  • Page 2 FCC Caution FCC Part 15.19 Caution: This device complies with Part 15 of the FCC Rules. Operation is subject to the • following two conditions: ◦ this device may not cause harmful interference and ◦ this device must accept any interference received, including interference that may cause undesired operation This device and its antenna(s) must not be co-located or operating in conjunction •...
  • Page 3 BR476n provides many Internet connecting way. It provides not only Ethernet (wired), but also 802.11n Wi-Fi、3.5G、Smartphone、LTE for user to choose. Rigorous Security mechanism • BR476n provides Wireless Security, Firewall to make sure that the data of user in network are protected securely. Easy to configure and manage •...
  • Page 4 Make sure you are under “Router Mode”. • Turn on your Computer. • Connect BR476n ethernet port to xDSL/ Cable modem with the Ethernet cable / • 3.5G dongle / LTE dongle / smartphone. Connect PC/NB to BR476n by wireless.
  • Page 5 Users can set or change user name and password used for accessing the web • management interface in this section. Input User Name and New Password, then input confirm password again. •...
  • Page 6 3 Function introduction Open a Web browser, and enter http://192.168.1.1 (Default Gateway) Download pdapp Logout Status page 3.1 Home menu Click Home button icon to enter MENU as below.
  • Page 7 Item Description Internet Setup There are several different method to access Internet，PPPoE、DHCP、Static IP、PPTP、L2TP、WiFi ISP If a router is already set at the house, and you want to make the wireless LAN communication WiFi AP When you connect to the internet wirelessly through PC and wireless device without wireless LAN function equipped.
  • Page 8 3.2 Internet Setup Click Internet Setup icon to enter WAN setup as below. The Internet Setup is depended on the service that you contract with the provider. The BRB72N provides five selections for the Internet Mode type, PPPoE, DHCP, Static IP , PPTP and L2TP 、 WiFi ISP、3.5G、Smart Phone、LTE.
  • Page 9 3.2.1 PPPoE Item Description User Name Input your user name provided by your ISP. If you don’t know, please check with your ISP. Password Input the password provided by your ISP. Wireless AP Turn on/off wireless SSID Service Set identifier, users can define to any or keep as default.
  • Page 10 Description MAC type Select "Universal” or “Specific" Universal：clone controller PC mac address as BR476n WAN mac address Specific：use BR476n itself mac address Wireless AP Turn on/off wireless SSID Service Set identifier, users can define to any or keep as default.
  • Page 11 3.2.3 Static IP Item Description IP Address Enter the IP address which is provided by your ISP. Subnet Mask Please enter the Subnet Mask address Gateway Input ISP Default Gateway Address. Input DNS information which is provided by your ISP Wireless AP Turn on/off wireless SSID...
  • Page 12 3.2.4 PPTP Item Description Address Mode Select "Dynamic" or "Static" Server IP Address Input your server IP address provided by your ISP. If you don’t know, please check with your ISP. User Name Input PPTP account provided by your ISP. Password Input the password provided by your ISP.
  • Page 13 3.2.5 L2TP Item Description Address Mode Select "Dynamic" or "Static" Server IP Address Input your server IP address provided by your ISP. If you don’t know, please check with your ISP. User Name Input L2TP account provided by your ISP. Password Input the password provided by your ISP.
  • Page 14 3.2.6 WiFi ISP BR476n WAN get IP address from other wireless AP and LAN/Wireless LAN client get IP from BR476n Item Description Survey List all available wireless AP Pre-Shared Key Input the wireless AP key which you want to connect...
  • Page 15 Mode Input your user name provided by your ISP. If you don’t know, please check with your ISP. Network Traffic Monitor BR476n will record 3.5G traffic usage volume Limit Internet Traffic User can limit 3.5G traffic usage volume to prevent...
  • Page 16 3.2.8 Smartphone Item Description Service BR476n support 4 kinds of smart phone、Nokia、Black Berry、Sansung、iPhone and Andriod phone iPhone and Andriod phone do not need to do any setting，all you need is to turn on hotspot function and connect it to USB port...
  • Page 17 Mode Input your user name provided by your ISP. If you don’t know, please check with your ISP. Network Traffic Monitor BR476n will record 3.5G traffic usage volume Limit Internet Traffic User can limit 3.5G traffic usage volume to prevent...
