  • Page 1: Epson Stylus Pro

    Epson Stylus Pro 7700 9700 Introducing the Performance. Precision. Brilliance. Epson Professional Imaging Division Sales Reference Guide v1.5a...
  • Page 2 What Defines an Epson Stylus® Pro 700 Series Printer? “To develop printing technology that exceeds the expectations of Corporate and Engineering Professionals.” “To ensure the output can be Archived.”...
  • Page 3: Target Markets

    Sign – POP Display, Indoor, and Company Signage – Engineering Scientific – GIS Mapping, CAD, Architecture, etc. The Highest-Quality Printer in its Class Product Pricing – Epson Stylus Pro 7700 Printer – 24” Only $2,995 (msrp) – Epson Stylus Pro 9700 Printer – 44” Only $4,995 (msrp)
  • Page 4 Epson Stylus Pro 7700 – 24” $2,995 myEpsonPrinter.com Compatible Epson Stylus Pro 9700 – 44” $4,995 Low Noise Design for Extremely Quiet Operation Contact Your Authorized Epson Dealer for the latest pricing information. 1 year Warranty and Support Provided by Epson (Pricing shown is MSRP)
  • Page 5 Epson Stylus® Pro 7700 | 9700 Series Photo Walkthrough Front View Front Printer Door Cut Sheet Loader Front Control Panel 2.5” Color LCD Roll Media Loader Rotary Cutter Electronic Ink Bay Door Y MK Robust Print Stand Fabric Catch Bin Epson Stylus Pro 9700 Shown 74”(W) x 26”(D) x 48”(H) | 295 lbs,...
  • Page 6 Epson Stylus® Pro 7700 | 9700 Series Photo Walkthrough Front View Epson Stylus Pro 7700 - 24” Epson Stylus Pro 9700 - 44” 54”(W) x 26”(D) x 48”(H) | 220 lbs, 74”(W) x 26”(D) x 48”(H) | 295 lbs,...
  • Page 7 Epson Stylus® Pro 9700 Series Photo Walkthrough Front View Auto Take-up Reel System Up to 44-Inch Wide Available for the Epson Stylus Pro 9700 Printer Only Optional Automatic Take-up Reel System – $1,195 msrp...
  • Page 8 Epson Stylus® Pro 7700 | 9700 Series Photo Walkthrough Front Control Panel Initiate Print Head Cleaning 2.5-Inch Color LCD ePlaten Release Delete or Cancel Job Button Electronic Ink Door Covers Rotary Cutter...
  • Page 9 Simple Tension Lever Ensures Quick and Secure Media Core Loading Extremely Fast Roll Media Loading with Less Chance of Media Damage Designed with Epson ePlaten™ Technology for Highly-Accurate Roll Media Loading Media Core Tension Lever 2– or 3–Inch Media Core Switch...
  • Page 10 All New Epson ePlaten™ Technology High-Accuracy Roll Media Loading System High-Accuracy Automatic Roll Media Loading, Movement, and Tracking Electronically Controlled Roll Media Rewind Automatic Media Core Rewind Upon Media Release Makes Overall Roll Media Usage Easier then Ever Before...
  • Page 11 Adjustable Roll Media Length Setting to Compensate for Various Roll Lengths Very Useful for Tracking Partially Used Media Rolls Auto Roll Media Identification – Both Genuine Epson and Custom Media Setting(s) Can Be Disabled if Not Required by Your Workflow...
  • Page 12 New High Performance Rotary Cutting System All New Rotary Type Cutting Mechanism – Extremely robust design and virtually maintenance free – Cutter mechanism is independent of print head, allowing for less print head media contamination High Performance Cutting Speeds – Able to cut a 44-inch wide sheet in less than one second Cuts Virtually Any Media Type –...
  • Page 13: Bundled Software

