Epson Stylus Pro 7700 Quick Reference Manual

Epson Stylus Pro 7700 and 9700 Print Engine Specifications
Printing Technology Media Handling
Advanced MicroPiezo TFP print head SP7700 Media input Single roll up to 24" wide
with ink-repelling coating technology Cut-sheet size Up to 24" wide media
10-channel, drop-on-demand, ink jet print head (auto-loading)
5-cartridge (C, VM, Y, PK or MK) SP9700 Media input Single roll up to 44" wide
Auto Head Alignment and Cleaning Technology Cut-sheet size Up to 44" wide media
Dual Black Ink Technology (auto-loading)
Epson UltraChrome with Vivid Magenta Ink Technology Roll media take-up reel Auto forward and backward;
Professional-level pigment-based ink technology (SP9700 only) Light-based media tension sensor
Media core compatibility User-adjustable roll media adapters
Resolution
accept either 2" or 3" media cores
1440 x 1440 dpi; 1440 x 720 dpi; 720 x 720 dpi;
Max. roll media diameter 6" (when using a 3" core)
720 x 360 dpi; 360 x 360 dpi
Media weight 12 lb bond (0.8 mm),
up to 1.5 mm posterboard
Print Engine Speed A
Minimum sheet size 210 mm x 279 mm / 8.27" x 1 1"
16" x 20" prints from 0:21 to 1:36 — Standard is 0:37
Built-in media cutter Rotary cutting, automatic and manual
22" x 30" prints from 0:41 to 3:22 — Standard is 1:16
40" x 50" prints from 1:55 to 9:14 — Standard is 3:32
Product/Accessories Part Numbers
SP7700
Operating Systems Supported
Epson Stylus Pro Printer SP7700VM
Macintosh Leopard 10.5, Snow Leopard 10.6,
and Lion 10.7
Additional One-year
Windows
Windows XP, Windows Vista, ® and Windows 7
Epson Preferred SM Plus Service EPP700B1
(both 32-bit and 64-bit supported)
Additional Two-year
Epson Preferred Plus Service EPP700B2
Printer Interfaces
Includes as standard one Hi-Speed USB 2.0 (1.1 compatible)
Automatic Take-up
and one Ethernet port (10/100Base-T)
Reel System Not Available
Dimensions
Additional Roll Media
SP7700 54" (W) x 27" (D) x 48" (H)
Adapters C12C81 1241
Weight: 220 lb
SP9700 74" (W) x 27" (D) x 48" (H) Replacement Printer
Weight: 295 lb Cutter Blade C12C815331
Dimensions and weight include printer stand
Replacement
Included CAD Driver Support Ink Maintenance Tank C12C890501
Included HDI Print Drivers Support AutoCAD
Epson UltraChrome
Versions 2004 – 2010
with Vivid Magenta Ink B (150 ml) (350 ml)
Photo Black ink cartridge T642100 T596100
Cyan ink cartridge T642200 T596200
Vivid Magenta ink cartridge T642300 T596300
Yellow ink cartridge T642400 T596400
Matte Black ink cartridge T642800 T596800
ML = Fill volume
A Based upon print engine speed only. Total throughput times depend upon front-end
RIP, file size, printer resolution, ink coverage, networking, etc. Standard production
mode based on Fine - 720 dpi high speed.
B Cartridge yields vary considerably for reasons including images printed, print
settings, temperature and humidity. Yields may be lower when printing infrequently
or predominantly with one ink color. A variable amount of ink remains in the cartridge
after the "replace cartridge" signal. Part of the ink from the first cartridges is used for
priming the printer. Ink is used for both printing and print head maintenance. All inks
are used for both black and color printing, and all colors have to be installed for
printing. For more information about cartridges, see www.epson.com/cartridgeinfo
For more details, visit our website at:
www.proimaging.epson.com
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada Limited
For more information on Epson's environmental programs, go to
185 Renfrew Drive, Markham, Ontario L3R 6G3 eco.epson.com
Specifications and terms are subject to change without notice. Epson, Epson Stylus, Epson UltraChrome, MicroPiezo and TFP are registered trademarks, Epson Exceed
Your Vision is a registered logomark and Better Products for a Better Future is a trademark of Seiko Epson Corporation. Epson Preferred is a service mark of Epson
America, Inc. Microsoft, Windows, Windows Vista and the Windows logos are trademarks of the Microsoft group of companies. All other product and brand names are
trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks.
Copyright 2011, Epson America, Inc. CPD-31533R2 7/11
SP9700
SP9700VM
EPP700B1
Epson Stylus Pro 7700 and 9700
®
EPP700B2
C12C815321
C12C811241
C12C815331
C12C890501
(700 ml)
T636100
T636200
T636300
T636400
T636800
R3187
Performance. Precision. Brilliance.
For more than a decade, Epson has set the standard by which
all other photographic printing technologies are measured. So,
REDEFINING THE
when our engineers decided to develop the ultimate printing
FUTURE OF PRINTING
technology for Corporate Graphics and Display Signage
applications, we focused on three main goals — Performance,
Precision, and Brilliance.
Introducing the all-new Epson Stylus Pro 7700 and
9700 printers.
By incorporating our latest achievements in high-performance
24- and 44-inch wide print engine technology, along with the
extreme precision of our latest MicroPiezo
our latest printing technology produces a final print with
uncompromising accuracy. And with our latest Epson UltraChrome
with Vivid Magenta pigment ink technology, your color work will
not only be brilliant — but archival as well.
Prepare to see your prints in a whole new way.
® TFP ® print head,
®