  • Page 18 3.3 AP If a router is already set at the house, and you want to make the wireless LAN communication. This mode does not support WAN、DHCP、NAT、DDNS、QoS、Firewall、Static/Dynamic route、VPN Server features Item Description Wireless AP Turn on/off wireless SSID Service Set identifier, users can define to any or keep as default.
  • Page 19 Survey List all available wireless AP Pre-Shared Key Input the wireless AP key which you want to connect Extend SSID Provide SSID for wireless client which want to connect to BR476n Encryption Select wireless encryption type form the drop-down list.
  • Page 20 3.5 Firmware Upgrade This function can upgrade the firmware of the router. There are two methods for user upgrade firmware: Auto upgrade and Manual upgrade. Caution: To prevent that firmware upgrading is interrupted by other wireless signals and causes failure. We recommend users to use wired connection during upgrading.
  • Page 21 3.6 Parental Control Parental Control provide URL Filtering and MAC Filter Schedule for setup 3.6.1 URL Filtering URL Filtering is used to restrict users to access specific websites in internet Item Description Enable URL Filtering Please select Enable MAC Filtering to filter MAC addresses URL Address Please enter the MAC address that needs to be filtered.
  • Page 22 3.6.2 MAC Filter Schedule When enabled, filtering will be based on the MAC address of LAN computers. Any computer with its MAC address on this list will be blocked from accessing the Internet.
  • Page 23 3.6.3 Wireless Schedule Wireless available schedule, this page allows you setup the wireless schedule rule. Please do not forget to configure systeim before enable this feature...
  • Page 24 Office control provide Multiple AP、Wireless Access Control、IP Filtering、IP Binding、QoS 3.7.1 Multiple AP The BR476n can register up to 4 SSIDs (wireless LAN group). It can be used as if there are multiple wireless LAN access points with one product. Item...
  • Page 25 3.7.3 IP Filtering When enabled, LAN clients are blocked / filtered from accessing the Internet based on their IP addresses Item Description Enable IP Filtering Please select Enable IP Filtering to filter IP addresses. Local IP Address Please enter the IP address that needs to be filtered. Protocol Please select the protocol type of the IP address Apply...
  • Page 26 3.7.4 IP Binding This function allows you reserve IP addresses, and assign the same IP address to the network device with the specified MAC address any time it requests an IP address. This is almost the same as when a device has a static IP address except that the device must still request an IP address from the DHCP server.
  • Page 27 3.7.5 QoS The QoS can let you classify Internet application traffic by source/destination IP address and port number. To assign priority for each type of application and reserve bandwidth can let you have a better experience in using critical real time services like Internet phone, video conference …etc.
  • Page 28 3.8 File Menu Only support one USB disk for Samba and FTP 3.8.1 Samba Storage Item Description Share mode User can access USB disk without account and password User mode User need account to access USB disk（login account is “admin”，password is “admin”）. 3.8.2 FTP Server Item Description...
  • Page 29 Enable FTP Server FTP server start or stop Enable Anonymous to Agree anonymous account login to FTP server Login Enable FTP Access Allow user access device FTP server from WAN from WAN side（internet） FTP Server Port Default FTP server port is 21 Idle Connection Time- FTP process should have an idle timeout, which will terminate the process and close the control connection if...
  • Page 30 3.9 Webcam Server Webcam server only support one webcam Item Description Enable Webcam Webcam start or stop Access from WAN Allow user to see webcam image from WAN side（internet） Connection Port Define webcam access port，default is 8080 Preview See webcam image Archive Format Setting Set remote FTP server information for recording webcam image...
  • Page 31 3.10 VPN Server The VPN Server function providing PPTP/L2TP mode are designed to allow users to an external network device / computer and office local area network to establish a secure network connection. And User can safe login office local area network and access to personal documents, files Sharing and other resources.
  • Page 32 3.11 DoS Item Description Home Check “Home” to enable DoS function for prevention. You also can check “No Prevention” to disable DoS function. Enterprise Check “Enterprise” to enable DoS function for prevention. You also can check “No Prevention” to disable DoS function.
  • Page 33 3.12 Remote Management This page allows you to access the GUI on WAN Item Description HTTP Connection Port Users can access GUI by this port，default is 80 Enable Web Server Allow user access GUI from WAN side Access on WAN...
