUT/Network Config page to get name of printer User Manual v1.0.0 http://www.sapido.com.tw/...
If you don’t have a DDNS account, please follow the steps to complete your DDNS with Dynamic IP settings. http://www.dyndns.com/ First access the Internet and fill into the address field of your web browser, then click Create Account. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 90
Fill in the form as required, and then click on Create Account button. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 91
When you got this account created message, close it, and check your mailbox. You would get a mail from DynDNS website. Click on the indicated address within your mail to confirm. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 92
Click on login. Click My Services after logging in. Click Add New Hostname. Put in your favorite hostname and service type, and then click Create Host after finished. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 93
Your hostname has been created when you see the following page. User Manual v1.0.0 http://www.sapido.com.tw/...
LAN cable, the changes cannot be made, or password is lost. A: In case GR-1736 is inaccessible; you can try to restore its factory default settings. Please press the “Reset” button and keep it pressed for over 7 seconds and the light of STATUS will vanish.
A: There are two ways to know. Way 1: Check with your Internet Service Provider. Way 2: Check the setting screen of GR-1736. Click on Status & Log item to select Network Configuration on the Main Menu. WAN IP is shown on the WAN interface.
Page 96
5. Select Direct connection to the Internet and click on OK button. 6. Click on OK button. Web page hangs, corrupt downloads, or nothing but junk characters is being displayed on the screen. What do I need to do? User Manual v1.0.0 http://www.sapido.com.tw/...
Q: Why does GR-1736’s setup page shut down unexpectedly? A: If one of the pages appears incompletely in GR-1736 ’s setup pages, please click on Logout item on the Main Menu before shutting it down. Don’t keep it working. Then, close Internet browser and open it again for going back to the previous page.
Finally, you might want to keep the system you're trying to configure in the same room as the router, at least during the initial configuration, in order to minimize potential interference from concrete walls or steel beams. User Manual v1.0.0 http://www.sapido.com.tw/...
Page 99
RF Shielding: Your environment may tend to block transmission between the wireless stations. This will mean high access speed is only possible when close to the Access Point. Q: Some applications do not run properly when using the Wireless Router. User Manual v1.0.0 http://www.sapido.com.tw/...
A: The default WEP of WinXP is Authentication Open System - WEP, but the WEP of GR-1736 is only for Shared Key - WEP, it caused both sides couldn’t communicate. Please select the WEP of WinXP from Authentication Open System to Pre-shared Key - WEP, and then the WEP wireless interface between WinXP and GR-1736 would be communicated.
In this situation, we suggest to disable DHCP server in router and configure your PC manually. USB Device Q: How many USB devices can be connected to the Product? A: GR-1736 has 2 USB ports. User Manual v1.0.0 http://www.sapido.com.tw/...
FireFox ver. 2.0.0.11 and the following related versions.3. Safari ver. 3.04 and the following related versions. 10.3 Communications Regulation Information Should any consumers need to learn more information, services and supports, please contact the supplier of your product directly. User Manual v1.0.0 http://www.sapido.com.tw/...