    Bundled Software Epson Stylus Pro 7700 and 9700 Series Epson Professional Drivers for Windows® and Macintosh® – Windows 7, Windows XP, and Windows Vista (both 32- and 64-bit) – Macintosh Tiger 10.4.9 or higher, Leopard 10.5 or Higher, and Snow Leopard 10.6 or higher Epson HDI Driver –...
  • Page 14 Epson Stylus Pro Printer Drivers...
  • Page 15 Epson Layout Manager Queue, rotate and layout individual files from almost any Windows based application Scale individual files independent of how it was sent to the Print Queue Fully integrated with the Epson Printer driver Windows Only...
  • Page 16 ViewCompanion® Express Software View, Print and Convert HPGL, HPGL/2, HP-RTL, and CALS 4 Windows Only Application...
  • Page 17 Epson UltraChrome® Vivid Magenta Ink Introducing A Next Generation Pigment Ink Technology...
  • Page 18 Improved Microcrystal Encapsulation™ Technology for Reduced Gloss Differential Improved Black Density up to 2.6 with an L* value of ~3.0 Sets a New Standard for Professional Four Color Ink Technology Dmax and L* Values based on Epson Premium Semigloss Photo Paper (250)
  • Page 19 Epson Stylus Pro 7700 Canon imagePROGRAF iPF 610 Extreme Color Gamut Accurate Color Matching Actual print comparison showing the extreme color gamut of Epson UltraChrome VM Inks Please Note: the presentation file and monitor you’re using may affect this comparison...
  • Page 20 Epson Stylus Pro 7700 Canon imagePROGRAF iPF 610 Accurate Color Matching Extreme Color Gamut Actual print comparison showing the extreme color gamut of Epson UltraChrome VM Inks Please Note: the presentation file and monitor you’re using may affect this comparison...
  • Page 21 Epson UltraChrome VM Ink Technology Dual Black Ink Modes – Photo and Matte Black Inks Two different black ink technologies are automatically used to optimize the black density and line-sharpness for virtually any media type Photo Black ink can produce professional results on any media type, but is optimized...
  • Page 22 Epson MicroPiezo TFP® Print Head Technology The World’s Most Advanced Inkjet Print Head Technology...
  • Page 23 Epson MicroPiezo TFP Print Head Technology Epson Stylus Pro 7700|9700 Series 10-Channel Print Head Technology Ink Repelling Coating Technology One-Inch Wide Print Head 360 Nozzles Per Inch Auto Nozzle Detection & Cleaning Variable Droplet Piezo | Advanced Thin Film Piezo (TFP) | 720 Nozzles x 5 Colors | 3.5 Picoliters...
  • Page 24 Epson MicroPiezo TFP Print Head Technology The World’s Most Advanced Inkjet Print Head Technology Actual Ink Droplet on Paper ~ 1,420X Magnification ~ 210X Magnification Print Head Direction Extreme Dot Placement Accuracy Perfectly Round & Consistent Droplets Low Vibration Meniscus and High Impact Control Technology Examples Shown Above...
  • Page 25 Epson Stylus Pro 7700 Canon imagePROGRAF iPF 710 Epson Singleweight Matte Paper Canon Premium Matte Paper Printed at 1,440 dpi Printed at 1,200 dpi 200x Magnification Actual Print Comparison Showing the Extreme Line Accuracy of the Epson MicroPiezo TFP Print Head...
  • Page 26 Performance Benchmarking Epson Stylus Pro 7700 - 24” Epson Stylus Pro 9700 - 44”...
  • Page 27 Performance Benchmarking Popular POS Print Sizes Epson Driver Print Mode 16” x 20” 22” x 30” 40” x 50” per Hour Draft - 360 dpi HS 21 Seconds 37 Seconds 1:36 Fine - 720 dpi HS 41 Seconds 1:16 3:22...
  • Page 28 Performance Benchmarking Popular CAD Plot Sizes Epson Driver Print Mode C – Size Plot (17” x 22”) D – Size Plot (22” x 34”) Draft - 360 dpi HS 20 Seconds 31 Seconds Fine - 720 dpi HS 38 Seconds...
  • Page 29 Competitive Benchmarking Epson Stylus Pro 7700 vs. Canon imagePROGRAF iPF610 Epson Stylus Pro 9700 vs. Canon imagePROGRAF iPF810...
  • Page 30 Product Feature Comparison EPSON STYLUS PRO 24–Inch COMPARISON Epson Stylus pro 7700 vs. Canon imagePROGRAF iPF610 Printer Feature Epson Stylus Pro 7700 Canon imagePROGRAF iPF610 Maximum Printer Width 24-Inch 24-Inch Ink Technology Epson UltraChrome® Vivid Magenta Canon Reactive Ink Technology...
  • Page 31 Product Feature Comparison EPSON STYLUS PRO 44–Inch COMPARISON Epson Stylus pro 9700 vs. Canon imagePROGRAF iPF810 Printer Feature Epson Stylus Pro 9700 Canon imagePROGRAF iPF810 Maximum Printer Width 44-Inch 44-Inch Ink Technology Epson UltraChrome® Vivid Magenta Canon Reactive Ink Technology...
  • Page 32 Epson Professional Media Line For CAD, GIS Mapping, Signage, and Graphics Applications...
  • Page 33 Specialty Papers: Singleweight Matte Paper, Doubleweight Matte Paper, and Presentation Paper Matte (available in rolls from 24” to 44”) – SemiGloss Paper: Epson Premium Semigloss Photo Paper (250) (available in rolls from 16” to 44”) – Posterboard: Epson Enhanced Matte Posterboard (24” x 30” and 30” x 40”) CAD and Engineering –...
  • Page 34 See www.epson.com/cartridgeinfo for more information about ink cartridges. Epson, Epson Stylus, Epson UltraChrome Vivid Magenta, and MicroPiezo TFP are trademarks or registered trademarks of Seiko Epson Corp. Epson AccuPhoto, Epson ePlaten, and Epson PreciseColor are trademarks of Epson America, Inc.
  • Page 35 www.proimaging.epson.com...