  • Page 34 3.13 Status You could check WAN, LAN, Client network in status WAN Configuration • LAN Configuration •...
  • Page 35 Client Configuration • Allow or block client to access internet Client Configuration •...
  • Page 36 3.14 Factory Default You could reset the current configuration to factory default. 3.15 Reboot This function is used to reboot 3.16 Logout This page is used to logout...
  • Page 37 4 Advance Setup 4.1 Internet Mode 4.1.1 Internet Setup Please refer Internet Setup 4.1.2 AP Please refer AP mode 4.1.3 WiFi AP Please refer WiFi AP mode 4.1.4 WiFi ISP Please refer WiFi ISP mode 4.2 IP Config 4.2.1 WAN 4.2.1.1 PPPoE Item...
  • Page 38 Demand, and Manual. MTU Size Maximum Transmission Unit. Usually provide by computer operation systems (OS). Advanced users can set it manually. Select Attain DNS Automatically. Or select Set DNS Manually, if you want to specify the DNS, and enter the DNS provided by your ISP in DNS 1 2 3.
  • Page 39 4.2.1.2 DHCP Item Description Host Name You can keep the default as the host name, or input a specific name if required by your ISP. MTU Size Maximum Transmission Unit. Usually provide by computer operation systems (OS). Advanced users can set it manually.
  • Page 40 4.2.1.3 Static IP Item Description IP Address Enter the IP address which is provided by your ISP. Subnet Mask Please enter the Subnet Mask address Gateway Input ISP Default Gateway Address. MTU Size Maximum Transmission Unit. Usually provide by computer operation systems (OS). Advanced users can set it manually.
  • Page 41 4.2.1.4 PPTP Item Description Enable Dynamic Route Enable or Disable dynamic route IP Address Enter the IP address which is provided by your ISP. User Name Input PPTP account provided by your ISP. Password Input the password provided by your ISP. MTU Size Maximum Transmission Unit.
  • Page 42 for execute current configuration. 4.2.1.5 L2TP Item Description Enable Dynamic Route Enable or Disable dynamic route IP Address Enter the IP address which is provided by your ISP. User Name Input L2TP account provided by your ISP. Password Input the password provided by your ISP. MTU Size Maximum Transmission Unit.
  • Page 43 Mode Input your user name provided by your ISP. If you don’t know, please check with your ISP. Network Traffic Monitor BR476n will record 3.5G traffic usage volume Limit Internet Traffic User can limit 3.5G traffic usage volume to prevent...
  • Page 44 Select correct phone service region Select correct phone service ISP Phone Type BR476n support 4 kinds of smart phone、Nokia、Black Berry、Sansung、iPhone and Andriod phone iPhone and Andriod phone do not need to do any setting，all you need is to turn on hotspot function and connect it to USB port Provide 3 kinds of speed，auto is recommended...
  • Page 45 Manually, if you want to specify the DNS, and enter the DNS provided by your ISP in DNS 1 2 3. Clone Mac Address Some ISPs require MAC address registration. In this case, enter the MAC address registered to the provider to "Clone MAC Address"...
  • Page 46 Mode Input your user name provided by your ISP. If you don’t know, please check with your ISP. Network Traffic Monitor BR476n will record 3.5G traffic usage volume Limit Internet Traffic User can limit 3.5G traffic usage volume to prevent...
  • Page 47 4.2.2 LAN Use this page to set up the local IP address and subnet mask for your router. Please select LAN Interface Setup under the IP Config menu and follow the instructions below to enter the LAN setting page to configure the settings you want. Item Description IP Address...
  • Page 48 DDNS service provider automatically. Service Provider Choose correct Service Provider from drop-down list, here including DynDNS, TZO, ChangeIP, Eurodns, OVH, NO-IP, ODS, Regfish embedded in BR476n . User Name/Email User name is used as an identity to login Dynamic-DNS service.
  • Page 49 4.3 Ipv6 Config Item Description Origin Type SLAAC、DHCPv6、IP。Please check ISP to get correct type WAN Link Type PPPoE、IP PPPoE Use IPv4 PPPoE account and password to do IPv6 connect Child Prefix Address Check ISP to get this data Static IP Check ISP to get IP address and default gateway IP address Router Name...
  • Page 50 4.4 Wireless 4.4.1 Wireless Basic Settings Item Description Disable Wireless Turn off the wireless service. Band Select the frequency. It has 6 options: 2.4 GHz (B/G/N/B+G/G+N/B+G+N). Mode Select the mode. It has 3 modes to select: (AP, Client, WDS, AP+WDS). Multiple AP: Please check Section 4.1.2.1.
  • Page 51 SSID to give the bottom layer user search. Multiple AP BR476n can register up to 4 SSIDs (wireless LAN group). It can be used as if there are multiple wireless LAN access points with one product. Each SSID could be set with different data rate, WMM and access type Save &...
  • Page 52 4.4.2 Advanced Settings Item Description Fragment Threshold To identify the maxima length of packet, the over length packet will be fragmentized. The allowed range is 256- 2346, and default length is 2346. RTS Threshold This value should remain at its default setting of 2347. The range is 0~2347.
  • Page 53 when they enable this function. WLAN Partition Shut down the communication between the connected wireless LAN devices. If you set up as "Enabled", devices connected with the router, such as a printer, will not be able to use. Default Setting: "Disabled" 20/40MHz Coexist Configure 20/40MHz coexisting scheme.
  • Page 54 4.4.3 Security Here users define the security type and level of the wireless network. Selecting different methods provides different levels of security. Please note that using any encryption may cause a significant degradation of data throughput on the wireless link. There are five Encryption types supported: “None”, “WEP”, “WPA”, ”WPA2”, and “WPA-Mixed”.
  • Page 55 802.1x Authentication For radius server authentication Radius Personal (Pre-Shared * If you configure Pre-Shared Key as Key) "Hexadecimal in 64 digits", please select "Hex (64 characters) ". * If you configure encryption key in "8 to 63 letters in half-width alphabets and numbers", please select "Passphrase 4.4.4 Access Control Please refer...
  • Page 56 Access Point in a minute without any hassle. SAPIDO BR476n could support both Self- PIN or PBC modes, or use the WPS button (at real panel) to easy enable the WPS function.
  • Page 57 Wireless dongle should connect to BR476n Start PBC: • ◦ Press the BR476n WPS button and wait for WPS LED blinking ◦ Press the dongle WPS button ◦ Wireless dongle should connect to BR476n...
  • Page 58 4.4.6 WDS When selected in the Basic Settings page and enabled here, Wireless Distribution System (WDS) enables the router to be used as a wireless bridge. Two Wireless-N Routers in bridge mode can communicate with each other through their wireless interfaces. To accomplish this, all wireless routers should be set to the same channel and the MAC address of other AP / Routers should be entered in the table.
  • Page 59 b Please check the MAC address c Enable WDS function from the page – “WDS Setting”, and then fill in the MAC address of Router_B. Click Apply Changes to save the setting data d The WDS AP List will show the WDS device MAC address Router_B：...
  • Page 60 b Router_B LAN PC will get IP address from Router_A If you failed the WDS setting, please check you setting with refer to the list below 4.4.7 Wireless Schedule Please refer Wireless Schedule...
  • Page 61 4.5 NAT This section contains configurations for the BR476n ’s advanced functions such as: virtual server, and DMZ to provide your network under a security environment 4.5.1 DMZ The DMZ feature allows one local user to be exposed to the Internet for special-purpose applications like Internet gaming or videoconferencing.
  • Page 62 Please find the following figure to know that what the virtual server is. The web server is located on 192.168.1.100, forwarding port is 80, and type is TCP+UDP.
  • Page 63 4.6 AirCloud Storage Please refer File Menu 4.7 AirCloud Monitor Please refer Webcam Server 4.8 VPN Server Please refer VPN Server 4.9 Firewall 4.9.1 DoS Please refer 4.9.2 QoS Item Description Enable QoS Check “Enable QoS” to enable QoS function for the WAN port.
  • Page 64 Local IP Address Set local IP Address if the address type is by IP Address MAC Address Set MAC Address if the address type is by MAC Address Mode Select Guaranteed minimum bandwidth or Restricted maximum bandwidth Uplink Bandwidth Key in the bandwidth. Downlink Bandwidth Key in the bandwidth.
  • Page 65 4.9.3 Port Filtering Item Description Select Enable Port Filtering to filter ports. Enable Port Filtering Port Range Enter the port number that needs to be filtered. Protocol Please select the protocol type of the port. Click on Add to save the setting data. Current Filter Table Check ISP to get IP address and default gateway IP address...
  • Page 66 4.9.8 VLAN Item Description Forwarding Rule Bridge or NAT mode Add VLAN tag to packet Set VLAN ID（1~4096 ） Priority It indicates the frame priority level. Values are from 0 (best effort) to 7 (highest); 1 represents the lowest priority Enable or Disable CIF...
  • Page 67 4.10 System Management This section including Wake on LAN, Change Username/Password, Upgrade Firmware, Profiles Save, Remote Management, Time Zone, UPnP, Route Setup, VPN Passthrough, and Wan Type Auto Detection. It is easy and helpful for users making more detailed settings 4.10.1 Wake on LAN Switch your computer ON through your LAN or the Internet .
  • Page 68 4.10.5 Remote Management This page allows you to access the GUI on WAN Item Description HTTP Connection Port Users can access GUI by this port，default is 80 Enable Web Server Allow user access GUI from WAN side Access on WAN...
  • Page 69 4.10.6 Time Zone Users can select time zone and synchronize the local clock on the router. 4.10.7 UpnP UpnP • Universal Plug and Play (UPnP) is a standard of networking protocols promulgated by the UPnP Forum. The goals of UPnP are to allow devices to connect seamlessly and to simplify the implementation of networks in the home (data sharing, communications, and entertainment) and in corporate environments for simplified installation of computer components.
  • Page 70 Static routing is a data communication concept describing one way of configuring path selection of routers in computer networks. It is the type of routing characterized by the absence of communication between routers regarding the current topology of the network.This is achieved by manually adding routes to the router routing table. Item Description Enable Dynamic Route...
  • Page 71 Item Description IPSec Pass-through Internet Protocol Security (IPSec) is a suite of protocols used to implement secure exchange of packets at the IP layer. To allow IPSec tunnels to pass through the router, IPSec Pass- through is enabled by default. To disable IPSec Pass-through , select Disable PPTP Pass-through Point-to-Point Tunneling Protocol is the method used to...
  • Page 72 4.10.10 Wan Type Auto Detection When this function enable， BR476n can detect WAN connection way，ethernet（PPPoE、DHCP、Static IP）、3.5G、LTE...
  • Page 73 A:There are two ways to know. Way 1:Check with your Internet Service Provider. Way 2:Check the setting screen of BR476n . Click on Status & Log item to select Network Configuration on the Main Menu. WAN IP is shown on the WAN interface.
  • Page 74 A: It’s possible that your Internet protocol (TCP/IP) was set to use the following IP address. Please do as the following steps. (Windows 2000 & XP) Start＞Settings＞ Network and Dial-up Connections＞double click on Internet Protocol(TCP/IP)＞ select obtain IP address automatically ＞ Click on OK button. Then, open Internet browser for testing.
  • Page 75 Why does BR476n ’s setup page shut down unexpectedly? • A:If one of the pages appears incompletely in BR476n ’s setup pages, please click on Logout item on the Main Menu before shutting it down. Don’t keep it working. Then, close Internet browser and open it again for going back to the previous page.
  • Page 76 When you're experiencing conductivity problems, it is always best to keep things simple. So next you are going to do is that, please disable any WEP encryption you might have configured. Successful implementation of encryption also includes the use of a shared key. A HEX key is the most common, but other formats are also used.
  • Page 77 A:The default WEP of WinXP is Authentication Open System - WEP, but the WEP of SAPIDO BR476n is only for Shared Key - WEP, it caused both sides couldn’t communicate. Please select the WEP of WinXP from Authentication Open System to Pre-shared Key - WEP, and then the WEP wireless interface between WinXP and SAPIDO BR476n would be communicated.
  • Page 78 5.8 Support What is the maximum number of IP addresses that the XDSL Router will support? • A:The Router will support to 253 IP addresses with NAT mode. Is the Router cross-platform compatible? • A:Any platform that supports Ethernet and TCP/IP is compatible with the Router. 5.9 Others Why does the router dial out for PPPoE mode very often? •...
  • Page 79 6 Appendices 6.1 Operating Systems Microsoft：Windows 2000, XP, Vista, Windows 7. • Apple：Mac OS X 10.4.7, Leopard and the following related versions. • Linux：Redhat 9, Fedora 6 & 7, Ubuntu 7.04 and the following related versions. • • 6.2 Browsers Internet Explorer ver.
